INTERNATIONAL CARBONIC SPACE CADET SCR Manual

I
C
I
SPACE CADET
INSTALLATION AND SERVI CE
MANUAL
INTERNATIONAL CARBONIC INC.
16630 KOALA RD.
ADELANTO, CA. 92301
SCR
RC- SC- R
1/03

IMPORTANT: This manual is a guide for installing, operating,
servicing and maintaining this equipment. Refer to Table of Contents
for page location of detailed information to answer questions that
arise during installation, operating, service and maintenance, or
installation of this equipment.

TABLE OF CONTENTS
PAGE
PREFACE ...................................................................................................................... 1
CHAPTER I GENERAL DESCRIPTION.......................................................................... 2
SYSTEM DESCRIPTION ................................................................................... 2
DESIGN DATA................................................................................................... 2
EXPLODED VIEW, SCR.................................................................................... 4
DESCRIPTION, EXPLODED VIEW, SCR .......................................................... 5
EXPLODED VIEW, RC-SC-R............................................................................. 7
DESCRIPTION, EXPLODED VIEW, RC-SC-R................................................... 8
ELECTRICAL SCHEMATIC, DUAL CARB, DIRECT WIRE............................... 10
ELECTRICAL SCHEMATIC, S-68-B ................................................................ 11
GENERAL FLOW VIEW................................................................................... 12
FLOW CHARTS............................................................................................... 13
THEORY OF OPERATION .............................................................................. 14
CHAPTER II INSTALLATION ....................................................................................... 18
UNPACKING AND INSPECTION..................................................................... 18
SELECTING LOCATION.................................................................................. 19
LOCATION RECOMMENDATIONS FOR SCR................................................. 19
INSTALLATION ............................................................................................... 19
INSTALL HIGH PRESSURE CO2 REGULATOR, CO2 CYLINDER
AND LINES...................................................................................................... 20
INSTALL LOW PRESSURE REGULATOR AND LINES ................................... 20
INSTALL WATER FILTER ASSEMBLY, (OPTIONAL)...................................... 21
INSTALL WATER PRESSURE REGULATOR, (OPTIONAL) ............................ 21
INSTALL WATER HOLDING TANK, (OPTIONAL)............................................ 21
INSTALL DRAIN LINE...................................................................................... 22
INSTALL B.I.B. OR SYRUP TANKS AND ACCESSORIES .............................. 22
CONNECTING WATER INLET ........................................................................ 22
ELECTRICAL REQUIREMENTS...................................................................... 22
CHAPTER III PREPARATION ...................................................................................... 23
PREPARING SYSTEM FOR OPERATION....................................................... 23
PREPARING AND STARTING REFRIGERATION UNIT .................................. 23
ACTIVATE HIGH PRESSURE CO2 SYSTEM.................................................. 23
ACTIVATE LOW PRESSURE CO2 GAS AND SYRUP SYSTEMS................... 24
ADJUST WATER FLOW RATE........................................................................ 24
ADJUST WATER-TO-SYRUP “RATIO” ............................................................ 24
ADJUST SIZE OF DRINK DISPENSED ........................................................... 24
CHAPTER IV OPERATORS INSTRUCTIONS.............................................................. 25
DAILY PRE-OPERATION CHECK ................................................................... 25
REPLENISHING CO2 SUPPLY ....................................................................... 25
REPLENISHING SYRUP SUPPLY................................................................... 25
COOLING UNIT MAINTENANCE..................................................................... 25
CHECKING WATER BATH .............................................................................. 26
CHANGING WATER BATH.............................................................................. 26
ADJUSTMENTS .............................................................................................. 26
ADJUSTING WATER FLOW RATE.................................................................. 26
ADJUSTING WATER-TO-SYRUP “RATIO” OF DISPENSED PRODUCT......... 26
ADJUSTING SIZE OF DRINK DISPENSED ..................................................... 26
TESTING FOR LEAKS..................................................................................... 26

TABLE OF CONTENTS (cont’d) PAGE
CHAPTER V SERVICE AND MAINTENANCE.............................................................. 28
PERIODIC INSPECTION AND CLEANING ...................................................... 28
SPACE CADET REMOTE CABINET MAINTENANCE ..................................... 29
CLEANING CONDENSER COIL ...................................................................... 29
CHECKING/CHANGING WATER BATH .......................................................... 29
WATER PUMP MAINTENANCE ...................................................................... 30
CARBONATOR MAINTENANCE ..................................................................... 31
LUBRICATION................................................................................................. 31
SERVICING CHECK VALVES ......................................................................... 32
EXPLODED VIEW, S-229 ASSEMBLY ............................................................ 33
REPLENISHING CO2 SUPPLY ....................................................................... 34
SYRUP FLAVOR CHANGE ............................................................................. 34
CHANGING WATER FILTER CARTRIDGE (OPTIONAL)................................. 34
ADJUSTMENTS .............................................................................................. 34
HIGH PRESSURE CO2 REGULATOR ................................................ 34
LOW PRESSURE CO2 REGULATOR................................................. 35
DIET SYRUP TANK CO2 REGULATOR.............................................. 35
CLEANING AND SANITIZING ............................................................. 35
CHAPTER VI TROULBESHOOTING............................................................................ 37
CARBONATOR................................................................................................ 37
WATER PUMP MOTOR WILL NOT OPERATE ................................... 37
WATER PUMP MOTOR WILL NOT SHUT OFF .................................. 37
WATER PUMP WILL NOT SHUT OFF AND PRESSURE
RELIEF ENGAGED............................................................................. 37
SHORT CYCLING OF WATER PUMP MOTOR................................... 37
WATER PUMP CAPACITY TOO LOW ................................................ 37
WATER PUMP OPERATES BUT WATER PUMP DOES
NOT PUMP ......................................................................................... 37
FROZEN WATER BATH...................................................................... 38
COOLING OR CONDENSING UNIT NOT OPERATIONAL.................. 38
AGITATOR MOTOR NOT OPERATING .............................................. 38
COMPRESSOR DOES NOT OPERATE.............................................. 38
COMPRESSOR WORKS CONTINUOUSLY BUT DOES
NOT FORM SUFFICIENT ICE BANK .................................................. 38
COMPRESSOR WILL NOT STOP AFTER SUFFICIENT
ICE BANK IS PRODUCED .................................................................. 39
CONDENSER FAN MOTOR NOT OPERATING.................................. 39
NO SYRUP BEING DISPENSED......................................................... 39
NO WATER BEING DISPENSED ........................................................ 39
DISPENSED PRODUCT CARBONATED TO LOW.............................. 39
DISPENSED PRODUCT MAKES FOAM AS IT LEAVES
NOZZLE.............................................................................................. 40
DISPENSED PRODUCT COMES OUT CLEAR BUT FOAMS
WHEN IT TOUCHES CUP OR GLASS ................................................ 40
WATER-TO-SYRUP “RATIO” TOO LOW OR TOO HIGH .................... 40
ADJUSTMENT OF SYRUP METERING PIN DOES NOT
PRODUCE DESIRED WATER-TO-SYRUP “RATIO” ........................... 40
CARBONATION TROUBLESHOOTING FLOW CHART #1 .............................. 41
CARBONATION TROUBLESHOOTING FLOW CHART #2 .............................. 42
CARBONATION TROUBLESHOOTING FLOW CHART #3 .............................. 43
NOTE SECTION........................................................................................................... 44

PREFACE
INTERNATIONAL CARBONIC INC. has enjoyed over 53 years of
manufacturing excellence in the field of carbonation and in the beverage
related industry. We have had a long and proud history with quality as our
standard and innovation as our goal. Originally started just after World
War II in Canfield, Ohio as Carbonic Dispensers. We enjoyed patents on
the first Sodajet type carbonator. This method of carbonation
instantaneously carbonated the water to 100% saturation. We developed
the first patented dispensing valve to dispense bulk beverage with
carbonation equal to or in excess of bottled beverages. A valve with three
flavors and soda was another first. We were the first to incorporate the
total postmix package, i.e., carbonation, refrigeration, and the ability to
dispense from one self contained unit. We have pioneered many such
firsts and will continue to develop advanced systems for the future, such
as electronic interrogatable portion controls to electronic liquid level
controls.
We hope you enjoy this piece of equipment that has been produced to
give many years of trouble free service. We thank you for your purchase
and hope we may serve you in the future.
1

CHAPTER I
GENERAL DESCRIPTION
This chapter gives the description, theory of operation, and design data for the SPACE
CADET REMOTE, (SCR) and related components.
SYSTEM DESCRIPTION
The Space Cadet is a complete self-contained remote cooling/carbonation unit which
when combined with related components, will produce a variety of cooled carbonated and
non-carbonated beverages.
The Space Cadet consists of a condensing unit, a water reservoir, water-cooling coil, a
carbonator tank, (carbonated systems only), an agitator pump, and syrup cooling coil(s).
The Space Cadet is manufactured in two configurations, i.e., (SC-R), SPACE CADET
REMOTE and (RC-SC-R) RECIRCULATING SPACE CADET REMOTE.
For proper function the Space Cadet must have a water supply, and electrical supply and
drainage. Other items that will be required if used in B.I.B., (Bag in Box), or transfer tank,
(FIGAL), installations will be high pressure regulator, Low pressure regulator, connecting
lines, quick couplers, or disconnects and C02.
WARNING: Before shipping or relocating a Space Cadet into a freezing
ambient environment empty plain and carbonated water. Syrup systems
should be flushed, ice bank melted, and water drained from water bath.
A freezing ambient environment will cause existing water in unit to freeze
possibly resulting in damage to pump/motor assembly, syrup coils, water
coil, water bath, etc.
TABLE I - I
DESIGN DATA
COOLING UNIT
Overall cabinet dimensions: SCR RC-SC-R
Height 29 1/4” 29 1/4”
Width 26 3/8” 36 1/8”
Depth 15 3/4” 15 3/4”
Weights:
Shipping 132 182
Dry weight 104 154
Operational Weight 204 254
Ice Bank 35 35
Capacities: Unit water bath (no ice bank) 9 gallons
Refrigerant requirement (R-134-A) 250 grams
Ambient operating temperature
40 F to 100 F.
2

Electrical Requirements: The cooling unit requires a 115 VAC, single phase, 60 Hertz
Power circuit.
SCR RC-SC-R
Ampacity 13.9 20.1
Condensing Unit 6.9 6.9
Water/Recirc. Pump Motor 6.2 6.2 X 2
Agitator .8 .8
Water Filter Recommended (Optional) See Manufacturer Specifications for Operating Conditions
Pressure
Incoming Water Pressure Regulator (Optional) 25 – 40
C02 High Pressure Regulator (Carbonated units only) PSI 65 – 75
C02 Low Pressure Regulator (Carbonated/Flavored units only) BIB Approx. 40 PSI
C02 Low Pressure Regulator (Carbonated/Flavored units only) FIGAL Approx. 30 PSI
C02 Low Pressure Regulator (Optional) FIGAL Approx. 30 PSI
C02 Diet Drink Pressure Regulator (if required) 6 - 10 PSI
DISPENSING VALVES Ambient Operating Temperature 40 F to 100 F
Electrical Requirements: Operating Voltage 24VAC, 6Ohz
3

INTERNATIONAL CARBONIC INC.
ADELANTO, CALIFORNIA
TITLE
DATE
DRN. BY
CHK. BY
APPR. BY
I
C
I
SPACE CADET REMOTE
SC- R
1/6/05
GLW
34
35
1
56
9
8
3
4
3
4
16
10
11 12
13
15
18
19
20
21
23
22
22
24
25
27
26
28
29
30
39
40
41
43
33
48
55
47
49
51
52
53
254
44
45
46
42
14
2
36
17
31 32
38
37
50
7
2
4

SC-R
SYM QTY PART NO. DESCRIPTION
1 1 S0680 LID ASSEMBLY
2 4 A0020 SCREW, 8-32 X 3/8 T.H., S.S.
3 2 S0679 SERVICE PANEL, SIDE
4 1 S0678 SERVICE PANEL, LARGE, FRONT & REAR
5 1 S0657 STANDPIPE, 7 3/4"
6 1 S0658 OVERFLOW, 8"
7 1 G0016 TY-RAP LARGE
8 4-6 S0588-B SYRUP COIL
9 1 S0840 AGITATOR PUMP
10 1 S0668 WATER LINE, COPPER
11 1 S0203 UNION
12 1 S0262 CARBONATOR TANK ASSEMBLY
13 1 S0073-48 PROBE ASSEMBLY
14 1 S0208-A WATER REGULATOR, OPTIONAL
15 1 S0666 WATER COIL W/YOKE
16 1 S0513-A ICE BANK CONTROL
17 1 S1304-U ICE BANK CONTROL PROBE BRACKET
18 5 S0661 EVAPORATOR COIL RETAINER
19 5 S1323 EVAPORATOR GUIDE WEDGE
20 5 S0662 EVAPORATOR COIL SUPPORT BRKT
21 1 . . . . . . . BEADBOARD, SIDES
22 1 . . . . . . . BEADBOARD, BACK
23 1 . . . . . . . BEADBOARD, FRONT
24 1 . . . . . . . BEADBOARD, BOTTOM
25 1 . . . . . . . MOISTURE BARRIER
5

SC-R Cont.
SYM QTY PART NO. DESCRIPTION
26 1 S0663 EVAPORATOR ASSEMBLY
27 1 S0509 ACCUMULATOR
28 1 Z0010 CAP TUBE, 9' - .050
29 1 S0656 BUCKET COMPLETE W/INSULATION
30 1 S0655 FRAME, COMPLETE
31 12 S1325 SQUARE GROMMET NUT
32 12 A0014 SCREW, #10 X 1/2" PH T.H., S.S. COMBO
33 1 SET S0765 LEGS
34 1 S0103 PUMP PROTECTOR
35 1 S0104 PUMP PROTECTOR BRACKET
36 1 S0170 HALF UNION, BRASS, 3/8 MP X 3/8 MF
37 1 S0175 ELBOW, 90 DEGREE, BRASS 3/8 MP X 1/4 MF
38 1 S0650 "Y" STRAINER, BRASS
39 2 A0045 5/16 X 18 1/2" FLANGE WHIZ LOCK SCREW
40 1 S0200 CARBONATOR PUMP, 100 GPH
41 1 S0106 CLAMP, "V" BAND CLAMP
42 1 S0096 MOTOR
43 1 E0141-9 CORD
44 1 AEA3440YXA 1/3 H.P. COMPRESSOR ONLY
45 2 A0046 5/16 X 18 FLANGE WHIZ LOCK SCREW, 3/4"
46 1 AEA3440YXAXL 1/3 H.P. CONDENSING UNIT
47 2 S-7/8 HOLE PLUG
48 1 S1308 CONTROL BOX W/COVER
49 5 S0046 BUSHING
50 4 S1335 TERMINAL BOARD SPACER, NYLON, 3/8"
51 2 A0049 8-32 X 3/8 PH, TYPE F. SELF TAP
52 1 S0068-B LIQUID LEVEL CONTROL
53 1 A0067 8-32 X 3/8 HEX HD, PH GREEN GROUND SCREW
54 1 S01310 CONTROL BOX COVER
55 1 E0664 STRAIN RELIEF
6

INTERNATIONAL CARBONIC INC.
ADELANTO, CALIFORNIA
TITLE
DATE
DRN. BY
CHK. BY
APPR. BY
I
C
I
RECI RCULATI NG SPACE
CADET REMOTE
RC- SC- R
1/20/05
GLW
36
37
39
50
40
46
38
43
44
45 49
48
41
42
47
1
78
13
12
11
3
4
6
5
26
21
15 16 17
18
20
23
24
25
28
29
27
27
30
31
33
32
34
35
51
40
59
49
60
66
70
64
67
69
71
272
62
61
73
50
14
19
2
54
55
56
57
58
52 53
63
10
2
68
9
22
65
2
7

RC-SC-R
SYM QTY PART NO.
DESCRIPTION
1
1
S0680
LID ASSEMBLY
2
4
A0020
SCREW, 8-32 X 3/8 T.H., S.S.
3 1 S0631
SERVICE PANEL, LEFT 1/2 PANEL
4 1 S0678
SERVICE PANEL, LARGE, REAR
5 1 S0678-A
SERVICE PANEL, FRONT, W/SWITCH HOLE
6 1 S0679
SERVICE PANEL, SMALL, RIGHT SIDE ONLY
7 1 S0657
STANDPIPE, 7 3/4"
8
1
S0658
OVERFLOW, 8"
9 1 G0016
TY
-RAP LARGE
10 1 S0644
RECIRCULATING POST
-COOLING COIL
11 1 S0645
RECIRCULATING PRE
-COOLING COIL
12
5
S0588-B
SYRUP COIL
13 1 S0840
AGITATOR PUMP
14 1 S0555
TEE, SWIVEL HOSE, S.S. 5/16H X 5/16H X 1/4 FF
15 1 S0670
WATER LINE, COPPER
16
1
S0203
UNION
17 1 S0262
CARBONATOR TANK ASSEMBLY
18 1 S0073-48
PROBE ASSEMBLY
19 1 S0208-A
WATER REGULATOR
20 1 S0666
WATER COIL W/YOKE
21
1
S0513-A
ICE BANK CONTROL
22
1
S1304-U
ICE BANK CONTROL BULB BRACKET
23 5 S0661
EVAPORATOR COIL RETAINER
24 5 S1323
EVAPORATOR GUIDE WEDGE
25
5
S0662
EVAPORATOR COIL SUPPORT BRKT
26
1
S0783
UNIT ON/OFF SWITCH
27 1 ...... .
BEADBOARD, SIDES
28 1 . . . . . . .
BEADBOARD, BACK
29 1 . . . . . . .
BEADBOARD, FRONT
30 1 . . . . . . .
BEADBOARD, BOTTOM
31 1 . . . . . . .
MOISTURE BARRIER
32
1
S0663
EVAPORATOR ASSEMBLY
33 1 S0509
ACCUMULATOR
34 1 Z0010
CAP TUBE, 9'
- .050
35 1 S0656
BUCKET COMPLETE W/INSULATION
36 1 S0572
HOSE ASSY., PUMP INLET, 6" (3/8" INNERBRAID)
37
1
S0208
REGULATOR, WATER PRESSURE
8

RC-SC-R Cont.
SYM
QTY
PART NO.
DESCRIPTION
38
1
S0110
0-60 GAUGE, 1/4 NPT
39 1 S0650 "Y" STRAINER, BRASS
40
4
A0045
5/16 X 18 1/2" FLANGE WHIZ LOCK SCREW
41 1 S0103 PUMP PROTECTOR
42
1
S0104
PUMP PROTECTOR BRACKET
43 1 I0006 BUSHING, BRASS, 3/8"MP X 1/4" FP
44 1 S0171 TEE, BRASS, 3/8" F.P.
45
1
S0174
NIPPLE, BRASS, 3/8" M.P. X 3"
46 1 S0640 NIPPLE, 3/8 MP, S.S., HEX
47
1
S0170
HALF UNION, BRASS, 3/8 MP X 3/8 MF
48 1 S0200 CARBONATOR PUMP, 100 GPH
49
2
S0106
CLAMP, "V" BAND CLAMP
50 2 S0096 MOTOR
51
1
S0655-RC
FRAME, COMPLETE W/RC MOTOR BRACKET
52 10 S01325 SQUARE GROMMET NUT
53
10
A0014
SCREW, #10 X 1/2" PH T.H., S.S. COMBO
54 2 S0533 SWIVEL ELBOW, 90 DEGREE, 1/4" FF X 5/16" H., SS
55
2
S0592
HALF UNION, S.S., 3/8 MP X 1/4 MF
56 1 S0651 STRAINER, PLASTIC
57 1 S0640 NIPPLE, 3/8 MP, S.S., HEX
58 1 S0665 PUMP INSULATION KIT
59
1
S0400
CARBONATOR PUMP, S.S., 100 GPH
60 2 E0141-9 CORD
61 1 SET S0765 LEGS
62 2 A0046 5/16 X 18 FLANGE WHIZ LOCK SCREW, 3/4"
63
1
AEA3440YXA
1/3 H.P. COMPRESSOR ONLY
64
1
S0866
TOGGLE SWITCH
65 5 S0046 BUSHING
66 2 S-7/8 HOLE PLUG
67 1 S1308 CONTROL BOX W/COVER
68
2
A0049
8-32 X 3/8 PH, TYPE F. SELF TAP
69 4 S1335 TERMINAL BOARD SPACER, NYLON, 3/8"
70 1 S0068-U-BT LIQUID LEVEL CONTROL
71 1 E0664 STRAIN RELIEF
72
1
A0067
8-32 X 3/8 HEX HD, PH GREEN GROUND SCREW
73 1 S1310 CONTROL BOX COVER
74 1 AEA3440YXAXL 1/3 H.P. CONDENSING UNIT
9

INTERNATI ONAL CARBONIC I NC.
ON/ OFF
POWER
G1 G2 G3 G4
IBC1
IBC2 CU1
CU2
B1 B2 B3 B4 B5
MOTOR1
MOTOR2
SHORT LONG GND
ON/ OFF A2 A3 A4 A5
S-68-B
GREEN
BLACK
WHI TE
ON/ OFF
TRANSFORMER
CARB
MOTOR/ PUMP
CONDENSI NG
UNI T
AGI TATOR PUMP
ELECTRODE
WHI TE BLACK
BLACK WHI TE
Note: Ground Terminals, Carbonator Tank
and Water Bath Must be
Commonly Grounded
120 VAC
GREEN
GREENGREEN
GREEN
GREEN
ELECTRICAL SCHEMATIC 120 VOLT
NOTE: IF USI NG EXTRA 120V. ACCESSORIES SUCH AS RECI RCULATI NG MOTOR, I LLUMI NATI ON
ETC., MAKE CONNECTIONS AT TERMI NAL A4, A5 FOR POWER/ BLACK LEG. TERMI NALS B4, B5,
FOR NEUTRAL/ WHITE LEG AND GROUND AT BOX OR ANY GROUND TERMINAL NOT IN USE.
TERMINALS
I CE BANK CONTROL
GROUND TERMINALS ARE G1, G2, G3, G4.
S-68-B
GROUND TERMI NAL SCREW I N
CONTROL BOX
S
C
R
M
S1
3 1
FAN MOT OR
COMPRESSOR
10

DI RECT WI RE CARB- RECI RC
DIRECT WI RE BLACK
DIRECT WI RE WHI TE
WHI TE
GREEN
DIRECT WI RE (GREEN) GROUND
TERMI NAL BLOCK
GREEN
WHI TE
BLACK
BLACK
WHI TE
" USE COPPER CONDUCTOR WI RE ONLY"
CONDENSI NG
UNI T
Note: Ground Termi nal s, Carbonator Tank
and Water Bath Must be
Commonl y Grounded
ON/ OFF
TOGGLE
RECIRC
MOTOR
ON/ OFF
POWER
G1 G2 G3 G4
IBC1
IBC2 CU1
CU2
B1 B2 B3 B4 B5
MOT OR1
MOT OR2
SHORT LONG GND
ON/ OFF
A2 A3 A4 A5
S- 68- B
GREEN
BLACK
WHITE
ON/ OFF
CARB
MOTOR/ PUMP
AGI TATOR PUMP
ELECTRODE
WHITE BLACK
BLACK WHI TE
120 VAC
GREEN
GREENGREEN
GREEN
GREEN
GROUND TERMI NAL SCREW I N
CONTROL BOX
BOARD #1
BOARD #1
CONDENSING UNIT
CONDENSING UNIT
BOARD #1
ON/ OFF
TOGGLE
FROM DIRECT
WI RE BAR
BLACK
WHITE
FROM DI RECT
WI RE BAR
10/ 01
11

SYRUP LINES
RECIRC. SODA LINE
FLOOR
RECIRC WATER LINE WATER BATH WATER
NON-CARBONATED WATER LINE
CONNECTED TO S-850 RECIRC PUMP CONNECTED TO SYRUP COILS RECIRC SODA CONNECTED TO POST AND PRE- COOLING COILS CONNECTED TO S-208-A WATER REGULATOR
SYRUP COILS
CO2 GAS TO CARBONATOR
INCOMING WATER LINE
INSULATED REMOTE DUCT LINES RUN UNDER FLOOR THROUGH TRANSIT
SYRUP LINES
RECIRC. SODA CONTINUOUS LOOP
NON-CARB WATER
FROM S-208-A
REFRIGERATED WATER FROM WATER BATH. A CONTINUOUS LOOP.
EXPOSED LINES TO WRAPPED WITH INSULATION AND THEN FINISHING TAPE.
EXPOSED LINES TO WRAPPED WITH INSULATION AND THEN FINISHING TAPE.
IT IS RECOMMENDED T0 ENLARGE I.D. OF TUBING TO A MINIMUM OF 3/8" WHEN DISTANCE FROM SYRUP SUPPLY TO DIS- PENSING STATION IS 50' OR GREATER.
SYRUP AND NON-CARB LINES TEE OFF TO STA #2
S-221 REGULATOR
B.I.B. RACK & BOXES
S-101 HI PRESSURE REG.
CO2 BOTTLE
LE MONSTRE
S-208 WATER REGULATOR
WATER FILTER
1/2" GATE VALVE
REAR VI EW OF VAL VE PLATES
DIRECTION OF FLOW
DUCT TUBING
RECIRC SODA
3/8" RECIRC. WATER, (WATER BATH)
SYRUP
NON-CARB
9/99
12

CARBONATOR TANK
100 GPH RECIRCULATING PUMP
POST- COOL
COI L S- 488- P
PRE- COOL
COI L S- 488- P
100 GPH RECIRCULATING PUMP
CARBONATOR TANK
RECI RC SODA FLOW CHART
TO DUCT TUBING
FROM DUCT
TUBING
FROM DUCT
TUBING
TO DUCT TUBING
S- 850 AGITAT OR PUMP
CONNECT TO
VALUTE OUTLET
CONNECT TO YOKE
ON WATER COIL
1/2" CLEAR RECIRC TUBING
FROM B.I.B.
TO DUCT TUBING
S- 488 SYRUP COI L
POST- COOL
COI L S- 488- P
PRE- COOL
COI L S- 488- P
TO DUCT TUBING
FROM DUCT TUBING
FROM B.I.B.
TO DUCT TUBING
S- 488 SYRUP COI L
FROM B.I.B.
TO DUCT TUBING
S- 488 SYRUP COI L
FROM B.I.B.
TO DUCT TUBING
S- 488 SYRUP COI L
FROM B.I.B.
TO DUCT TUBING
S- 488 SYRUP COI L
PLAI N WATER FLOW CHART
INCOMING WATER
THROUGH WATER COIL
TO CARBONATOR TANK/S
DOUBLE CHECK VALVE
TO NON- CARBONATED VALVE/ S S- 208- A REGULATOR
TO DUCT TUBING
RECI RC. WATER BATH WATER FLOW CHART
SYRUP FLOW CHART
WATER BATH COMPONENTS
AND FLOW CHARTS
13

THEORY OF OPERATION
The SCR was designed to manufacture and dispense carbonated or non-carbonated
beverages much like your local bottling plant that cans or bottles your favorite carbonated
or non-carbonated drink.
Initially water is chilled and then carbonated to dispense a quality drink. To chill the water
the water is routed through a water coil that is submerged in an ice-cold water bath. The
temperature of the incoming water is at ambient temperature as it enters the water coil.
As the incoming water passes through the water coil the heat is removed from the water
in the water coil and chilled to a temperature acceptable for a quality drink. The water is
now routed into a carbonator tank where this cold water is mixed with CO2. This water is
now transformed into a carbonic acid, (soda water), and then routed to a remote station
and then valves where it will be mixed with syrup concentrates and dispensed.
The water bath holds approximately 9 gallons of water. A certain amount of this water
will be transformed into ice, approximately 35 pounds. This water reserve and ice bank
will act as a reservoir for refrigeration. This reserve is utilized during peak periods when
the BTU output of the compressor is not sufficient to meet the demand of the draw.
It should be recognized that without refrigeration your carbonation system would not
produce a drink that will hold carbonation. There is a direct relationship between
dispensed temperature and the volumes of C02 that can be held in liquid form.
The following will give a general overview of the flow of individual circuits and a clearer
understanding of our mini bottling plant.
Carbon dioxide gas (CO2) passes from a C02 cylinder through high-pressure regulator
(S-101). The high-pressure regulator regulates the CO2 feeding the SCR and should be
set at 65-75 PSI. The gas, after leaving the high-pressure regulator, is routed through
flexible tubing to a low-pressure regulator. The flow of CO2 is teed to go in two directions
at the low-pressure regulator. One path takes the gas, set at 65 to 75 PSI, to the
carbonator tank. This gas must be at a pressure greater than the incoming water by at
least 25-PSI to assure the proper function of the carbonator. The second path of C02 is
routed through low-pressure regulator to be regulated at pressures suitable for the syrup
concentrate being dispensed. The low-pressure regulator may be set at many different
settings but primarily the settings are directed towards B.I.B. or transfer tank type
installations. The average settings may vary from 10 to 60 PSI, this of course will be
influenced by length of run, ambient temperature and baume of product. Typically B.I.B.
installations are set at an average of 40 PSI and transfer tank installations are set at an
average of 30 PSI.
As discussed earlier plain water enters the SCR through the incoming water line. This
water proceeds through the water coil where it is chilled prior to entering the carbonator
tank or in the case of non-carbonated drinks chilled prior to going directly to a valve.
Prior to entering the carbonator tank an optional regulator (S-208A) may be installed.
This assembly is utilized to maintain water pressure feeding a non-carbonated valve
when used in conjunction with a carbonated valve.
The water source should be regulated, this is normally performed by the use of an in line
water regulator. If the water is not regulated and the water pressure is equal or greater
than the incoming CO2 the act of carbonation will be greatly inhibited or completely
eliminated.
14

At the proper settings, the gas pressure will stop the water from entering the carbonator
tank. To force the water into the tank a liquid level control and motor/pump will be used.
This combination will force the water into the tank mixing the water and CO2 together.
The carbonator utilizes a Soda Jet Recirculating Principle. Our Company pioneered this
principle in the early 1950's. This principle produces instantaneous carbonation at
extremely large capacities of 100 gallons per hour minimum.
The level of the water within the stainless steel mixing tank, (carbonator tank), will
determine the cycle on or cycle off of the water pump and motor. The liquid level control,
in conjunction with a probe housed in the carbonator tank, control the pump motor. The
motor will come on when the carbonated water within the mixing tank recedes to a
predetermined low level and stops the pump motor when the carbonated water reaches a
predetermined high level.
During the cycle of operation, fresh water enters the carbonator tank through the soda jet
after passing through a short tube to the water pump inlet fittings. The water pump has
impellers which drives the water through a dual check valve and then through the soda
jet and into the carbonator tank.
The position and angle of the soda jet is fixed to direct an extremely high velocity solid jet
of fresh water so as to impinge upon the surface of the stored body of carbonator water
within the stainless steel mixing tank. The force created by this jet of fresh water entering
the mixing tank causes all the water within to cascade and foamesce through the carbon
dioxide gas area in a continuous recirculating-manner.
This action causes a breakdown of the surface tension of the water, forming numerous
minute gases filled water bubbles. The micro thin walls of these water bubbles
surrounded by gas both inside and out, offer maximum water surface for the absorption
of the gas. The size opening through this jet permits large volumes of water to be
carbonated.
As the incoming water is being carbonated, the level within the tank rises to contact the
upper probe, which will de-energize a relay on the liquid level control and stop the motor
from turning the pump. This motor will be inactive until water within the tank recedes
below the long probe, at which time, the relay on the liquid level control will close,
engaging the motor once again.
REMOTE CIRCULATING COOLING SYSTEM
The remote station circulating cooling system is used as its name implies to cool the
water, soda water, and syrup lines between the dispenser and the remote stations.
The cooling is accomplished by circulating the water from the cold water bath of the
dispenser through tubing to the remote station and then returning this partially warmed
water to the water bath.
When installing stations remote from the dispenser cabinet, the following operations are
very important:
Location of the Cabinet: - Locating the dispenser cabinet properly depends upon two
factors: convenience to the user and convenience of installation and service.
15

If cabinet is not used as a serving station it is permissible to place it in a basement, back
room, or any other out of the way place. However, it is important to locate the cabinet as
close as possible to the remote station in order to keep the heat loss through the
insulated extended lines at a minimum. When used as a serving station, it is necessary
to place the cabinet where it will be most accessible to the operator.
Water shut off valves and power switches should be located as near the cabinet as
possible in order to facilitate service. Where an air-cooled condenser is used, there
should be enough space surrounding the cabinet to insure adequate air circulating
through the refrigeration condenser. Space should also be provided if possible, for doing
service work on the cabinet. Note: when units are located in isolated rooms outside
ventilation is necessary and air conditioning is recommended.
CAUTION: In order to have even distribution of cold water, the cold-water circulating
lines must always be run in series even on multiple station installations.
IMPORTANT: Be sure to leave all connections and fittings exposed until after the entire
system has been pressure tested.
In order to insure maximum heat transfer between the braided plastic
lines (through which the water, soda, and syrup are carried) and the
circulating tubing, it is necessary to tape these lines firmly together.
When the remote lines consist of three syrup lines and one soda line, tape the soda line
and one syrup line to the inside of the out-going water circulating tubing and tape the
remaining two syrup lines to the inside of the return water circulating tubing.
When there is a fresh water remote line used, then the fresh water line and the soda line
are taped to the inside of the out-going water circulating tubing and the three syrup lines
taped to the inside of the return water circulating tubing. The lines should be taped at
one-foot intervals.
The two groups of lines should then be drawn together and taped firmly so that the
braided lines are on the inside of the cluster.
It is of utmost importance that the extended lines of the remote
installation be properly and adequately insulated. Failure to do this will
cause overloading of the refrigeration unit and ice bank, condensation
on the outside of the insulation and reduced cold drink dispensing
capacity.
CAUTION: All open ends, joints and connections of the insulation must be sealed air
tight to prevent outside air from entering the insulated duct. Outside air, which contains
moisture, would condense this moisture within the insulation duct resulting in the
insulation becoming wet, which would reduce its insulating qualities. Water dripping from
duct would also result.
Pressure Drop within the Carbonated Water Lines – All Soda systems will maintain the
pressure necessary to prevent any carbonation loss through out the entire system even
while the valve is open.
Attention must be given to avoid restrictions in the lines, which may cause a reduction in
pressure upon the carbonated water and allow some of the gas to escape from the
carbonated water in the lines.
16
