Inteset INT-BTRxTx100 User manual

Bluetooth 2-in-1 Audio Receiver and
Transmitter Adapter
Model: INT-BTRxTx100

2
Product Diagram and Parts
Adapter Components
1. LED Indicator Light
2. Multi-function Button: Power/Play/Pause
3. 3.5 Mini Jack: Audio Output/Input
4. Mini USB Input (for charging only)
5. Receive (RX) / Transmit (TX) Switch
Included Cables
6. 3’ 3.5 mini to 3.5 mini cable (not shown)
7. USB charging cable (not shown)
8. 3.5 mini to RCA left/right Y-cable (not shown)

3
Specifications
Bluetooth Version: 2.1 +EDR
Frequency Range: 2.4 GHz
Output Power Category: Class 2
Bluetooth Mode: A2DP/AVRCP
Bluetooth Range: Up to 30 feet
Electric Voltage: DC 3.7v
Working Current: DC 3.7v/38mA (Max)
Charge Voltage: DC 5.0v
Charge Current: DC 5v/130mA (Max)
Operation
Receiver Mode
Use the Receiver mode (RX) to turn your headphones, car
radio, home stereo system, or amplified speaker into a
Bluetooth enabled device.

4
Receiver Mode Usage Instructions
1. Turn the adapter’s Transmit/Receive switch to the
“RX” position.
2. Press and hold the adapter’s multi-function button.
The device will power on.
3. Continue to hold the button until the LED pulses
red/blue quickly indicating it’s in pairing mode.
4. Open the Bluetooth function on your mobile
device.
5. Search for the Bluetooth device “INT-BTRxTx100”
and connect to it.
6. Enter the code “0000” if needed.
7. Once pairing is successful, the LED will stay blue.
8. Connect the adapter to your wired headphones, or
car radio, home stereo , or amplified speaker using
the 3.5 mini to 3.5 mini audio cable.
9. Play the audio on your mobile device and enjoy.
10. Turn off the adapter by long pressing the multi-
function button until the LED turns off.

5
Notes:
Once you have successfully paired your mobile
device the first time, subsequent times will
reconnect automatically.
Your phone will not pair while another device is
connected to the adapter.
To use the adapter with your car stereo, be sure to
switch to the audio input on your stereo to AUX.
If you want to switch to the Transmit (TX) mode,
you must power the adapter OFF first.
Transmitter Mode
Use the Transmitter mode to listen to your TV,
radio/receiver, or any other A/V device wirelessly using a
Bluetooth headset or Bluetooth speaker.
Transmitter Mode Usage Instructions
1. Turn the adapter’s Transmit/Receive switch to the
“TX” position.

6
2. Connect the 3.5 mini audio cable from the audio
output port of your Bluetooth (BT) media device to
the audio input port of the adapter.
3. Press and hold the adapter’s multi-function button.
The device will power on.
4. Continue to hold the button until the LED pulses
blue quickly indicating it’s in pairing mode.
5. Refer to your BT media device paring instructions to
proceed with the pairing.
6. Once the pairing is successful the LED will stay blue.
7. Turn off the adapter by long pressing the multi-
function button until the LED turns off.
Note:
When the adapter is out of range, it will disconnect
and will reconnect when it is back in range.
When the adapter is in low power state, it will
produce an alarm and power off (below 3 volts.)
You can charge the adapter while it is in use. The
LED will be red while charging.
The adapter will power off after continued non-use
even if the USB cable is connected.
