Inter-fab T7 Programming manual

T7-IM Rev. 4/09 (BBK-T7 INSTAL)
T7™DIVING SYSTEM
Assembly & Installation Instructions
3050 S. ALVERNON WAY • TUCSON, AZ 85713
520.790.7040 • 800.737.5386 • FAX [phone]
inter-fab.com

For Technical Support or Assistance,
Contact Customer Service at:
INTER-FAB, INC.
3050 S. ALVERNON WAY
TUCSON, AZ 85713
[phone]
or visit: www.inter-fab.com
To obtain complete copies of the ANSI/NSPI-5 2003
Standard for Residential Inground Pools or to obtain
copies of the “Plan Your Dive, Steer Up” or “The
Sensible Way to Enjoy Your Inground Swimming Pool”
contact:
The Association of Pool & Spa Professionals
(APSP)
2111 Eisenhower Ave.
Alexandria, VA 22314
[phone]
or visit: www.theapsp.org

INSTALLATION MANUAL T7™ DIVING SYSTEM
1
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
TABLE OF CONTENTS:
Safety First ............................................................................2
Intended Use Instructions ........................................................3
Important Notices to the Installer..............................................4
Minimum Diving Water Envelope Information...............................5
T7 Placement ........................................................................6
T7 Jig Info & Placement Tips ...................................................7
Step 1: Install Water Feature (optional equipment) ...................8-9
Step 2: T7 Assembly..........................................................9-10
T7 Exploded View & Parts List................................................11
T7 Care & Maintenance ........................................................12
Article 5 Extracted from ANSI/NSPI-5 2003 .......................13-18
Inter-Fab Limited Warranty.....................................................19

INSTALLATION MANUAL T7™ DIVING SYSTEM
2
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
This Inter-Fab diving board and stand shall be installed only by a professional swimming pool contractor
or with the direct supervision of a licensed professional, engineer or architect. Diving boards may
be installed only on residential inground swimming pools properly designed for their use.
Diving boards that are improperly installed can be very dangerous to the user resulting in possible
serious head and/or spinal column injury, including the paralysis or death of the user.
It is very important that this diving board and stand be installed only on Type 1 or greater pools
build in strict accordance with the American National Standard for Residential Inground Swimming
Pools (ANSI/NSPI-5 2003) and in accordance with the included INTER-FAB RESIDENTIAL POOL
SPECIFICATIONS TABLE 2.
In addition to the above standard and referenced table, these installation instructions provided by
Inter-Fab, Inc. must be diligently followed.
It is also important that any and all warnings provided with the diving board be strictly adhered to
and posted in a conspicuous location. If not provided or they are misplaced, please purchase
warning signs from your pool contractor or professional pool supply store and post them in a location
that the users of the diving board can clearly see.
SAFETY FIRST!
DIVING TIPS: Even the safest equipment must be used properly. Inter-Fab promotes safe diving by
offering these tips on the proper use of your diving board: always dive into water that meets depth
requirements, with arms extended; be aware of the bottom and the walls of the pool; avoid collisions
with pool toys and floats; and instruct your pool users to always “steer up”. When you begin your
dive you must get ready to steer up. As you enter the water, your arms must be extended over
your head, hands flat aiming up. Hold your head and arch your back.
FOR RESIDENTIAL INGROUND SWIMMING POOL USE ONLY
NO COMMERCIAL, PUBLIC OR SEMI-PUBLIC USE IS ALLOWED
ONLY ONE PERSON ON THE DIVING BOARD AT ONE TIME
MAXIMUM WEIGHT = 300 LBS
Plan Your Dive
Back Arched
Arms Extended
Head and Hands Up
Hold Diving Form
Steer up for a safe dive.
PLAN YOUR DIVE, STEER UP

INSTALLATION MANUAL T7™ DIVING SYSTEM
3
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
“A pool is the safest place to swim and a diving board installed in compliance with manufacturers
instructions and the 2003 ANSI/NSPI Standard for In-ground Residential Pools is the safest place
to dive from. To ensure that you and your family and guests are able to safely enjoy your diving
board for many years, it is critical that you follow the following instructions.”
INTENDED USE INSTRUCTIONS
DO
1. Know the shape and depth of the pool before
you dive.
2. Make sure that all family members and guests
are familiar with these instructions before they
use your pool and diving board.
3. Make sure that the diving board has been
installed in compliance with the Assembly and
Installation Instructions and with the 2003
ANSI/NSPI Standard for In-ground Residential
Pools. This includes the shape and depth of
the pool as well as the height of the diving
board.
4. Enter feet first the first time.
5. Plan your path to be sure you avoid any other
swimmers, or objects in or under the water,
such as floats, tires, toys etc.
6. Keep your head up, arms up and fully extended
and steer up with your hands.
7. Practice carefully before you dive headfirst.
8. Become familiar with the diving board and its
spring before diving headfirst
9. Dive straight ahead, not to the side of the
board or pool.
10. Dive from the diving board only.
11. Make sure that children and non-swimmers
are supervised at all times.
12. Always remember that when you dive you must
steer up.
13. Inspect your diving board, base and stand on
a regular basis (at least twice a year) and keep
them in proper repair.
14. Contact your dealer, installer or Inter Fab
(800-737-5386) with any questions or concerns
about the safe use of your diving board.
DON’T
1. Don’t drink and dive.
2. Don’t install this or any diving board on an
above ground pool or dive into an above
ground pool from any surface.
3. Don’t dive into a pool from anyplace not specif-
ically designated for diving. Never dive into the
shallow portion of any pool.
4. Don’t dive across the width of the pool or to
the sides of the pool.
5. Don’t Run and dive.
6. Don’t engage in horseplay in or around the diving
board or pool.
7. Don’t use your diving board as a trampoline.
8. Don’t do a back dive. Backyard pools are not
built for that type of activity.
9. Don’t try fancy dives. Keep the dives simple.
10. Don’t dive into or through objects or toys such
as inner tubes.
11. Don’t swim or dive alone.
12. Don’t use a diving board or stand or base that
is rusted or worn out or in poor repair.
THE T7 DIVING SYSTEM IS A JUMP BOARD

INSTALLATION MANUAL T7™ DIVING SYSTEM
4
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
The specifications found on page 5 of this manual represent the minimum water envelope required
by Inter-Fab and by the ANSI/NSPI-5 2003 Standard for Residential Inground Swimming Pools.
Each of these dimensions must be met or exceeded. Installation of a diving board of any type on
a pool that does not meet or exceed each of the minimum specifications as provided on page 5,
including but not limited to the slope requirement, is in direct violation of this manufacturer’s
instructions and the 2003 Standard, and can result in serious injury or death.
The installation of the T7 diving system is not complete until you, the installer have measured the
pool to ensure it meets the Inter-fab residential inground minimum pool specifications and the
ANSI/NSPI-5 2003 Standard for Residential Inground Swimming Pools
The installation of the T7 diving system is not complete until you the installer has delivered to your
customer and reviewed with your customer the “Owners Manual” as well as the “Plan Your Dive
Steer-Up” brochure.
The T7 diving system (diving board, springs, and base) is a complete system and must be installed
as a complete system. It is strictly prohibited to install any T7 component on any other stand,
spring, or base.
Inter-fab highly recommends that you, the installer, obtain and consult the ANSI/NSPI-5 2003
Standard for Residential Inground Swimming Pools before proceeding with the installation.
WARNING:
IF YOU ARE INSTALLING AN EDGEWATER UNIT WITH LED LIGHTING: Do not attach the color controller
directly to 110V, the LED lighting is a low voltage system requiring a transformer (not included) to
provide power to the color controller. Inter-Fab recommends the Intermatic PX100 transformer.
If the Intermatic PX100 is not utilized the color controller Input Rating is: 12 VAC, 1.7 Amp 60/50HZ.
Exceeding the input rating will severely damage the color controller and void the warranty.
IMPORTANT NOTICES
TO THE INSTALLER
THE T7 DIVING SYSTEM IS A JUMP BOARD.
ONLY ONE PERSON AT A TIME ON THE DIVING BOARD,
WITH A MAXIMUM WEIGHT LIMIT OF 300 LBS.

INSTALLATION MANUAL T7™ DIVING SYSTEM
5
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
MINIMUM DIVING WATER ENVELOPE:
NOTE: DRAWINGS ARE NOT TO SCALE.
NOTE: TABLE 1 AND TABLE 2 SHOWN ON THIS PAGE ARE APPLICABLE
ONLY TO INTER-FAB’S COMPLETE T7™ DIVING SYSTEM.
NOTES:
DIVING EQUIPMENT
TIP OF BOARD
ABOVE POINT A
DIVING EQUIPMENT PROHIBITED
DIVING EQUIPMENT PROHIBITED
A B C D A B C D WA+/-3” AB BC CD* DE WE
0
I 6’-0” 7’-6” 5’-0” 2’-9” 10’-0” 12’-0” 10’-0” 8’-0” 1’-6” 7’-0” 7’-6” VARIES 6’-0” 28’-9”
II 6’-0” 7’-6” 5’-0” 2’-9” 12’-0” 15’-0” 12’-0” 8’-0” 1’-6” 7’-0” 7’-6” VARIES 6’-0” 28’-9”
III 6’-10” 8’-0” 5’-0” 2’-9” 12’-0” 15’-0” 12’-0” 8’-0” 2’-0” 7’-6” 9’-0” VARIES 6’-0” 31’-3”
IV 7’-8” 8’-6” 5’-0” 2’-9” 15’-0” 18’-0” 15’-0” 9’-0” 2’-6” 8’-0” 10’-6” VARIES 6’-0” 33’-9”
V 8’-6” 9’-0” 5’-0” 2’-9” 15’-0” 18’-0” 15’-0” 9’-0” 3’-0” 9’-0” 12’-0” VARIES 6’-0” 36’-9”
POOL
TYPE
MINIMUM DEPTHS
AT POINT
MINIMUM WIDTHS
AT POINT
MINIMUM LENGTHS
BETWEEN POINTS
TABLE 1 - MINIMUM WATER ENVELOPE (ANSI/NSPI-5 2003)
DBL** HOW** F G H J K L M N
0
I 7’ T7 ONLY 20” 2’-9” 5’-0” 4’-0” 7’-2.5” 7’-6” 6’-0” 3’-9” 2’-1.5” 12’
II 7’ T7 ONLY 20” 2’-9” 3’-10” 4’-2” 7’-2.5” 7’-6” 6’-8” 3’-9” 2’-1.5” 12’
III 7’ T7 ONLY 26” 2’-9” 4’-4.75” 4’-4.5” 7’-5.5” 8’-0” 6’-7” 3’-11.5” 1’-7.5” 13’
IV 7’ T7 ONLY 30” 2’-9” 5’-10.5” 3’-10” 7’-8” 8’-6” 8’-3” 5’-7” 2’-7” 13’
V 7’ T7 ONLY 40” 2’-9” 6’-2” 3’-11.5” 7’-9.5” 9’-0” 8’-2.5” 5’-9” 2’-7” 14’
POOL
TYPE
T7 DIVING
SYSTEM
MAX. HEIGHT
OVER WATER
AT POINT A
CROSS SECTIONAL
DIMENSIONS AT
POINT A
CROSS SECTIONAL DIMENSIONS AT POINT B
TABLE 2 - INTER-FAB RESIDENTIAL POOL MINIMUM SPECIFICATIONS
MIN. HEAD
ROOM
ABOVE
DIVING
SURFACES
*Min. length between points CD may vary based upon water depth at point D and the slope between points C & D
ABBREVIATIONS: **DBL=Diving Board Length; DB=Diving Board; JB=Jump Board; **HOW=Height Over Water
F
G
H
JK
N
M
L
DIVING EQUIPMENT

INSTALLATION MANUAL T7™ DIVING SYSTEM
6
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
Concrete Minimums:
8’ Long
4’ Wide
6” Deep
NOTE: READ THESE INSTRUCTIONS IN THEIR ENTIRETY BEFORE ATTEMPTING T7
INSTALLATION.
REFER TO: ANSI/NSPI-5 2003 American National Standard for Residential Inground Swimming Pools and to
page 5 for Inter-Fab Residential Inground Pool Minimum Specifications.
INTER-FAB CANNOT GUARANTEE CUSTOMER’S CONCRETE OR THICKNESS
The top surface of the diving board from the deck end to
the tip end shall be level or have an upward slope of 5/8"
per foot maximum. Elevation difference shall not exceed
4-3/8" from the deck end to the tip of the board. There
shall be no downward slope towards the water. The slope
shall be measured using a level as shown in the graphic to
the left.
T7 DIVE
STAND
NOMINAL
BOARD
LENGTH
ANSI/
NSPI-5
POOL
TYPE
DISTANCE FROM
WATER’S EDGE TO
FORWARD JIG BOLT
(S) *
DISTANCE FROM
WATER END OF
BOARD TO FORWARD
JIG BOLT
MAX HEIGHT OF
BOARD OVER
WATER
(HOW)
7’ T7 ONLY I 31” 50” 18” 20”
7’ T7 ONLY II 31” 50” 18” 20’
7’ T7 ONLY III 25” 50” 24” 26”
7’ T7 ONLY IV 19” 50” 30” 30”
7’ T7 ONLY V 13” 50” 36” 40”
MUST BE INSTALLED ON TYPE I POOL OR GREATER
MIN. OVERHANG
POINT A TO
POINT W
+/- 3” **
ONLY T7
DIVING
BOARD CAN
BE UTILIZED
ON T7 DIVE
STAND
IMPORTANT: THESE DIMENSIONS ARE ACCURATE ONLY FOR VERTICAL POOL WALLS,
TYPICALLY GUNITE CONSTRUCTION, WITH LESS THAN A 3’ RADIUS TO THE POOL FLOOR.
DUE TO THE VARYING SIZES OF OTHER POOLS, TYPICALLY VINYL LINER CONSTRUCTION,
PLEASE CONTACT CUSTOMER SERVICE FOR PROPER JIG PLACEMENT. 1.800.737.5386
TABLE 3 – PLACEMENT CHART
FIG. A – T7 PLACEMENT SPECIFICATIONS:

INSTALLATION MANUAL T7™ DIVING SYSTEM
7
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
• T7 Installation limited to Residential Inground Swimming Pools conforming to a Type I or greater dimension
in accordance with the ANSI/NSPI -5 2003 Standard and Inter-Fab’s Residential Inground Swimming Pool
Minimum Specifications.
• Install jig on the deep end of the pool on centerline.
• Before installing the T7 jig ensure the concrete deck surrounding the jig meets the minimum 8’ long x 4’
wide x 6” deep minimum.
• Jig should be grounded. Comply with all local electrical codes for grounding.
• Be careful to ensure that the red capped bolt is toward the pool and set back from the water’s edge at the
correct distance based on the table on page 6.
• The 3 jig bolts must extend 2” above the final deck surface.
• Ensure the deck surrounding the jig and base/step is flat and level so the base/step makes uniform contact
with the deck surface.
• Leave the protective caps on the bolts until the concrete has cured and base/stand is ready to be installed.
• If installing a waterfall or lighted waterfall feature with the T7 ensure that a 1/2” water stub-up and electrical
conduit are located per the diagram on page 6 and as shown in the above illustration. Provide a minimum
of 10 gallons per minute to the end of the T7 diving board. Ensure electrical conduit, wiring and transformer
installations comply with local or national electrical building codes, whichever is greater.
JIG PLACEMENT TIPS:
MOUNTING JIG:
SIDE VIEW TOP VIEW
T7™ JIG INFO:
TOWARD POOL
RED
CAP
YELLOW
CAPS

INSTALLATION MANUAL T7™ DIVING SYSTEM
8
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
If purchased, attach the optional waterfall assembly to the underside of the diving board as follows:
IMPORTANT: To keep the T7 water feature from clogging, ensure water is from a filtered return line
from the pool.
A) The center (central) rib on the underside of the diving board is hollow and is capped at the factory. Remove the
cap from front of the center rib exposing the hollow channel.
B) The Edgewater comes from the factory with an 8' length of 1/2" flex PVC pipe attached. The 8' length
goes thru the board and attaches with PVC glue to one side of the 1/2" union. The 4" length of flex PVC
pipe attaches with PVC glue to the stub-up and then to the other side of the 1/2" union.
C) (If Purchased) your waterfall comes with an optional pre-wired, factory installed LED or Fiber Optic lighting
system. Simply thread the wiring attached to your waterfall lighting system down the conduit in the central
rib on the board along side the 1/2” PVC tubing.
TIP: You may find it simpler to put end of wire into end of hose or tape the wiring to the end of the 1/2”
flex PVC and thread them thru the conduit at one time.
The LED lighting system comes with 10’ of wire attached to the LED which goes through the board
and attaches to the coupler, the additional 25’ of wiring attaches to the coupler and then passes
through the customer installed conduit to the color controller.
The fiber optic lighting comes with 55’ of continuous cable which is passed through the board, then
through the customer installed electrical conduit to the customer provided color light source.
STEP 1: INSTALL WATER FEATURE: (OPTIONAL EQUIPMENT)
T7™ EDGEWATER CONFIGURATIONS: (OPTIONAL EQUIPMENT)
1. T7 EDGE-GR: kit consists of Edgewater, Mounting Hardware (4 screws), 8’ & 4” of 1/2” Flex PVC Pipe,
1-Union
2. T7 EDGE-L-GR: kit includes Edgewater parts PLUS LED Lights Assembled (RGB), Color Controller, 35’ of
Wire (10’ on unit – 25’ on controller), Coupler. NOTE: No transformer is provided. *
3. T7 EDGE-F-GR: kit includes Edgewater parts
PLUS 55’ of 25 Strand Fiber Optic Cable Assembled.
NOTE: No light source is provided.
IMPORTANT: The gel coat surface of the T7 Diving System is similar to a high quality automotive finish;
it is long lasting, strong and beautiful but will scratch if mishandled.
Do not place unprotected parts on the ground. Do not slide or pull unprotected parts along any surface.
Be careful unpacking parts and with tools during assembly.
ABC
T7 Diving System
INSTALLATION INSTRUCTIONS

INSTALLATION MANUAL T7™ DIVING SYSTEM
9
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
TIP: Make sure to use the anti-seizing compound on all the bolts or the nuts will seize
1. Lay board upside down on packaging being careful not to damage the gel coat surface.
2. Place T7-NSPRING over the 8 bolts on the board as shown in photo below.The single center drill hole in
the spring center faces toward the pool. Use hardware kit T7-102-SS and attach the springs to board
as shown in exploded view in page 11. Hand tighten only at this time.
TIP: The springs are directional. The longer end of the spring goes toward the pool. NOTE: The springs have
a sticker with an arrow that states “this end toward pool”.
STEP 2: T7 ASSEMBLY:
D) Once the water tubing and wiring are threaded all the way thru the diving board, from the base side, gently
pull the end of the tubing until the waterfall assembly is pulled gently but snugly against the end of the
center rib.
E) Attach the waterfall unit to the Diving Board by inserting the 4 provided screws thru the pre-drilled holes in
the waterfall assembly; hand tighten only (DO NOT USE SCREW GUN), over tightening the screws will
cause them to strip inside the board or break the waterfall housing, and voids the warranty.
*WARNING: Do not attach the color controller directly to 110V, the LED lighting is a low voltage system
requiring a transformer (not included) to provide power to the color controller. Inter-Fab recommends the
Intermatic PX100 transformer. If the Intermatic PX100 is not utilized the color controller Input Rating is:
12 VAC, 1.7 Amp 60/50HZ.
Exceeding the input rating will severely damage the color controller and
void the warranty.
INSTALL WATER FEATURE: (OPTIONAL EQUIPMENT) – CONT.
3. Edgewater Waterfall (optional) Board
If installing and Edgewater waterfall, run the hose
and LED or Fiber optic (if supplied) through the
board as shown in photo. Use the 4 screws provided
with the Edgewater unit to attach to bottom of
board.

INSTALLATION MANUAL T7™ DIVING SYSTEM
10
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
5. Feed the hose and LED or Fiber optic (if supplied*)
through the base and sit the base on the
springs as shown in photo.
*
Please note that the Edgewater waterfall can be
ordered in 3 different configurations. See page 8
for more information.
Use hardware kit EDGE-SP and attach the base
to the springs as shown in exploded view on
page 11.
Use a dab of anti-seize provided and tighten
these now to 25-30 ft lbs torque.
STEP 2: T7 ASSEMBLY – CONT.
4. Edgewater Waterfall (optional) Base
If installing the Edgewater waterfall, remove the
hole black cap on the base by pushing it out
from the underside. Do not try to remove from
the top as damage to the gel coat surface can
occur.
See arrow reference in photo shown.
6. Tighten the 8 nuts that hold the board to the springs at this time. Torque to 20-25 ft lbs. (Note: all hardware
should be tight at this point of installation)
7. With the assembly upside down and on protective cardboard move as close as possible to mounting jig.
Attach Edgewater waterfall plumbing and LED or Fiber optics as described in installation manual “Install
Water Feature” on pages 8 and 9.
8. The assembly is now ready to set on the jig bolts. With 2 persons carefully set the assembly upright and
onto the jig. If installing an Edgewater waterfall, tuck the excess hose underneath the base as it is set
on the jig bolts. Using hardware kit T7-NBK attach the base to jig as shown in exploded view on page 11.
Tighten these nuts to 40-50 ft lbs torque.

INSTALLATION MANUAL T7™ DIVING SYSTEM
11
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
RECOMMENDED
TORQUE SCHEDULE
FOR ASSEMBLY:
1/2” SS Hardware (T7-NBK Kit)
---> 40-50 FT-LBS
3/8” SS Hardware (T7-102-SS Kit)
---> 20-25 FT-LBS
3/8” SS Hardware (EDGE-SP Kit)
---> 25-30 FT-LBS
T7 DIVING SYSTEM (T7 DB-GR, T7 BASE-GR, T7 SPRING-GR):
DRAWING REPRESENTS THE
FOLLOWING PART NUMBERS:
NOTES:
* Part #T7 BASE-GR comes WITH jig.
The T7 diving board, base, and springs must be used together and cannot be used separately in any other configuration.
ITEM # COMPONENT DESCRIPTION
T7-NBK
T7-102-SS
EDGE-SP N/A
KITS – QTY. COUNTS
1 T7-NBASE-(color code) NO STEP T7 BASE 1
2 T7-DB-(color code) 7’ T7 DIVING BOARD 1
3 T7-NJIG 3 BOLT T7 NO STEP BASE JIG 1
4 T7-NSPRING-(color) T7 NBASE SPRINGS (pair) 1
5 SPRING PAD (factory installed) T7 NSPRING PAD 2
6 T7-EDGE-GR (F-GR) / (L-GR) OPTIONAL EDGEWATER ASSEMBLY 1
7 H-1/2 SPA HOSE 1/2” PVC FLEX SPA HOSE GRAY 1
8 H-1/2 NYLON WAS 1/2” FLAT NYLON WASHER 3
9 H-SS 1/2 F WAS 1/2” SS FLAT WASHER 3
10 H-SS 1/2 LOC WA 1/2” SS LOCK WASHER 3
11 H-SS 1/2 H NUT 1/2” SS HEX NUT 3
12 H-1-1/2 WHT CAP .750 X 1-1/2 WHITE UV NUT CAP 3
13 H-SS 3/8 FLT WA 3/8” SS FLAT WASHER 8 12
14 H-SS 3/8 LOC WA 3/8” SS LOCK WASHER 8 6
15 H-SS 3/8 F NUT 3/8” SS FINISH HEX NUT 8 6
16 H-.562 X .390 CAP .553 X 1/2” GRAY PROTECTIVE CAP 8
17 H-SS 3/8 X 2-1/2 3/8” X 2-1/2” HEX HEAD BOLT SS 6
18 H-SS #8 X 3/4 SS 8 X 3/4” PAN HEAD PHILLIPS SCREW 4
T7 DB-GR
T7 BASE-GR
T7 SPRING-GR
T7 EDGE GR
TABLE 4 – PARTS LIST
HARDWARE NOTE:
Use a small dab of
anti seize lubricant
(included) on all bolt
threads.

INSTALLATION MANUAL T7™ DIVING SYSTEM
12
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
T7™ CARE & MAINTENANCE:
Your T7 diving system requires periodic maintenance to keep it looking like new.*
• Wash Monthly or more frequently, if needed. Be careful to keep cleaning material from
entering the pool.
• Wash with a mild soap such as hand dishwashing soap, avoid using strong cleaners or
abrasives. Avoid strong alkaline (such as tri-sodium phosphate) or highly acidic cleaners.
Avoid bleach and ammonia.
• With the exception of the slip resistant surface on the top of the diving board and step,
wax the diving system once or twice a year with a good grade paste wax formulated for
gel coat surfaces. CAUTION: be careful when applying wax. Waxing the slip resistant
surfaces may cause them to become slippery resulting in possible serious injury.
* These suggestions and data based on information believed to be reliable, from our raw materials
manufacturers. They are offered in good faith, but without guarantee, as conditions and methods
of use and procedures are beyond our control.

INSTALLATION MANUAL T7™ DIVING SYSTEM
13
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES
Extracted from ANSI/NSPI- 2003, American National Standard for Residential Inground Swimming Pools

INSTALLATION MANUAL T7™ DIVING SYSTEM
14
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES
Extracted from ANSI/NSPI- 2003, American National Standard for Residential Inground Swimming Pools

INSTALLATION MANUAL T7™ DIVING SYSTEM
15
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES
Extracted from ANSI/NSPI- 2003, American National Standard for Residential Inground Swimming Pools

INSTALLATION MANUAL T7™ DIVING SYSTEM
16
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES
Extracted from ANSI/NSPI- 2003, American National Standard for Residential Inground Swimming Pools

INSTALLATION MANUAL T7™ DIVING SYSTEM
17
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES
Extracted from ANSI/NSPI- 2003, American National Standard for Residential Inground Swimming Pools

INSTALLATION MANUAL T7™ DIVING SYSTEM
18
T7-IM Rev. 4/09 (BBK-T7 INSTAL)
SUPPORT INFORMATION: ARTICLE 5 – POOL DIMENSIONS AND TOLERANCES
Extracted from ANSI/NSPI- 2003, American National Standard for Residential Inground Swimming Pools
To obtain complete copies of the ANSI/NSPI-5 2003 Standard
for Residential Inground Pools contact:
The Association of Pool & Spa Professionals (APSP)
2111 Eisenhower Ave.
Alexandria, VA 22314
[phone]
or visit: www.theapsp.org
