Interroll RollerDrive EC310 User manual

User manual
Version 2.1 (08/2013) en
Translation of the original
instructions
Interroll RollerDrive
EC310
Chapter-ID: User manual
Chapter-ID: Version
Chapter- ID: Translatio n of the original ins tructions

Version 2.1 (08/2013) en
Translation of the original instructions1004472
Manufacturer's address
Interroll Engineering GmbH
Hoeferhof 16
D-42929 Wermelskirchen
Tel. [phone]
Fax. [phone]
www.interroll.com
Copyright
The copyright of this manual remains with Interroll Engineering GmbH. The
operating instructions contain technical regulations and drawings which may not
be reproduced partially or in full, transmitted by any means, utilized without
permission for competitive purposes or disclosed to third parties.

1
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Table of contents
Introduction
Information about the operating instructions. . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings in this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Further symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety
General safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Unintended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Qualified persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Dangers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Product information
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
RollerDrive Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Product identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Performance Data for RollerDrive EC310 . . . . . . . . . . . . . . . . . . . . . . . . . 10
DriveControls for the RollerDrive EC310 . . . . . . . . . . . . . . . . . . . . . . . . . 11
Speed settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Motor plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Dimensions of the Motor Shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Dimensions of idler cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Arrangement of Round Belt Grooves . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Conical RollerDrives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Transport and storage
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Assembly
Warning information for assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Warning notices concerning the electrical installation. . . . . . . . . . . . . . . . 19
Installing the RollerDrive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Mounting tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Initial startup and operation
Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Procedure in case of accident or malfunction . . . . . . . . . . . . . . . . . . . . . . 23
Maintenance and cleaning
Warnings concerning maintenance and cleaning . . . . . . . . . . . . . . . . . . . 24
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Troubleshooting
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Abandonment and disposal
Abandonment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Appendix
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Installation Declaration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

2Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Introduction
Information about the operating instructions
Contents This manual contains important advice, notes and information about the
RollerDrive EC310 in all phases of its lifecycle:
• Transport, assembly and start-up
• Safe operation, maintenance and troubleshooting, disposal
• Accessories
Validity of the manual The manual describes the RollerDrive EC310 as it is delivered by Interroll.
In addition to this manual, special contractual agreements and technical
documents apply to special versions.
The manual is part of the
product
For trouble-free, safe operation and warranty claims, read the manual and
follow the instructions before handling the RollerDrive EC310.
Keep the manual near to the RollerDrive EC310.
Pass the manual on to any subsequent operator or occupant of the
RollerDrive EC310.
Interroll does not accept any liability for malfunctions or defects due to non-
observance of this manual.
If you have any questions after reading the operation manual, feel free to
contact our customer service. See the last page for your local contact.
Warnings in this manual
The warnings in this document refer to risks which may arise while using the
RollerDrive EC310. For relevant warnings, see "Safety", page 4 and the warnings
at the beginning of each chapter.
There are three categories of danger. The following signal words are used in the
document as required:
• Danger
• Warning
• Caution
Structure of warnings
Signal word Meaning
Danger Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Warning Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
Caution Indicates a hazardous situation which, if not
avoided, may result in minor or moderate injury.
Nature and source of the hazard
Possible consequence of non-observance
Information about how to avoid the hazard.
DANGER

3
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Introduction
Further symbols
This symbol marks the steps that have to be carried out.
This symbol identifies possible material damage.
Information about how to avoid damage.
Important
This symbol displays safety instructions.
Hint
This symbol marks useful and important information.

4Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Safety
General safety instructions
The RollerDrive EC310 is designed according to the technical state of the art and
is reliable in operation, once distributed. However, risks may still arise.
• Risks of physical injury to the user or bystanders.
• Adverse effects of the RollerDrive and other material.
Always read the entire operating and safety instructions before starting to
work with the RollerDrive and follow the information contained herein in full.
Only instructed and qualified persons may work with the RollerDrive.
Always keep this user manual at hand when working on the RollerDrive so
that you can consult it quickly if required.
Always comply with relevant national safety regulations.
If you have any questions after reading this user manual, feel free to contact
our customer service. See the last page for contact information.
Intended use
The RollerDrive EC310 may only be used for industrial applications and in an
industrial environment to convey goods such as parts, cartons, totes or boxes. It
must be integrated in a conveyor module or a conveying system. Any other use is
not permitted.
Any changes that affect the safety of the product are not allowed.
The RollerDrive EC310 may only be used within the given operation limits.
Unintended use
The RollerDrive EC310 may not be used to transport persons, bulk cargo or small
parts.
The RollerDrive is not intended for use under impact or shock loads.
Applications not according to the intended use of the RollerDrive EC310 require
approval from Interroll.
Important
Disregarding the warnings in this manual may lead to serious injury.

5
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Safety
Qualified persons
Qualified persons are persons who read and understand the manual and, taking
national regulations into account, can competently execute incidental work.
Only instructed and qualified persons may work with the RollerDrive, taking the
following into account:
• the relevant manuals and diagrams,
• the warning and safety instructions in this manual,
• the system specific regulations and requirements,
• national or local regulations and requirements for safety and accident
prevention.
Dangers
Bodily injury Maintenance or repair work must only be performed by authorized and
qualified persons in accordance with the applicable regulations.
Before turning on the RollerDrive, ensure that no unauthorized persons are
near the conveyor.
Electricity Only perform installation and maintenance work after you have switched off
the power. Ensure that the RollerDrive cannot be turned on accidentally.
Rotating parts Keep your fingers and hair away from moving parts.
If you have long hair, always wear a hair net.
Never wear loose clothing.
Never wear jewelery, such as necklaces or bracelets.
Wear safety shoes.
Heat Do not touch the RollerDrive during operation. With applications with high
switching cycles, the temperature of the tube can reach up to 60 °C (140 °F).
Working environment Do not use the RollerDrive in explosive atmospheres.
Remove equipment or material which is not required from the workspace.
Wear safety shoes.
Regulate and monitor careful placement of the goods on the conveyor.
Faults during operation Regularly check the RollerDrive for visible damage.
In case of fumes, unusual noise or blocked or damaged goods, stop the
RollerDrive at once and ensure that the RollerDrive cannot be started
accidentally.
Contact qualified personnel immediately to find the source of the fault.
Do not step on the RollerDrive during operation.
Maintenance As the product is maintenance free, you only need to check regularly for
visible damages, unusual noise and that the screws and nuts are still
tightened.
Do not open the RollerDrive.
Accidental start-up Make sure that the RollerDrive cannot start up accidentally, particularly during
assembly, maintenance work and in the event of a fault.
Important
The following list provides information about the various types of danger or
damage that may occur while working with the RollerDrive EC310.

6Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Safety
Interfaces
By assembling the RollerDrive in a conveyor module, potential hazards may
occur. These are not described in this manual and have to be analyzed during the
design, installation, and startup of the conveyor module.
After assembling the RollerDrive in a conveyor module, check the whole
system for any new potential dangerous condition prior to turning on the
conveyor.
Operating modes
Normal mode Operation of the installed device at the end customer's as a component in a
conveyor in a complete system.
Special mode All operating modes which are required to guarantee and maintain safe and
normal operation.
Special operating mode Explanation Comment
Transport/Storage Loading and unloading, transport and
storage
-
Assembly/Initial start-up Installation at the end customer's and
performing the test run
When de-energized
Cleaning External cleaning When de-energized
Maintenance/Repairs Maintenance and inspection tasks When de-energized
Troubleshooting Troubleshooting in the event of a fault When de-energized
Fault elimination Eliminating the fault When de-energized
Shut-down Dismantling from the conveyor When de-energized
Disposal Disposal of RollerDrive and packaging -

7
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
Components
RollerDrive EC310
1Motor plug with cable
2Motor shaft
3Fixed bearing housing assembly
4Motor
5Fastening screw for idler shaft
6Idler bearing housing assembly
7Tube
8Pipe coupling
9Gears

8Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
Product Description
The RollerDrive EC310 is an electronically commutated drive roller. The motor
electronics, motors and gears are installed in the RollerDrive . It has nine gear
stages and can be operated at a constant conveying speed.
Overload protection device There are several overload protection systems.
•Stall timing device: If the RollerDrive is stalled while there is a run command,
the motor tries to restart ten times every three seconds for one second. If the
stall persists after these ten attempts, a failure signal is set and the
RollerDrive tries to restart with a 60:1 cycle (restart for one second every 60
seconds) until the stall is eliminated. The RollerDrive will not be damaged if
the system operates in a stall time device mode for a long period of time. If the
RollerDrive is running at the selected speed again or the run command is
withdrawn, the failure signal will be cancelled.
•Slow running: If there is a speed deviation of +/- 20% from the chosen value
for more than 10 seconds, the motor will be switched off and the failure signal
will be set. The RollerDrive will try to start again after 60 seconds. If the
RollerDrive is running at the selected speed again or the run command is
withdrawn, the failure signal will be cancelled.
•Temperature monitoring: The temperature of the motor and electronic
assemblies is monitored.
If used appropriately, the roller can be installed in the conveyor with the required
controls and then operated maintenance-free throughout the service life of the
product.
Holding brake
(Zero Motion Hold)
The RollerDrive EC310 is fitted with an electronic holding brake that allows it to
be used on conveyors on a gradient or incline. The motor's rotor is held in
position if no travel signal is pending. In the event of failure of the supply voltage,
the holding brake becomes ineffective as it is not a mechanical brake.
Energy feedback The RollerDrive EC310 feeds energy back when the goods being conveyed
brake. This results in the motor heating up less in operation and improves the
energy efficiency of the system. Interroll DriveControls are fitted with a switch
that prevents the voltage rising above 28 V in the supply voltage. When installing
the system, ensure that the power units are capable of feedback.

9
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
RollerDrive Label
The information on the RollerDrive label is used to identify the RollerDrive. This is
necessary in order to use the RollerDrive as intended.
Product identification
The following information is needed to identify a RollerDrive. You can enter the
values of your RollerDrive in the last column.
Label
1Manufacturer
2Date of production
3Gear ratio
4Performance
5Rated voltage
6Speed range
7Type of RollerDrive
8Serial number
I
N
T
E
R
R
O
L
L
R
o
l
l
e
r
D
r
i
v
e
03/10
16:1
37 W
24 VDC
0,05 –
0,98 m/s
EC 310
123456789
I
n
t
e
r
r
o
l
l
E
n
g
i
n
e
e
r
i
n
g
G
m
b
H
/
D
6
7
8
a
Information Possible value Own value
RollerDrive type
plate
Motor type
Gear ratio
Serial number
Tube diameter 50 mm or 1.9 in
Tube material Zinc-plated, aluminum or
stainless steel (with or without
sleeves)
Roller installation
lengths
EL/BF
Roller transmission Torque transmission
Idler shaft Spring loaded or female
threaded shaft pin
(see "Dimensions of idler
cartridges", page 14)

10 Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
Technical specifications
1) Value can vary according to installation conditions, profile shapes and the
resonance behavior of the system.
Performance Data for RollerDrive EC310
Rated voltage 24 VDC
Voltage range 18 to 28 VDC
Idle current 0.4 A
Rated current 2 A
Maximum peak current 5 A
Rated power 32 W
Maximum ripple from power supply 3 %
Maximum number of starts/stops per
minute
30
Maximum noise emission (mounted) 55 dB(A) 1)
Protection classification IP54 or IP66
Ambient temperature in operation 0 °C to 40 °C (32 °F to 104 °F)
Ambient temperature during transport
and storage
-30 °C to +75 °C (-22 °F to +167 °F)
Air humidity 5 to 85 %
Installation height above sea level max. 1000 m (max. 3300 ft)
Hint
Data applies to an ambient temperature of 20 °C (68 °F).
Gear ratio Speed range
m/s
Nominal torque
Nm
Starting torque
Nm
Holding torque
Nm
9:1 0.09 to1.75 0.45 1.10 0.36
12:1 0.07 to1.31 0.61 1.46 0.48
16:1 0.05 to0.98 0.81 1.95 0.64
20:1 0.04 to0.78 1.01 2.44 0.80
24:1 0.03 to0.65 1.21 2.92 0.96
36:1 0.02 to0.44 1.82 4.38 1.44
48:1 0.02 to0.33 2.42 5.85 1.92
64:1 0.01 to0.25 3.23 7.80 2.56
96:1 0.01 to0.16 4.84 11.69 3.84

11
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
DriveControls for the RollerDrive EC310
Interroll recommends using the RollerDrive EC310 in combination with the
corresponding Interroll DriveControl 20 or 54.
Speed settings
If you do not use the recommended DriveControl (see "DriveControls for the
RollerDrive EC310", page 11), you may change the speed of the RollerDrive
EC310 by altering the voltage on pin 5 of the motor plug.
Speed setting on the
DriveControl
Hint
For more detailed information on the DriveControl, please refer to the
corresponding operating manual, relevant catalogues or publications at
www.interroll.com.
DIP switch setting on the
DriveControl
Speed at gear ratio
m/s
A B C D 9:1 12:1 16:1 20:1 24:1 36:1 48:1 64:1 96:1
on on on on 1.75 1.31 0.98 0.78 0.65 0.44 0.33 0.25 0.16
on on on off 1.63 1.22 0.92 0.73 0.61 0.41 0.31 0.23 0.15
on on off on 1.51 1.13 0.85 0.68 0.57 0.38 0.28 0.21 0.14
on on off off 1.39 1.04 0.78 0.62 0.52 0.35 0.26 0.20 0.13
on off on on 1.27 0.95 0.72 0.57 0.48 0.32 0.24 0.18 0.12
on off on off 1.15 0.86 0.65 0.52 0.43 0.29 0.22 0.16 0.11
on off off on 1.03 0.78 0.58 0.47 0.39 0.26 0.19 0.15 0.10
on off off off 0.92 0.69 0.52 0.41 0.34 0.23 0.17 0.13 0.09
off on on on 0.80 0.60 0.45 0.36 0.30 0.20 0.15 0.11 0.07
off on on off 0.68 0.51 0.38 0.31 0.25 0.17 0.13 0.10 0.06
off on off on 0.56 0.42 0.32 0.25 0.21 0.14 0.11 0.08 0.05
off on off off 0.44 0.33 0.25 0.19 0.17 0.11 0.08 0.06 0.04
off off on on 0.32 0.24 0.18 0.15 0.12 0.08 0.06 0.05 0.03
off off on off 0.21 0.15 0.12 0.09 0.08 0.05 0.04 0.03 0.02
off off off on 0.09 0.07 0.05 0.04 0.03 0.02 0.02 0.01 0.01
off off off off Stop or in accordance with the signals on the Speed A-C ports

12 Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
External speed setting via
digital inputs
* H = logically active; L = logically inactive
Speed input on the DriveControl * Speed at gear ratio
m/s
ABC9:112:116:120:124:136:148:164:196:1
HHH1.751.310.980.780.650.440.330.250.16
H H L 1.47 1.10 0.83 0.66 0.55 0.37 0.28 0.21 0.14
H L H 1.19 0.89 0.67 0.53 0.45 0.30 0.22 0.17 0.11
H L L 0.92 0.69 0.52 0.41 0.34 0.23 0.17 0.13 0.09
L H H 0.64 0.48 0.36 0.29 0.24 0.16 0.12 0.09 0.06
L H L 0.36 0.27 0.20 0.17 0.14 0.09 0.07 0.05 0.03
L L H 0.09 0.07 0.05 0.04 0.03 0.02 0.02 0.01 0.01
L L L 000000000

13
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
Motor plug
Pin Color Function Value
1 brown Power supply input (+) Rated voltage: 24 VDC
Voltage range: 18 to 28 VDC
2 white Direction of rotation,
seen from the cable end
of the RollerDrive
U < 4 V = counter clockwise
U > 7 V = clockwise
3 blue Earth for power supply
and signal (-)
Ground
4 black Fault output Open Collector
Ucesat = 0.5 V for Ic= 5 mA
Umax = 30 V
Icmax = 5 mA
Error: Signal low
No fault: Signal high
5 gray Analogue speed/start
signal
see table below
Analogue speed/start signal (Pin 5)
Voltage range 0 to 24 VDC
Stop (braked state) 0 to 2.3 VDC
Speed 2,3 VDC to 10 VDC
(Incline rate above 2.3 VDC: 740 rpm (motor
revolutions)
linear between 2.3 and 10 VDC)
Max. speed 10 VDC to 24 VDC
The conveyor speed is calculated from the gear ratio and the nominal value.
(also see "Speed settings", page 11)
Hint
In case the RollerDrive is not directly connected to the corresponding
DriveControl or the Interroll extension cable, connect the motor plug using a
Conec M8 snap-in coupling.
Pins 1 and 3 are not protected against incorrect
polarity connection.
Damage to the motor.
Ensure the correct polarity.

14 Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
Dimensions of the Motor Shaft
Dimensions of idler cartridges
11 mm (0.44 in) hex
M12 x 1 mm
BF/EL
13 mm (0.51 in)
5 mm (0.2 in)
480 mm (18.9 in)
11 mm (0.44 in) hex,
spring-loaded shaft
Female threaded M8 (FTM8) shaft pin
Straight
Straight IP66
Round belt head
PolyVee head
%)(/
5 mm (0.2 in)
15.5 mm (0.61 in)
%)(/
5 mm (0.2 in)
AF 13 mm (0.51 in)
10 mm (0,39 in)
SW 13 mm (0,51 in)
%)(/
31 mm (1.22 in)
ø37.8 mm (1.49 in)
%)(/
4 mm (0.16 in)
11 mm (0.44 in)
←
13.5 mm (0.53 in) 13 mm (0.51 in)
31 mm (1.22 in)
%)(/
4 mm (0.16 in)
13.5mm (0.53 in) 13 mm (0.51 in)
AF 17mm (0.67in)
ø37.8 mm (1.49 in)
4 mm (0.16 in)
31 mm (1.22 in)
%)(/
11 mm (0.44 in)
ø43 mm (1.7 in)
4 mm (0.16 in)
31 mm (1.22 in)
%)(/
ø43 mm (1.7in)
AF 17mm (0.67in)

15
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
BF/EL = Between Frames / Installation Length
PolyVee head IP66
Toothed belt head Poly-Chain GT; 8 mm pitch; 18 teeth
Sprocket head 11 mm (0.44 in) hex shaft; 3/8 in pitch;
20 teeth
11 mm (0.44 in) hex,
spring-loaded shaft
Female threaded M8 (FTM8) shaft pin
4 mm (0,16 in)
31 mm (1,22 in)
%)(/
ø43 mm (1,7in)
SW 13 mm (0,51 in)
35mm (1.38 in)
%)(/
27.5mm (1.08 in)
4 mm (0.16 in)
ø45.8 mm (1.8 in)
AF 11 mm (0.43 in) hex
9.5 mm (0.37 in)
16.8 mm (0.66 in)
35 mm (1.38 in)
%)(/
ø60.9 mm (2.4 in)

16 Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
Arrangement of Round Belt Grooves
IGM8 female thread shaft pin,
single bearing
Spring-loaded hex, double
bearing
Conical RollerDrives
For conical RollerDrives there must be an 1.8° angle compensation on both end
to avoid bending forces on the RollerDrive.
min. 30 mm (1.2in)
min. 22 mm (0.87in)
for tubediameter 50 mm
for tubediameter 1.9 in
min. 31.75 mm (1.25 in) min. 31.75 mm (1.25 in)
ø38.4 mm (1.51 in)
ø38.1 mm (1.5in)
%)(/
min. 22 mm (0.87in)
for tubediameter 50 mm
for tubediameter 1.9 in
min. 31.75 mm (1.25 in)
min. 50 mm (1.9 in)
min. 54.6 mm (2.15in)
←
ø38.4 mm (1.51 in)
ø38.1 mm (1.5in)
%)(/
Hint
Other tube groove arrangements are possible.

17
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Transport and storage
Transport
• Every RollerDrive has end-protectors to cover its ends.
Do not stack pallets.
Do not stack more than four cardboard boxes on top of each other.
Check that the RollerDrives are correctly fixed prior to transport.
Avoid serious impacts during transport.
Check every RollerDrive for visible damage after transport.
In the event of damage, take photos of the damaged parts.
Report any damage caused by transport immediately to the transport
company and Interroll to retain the right to claim for compensation.
Do not expose the RollerDrives to serious fluctuations in temperature as this
could lead to condensation.
Storage
Check each RollerDrive for damage after storage.
There is a risk of injury if transported incorrectly
Only qualified and authorized persons should transport
the product.
Follow the instructions below.
CAUTION
Risk of injury due to improper storage
Do not stack pallets.
Do not stack more than four cardboard boxes on top of
each other.
CAUTION

18 Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Assembly
Warning information for assembly
Do not drop or mishandle the RollerDrive to avoid internal damage.
Check each RollerDrive visually for damage before assembly.
In order to prevent damage to the internal connections, do not hold, carry or
secure the RollerDrive by the motor cable.
Do not force the RollerDrive when inserting it into the conveyor frame. It
should fit easily into the holes in the frame.
Ensure that the proper tightening torque is applied to the RollerDrive hex nut
to prevent the shaft spinning in the frame and the wires twisting (see
"Securing the RollerDrive in the conveyor frame", page 22).
Do not twist the motor cable.
Rotating parts
Risk of pinched fingers
Do not insert fingers between the RollerDrive and the
round belt, PolyVee belt or roller chain.
Install a protection device (such as a guard plate) to
prevent fingers from getting trapped in the round belt,
PolyVee belt or roller chain.
Install an appropriate warning on the conveyor.
Risk of damage leading to failure or shortened life
expectancy of the RollerDrive
Follow the instructions below.
CAUTION
