Scape®
Hardware
stxx-005 & pcsi-005/6
Installation guide

1. Connections and controls
—
Scape® Hardware Technical specifications are subject
Installation guide to change without notice.
stxx-005 & pcsi-005/6 Version 1.1 – Status: 12/2019
Page 2 of 9 poc: SFi
Scape® Hardware
Installation guide
Contents
1. Connections and controls __________________________________________________________________________________________4
Scape® Tangible______________________________________________________________________________________________________ 4
Silent PC ______________________________________________________________________________________________________________5
2. Wiring ______________________________________________________________________________________________________________6
Capore® touch and object recognition _______________________________________________________________________________ 6
Windows touch _______________________________________________________________________________________________________7
3. Troubleshooting tips _______________________________________________________________________________________________8
Manufacturer – Support _____________________________________________________________________________________________ 8

1. Connections and controls
—
Scape® Hardware Technical specifications are subject
Installation guide to change without notice.
stxx-005 & pcsi-005/6 Version 1.1 – Status: 12/2019
Page 3 of 9 poc: SFi
Notes
This document provides graphics for the correct wiring of a Scape® Tangible with a Silent PC for operation with
Windows Touch or Capore® Touch and object recognition.
This manual is applicable for the following devices:
·Scape® Tangible (stxx-005)
·Silent PC 2060 (pcsi-005)
·Silent PC 2070 (pcsi-006)
Information in this document is subject to change without notice.
©2019 Interactive Scape GmbH. All rights reserved.
The document or excerpts from the document may not be duplicated without the prior permission of Interactive Scape
GmbH.
Interactive Scape GmbH shall not be liable for any errors contained in this document or any other incidental or
consequential damages resulting from the delivery, use or application of this material.
All product names mentioned in this document are trademarks or registered trademarks of their respective owners.

1. Connections and controls
—
Scape® Hardware Technical specifications are subject
Installation guide to change without notice.
stxx-005 & pcsi-005/6 Version 1.1 – Status: 12/2019
Page 4 of 9 poc: SFi
1. Connections and controls
Scape® Tangible
1
IR-Sensor for remote control
2
Switch between Touch TUIO / USB Touch
3
RJ-45 Lan interface – to use the Capore® Touch & Object Assistant
4
USB
-Connection Type B – for direct connection of touch and PC
5
Line Out output
6
DisplayPort input
7
HDMI 2.0 input (UHD 60 Hz)
8
HDMI
1.4 input
9
Stand-by
10
Status LED
11
Close OSD / > back / > show input selection
12
Plus / Right
13
Minus / Left
14
Open OSD / confirm selection
15
IEC socket for connection to 230V 50Hz
16
Main power switch
1
2 3 4
15
16
5
6
7
8
9
10
11
12
13
14

1. Connections and controls
—
Scape® Hardware Technical specifications are subject
Installation guide to change without notice.
stxx-005 & pcsi-005/6 Version 1.1 – Status: 12/2019
Page 5 of 9 poc: SFi
Silent PC
1
Switch
PC on / off
2
SD(HC/XC)-Slot
3
USB 3.1 (type A)
4
Microphone input (3.5mm jack)
5
Audio output (3.5mm jack)
6
USB 3.1 (type C)
7
Power supply
8
Gigabit Ethernet (internal
–
Capore®
)
9
Gigabit Ethernet (external)
10
2x external WIFI antennas
11
DisplayPort out
12
2x HDMI 2.0 out
13
USB 3.1 (type C)
14
4x USB 3.0 (type A)
1
2
3
4
5
6
7
8
9
10
11
12
13
14

2. Wiring
—
Scape® Hardware Technical specifications are subject
Installation guide to change without notice.
stxx-005 & pcsi-005/6 Version 1.1 – Status: 12/2019
Page 6 of 9 poc: SFi
2. Wiring
Capore® touch and object recognition
* PC network settings:
IPv4 address: 10.0.0.21
Subnet mask: 255.255.255.0
1
Set switch to TUIO
2
Establishing a network connection (RJ45 connector)*
3
Establishing an HDMI 2.0 connection
1
2 3

2. Wiring
—
Scape® Hardware Technical specifications are subject
Installation guide to change without notice.
stxx-005 & pcsi-005/6 Version 1.1 – Status: 12/2019
Page 7 of 9 poc: SFi
Windows touch
1
Set switch to USB Touch
2
Establishing a USB Connection (USB A
-to-B Cable)
3
Establishing an HDMI 2.0 connection
1
2
3

3. Troubleshooting tips
—
Scape® Hardware Technical specifications are subject
Installation guide to change without notice.
stxx-005 & pcsi-005/6 Version 1.1 – Status: 12/2019
Page 8 of 9 poc: SFi
3. Troubleshooting tips
Do not open the housing of the Scape® Tangible and Silent PC by yourself.
If your devices do not work as intended, contact Interactive Scape Hardware Support. You can reach them on
weekdays at +49 30 698 094 150.
Manufacturer – Support
Interactive Scape GmbH
Wilhelmine-Gemberg-Weg 6
10179 Berlin
Germany
+49 (0)30 698 094 150
