FreeVision DSD320-N User manual

DSD320-N
User Manual
DIGITAL SATELLITE RECEIVER
Helpline: 0861 40 41 42 • www.spacetv.co.za

HELPLINE 0861 40 41 42 • www.spacetv.co.za
2
No part of this manual may be copied, reproduced, transmitted, transcribed or translated into any language without permission.
Space Television reserves the right to change the specications of the hardware and software described in these manuals at any time.
Space Television cannot be held liable for any damages resulting from the use of this product. Specications are subject to change without notice.
© Space Television - 78 Republic Road, Ferndale, Randburg, 2125
PO Box 9317, Johannesburg 2000
T 0861 40 41 42
email [e-mail]
www.spacetv.co.za
IMPORTANT SAFETY INSTRUCTIONS:
Read and follow all instructions, heed all warnings to avoid damaging your STB device and other device
and prevent the risk of serious injury to yourself and others.
• Place the STB on a durable standstill table to prevent the STB from falling. Avoid stacking the STB on
top or below of any electronic devices.
• Follow the type of power source indicated on the label marking.
• Do not place or operate the STB near water or wet surfaces.
• Always unplug the AC power of the STB before cleaning it. Use dry clean cloth only.
• Install according to instructions. Use only recommended accessories.
• Do not place near any heat sources such as radiators, heat registers, stove, or other apparatus
(including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized plug. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched.
• Check all connections if properly inserted/tted before turning the power on.
• Unplug the STB from the outlet and the antenna connection during lightning storms or when unused
for long periods of time.
• Refer all servicing to authorized service personnel. Users are not allowed to open or remove the STB
cover because this will void the warranty and to prevent from electric shock.
• Hold and grip the power plug to disconnect it from the power outlet not the cord.
• The ventilation holes should not be covered with items such as newspapers, table-cloth, curtains, etc.
to prevent the STB from overheating.
• No naked ame sources, such as lighted candles, lighter and matches should be placed on the STB.
• Attention should be drawn to the environmental aspects of battery disposal.
• Use the STB with a moderate temperature surroundings.
WARNING: To avoid the risk of serious injury, electric shock and damage to the STB, the
device should not be placed near to any water. Avoid any water/liquid drip and sprinkler.
DSD320-N Digital Satellite Receiver
User Manual

HELPLINE 0861 40 41 42 • www.spacetv.co.za 3
WARRANTY:
• The Space DSD320-N, Satellite Receiver is supplied with a 12 month manufacturers guarantee from
date of purchase, to be free from any defects and to perform as specied (Please retain invoice as
proof of purchase).
• Our Space Television (PTY) LTD standard warranty does not cover lightning damage, power surge,
water ingress and tampering.
• The Warranty is a “Carry In“ Warranty to any Space Television (PTY) LTD Branch Oces or Trade
Kiosks in South Africa.
• Helpline: 0861 40 41 42
• Website: www.spacetv.co.za
DSD320-N Digital Satellite Receiver
User Manual
SENTECH:
Call Centre: 0860 736 832
WhatsApp: [phone]
Email: [email protected]
Website: www.sentech.co.za

HELPLINE 0861 40 41 42 • www.spacetv.co.za
4
FRONT VIEW:
REAR VIEW:
1. On/Standby: Switch STB to On or Standby.
2. Menu: Switch to main Menu
3. OK: Select or conrm
4. CH-: Navigate channel down.
5. CH+: Navigate channel up.
6. LED Display: Display Runing Station.
1. USB:：2 USB 2.0 Interface for Upgrade and
PVR.
2. LNB IN: Connect via coaxial cable to a dish to
receive digital broadcasts.
3. HDMI: Connect HDMI cable to HDMI input of
the TV.
4. AV: Connect to the Audio Video input of the
TV.
5. COAXIAL: Audio signal output.
6. USB:：2 USB 2.0 Interface for Upgrade and
PVR.
7. DC Power: Connect the 12V power adapter.
DSD320-N Digital Satellite Receiver
User Manual

HELPLINE 0861 40 41 42 • www.spacetv.co.za 5
REMOTE CONTROL UNIT:
1. Email: Jump to email menu.
2. Power: Switches the product to on or standby.
3. FAV: Turns on Favorite Menu.
4. SAT: Selects the Satellite/ Jumps to special
time during media play.
5. TEXT: Display Teletext information.
6. SUB: Display subtitle information.
7. Rewind: Play fast backward with x2,x4,x6,x8,x16
and x32 times of Speed, taking effect in PVR
playback.
8. Fast forward: Play fast forward with
x2,x4,x6,x8,x16 and X32 times of Speed, taking
effect in PVR playback.
9. PREV: switch to previous video.
10. NEXT: switch to next video.
11. REC: record the program.
12. PLAY/PAUSE: Starts or pauses media play.
13. STOP: Stops media play/ Stop record the
program.
14. USB: Jump to usb menu.
15. EPG: (Electronic Program Guide) Displays
channel program list.
16. MENU: Turns on main Menu.
17. LEFT/RIGHT: Direction buttons or Adjust
volume.
18. UP/DOWN: Direction buttons or Switch
channels.
19. OK: Select to conrm.
20. AUDIO: Sets audio to stereo, mono, left or right.
21. EXIT: Exit the current menu or return to previous
menu.
22. VOL+/VOL-: Adjusts volume.
23. MUTE: Mute or Restores Audio Output.
24. INFO: Displays additional channel information.
25. CH+/CH-: Channel up/down.
26. 0-9(Number Key): Selects a channel or setting.
24. TV/Radio: Switches channels between TV
channels and Radio channels.
25. VIDEO MODE: Switch video resolution.
DSD320-N Digital Satellite Receiver
User Manual

HELPLINE 0861 40 41 42 • www.spacetv.co.za
6
INSTALLATION SETUP GUIDE:
• Please wait for the STB to initialize and follow the on-screen instructions.
After the welcome logo, Channel/Satellite scan will appear.
• Please wait until the Satellite scan is nished. This may take a few minutes.
After the scan has successfully completed, continue by pressing the <OK> button.
• STB will display theTV channels list. Enjoy and experience your favorite TV programs.
BASIC CHANNEL FUNCTION:
ADDING FAVORITE CHANNELS
TV Channels List:
Displays list of channels, users can manage favorite channels, lock and unlock channels.
1. Press <Menu> from the remote control.
2. Use <> keys and choose Channel List.
3. Look for TV Channels List and press the <OK> key.
4. While in the TV Channels List screen, choose the desired channel and press the <FAV> key.
5. After adding all your favorite channels, press the <EXIT> key and a pop-up “SAVE” message
will appear. Use <> buttons and choose <Yes> then press <OK>.
DSD320-N Digital Satellite Receiver
User Manual

HELPLINE 0861 40 41 42 • www.spacetv.co.za 7
LOCKING CHANNELS:
Make sure to set Channel Lock to “ON”.
From the main Menu screen, use <> keys to select “System”. And then select “Parental Lock” then
press <OK>. Under Parental Control screen and then select “Channel Lock”, use <> keys to switch ON
or OFF channel lock function and then press <EXIT> to go back to the main Menu.
1. While in the main Menu screen, use <> keys to choose Channel List.
2. Look for TV Channels List and press <OK>.
3. While in the TV Channels List screen, use <> keys to select channel to be locked. Press
the <RED> key and input your 4-digit PIN code then press the <EXIT> key and a pop-up
“SAVE” message will appear. Use the <> buttons and choose “Yes” then press <OK>.
DSD320-N Digital Satellite Receiver
User Manual

HELPLINE 0861 40 41 42 • www.spacetv.co.za
8
LIST OF CHANNELS:
While watching, press the <OK/List> key and then the “ALL” menu screen will appear displaying all TV
or Radio channels available. Use the <> keys to nd and select a new channel, then press <OK> to
conrm.
EPG (ELECTRONIC PROGRAM GUIDE):
Displays the lists of current and upcoming TV programs on all available channels.
• While watching, open the EPG menu screen by pressing the <EPG> key. Press <> keys to nd and
select a channel, press <OK> thenpress <Exit>.
CHANNEL INFORMATION BAR:
Displays Channel Information currently being watched. It is displayed when pressing the <INFO> key
while watching or when changing channels.
• To adjust the channel bar display timeout and transparency, press <MENU> and then select “OSD
Setting”. Use <> keys and then select “OSD Transparency”. Adjust your desired timeout and
transparency of the channel bar.
DSD320-N Digital Satellite Receiver
User Manual

HELPLINE 0861 40 41 42 • www.spacetv.co.za 9
PVR FUNCTION:
• When a USB drive is connected to this unit ,while watching TV channels press PVR to start recording
video from the channel to USB . Press STOP button to stop recording.
• Personal video recorder (PVR) is a feature enabling you to record live TV.
There are two ways to use it:
• Insert a USB storage device in the USB port and press the REC button on the RCU .
• Schedule a specic program you want to record using the blue button or from within the EPG
TIME SHIFT FUNCTION:
• The Time Shift function allows you to reserve part of the USB-disk space and ensures a continuous
background recording of the selected channel. Time Shift allows you to pause watching or rewind
recording back and resume viewing from the missed point.
• After you activate the channel recording, press PAUSE button on the RCU. Time Shift function is
activated, at the bottom of the screen will be a status bar with countdown. Now you can rewind the
recorded video by press REV /FWD buttons and set to pause by pressing PAUSE button. To disable
Time Shift, press EXIT button on the RCU and then press OK to conrm the operation.
TROUBLESHOOTING:
Problem Potential Reasons What to do
No picture Power isn’t connected Connect the power
The power switch is not on Switch on the power
Screen shows no
signal
DVB-S cable not connected Plug in the DVB-S cable
Incorrect setting Set up correct parameter
No sound from
speaker
No or incorrect connection with audio
cable
Connect the audio cable correctly
Mute is active Switch on the correct volume
control
Incorrect sound track Try another sound track
Only sound, no image
on the screen
No or incorrect connection with AV
cable
Make sure AV cable is connected
properly
The program is in radio program Press <TV/RADIO> key to shift into
TV mode
Remote control unit is
not working
Dead battery Change new battery
Remote control unit is not in the right
opposite of the front panel or too far
from it
Point the remote control unit
towards the front panel and near
from the panel
The image stops
suddenly, poor picture
quality
The signal is too weak Check signal strength. Check LNB
cable connection.
DSD320-N Digital Satellite Receiver
User Manual

HELPLINE 0861 40 41 42 • www.spacetv.co.za
10
TECHNICAL SPECIFICATIONS:
Item Specication
Tuner Frequency range 950MHz to 2150MHz
Input impedance 75Ohm unbalanced
Signal input level -65~-25dBm
Symbol rate 2-45Mbps
LNB power 13/18V,Max 350mA
Demodulation Demodulator QPSK/8PSK
FEC 1/2,2/3,3/4,5/6,7/8,8/9,9/10
Connections LNB IN F connector
USB USB 2.0
Power Input 100-240V~50/60 Hz
Consumption Max 12W
Display Decoder module PAL,NTSC
Resolution 480i,480p,576i,576p,720p,1080i,1080p
Decoding Aspect rate 4:3(Letterbox, Pan Scan),16:9
Video MPEG2 Transport [email protected]
MPEG4 AVC/H.264 HP@L4
Audio MPEG2 Audio Layer I&II
Others Compliance ETS/EN 300421 DVB-S compliant
Sound mode Right, Left, Stereo
DSD320-N Digital Satellite Receiver
User Manual

HELPLINE 0861 40 41 42 • www.spacetv.co.za 11
DSD320-N Digital Satellite Receiver
User Manual

DIGITAL SATELLITE RECEIVER
www.spacetv.co.za
RandbuRg (Head office)
78 Republic Road Ferndale,
Randburg Johannesburg, 2125
Phone: [phone]
E-mail: [e-mail]
JoHannesbuRg
2 Laub Street, Cnr Eloff Street Ext
New Centre, Johannesburg
Phone: [phone]
E-mail: [e-mail]
pRetoRia
Kloofsig Center Cnr Botha & Theodore
Street, Kloofsig, Pretoria
Phone: [phone]
E-mail: [e-mail]
cape town
180 Sir Lowry Street, Woodstock
Cape Town, 8001
Phone: [phone]
E-mail: [e-mail]
bRacKenfeLL
21 Viben Street, Cnr Beatrix Street
Brackenfell, Cape Town, 7560
Phone: [phone]
E-mail: [e-mail]
duRban
681 Umgeni Road, Durban,
Kwa-Zulu Natal, 4001
Phone: [phone]
E-mail: [e-mail]
poRt eLizabetH
32-34 Crawford Street
North End, Port Elizabeth
Phone: [phone]
E-mail: [e-mail]
east London
Shop 2, BMW Building, Cnr Chamberlain
& Derby, Berea, East London, 5247
Phone: [phone]
E-mail: [e-mail]
bLoemfontein
Unit No. 7, DIY Square, 2-8 Hornby
Street, Oranjesig, Bloemfontein, 9301
Phone: [phone]
E-mail: [e-mail]
Scan the QR code to find youR neaReSt SpaceXpReSS tRade KioSK.
