InterTest Shot Xblock XBC-KZ12G User manual

XBC-KZ12G
Block Camera
Part No.
EM13546

2iShot® Xblock® XBC-KZ12G Block Camera www.intertest.com
2
Revision History
Date Version Contents
2017.09.01 V1.0.0 Release Document
Revision History
2019.05.20 V1.0.1 Release Document

3www.intertest.com Operating Manual
3
TABLE OF CONTENTS
----------------------------------------------------
3
FEATURES
----------------------------------------------------
4
PRECAUTION
----------------------------------------------------
5
SPECIFICATIONSS
----------------------------------------------------
6
DIMENSIONS
----------------------------------------------------
9
INTERFACE
----------------------------------------------------
10
OSD & MENU
----------------------------------------------------
20
FUNCTIONS
----------------------------------------------------
24
COMMAND LIST
----------------------------------------------------
35
TABLE OF CONTENTS
Table of Contents

4iShot® Xblock® XBC-KZ12G Block Camera www.intertest.com
Features
4
This Product is a high performance CCTV camera
with built-in 12x optical zoom and 12x digital
zoom technologies. This product can be applied to
various fields such as security camera for
surveillance (CCTV camera), data viewer, Video
presenter(VP) and speed dome camera and
industrial applications.
• This camera uses a 1/1.8”3.19M Global shutter
CMOS Image Sensor that supports HD (high
definition) to produce high-quality images.
• Using progressive scan, images with a wide
dynamic range can be obtained with the newly
developed image signal processor (Wide
Dynamic Range function, WDR).
• The camera is equipped with a bright zoom lens
with 12× optical zoom and F1.5 aperture (optical
zoom + digital zoom = 144×)
• Low-noise images can be obtained even in low-
light environments using the Noise Reduction
function(3DNR/2DNR/2DNR+3DNR)
• Video signals can be output as digital only.
Depending on register settings, you can select
from a variety of digital output methods:
1080p/60,1080p/50,1080p/30, 1080p/25,
720p/60,720p/50,720p/30, 720p/25, 1080i/50,
1080i/60
• An infrared (IR) Cut-Filter can be disengaged
from the image path for increased sensitivity in
low light environments. The ICR will
automatically engage depending on the ambient
light, allowing the camera to be effective in
day/night environment.
• A Privacy Zone Masking function (max. 8
blocks) is available.
• A Motion Detection function is available.
• A title composed of up to 21 lines can be set
for displaying on the screen. 30 characters can
be used on one line (VISCA).
• Support 256 internal zoom/focus presets.
• Digital Image Stabilizer function reduces image
blurring caused by vibration.
• Output format
LVDS/CVBS/PARALLEL
• Asynchronous Reset Function
FEATURES

5www.intertest.com Operating Manual
Precaution
5
Operation is subject to the following
conditions;
•This device may not cause harmful interference.
•This device must accept any interference
received, including interference that may cause
undesired operation.
•A regulated DC 12V 500mA power supply is
recommended for use with this camera for the
best image and the most stable operation.
An unregulated power supply can cause
damage to the camera. When unregulated
power supply is applied, product warranty will
be out of subject.
•If it is used for CVBS application. It is
recommended that the camera is used with a
monitor that has a CCTV quality 75 Ohm video
impedance level. If your monitor is switched to
high impedance then please adjust accordingly.
•Do not attempt to disassemble the camera to
gain access to the internal components. Refer
servicing to tour dealer.
•Never face the camera towards the sun or any
bright or reflective light, which may cause
smear on the image and possible damage to the
CMOS.
•Do not remove the serial sticker for the warranty
service.
•Do not drop the thing or give a strong impact to
the product.
•Avoid the place where is so dusty, humid or
soot-covered. It may cause electric shock or fire.
•Do not expose to an intense light source such as
direct sunlight or spotlight. It may damage the
CMOS.
•If the camera operates more than 24 hours, It is
recommended that you execute the lens initial
action or reset the camera.
PRECAUTION
Information may be changed without notice
This document provides technical information for the user. KT&C reserves the right to modify the information in this
document as necessary. The customer should make sure that they have the most recent manual version.
5
Operation is subject to the following
conditions;
•This device may not cause harmful interference.
•This device must accept any interference
received, including interference that may cause
undesired operation.
•A regulated DC 12V 500mA power supply is
recommended for use with this camera for the
best image and the most stable operation.
An unregulated power supply can cause
damage to the camera. When unregulated
power supply is applied, product warranty will
be out of subject.
•If it is used for CVBS application. It is
recommended that the camera is used with a
monitor that has a CCTV quality 75 Ohm video
impedance level. If your monitor is switched to
high impedance then please adjust accordingly.
•Do not attempt to disassemble the camera to
gain access to the internal components. Refer
servicing to tour dealer.
•Never face the camera towards the sun or any
bright or reflective light, which may cause
smear on the image and possible damage to the
CMOS.
•Do not remove the serial sticker for the warranty
service.
•Do not drop the thing or give a strong impact to
the product.
•Avoid the place where is so dusty, humid or
soot-covered. It may cause electric shock or fire.
•Do not expose to an intense light source such as
direct sunlight or spotlight. It may damage the
CMOS.
•If the camera operates more than 24 hours, It is
recommended that you execute the lens initial
action or reset the camera.
PRECAUTION
Information may be changed without notice
This document provides technical information for the user. KT&C reserves the right to modify the information in this
document as necessary. The customer should make sure that they have the most recent manual version.

6iShot® Xblock® XBC-KZ12G Block Camera www.intertest.com
Specications
6
Format / Model
ATC -HZ5512W-LP
Video System
Image Sensor
Effective Pixels
1/1.8”3.19M Global shutter CMOS Image Sensor
2064(H)x1544(V), Unit Cell Size(3.45µm X 3.45µm)
Output Format
LVDS/PARALLEL/CVBS : 1080p60/50/30/25, 720p60/50/30/25, 1080i60/50
Sensor Output : FULL/CROP
Video Output : FULL/CROP
Sensor Operating System Sensor Master / Sensor Slave
Sync System
CVBS scale
LVDS mode
Internal
16:9 / 4:3 (CVBS 720H)
Single / Dual
Video Output
CVBS
LVDS/ PARALLEL
Min. illumination
Day
Night (IR-cut filter on)
S/N ratio
(Sens-up Off, AGC 28dB)
0.1 Lux @ F1.5
0.05 Lux @ F1.5
More than 52 dB
Optical Lens
Zoom Magnification
Practical f-value
Practical Horizontal-Angle
Practical Vertical Angle
Practical Diagonal Angle
F-value
X12
7.0 to 84 mm
51.50°(W) ~ 5.0°(T)
30.0°(W) ~ 3.2°(T)
68.0°(W) ~ 6.7°(T)
F1.5(W ) ~ F1.9(T)
Zoom
Maximum Zoom Ratio
Optical Zoom Ratio
Digital Zoom Ratio
Digital Pan/Tilt
Speed (Focus Tracking On)
(Focus Tracking Off)
x1 ~ x144
x1 ~ x12
x1 ~ x12
-
2.5 ~ 30 sec
2.0 sec
Focus
Control Mode
Focal Range
IR correction
Auto / Manual / Interval / One Shot(=Zoom Trigger, One Push)/Preset
Infinity~ 0.5m(T)~0.1m(W)
Standard/IR Light/user -20~+20
Day & Night
D&N mode
Night Color
Auto / Day (Color) / Night (BW) / External-H / External-L
Off/On
White Balance Auto / ATW / Indoor / Outdoor / Push / Manual
Exposure
AE mode
Brightness (Exp.Comp)
AGC Limit
Manual Shutter
Manual AGC
Manual Iris
Sens-Up
ETC
Auto / Shutter Priority / Iris Priority/AGC Priority/Manual
0~14
0(-3dB)~255(45dB)
1/1,1/2,1/4,1/8,1/15(16),1/25(30)/1/50(60) ~ 1/10000
-3dB ~ 45dB
F1.6 ~ F32, Close
Off ~ 32fields
Spot AE, Slow AE response
SPECIFICATIONS
EM13546

7www.intertest.com Operating Manual
7
Format / Model
ATC-HZ5512W-LP
DSP functions
Digital Slow Shutter
Image Freeze
Image Reverse (E-FLIP)
Privacy Masking
Title Display
Motion Detect
D-WDR
Max. 32 fields
Off / On
Off / Horizontal(mirror) / Vertical / H+V(180° flip)
Spherical Privacy
- 8-zone
- Interlock / Non-Interlock Mask
- 14 mask color selectable, semi-transparency
- Pan(0°~360°), Tilt(+90°~-90°)
16 characters (display position selectable)
4-Zone
- Alarm output : OSD / Serial Communication
Off / Low/Middle/High
WDR Off/On, Adjustable(Level:0~29, Contrast:0~5)
BLC
HLC
AGC
Sharpness
3DNR
2DNR
Defog
Gamma
Lens Shading
Defect Detection
Digital Image Stabilizer
Picture Effect
Picture In Picture
Off / On, Area selectable
Off / On, Area selectable
Max. 45dB
Adjustable(0~15)
Off/On(0~4)
Auto/Manual(Weight High/Middle/Low)
Off / Low / Middle / High
0.40/0.45/0.50/0.55/0.60/0.70/0.80/0.90/1.00
Off /ON
Support
On /Off
OFF/NEGATIVE/GRAY MODE/REDDISH-1~4/BLUISH-1~4/GREENISH-1~4
1/4,1/9,1/16,1/25
Position Preset (zoom/focus)
Non-volatile 256 position(zoom/focus) presets.
Memory Preset
16-presets & custom preset
OSD
English
Coaxial Communication
-
-
-
-
Communication (UART)
Camera ID
Remote Control
Control Protocol
Communication Speed
0~255
RS-232 TTL +5.0V (+3.3V Compatible)
VISCA /Pelco-D/Pelco-P/HITACHI : automatically detection
2400/4800/9600(default)/19200/38400/57600/115200bps selectable
Power
Supply Voltage
Supplied Current (motor on)
Consumption (motor on)
DC 12V (+7.0V ~ +15V)
290mA(420mA )
3.5W(5.1W)
Physical
WxHxD[mm], Weight[g]
- Standard 50.30X58.40X92.00mm, 253g
Temperature& Humidity
Operating condition
Storage condition
Temperature (-10°C~50 °C / 14°F~122°F), Humidity (20% ~ 80%)
Temperature (-20°C~60 °C / -4°F~140°F), Humidity (20% ~ 95%)
EM13546

8iShot® Xblock® XBC-KZ12G Block Camera www.intertest.com
8
INTERFACE SUMMARY
Interface & Video
ATC-HZ5512W-LP
Video
Output
PARALLEL ◎
CVBS O
LVDS ◎
Interface
MMCX O
32pin Micro Coaxial
(USL00-30L-A, 0.4mm)
◎
36pinFFC
(FH12-36S-0.55H, 0.55mm) O
12pin Extermal Sync& Trigger&Strobe
(SM08B-SRSS-TB, 1.0mm)O
4pin CVBS&ADKey&12V
(SM04B-SRSS-TB, 1.0mm) O
3pin Exrernal D&N
(SM03B-SRSS-TB,1.0mm)
O
3pin RS-232TTL
(SM03B-SRSS-TB,0.1mm) O
ATC-HZ5512W-LP
EM13546
EM13546

9www.intertest.com Operating Manual
9
DIMENSIONS
ATC-HZ5512W-LP
DIMENSION
Dimensions
EM13546

10 iShot® Xblock® XBC-KZ12G Block Camera www.intertest.com
10
INTERFACE
ATC-HZ5512W-LP
CN303/SM03B-SRSS-TB
NO
Name
Description
1
EXT_DN
External D&N Input
2
GND
3
+3.3V
+3.3V Out (For Sensor)
CN307/SM03B-SRSS-TB
NO
Name
Description
1
GND
2
UART_RX
UART_RX
3
UART_TX
UART_TX
CN301/SM12B-SRSS-TB
NO
Name
Description
1
VS_OUT
EXT_VS Out
2
HS_OUT
EXT_HS Out
3
CLK_OUT
EXT_CLK Out
4
GND
5
VS_IN
EXT_VS In
6
HS_IN
EXT_HS In
7
CLK_IN
EXT_CLK In
8
GND
9
TRIG_COM
10
Trigger_IN
EXT_TRIG In
11
STROMBE_COM
12
STROMBE_IN
STROBE
CN302(CVBS)/SM04B-SRSS-TB
NO
Name
Description
1
+12V_IN
+12V In
2
GND
3
CVBS_OUT
CVBS Out
4
AD_KEY
AD_KEY
CN301
1
2
…
11
12
CN307
3
2
1
J303
1
2
…
31
32
CN302
4
3
2
1
SW101
1
2
J303 (LVSDS)/USL00-30L-C
NO
Name
Description
1
TX_OUT3+
2
TX_OUT3-
3
TX_CLKOUT+
LVDS_CLK
4
TX_CLKOUT-
LVDS_CLK
5
TX_OUT2+
6
TX_OUT2-
7
TX_OUT1+
8
TX_OUT1-
9
TX_OUT0+
10
TX_OUT0-
11
GND
12
TXD
5.0V (compatible 3.3V)
13
RXD
5.0V (compatible 3.3V)
14
+12V DC
15
+12V DC
16
+12V DC
17
+12V DC
18
+12V DC
19
GND
20
GND
21
TX_OUT7+
Single out mode : open
22
TX_OUT7-
Single out mode : open
23
TX_OUT6+
Single out mode : open
24
TX_OUT6-
Single out mode : open
25
NC/CVBS
CVBS Out
26
RESET_IN
Reset:Low(GND),Normal(1.8V)
27
TX_OUT5+
Single out mode : open
28
TX_OUT5-
Single out mode : open
29
TX_OUT4+
Single out mode : open
30
TX_OUT4-
Single out mode : open
31
GND
32
GND
SW101
Sensor Mode
Switch 1
Switch 2
Sensor Master
ON
OFF
Sensor Slave
OFF
ON
CN303
3
2
1
INTERFACE
Interface
