Invacare 1011941 Assembly instructions

Part No 1012053 1Patient Lift Hydraulic Pump Hardware
For more information regarding Invacare products, parts, and services, please visit www.invacare.com
Patient Lift Hydraulic Pump Hardware
Kit. No. 1011941
NOTE:Checkallpartsforshippingdamage.Incaseofshippingdamage,DONOTuse.Contactcarrier/dealerfor
furtherinstruction.
Toensurethesafeinstallation,operationanduseofthePatientLift,theseinstructionsMUSTbefollowed:
 WARNING
DO NOT install this equipment without first reading and understanding these instructions. If you are
unable to understand the Warnings, Cautions, and Instructions, contact Invacare Technical Support
before attempting to install this kit - otherwise, injury or damage may result.
After ANY adjustments, repair or service and before use, make sure that all attaching component
parts are secure.
USE ONLY the appropriate patient lift components for maintenance and replacement.
Kit Description
KitNo.1011941includesthefollowingparts:
Removing/Installing Hardware
NOTE:Forthisprocedure,refertoFIGURE 1onpage2.
Removing
Usingapunch,slightlytapthespringpinsoutofthemountingholes.
Installing
Performthefollowing:
•PumpHeadandLink
1. Putaflatwasheronthepanheadscrew.
2. Insertthepanheadscrew(withthescrewheadfacingtowardstheoutsideofthepumpassembly)
throughthemountingholetosecuresthepumpheadandlinktogether.
3. Placethenutontothepanheadscrewandsecurelytighten.
NOTE:Whenthepanheadscrewispositionedproperly,thenutwillbepositionedtowardthecenterofthepumphead.
Assembly, Installation and Operating Instructions
SAVE THESE INSTRUCTIONS
DESCRIPTION PART NUMBER QTY
Screw, 6-32 Pan Head 1154669 3
Washer, Flat 1087757 3
Nut, 6-32 Hex Mach 1154650 3
Sheet, Instruction 1012053 1

Patient Lift Hydraulic Pump Hardware 2Part No 1012053
•PumpHandle
1. Putaflatwasheronthepanheadscrew.
NOTE:Whenthepanheadscrewsarepositionedproperly,thescrewheadswillbetowardsthecenterofthepumphead
ontheinsideofthepumphandle.
2. Insertthepanheadscrewwithwasherintothepumphandle.
3. Placethenutontothepanheadscrewandsecurelytighten.
4. RepeatSTEPS1‐3toinstalltheotherpanheadscrew,flatwasherandhexmachnut.
FIGURE 1 Removing/Installing Hardware
Adjusting the Control Handle
NOTE:Forthisprocedure,refertoFIGURE 2onpage3.
1. Positionthecontrolhandlebetweentheramandpistononthepumpassemblyasshownin
FIGURE2.
2. Loosenthesetscrewonthecontrolhandle.Removethecontrolhandle.
3. Turnthecontrolrodclockwisetotighten.
CAUTION
DO NOT overtighten the control rod. Excessive force may damage the pump beyond repair.
4. Putthecontrolhandleonthecontrolrod.Tightenthesetscrew.
One 6-32 Pan Head Screw
(head of screw towards outside of
pump assembly)
One Flat Washer
One 6-32 Hex Mach Nut
Two 6-32 Pan Head Screws
Two Flat Washers
Two 6-32 Hex Mach Nuts
(nuts towards outside of pump assembly)
Pump Handle
Pump Head and Link Pump Handle

Part No 1012053 3Patient Lift Hydraulic Pump Hardware
FIGURE 2 Adjusting the Control Handle
Testing the Patient Lift
NOTE:Forthisprocedure,refertoFIGURE 3.
NOTE:PerformthistestBEFOREusingthepatientliftforthefirsttimeafteranyrepairormaintenanceprocedureto
ensureproperpatientliftoperation.
NOTE:ThecontrolvalveMUSTbeintheclosedposition(controlvalvepositionedtowardsthepumphandle)tomove
thepumphandleupanddowntoelevatetheboomandthepatientuntiltheboomlocksinthenotchofthebracket.
Raising
Movethepumphandleinanupanddownmotiontoraisetheboom.
Lowering
NOTE:Asafetygateispartofthehydraulicsystemthatcontrolsthemaximumdescentoftheboomregardlessofhow
farthecontrolvalveisopened.
Openthecontrolvalveandpulldownontheboom.
FIGURE 3 Testing the Patient Lift
Pump Head
Setscrew
Control Rod
Clockwise
Allen Wrench
Piston
Ram
Control Handle
Pump Handle
Closed
Control Valve
Open
Pump
Handle
