Inter-m PA-9336 User manual

OPERATING MANUAL
PUBLIC ADDRESS POWER
AMPLIFIER
PA-9336

11
UNPACKING AND INSTALLATION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
This symbol is intended to alert the user to the
presence of important operation and main-
tenancy (servicing) instructions in the literature
accompanying the appliance.
Caution: To prevent electric shock do not use this (polarized) plug
with an extension cord, receptacle or other outlet unless
the blades can be fully inserted to prevent blade ex-
posture.
Attentions: Pour prévenir les chocs électriques ne pas utilizer cette
fiche polarisée avec un prolongateur, une prise de
courant on une autre sortie de courant, sauf si les
lames peuvent étre insérées à fond sans en laisser
aucune partie à découvert.
Although it is neither complicated to install nor difficult to operate your PA amplifier, a few minutes
of your time is required to read this manual for a properly wired installation and becoming familiar
with its many features and how to use them. Please take a great care in unpacking your amplifier
and do not discard the carton and other packing materials. They may be needed when moving
your set and are required if it ever becomes necessary to return your set for service.
Never place the unit near radiators, in front of heating vents, in excessively humid or dusty
location to avoid early damage and for your years of quality use. Connect your complementary
components as illustrated in the following page.

22
FEATURES
• THERMAL PROTECTION & AUTOMATIC IDLING CIRCUITRY
To insure stability and reliability against over-current and over-heating, thermal protection
circuitry is provided. In addition, automatic idling circuit is provided to protect against thermal
run-away.
• BALANCED INPUT
A balanced input is provided to reduce hum picked up from a long distance input cable and to
avoid ground loop problem when you build the system.
• GAIN ADJUSTMENT
You can adjust the input gain from –12dB to 0dB (1V) by using of input gain adjust control.
• USE OF EMERGENCY BATTERY
You can operate this PA amplifier by using emergency battery for unexpected AC power failure.
• COMPACT SIZE
For valuable saving in rack space and slim exterior view, this amplifier is designed with a
compact size of 3µ.

FRONT PANEL CONTROLS
33
1. POWER INDICATING LED
This LED indicates power is turned ON.
2. POWER SWITCH
Pressing this switch to ON will make the power indicating LED ON and supply the power to
unit.
3. OUTPUT LEVEL INDICATORS
These LEDs indicates the output level of this amplifier. Be sure not to operate the unit with the
clip LED ON continuously (RED).
4. PROTECTION INDICATOR
This LED indicates the condition of the protection circuit. When the protection LED is “ON” the
amplifier is not operating normally (power on delay, overheating and limiting), please check
the INPUT/OUTPUT condition of the amplifier.
5. FAN
The fans should be kept free of all obstructions and be accessible to cool fresh air when
possible. It is important that the fans be used in a dust free environment.
PUBLIC ADDRESS POWER AMPLIFIER
PA-9336
POWER
ON
OFF
CLIP
-10dB
-40dB
OUTPUT&PROTECTION
PROT
5
3 2
4 1

44
REAR PANEL CONTROLS
1. SPEAKER OUTPUT TERMINALS
These terminals are for connection of speaker lines to deliver power output to speakers.
Impedance (voltages) of 4Ω, 8Ω, 70V and 100V are provided for convenience. In any case,
use the speakers whose combined impedance is equal to or higher than the rated output
impedance of amplifier.
2. INPUT JACKS
These input jacks and terminals are for the balanced input signal. You can connect amplifiers
in parallel by using XLR jack.
3. LEVEL ADJUST CONTROL
This control is for adjusting the level of amplifier from –12dB to 0dB with the reference input
sensitivity of 0dB (1V). Rotating the control clockwise increases the level and counter-
clockwise decreases the level.
4. FUSE HOLDERS
These fuse holders contain AC. Replace them with the same type fuse when they are blown
out. If they continuously blow, stop replacing fuses and refer servicing to qualified personnel.
Impedance 4Ω8Ω13.6Ω
Output Voltage 38V 53V 70V
Impedance 4Ω13.6Ω27.8Ω
Output Voltage 38V 70V 100V
• USA/CANADA & Associated Version • EC & Associated Version
31V(4Ω)
B
70V(21Ω)
A
100V(41Ω)
COM
OUTPUT
AC INPUT
230V 50Hz, 380W
~
HPF
OFF
ON
0dB
INPUT(ADJ)
-12dB
+
DC INPUT
24V
FRAME
FLOAT
GROUND
LIFT
BALANCED
INPUT
1V/10KΩ
LINK
FUSE : T6.3AL/250V
S/N
MODEL NO;PA-9336
PUBLIC ADDRESS
POWER AMPLIFIER
MADE IN KOREA
OUTPUT POWER:360W
1 3
8 972645

55
5. AC INLET
This terminal is connected AC input cord.
6. HIGH-PASS FILTER SWITCH
This switch is for activating the High-pass Filter circuit, to protect speakers from excessive low
frequency power demands. The –3dB frequency of the High-pass Filter is 400Hz.
7. EARTH LINK SWITCH
This slide switch provides for separation of “safety” earth and “signal” earth to prevent from
hum loops.
8. DC INPUT TERMINALS
These terminals are for connecting DC power supply of battery, Connect red colored terminal
to positive lead of battery and black colored one to negative lead of battery.
9. VENTILATOR
This ventilator releases an heated air occurred inside the set.
Be careful so that this ventilator is not closed by any obstruction.

66
CONNECTIONS
31V(4Ω)
B
70V(21Ω)
A
100V(41Ω)
COM
OUTPUT
AC INPUT
230V 50Hz, 380W
~
HPF
OFF
ON
0dB
INPUT(ADJ)
-12dB
+
DC INPUT
24V
FRAME
FLOAT
GROUND
LIFT
BALANCED
INPUT
1V/10KΩ
LINK
FUSE : T6.3AL/250V
S/N
MODEL NO;PA-9336
PUBLIC ADDRESS
POWER AMPLIFIER
MADE IN KOREA
OUTPUT POWER:360W
CH8
CH7
CH6
CH5
CH4
CH3
CH2
CH1
-
+
DC INPUT
24V
CH16
CH15
CH14
CH13
CH12
CH11
CH10
CH9
AMP IN 1
AMP IN 2
ALL
GROUP 1
GROUP 2
TIMER
REMOTE
(+)
(-)
(+)
(-)
S/N
LINE OUT
REC
-
+
DC INPUT
24V
OUT
GND
TUNER
DECK
AUX
CD
PHONO
MIC6
MIC5
MIC4
MIC 33
MIC2
MIC1
MUTE
230
CHIME
MIXER
~AC INPUT 230V
50Hz
FUSE
T200mAL/250V
31V(4Ω)
B
70V(21Ω)
A
100V(41Ω)
COM
OUTPUT
AC INPUT
230V 50Hz, 380W
~
HPF
OFF
ON
0dB
INPUT(ADJ)
-12dB
+
DC INPUT
24V
FRAME
FLOAT
GROUND
LIFT
BALANCED
INPUT
1V/10KΩ
LINK
FUSE : T6.3AL/250V
S/N
MODEL NO;PA-9336
PUBLIC ADDRESS
POWER AMPLIFIER
MADE IN KOREA
OUTPUT POWER:360W
SHOCK HAZARD DO
NOT OPEN. NO USER SERVICEABLE
PARTS INSIDE.DO NOT EXPOSE
UNIT TO RAIN OR MOISTURE
WARNING;
RISQUE DE CHOC ELECTRIQ-
UE NE PAS OUVRIR.
AVIS;
CAUTION; REPLACE WITH THE
SAME TYPE FUSE AS INDICATED. UTI-
LISER UN FUSIBLE DE RECHANGE DE
MEME TYPE.
230
AC INPUT: 220V,60Hz 139VA
~
FUSE: 1A/250V
MODEL NO;PB-92O7A
BATTERY CHARGER
MADE IN KOREA
( )
( )
S/N
BATTERY IN
EMERGENCY
AC FUSE
2A/250V
DC FUSE
7A/250V
BATTERY
INPUT
(+)
( )
AC INPUT
230V/50Hz,217VA
GND
(+)
( )
UNSWITCHED
DC OUTPUT 24V
+
-
DC OUT 24V
(RACK ONLY)
SWITCHED
5A MAX
(AMP ONLY)
SWITCHED DC OUT 24V
REMOTE
SW
C
H
SWED 1 (2000W)
SWED 2 (2000W)
SWED 3 (2000W)
UNSWED (700W)
BATTERY
DC 24V
BATTERY
DC 24V
AC CORD
TURN TABLE
PP-9113
PA-9336
PA-9336
PS-9116
PD-9359
MIC
SPEAKER
PB-9207A

SPECIFICATIONS
77
ELECTRICAL
Rated output (THD 1%) ........................................................................................360W (RMS)
4Ω(38V)
8Ω(53V)
13.6Ω(70V)
27.8Ω(100V)
Input Sensitivity/Impedance ...............................................................................1V/10KΩ, BAL
T.H.D (at 1KHz, Rated Output) ............................................................................Less than 1%
Frequency Response (+1/–3dB) ..........................................................................70Hz~20KHz
S/N..................................................................................................................Better than 95dB
H.P.F ..................................................................................................................–3dB at 400Hz
Input Level Adjustment ...........................................................................................–12dB~0dB
GENERAL
Power Source .................................................................AC 110V~240V, 50Hz/60Hz, DC 24V
Weight (Net) ......................................................................................................................21Kg
Dimensions ................................................................................482(W) 132(H) 280(D)mm
Specifications and design subject to change without notice for improvements.

MADE IN KOREA
