Invicta tipi User manual

TIPI:
MODEL SPECIFICATIONS
1. TECHNICAL DATA 2
2. PRE-INSTALLATION 3
3. INSTALLATION 5
4. OPERATION 9
5. TESTING 10
Keep for future use

page 2
oblica | tipi installation and User ManUal
1. TECHNICAL DATA
DETERMINED UNDER TEST CONDITIONS:
Nominal thermal output 10kW
Efficiency (Australian Test) 57%
Emissions (Australian Test) 1.6 g/Kg
FLUE
Standard 8”
754
1585
WEIGHT AND DIMENSIONS:
Dimensions Firebox W754 x H1585 x D600mm
Firebox weight 143kg
Flue kit Standard 8”/10”/12”

page 3
oblica | tipi installation and User ManUal
2. PRE-INSTALLATION
Congratulations on your purchase of the Tipi. This appliance should be installed and checked by a qualified
professional. Ensure you have read the operation guidelines thoroughly prior to first use. For any questions or concerns
please contact Oblica on 03 9416 0400.
The installation process is outlined below:
– Determine position of firebox and flue carefully observing the clearances described within this section
– Install the external flue
– Install the internal flue and engage the firebox
– Ensure the floor has adequate protection
CAUTION:
Using components or parts other than those provided by the manufacturer or modifying the specification of components
may result in inferior or unsafe operation. If such action is necessary, consult the manufacturer in the first instance.
Warning:
• Theapplianceandflue-systemmustbeinstalledinaccordancewithAS/NZS2918andthe
relevantbuildingcodeorcodes.
• Anymodificationoftheappliancethathasnotbeenapprovedinwritingbythetestingauthority
willbeinbreachoftheapprovalgrantedforcompliancewithAS/NZS4013.
• Oncethefluehasbeeninstalledandapprovedbyaprofessionalinstaller,thefluemustnotbe
modifiedinanyway.

page 4
oblica | tipi installation and User ManUal
MINIMUMCLEARANCE–INTERNAL
2.1 Clearance from non-combustible surfaces
(eg masonry)
100mm minimum clearance is required from fully
non-combustible surfaces.
100
100
Non Combustible
Non Combustible
Glass (frameless or aluminium frame)
Glass (frameless or aluminium frame)
600mm
600mm
Combustible
Combustible
750mm
700mm
Combustible
Combustible
700mm
700mm
2.2 Clearance from glass
600mm minimum clearance is required from normal
non-combustible glass.
2.3 Clearance from combustible surfaces
(eg timber joist & concrete)
Clearances may be reduced with the application of
heat shielding to walls in accordance to the
Australian Building Code.
For information on heat shielding please contact our
office on 03 9416 0400 or email [email protected].
IMPORTANT:
Frames must also be considered. Timber window
frames must be treated as combustible surfaces
(see 2.3). Aluminium frames can be treated as
non-combustible surfaces (see 2.2).
2. PRE-INSTALLATION (CONTINUED)
100
100
Non Combustible
Non Combustible
Glass (frameless or aluminium frame)
Glass (frameless or aluminium frame)
600mm
600mm
Combustible
Combustible
750mm
700mm
Combustible
Combustible
700mm
700mm
100
100
Non Combustible
Non Combustible
Glass (frameless or aluminium frame)
Glass (frameless or aluminium frame)
600mm
600mm
Combustible
Combustible
750mm
700mm
Combustible
Combustible
700mm
700mm
100
100
Non Combustible
Non Combustible
Glass (frameless or aluminium frame)
Glass (frameless or aluminium frame)
600mm
600mm
Combustible
Combustible
750mm
700mm
Combustible
Combustible
700mm
700mm
Configuration 1 – Parallel installation
Configuration 2 – Corner installation

page 5
oblica | tipi installation and User ManUal
3. INSTALLATION
3.1 Typical flue kit installation
Cowl (Chinaman Hat)
10” Outer Case
12” Outer Case
10” Outer Case
12” Outer Case
8” Active Flue
8” Active Flue
CEILING RING
RUBBER
DEKTITE FLASHING

page 6
oblica | tipi installation and User ManUal
3. INSTALLATION (CONTINUED)
3.2 Installing the external flue
1. Place the connection piece inside the suspension bracket. This will join the single skin flue below the
bracket and the triple skin flue above the bracket which have different diameters.
2. Ensure the triple skin flue is installed as per Australian standards (see diagrams below).
The top of the flue must be 400mm higher than the highest point of the roof. Alternatively, there must be a
minimum distance of 8 meters from any higher section of roof.
> 40 cm
–> 40 cm
–> 40 cm
–
> 8 m
–
> 120 cm
–
> 8 m
–
> 120 cm
–
> 120 cm
–
> 40 cm
–> 40 cm
–> 40 cm
–
> 8 m
–
> 120 cm
–
> 8 m
–
> 120 cm
–
> 120 cm
–
The top of the flue must be 1200mm above the roofline. Alternatively, there must be a minimum distance of
8 meters from any higher section of roof.
PITCHED ROOF INSTALLATION
FLAT ROOF INSTALLATION (LESS THAN 5˚ PITCH)

page 7
oblica | tipi installation and User ManUal
3.3 Protecting the floor
• Any combustible floor beneath a fireplace must have a floor protector that extends 100mm beyond the sides
and back of the firebox and 300mm at the front.
• If installed directly on combustible material, the floor protector must be made of a minimum 24mm thick cement
sheet. Non-combustible finishes can be applied to the floor protector (tiles, steel sheet, light concrete, etc).
• If the combustible floor is installed on concrete, you can replace the combustible material with non-
combustible material laid directly onto the concrete.
100mm
Joist
Insulative board (6mm)
+ non combustible finish
Non combustible finish
(eg.tiles)
Concrete
Combustible
floor (eg. timber)
Joist
Insulative board (6mm)
+ non combustible finish
Combustible
floor (eg. timber)
Combustible
floor (eg. timber)
100mm
300mm
DOORS
Combustible floor
(eg: Timber)
Floor protector
100mm
FLOOR PROTECTOR LAID ON TIMBER FLOOR
3. INSTALLATION (CONTINUED)
100mm
Joist
Insulative board (6mm)
+ non combustible finish Non combustible finish
(eg.tiles)
Concrete
Combustible
floor (eg. timber)
Joist
Insulative board (6mm)
+ non combustible finish
Combustible
floor (eg. timber)
Combustible
floor (eg. timber)
100mm
300mm
DOORS
Combustible floor
(eg: Timber)
Floor protector
100mm
FLOOR PROTECTOR LAID ON JOIST

page 8
oblica | tipi installation and User ManUal
100mm
Joist
Insulative board (6mm)
+ non combustible finish
Non combustible finish
(eg.tiles)
Concrete
Combustible
floor (eg. timber)
Joist
Insulative board (6mm)
+ non combustible finish
Combustible
floor (eg. timber)
Combustible
floor (eg. timber)
100mm
300mm
DOORS
Combustible floor
(eg: Timber)
Floor protector
100mm
100mm
Joist
Insulative board (6mm)
+ non combustible finish Non combustible finish
(eg.tiles)
Concrete
Combustible
floor (eg. timber)
Joist
Insulative board (6mm)
+ non combustible finish
Combustible
floor (eg. timber)
Combustible
floor (eg. timber)
100mm
300mm
DOORS
Combustible floor
(eg: Timber)
Floor protector
100mm
FLOOR PROTECTOR LAID ON CONCRETE
3. INSTALLATION (CONTINUED)
TOP VIEW

page 9
oblica | tipi installation and User ManUal
4. OPERATION
4.1 What you should burn
• Untreated, air dried hardwood
• Split logs with a humidity content of less than 20%
4.2 Do not burn
• Trash
• Painted plastic
• Coated or preservative treated wood
• Waste or black coal
• Inflammable liquids
• Fire gels
• Moist wood with a residual humidity content of more than 20% (this may cause soothing of the chimney).
Warning:
•Donotuseflammableliquidsoraerosolstostartorrekindlethefire.
• Donotuseflammableliquidsoraerosolsinthevicinityofthefireplacewhenoperating.
• Donotstorefuelwithinprescribedinstallationclearancedistances.
• Theuseofsometypesofpreservative-treatedwoodsasafuelcanbehazardous.
IMPORTANT:
• Misuse may lead to unhealthy and environmentally harmful emissions and will void any warranty or guarantee.
• The maximum load capacity for the Tipi is 10kg of wood.
• Burning only seasoned hardwood helps to protect the environment and lower emissions.
For details of a wood supplier in your area please call our office on 03 9416 0400 or email [email protected].

page 10
oblica | tipi installation and User ManUal
5. TESTING
TESTREPORTNOHCMG/14/045
TESTING LABORATORY: HRL Technology
MANUFACTURER: Invicta
MODEL: Tipi fireplace
WORK REQUESTED: Assessment of appliance to AS/NZS 4012:1999
for determination of Power Output and Efficiency
and AS/NZS 4013:1999 for Flue Gas Emission
using hardwood fuel.
ISSUE DATE: 8/7/2014
INVESTIGATING OFFICER: Steve Marland
RESULTS: The appliance particulate emission factor established
in testing is 1.6g/kg of dry wood, within the maximum
specification of 4.0g/kg of dry wood.
CONCLUSION: This appliance does comply with the requirements
of AS/NZS 4013:1999 for the configuration tested.
