Intouch It7350 User manual

Intouch

IT7350&IT7340

Version –B

User Guide Version 0. 1

Safety Precautions

Make sure to follow the directions below to prevent personal injury, accidents and damage to the product.

Warning: To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the following precautions:

hMake sure to insert the power plug until it is firmly in place.

hDo not use a damaged power plug, power cord, or plug into a damaged outlet.

hDo not use force to pull the power cord.

hDo not touch the power plug with wet hands.

hDo not connect more than one appliance to a single outlet.

hDo not place anything heavy on the power cord.

hMake sure to turn the power off and disconnect the power plug from the outlet before moving the product.

hMake sure to disconnect any connected cables from other devices as well.

Caution: Failure to follow the accompanying directions may lead to minor personal injury or property damage.

hHold and pull out the plug by its body when disconnecting it from the outlet, as pulling the plug out by the cord may cause it to be damaged. Failing to do

so, may cause fire, or the product may not turn on normally.

hEnsure that the power plug is disconnected before cleaning the product. Failing to do so, may cause electric shock or fire.

hDo not let water come into contact with or enter the power adapter, as this may cause electric shock or fire.

hDo not use the product outdoors in snowy or rainy weather, or near any water.

hWhen cleaning the floor with water, avoid any water contact with the power adapter.

hDo not place the power adapter near a heater, as this may cause fire.

Installation

Warning: Failure to follow the accompanying directions may lead to serious injury or death.

Caution: Plug the adapter to the socket outlet that near the equipment and shall be easily accessible. Use only the E-TEK (Output: 5.0V / 3.0A,

Input: AC 100 -240V ~ 50 / 60 Hz 0.8A) power supply that came with this unit. Using other power supplies may damage the unit.

iii

hWhen installing the product on a cabinet or shelf, do not let the front end of the product project beyond its front edge. Failing to do so, may cause the

product to fall, resulting in a product malfunction or personal injury.

hDo not place the power cord near a heater, as the power cord may melt, causing electric shock or fire.

hDo not install the product in a car or a location exposed to oil, smoke, moisture, water, or rainwater. Any contact of these materials with the product may

cause electric shock or fire.

hDisconnect the power plug when there is thunder or lightning. Failing to do so, may cause electric shock or fire.

hFor Pluggable Equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible

IMPORTANT SAFETY INSTRUCTIONS

hWhen using your wireless internet frame and equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and

injury to persons, including the following:

hDo not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

hThe socket-outlet shall be installed near the equipment and shall be easily accessible

hUse only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for

possible special disposal instructions.

SAVE THESE INSTRUCTIONS

Caution: Failure to follow the accompanying directions may lead to minor personal injury or property damage.

hPlace the product down gently when installing it. Failing to do so may cause product damage or personal injury.

hDo not install the product in a location easily reached by children. As the product may fall and cause personal injury.

DECLARATION OF CONFORMITY

Interference Information

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,

and (2) This device must accept any interference received, including interference that may cause undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's

authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

hReorient or relocate the receiving antenna.

hIncrease the separation between the equipment and receiver.

hConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.

hConsult the dealer or an experienced radio/TV technician for help.

FCC RF Radiation Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated

with a minimum distance of 20 centimeters between the radiator and your body.

Shielded cables must be used with this unit to ensure compliance with the Class B FCC limits.

This class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Table of Contents

Getting Started....................................................................1

Package Contents..............................................................................1

Wireless Internet Frame Overview...................................................2

Front panel......................................................................................2

Back panel......................................................................................3

Left Panel........................................................................................4

Right Panel.....................................................................................4

Connecting the AC/DC Power Adapter and USB cable.................5

General Button Description..............................................................6

Turning your Frame on ......................................................7

Standing the Frame up......................................................................7

Calibrate the Touch Screen..............................................................7

Language Selection...........................................................................7

End User License Agreement (EULA) .............................................8

The Home Screen ...............................................................9

Home Screen Overview.....................................................................9

Home Settings Screen.....................................................................10

Additional Home Settings.............................................................11

Power Icon........................................................................................11

Wi-Fi icon..........................................................................................12

News Bar...........................................................................................12

Wallpaper Settings ..........................................................................13

For a still picture as wallpaper......................................................13

For a slide show as the wallpaper................................................14

Slide Show Control Buttons..........................................................15

Clock and Calendar..........................................................16

Setting up the Calendar ..................................................................16

Set the Date..................................................................................16

Set Date Format ...........................................................................16

Calendar Preview.............................................................................17

Using the Calendar preview.........................................................17

Setting up the Clock........................................................................17

Set the Time .................................................................................18

Select Time Format......................................................................18

Select Internet Time Synchronization...........................................18

Select Time Zone .........................................................................18

Setting up and using the Clock Alarm...........................................19

To set an Alarm............................................................................19

To change an alarm......................................................................20

Alarm Control................................................................................20

Frame Tools ......................................................................21

Main Menu ........................................................................................21

Tools Screen ....................................................................................21

Keyboard ..........................................................................................22

On-Screen Display Bar....................................................................23

Open and close the On-Screen Display (OSD) Bar.....................23

OSD Bar Description....................................................................23

Adjust LCD Brightness using OSD Bar........................................24

Adjust Volume Level using OSD Bar............................................24

Lock / Unlock the screen using OSD Bar.....................................24

Settings .............................................................................25

Network.............................................................................................26

Setup Wi-Fi Network - Access Point’s DHCP settings is On and the AP

SSID is not hidden........................................................................26

Setup Wi-Fi Network - Access Point’s DHCP settings is ON but the AP

SSID is hidden and no encryption key is needed.........................28

Manual Edit Wi-Fi Network Screen ..............................................29

Advanced Settings........................................................................30

Date / Time........................................................................................32

Display..............................................................................................32

Screen Calibration........................................................................32

Brightness.....................................................................................32

Auto Playback Demo Video..........................................................33

System Settings...............................................................................34

Language......................................................................................34

Firmware Upgrade........................................................................34

Factory Reset ...............................................................................36

Show Details.................................................................................36

Motion Sensor (Model IT7350 only) .............................................37

Screen Taps Sound......................................................................37

Power Management.........................................................................38

Sleep Mode...................................................................................38

Interval Time (Sleep Interval Time) ..............................................38

Battery Profile...............................................................................39

Photo / Content Service ...................................................40

Photo Player Main Page controls...................................................40

Photo.................................................................................................41

Frame................................................................................................41

Slide Show Control Buttons..........................................................41

Zoom Control Buttons...................................................................42

Disk ...................................................................................................43

Home Network..................................................................................43

Adding Photos to the Library........................................................43

Checking Shared Photos..............................................................46

Sharing Settings for Accepting Connections from Your Frame....47

View for Sharing the Photos on your frame..................................48

Web ...................................................................................................49

Photo Setup......................................................................................49

Slide Show....................................................................................49

Setup Web Photo Account ...........................................................50

Content Service (Windows Live FrameIt)......................................52

Account.........................................................................................52

Setup Windows Live FrameIt Account .........................................52

Content Service (Framechannel ) ..................................................54

Account.........................................................................................55

Setup Framechannel Account......................................................55

Copy/ Delete Photos........................................................................56

Copy One .....................................................................................56

Copy All ........................................................................................57

Delete One ...................................................................................57

Delete All ......................................................................................57

vii

RSS News Reader (RSS2.0) .............................................58

RSS News Feed screen...................................................................58

News Feed List screen....................................................................59

RSS News Reader............................................................................60

RSS News Reader Control Buttons / Icons..................................60

News Text Content.......................................................................60

News Media Player.......................................................................60

RSS News Reader > News Text Content.....................................61

Refresh / Delete News.....................................................................61

Refresh RSS News Feed screen .................................................61

Delete One RSS News Headline..................................................62

Delete All RSS News Headlines...................................................62

Delete All RSS News Read Headlines.........................................62

Delete One in RSS News Reader Screen....................................62

News Setup.......................................................................................63

Set General Settings ....................................................................63

Add / Edit RSS News Feeds (Support RSS2.0 Format only) .......64

Get RSS News Feed Address from Internet ................................64

Add a new RSS News Feed.........................................................65

Edit a RSS News Feed.................................................................66

Delete a RSS News Feed.............................................................67

Media Player......................................................................68

Music / Video....................................................................................69

Internet Radio and Web TV.............................................................70

Stations, Podcast or Web TV .......................................................70

More..............................................................................................70

Add to Favorites ...........................................................................71

Media Setup......................................................................................71

Setup Media Playback..................................................................71

Add a Station................................................................................72

Edit an added Internet Radio Station ...........................................73

Delete an added Internet Radio Station.......................................73

Copy / Delete Media Files................................................................74

Copy One .....................................................................................74

Copy All ........................................................................................74

Delete One ...................................................................................75

Delete All ......................................................................................75

Specifications ...................................................................76

Troubleshooting ...............................................................78

Getting Started

Package Contents

Please check to make sure that the following items are included in the box:

Item Quantity

Wireless Internet Frame 1

AC/DC Power Adaptor 1

Quick Start Guide 1

Customer Support Contact Sheet 1

CD-ROM (includes User Guide and Warranty Information) 1

Wireless Internet Frame Overview

Front panel

Motion Sensor ON/OFF

indicator light

(

Onl

for

IT7350)

Back panel

DC power jack

DC 5V / 3.0A

Battery

Mode button

Press to display

On-Screen buttons.

USB port

Insert a USB flash

drive here that

contains stored

pictures, music and

video to access.

Left Panel Right Panel

4-in-1 card slot

Insert a memory card here that

contains stored pictures, music,

or video that you would like to

access.

CF (Compact Flash) card slot

Insert a compact flash here that

contains stored pictures, music

or video that you would like to

access.

PC (mini-USB) port

Connect to PC with

provided USB cable.

Reset button

Restart your frame

Audio output jack

Connect to external audio output (e.g.

earphones, headphones, speakers)

Soft Power switch

Press and hold this key

to turn power on and

off.

Connecting the AC/DC Power Adapter and USB cable

Notes:

1) When connecting an external device to the USB port, use the USB cable provided with the external device.

2) Some external devices provide a cable that does not meet USB standards, which may cause a malfunction.

3) If an external storage device does not work normally when connected to your digital photo frame, try to connect it to your PC. If it still does not work

normally after re-connecting to your PC, then contact a service center for that external device or your PC.

DC power adapter

Plug the DC power adapter end into the DC

5V/ 3.0A jack on the back of the frame.

AC power cord

Plug the AC power cord

into a nearby outlet.

Connecting USB

To connect an external USB supported device

to your frame, use an USB cable and plug it

into the USB jack on the back of the frame.

General Button Description

Icon Button Name Function

Submenu button Enter into submenu

Select option button Select option

Select file button Select file

Delete button Delete some setups

Keyboard button Input characters

More button View more details

Turning your Frame on

If it’s your first time turning on your frame, or you have reset the frame to factory presets, then you must calibrate the frame, select your language and accept

the End User License Agreement (EULA).

Standing the Frame up

Rotate the frame handle to the desired viewing angle. To release the handle, press on both ends at the same time to release the locking mechanism.

Calibrate the Touch Screen

1. Slide the OFF / ON switch to ON.

2. There are five (5) points (+) needed to tap to calibrate the touch screen. The first point (+) is in the center of the screen and there is one (1) point (+) in each

corner. Follow the on screen instructions to calibrate the frame.

3. After completing the calibration, the Language screen will appear.

Language Selection

1. On the Language screen, tap on the language you want.

2. Next, tap OK to accept the selected language.

Language pop-up menu

End User License Agreement (EULA)

After selecting the language, you must review the EULA

To accept the EULA:

1. To accept the EULA, tap the check box next to “I accept the terms in the

license agreement”.

2. Next, tap OK. The Home Screen will appear.

EULA

To not accept the EULA:

1. If you do not want to accept the terms of the EULA then tap the check box

next to “I do not accept the terms in the license agreement”.

2. Next, tap OK.

3. A pop-up screen will appear telling you to “Please switch off the device”.

If you tap OK on the pop-up screen you will be sent back to the EULA screen.

EULA – no acceptance pop-up

The Home Screen

Home Screen Overview

Clock

Tap to set the clock’s

alarm.

Menu button

Tap to open the Main

Menu.

Calendar

Tap to view calendar.

WiFi indicator

Indicates the network

connection status.

News Bar

Tap to open the news article (works when

connected to the internet).

Wallpaper area

Tap to open the Home Settings screen to

change settings to the home display, e.g.

change background image or slideshow.

Power indicator

Indicates the rechargeable

battery power level.

Home Settings Screen

Home Settings screen

Notes:

1) The wallpaper will default to the factory preset if you factory reset the frame.

2) The selected still picture used for the wallpaper is copied to internal memory. If you delete this picture in the Photo application, it will not be deleted

from the internal memory.

3) To add background music or change other settings for the slide show in the Home Screen, please go to the Photo Setup section.

4) User can play a slide show from internal memory or card only, Web or Home Network selection IS NOT enabled for the Home Screen.

Wallpaper

Choose a still picture or

slide show as wallpaper on

the Home Screen.

Clock

Choose between a digital or

analog clock on the Home

Screen, and turn it on or off.

Calendar

Turn the Home Screen

calendar on or off. News Bar

Turn it on or off on the Home

Screen.

Additional Home Settings

In addition to the wallpaper settings, you can also make additional Home

Screen settings:

Clock – Allows you to turn the Home Screen clock on or off.

Clock Mode – Lets you select the display clock mode (digital or analog) in the

Home Screen.

Clock Mode is disabled when slide show is selected or the clock is turned off.

Calendar – Allows you to turn the Home Screen calendar on or off.

News Bar – Allows you to turn the News Bar display on or off in the Home

Screen.

News Bar is disabled when slide show is selected.

Home Display screen

Power Icon

1. When the battery is empty, a pop-up screen will appear and the alarm will

sound.

2. When the battery is empty, connect the power adapter. The battery icon

will flash from empty to full repeatedly.

3. When the battery is full the battery icon will be displayed. When

the battery is not full it displays the current battery status.

Battery status pop-up

>>> >>> >>> >>> .

Wi-Fi icon

Icons Icon Name Description

Wi-Fi icon Connection to wireless access point is present.

The WiFi icon on the Home Screen displays the status of

your network connection.

If the Wi-Fi icon is tapped, the screen will jump to the Wi-Fi

setting screen.

No Wi-Fi icon Connection to wireless access point is not present.

News Bar

The News Bar lets you read news articles by tapping on the article. The News Bar works only when the frame is connected to the internet. Please refer to the

RSS News Reader section for more detailed instructions on how to set up the news feed.

The news feed on the Home Screen is pulled from the News Feeds listed in the RSS News Feeds screen (see News Feed Reader application). The News

Bar will begin with the first news feed listed and displays the news articles in that feed, and then proceeds to the next news feed and displays all of its articles,

then goes to the next news feed, and so forth. This sequence is continuously repeated. The selection of news feeds and their sequence can not be changed.
