INVENTOR GLX09014 User manual
1
FRONT LOAD
MODELS:
GLX09014
GLX12014
WASHING MACHINE
• USER’S MANUAL
• ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ
ENGLISH | ΕΛΛΗΝΙΚΑ
3
CONTENTS
SAFETY INSTRUCTIONS
■Safety Instructions .................................................................. 4
INSTALLATION
■Product Description................................................................ 9
■Installation ............................................................................. 10
OPERATIONS
■Quick Start . ............................................................................ 13
■Before Each Washing ...........................................................14
■Detergent Dispenser ............................................................15
■Control Panel . ....................................................................... 16
■Option..................................................................................... 17
■Other Functions ....................................................................18
■Programmes. ......................................................................... 20
■Washing Programmes Table ...............................................21
MAINTENANCES
■Cleaning And Care ................................................................ 23
■Trouble Shooting...................................................................26
■Technical Specications ....................................................... 27
■Product Fiches ....................................................................... 28
ACTIVATE YOUR WARRANTY .............................................................33
4
Electric shock!
5
Electric shock!
6
Do not wash or dry articles that have been cleaned in, washed
in, soaked in, or dabbed with combustible or explosive
substances (such as wax, oil, paint, gasoline, degreasers, dry-
cleaning solvents, kerosene, etc.) This may result in re or
explosion.
Before hand thoroughly rinse items of washing by hand.
7
Do not wash or dry articles that have been cleaned in, washed
in, soaked in, or dabbed with combustible or explosive
substances (such as wax, oil, paint, gasoline, degreasers, dry-
cleaning solvents, kerosene, etc.) This may result in re or
explosion.
Before hand thoroughly rinse items of washing by hand.
Your product is only for home use and is only designed for the
textiles suitable for machine washing.
Do not climb up and sit on top cover of the machine.
Do not lean against machine door.
Cautions during Handling Machine:
1.Transport bolts shall be reinstalled to the machine by a
specialized person.
2.The accumulated water shall be drained out of the machine.
3.Handle the machine carefully. Never hold each protruded part
on the machine while lifting. Machine door can not be used
as the handle during the conveyance.
4.This appliance is heavy. Transport with care.
Please do not close the door with excessive force. If it is found
difcult to close the door, please check if the clothes are put in
or distributed well.
It is forbidden to wash carpets.
Before washing the clothes at rst time, the product shall be
operated in one full washing cycle without clothes inside.
Flammable and explosive or toxic solvents are forbidden.
Gasoline and alcohol etc. shall not be used as detergents.
Please only select the detergents suitable for machine washing,
especially for drum.
8
Make sure that all pockets are emptied. Sharp and rigid items
such as coins, brooches, nails, screws or stones etc. may cause
serious damages to this machine.
Please check whether the water inside the drum has been
drained before opening its door. Please do not open the door if
there is any water visible.
Be careful of burning when the product drains hot washing
water.
Never rell the water by hand during washing.
After the program is completed, please wait for two minutes to
open the door.
9
Make sure that all pockets are emptied. Sharp and rigid items
such as coins, brooches, nails, screws or stones etc. may cause
serious damages to this machine.
Please check whether the water inside the drum has been
drained before opening its door. Please do not open the door if
there is any water visible.
Be careful of burning when the product drains hot washing
water.
Never rell the water by hand during washing.
After the program is completed, please wait for two minutes to
open the door.
10
Stability is very important to prevent the product
from possible slight displacement.
Be certain the product is not standing on the power
cord
11
12
The door lock and the [Start/Pause] lights ash with the buzzer beeping or two indicators
ash on the digital screen.
Before usage, be certain this unit is installed properly.
Prior to the initial wash , please operate this unit for one full cycle, empty.
Main
wash
Prewash
Softener
13
The door lock and the [Start/Pause] lights ash with the buzzer beeping or two indicators
ash on the digital screen.
Before usage, be certain this unit is installed properly.
Prior to the initial wash , please operate this unit for one full cycle, empty.
Main
wash
Prewash
Softener
The door lock and the [Start/Pause] lights ash with the buzzer beeping or two indicators
ash on the digital screen.
Before usage, be certain this unit is installed properly.
Prior to the initial wash , please operate this unit for one full cycle, empty.
Main
wash
Prewash
Softener
The word “END” will appear on the display.
14
•
Washing a single garment can cause a load imbalance and may result on a
warning beep from the washing machine. It is advised to add one or more extra
clothes to ensure a smooth drainage.
•
Do not wash any clothes that have come in contact with kerosene, gasoline,
alcohol or other ammable substances.
• The working condition of the washer should be 0-40°C. If used under 0°C, the inlet valve
and draining system may be damaged. If the machine is placed under condition of 0°C or
less, then it should be transferred to normal ambient temperature to ensure the water supply
hose and drain hose are not frozen before use.
• Please check the labels and the explanation of using detergent before wash. Use non-
foaming or less-foaming detergent suitable for machine washing properly.
15
•
Washing a single garment can cause a load imbalance and may result on a
warning beep from the washing machine. It is advised to add one or more extra
clothes to ensure a smooth drainage.
•
Do not wash any clothes that have come in contact with kerosene, gasoline,
alcohol or other ammable substances.
• The working condition of the washer should be 0-40°C. If used under 0°C, the inlet valve
and draining system may be damaged. If the machine is placed under condition of 0°C or
less, then it should be transferred to normal ambient temperature to ensure the water supply
hose and drain hose are not frozen before use.
• Please check the labels and the explanation of using detergent before wash. Use non-
foaming or less-foaming detergent suitable for machine washing properly.
OPERATIONS
Model: Galaxy GLX06102 6kg
When using abrasive detergents or softeners, prior to placing them in the
appropriate sections of the drawer, it is recommended to dissolve in water, thus
avoiding the risk of possible blockage of the detergent drawer or a possible
water overow.
Choose the right type of detergent for the various washing temperatures to get
optimal results with less water and energy consumption.
10
16
Detergent Dispenser
Pre wash detergent
Main wash detergent
Softener
II
I
Pull out the dispenser
Caution!
• Detergent only need to be added in "case I “after selecting pre-washing
for machines with this function.
OPERATIONS
Programme
Cotton
Synthetic
Mix
Sportswear
Baby Care
Jeans
Rinse & Spin
ECO 40-60
Programme
Spin Only
Bulky
Wool
Quick 15’
Rapid 45’
20
℃
Intensive
Means must ○ Means optional
• As for the agglomerated or ropy detergent or additive, before they are
poured the detergent box, it is suggested to use some water for
dilution to prevent inlet of detergent box from being blocked and
overflowing while filling water.
•
into
the
Please choose suitable type of detergent for the various washing
temperature to get the best washing performance with less water and
energy consumption.
Note!
ECO 40°C-60°C
16
Models: Galaxy GLX081432S 8kg slim / Galaxy GLX091431 9kg / Galaxy GLX121433 12kg
Models: Galaxy GLX081432S 8kg slim / Galaxy GLX091431 9kg / Galaxy GLX121433 12kg
Models: GLX09014 9kg/ GLX12014 12kg
Models: Galaxy GLX081432S 8kg slim / Galaxy GLX091431 9kg / Galaxy GLX121433 12kg
3’’3’’ 3’’3’’
53
142
Cotton
Synthetic
Mix
20°C
Baby Care
Sportswear
Jeans
Quick 15'
Wool
Bulky
Rinse & Spin
OFF Rapid 45'
Intensive
ECO 40°C-60°C
Spin Only
17
Models: Galaxy GLX081432S 8kg slim / Galaxy GLX091431 9kg / Galaxy GLX121433 12kg
Models: Galaxy GLX081432S 8kg slim / Galaxy GLX091431 9kg / Galaxy GLX121433 12kg
The washing time and intensity will increase for better washing
results.
20 OC
ECO 40°C-60°C
18
OPERATIONS
10
19
Temp.
,Press the button to regulate the temperature(Cold,20°C 30°C, 40°C,60°C,90°C)
Delay
Set the Delay function:
1. Select a programme
2.Press the Delay button to choose the time(the delaying time is 0-24 H.)
3.Press [Start/Pause] to commence the delay operation
Choose the Programme Start
Settingtime
Cancel the Delay function:
Press the [
[
Delay]
]
button until the display be 0H.It should be pressed before
starting the programme. If the programme already started, should switch off
Caution!
• In the event of a power failure and while your device is operating, the selected setting/program
is saved in smart memory. Once the power has been restored, the program will continue from
the point where it stopped.
Speed
Press the button to change the speed.
1400：0-400-600-800-1000-1200-1400
1500: 0-400-600-800-1000-1200-1400-1500
Programme
Default Speed(rpm)
Cotton
Synthetic
Mix
20℃
Sportswear
Baby Care
Jeans
Rinse & Spin
Programme
Default Speed(rpm)
Spin Only
Bulky
Wool
ECO 40-60
Intensive
Quick 15’
Rapid 45’
1400
1400
1200
800
1000
800
800
1000
1000
1000
1000
600
--
800
800
800
1500
1500
1200
800
1000
800
800
1000
1000
1400 1500
1000
1000
600
--
800
800
800
Models: GLX09014 9kg/ GLX12014 12kg
programme to reset a new one.
ECO 40°C-60°C
3’’3’’
3’’ 3’’ 3’’
3’’3’’
3’’ 3’’ 3’’
19
Other functions
10
20
OPERATIONS
• Don't use the Reload function when the water level over the edge of the
inner tub or the temperature is higher.
Reload
This function can be used once the washing process in is progress.
When the drum is still rolling, the high amount of heated water is dangerous
for the user and the door cannot be opened forcefully. To pause the washing
and to add clothes safely, press the Start/Pause button for 3 sec. and follow
the steps below:
1.Wait until the drum stops rotation.
2.The door lock is unlocked.
3.Close the door when the clothes are reloaded and press the [ ]
button.
Start
P 3sress[ ] ec.
Clothes
Reload the clothes
Caution!
ChildLock
To avoidmis operationby children.
Start Press [ Delay] and [Funct.]
3 sec. till buzzer beep.
Delay Funct.
• Press the two button 3sec. also to be released the function.
• The “ChildLock”will lockall buttons except [
Off].
• The child lockwill remain effective when the power is resumed.
Caution!
Choose the Programme
10
21
OPERATIONS
Press the [Temp.]button for 3sec.,the buzzer is
mute.
Mute the buzzer
Temp.
To act the buzzer function, press the two buttons again for 3 seconds.The setting
until the next reset.
will be kept
Start
• muAfter ting the buzzer function, the sounds will not be activated any more.
Caution!
Other functions
10
20
OPERATIONS
• Don't use the Reload function when the water level over the edge of the
inner tub or the temperature is higher.
Reload
This function can be used once the washing process in is progress.
When the drum is still rolling, the high amount of heated water is dangerous
for the user and the door cannot be opened forcefully. To pause the washing
and to add clothes safely, press the Start/Pause button for 3 sec. and follow
the steps below:
1.Wait until the drum stops rotation.
2.The door lock is unlocked.
3.Close the door when the clothes are reloaded and press the [ ]
button.
Start
P 3sress[ ] ec.
Clothes
Reload the clothes
Caution!
ChildLock
To avoidmis operationby children.
Start Press [ Delay] and [Funct.]
3 sec. till buzzer beep.
Delay Funct.
• Press the two button 3sec. also to be released the function.
• The “ChildLock”will lockall buttons except [
Off].
• The child lockwill remain effective when the power is resumed.
Caution!
Choose the Programme
3’’3’’
3’’ 3’’ 3’’
3’’3’’
3’’ 3’’ 3’’
3’’3’’
3’’ 3’’ 3’’
20
Programmes
Wool
Mix
Cotton
Hard-wearing textiles, heat-resistant textiles made of cotton or
linen.
Wash synthetic articles, for example: shirts, coats, blending.
While washing the knitting textiles, detergent quantity shall be
reduced due to its loose string construction and easily forming
bubbles.
Spin Only
Rinse&Spin
Sportswear
Synthetic
20℃
10
22
OPERATIONS
Programmes are available according to the laundry type.
Programmes
ECO 40-60
Intensive
Bulky This program is specially designed for washing duvet coats.
Rapid 45' Washing few and not very dirty clothes quickly.
Mixed load consisting of textiles made of cotton and synthetics.
20℃ default, can choose cold water.
Washing the activewear.
Baby Care Washing the baby’s clothes, it can make the baby's wear cleaner.
and make the rinse performance better to protect the baby skin.
Jeans Specially for jeans.
Extra rinse with spin.
Extra spin with selectable spin speed.
Hand or machine-washable wool or richwool textiles.Especially
gentle wash programme to prevent shrinkage, longer programme
pauses (textiles rest in wash liquor).
To increase the washing effects, washing time is increased.
Default 40℃,not selectable,suitabale for laundry washing at
about 40℃-60℃.
Quick 15'
Extra short programme approx, suitable for lightly soiled
washing as a small amounts of laundry.
ECO 40°C-60°C
This manual suits for next models
1
Table of contents
Languages:
Other INVENTOR Washer manuals
