INVT WIFI200 User manual

1/5

INVTWIFI200InstallationInstruction
Monitoringyourinverterremotely(WIFI200+Wirelessrouter+Internet+Mobile/Computer)



Just3stepstocompletethewholesetting
1.SettingWIFI200;
2.RegisteringtheUser;
3.MonitoringyourPVsystem.

Preface:PluginandfastentheWIFI200intotheRS485portofinverterand
KeeptheDCisolator“ON”andACcircuitbreakers“OFF”.
ThemostimportantstepishowtoconnecttheWIFI200toyour/customer`shomerouter.

1. SettingyourWIFI200(bySmartphoneAPP)
‐DownloadandinstallAPP“iMarsPhoneExpert”onSmartphone.
(APPisavailableinAppleAppStoreandGooglePlayStore)
‐GotoSettingfunctiononyourphone,andentertoWLAN,findtheWIFIsignal:“iMars‐WiFi“andconnecttoit.
‐Runthe“iMarsPhoneExpert”appandClickyellowicon“WIFI200Setting”toenterthesettinginterface,and
ClickSearchbutton,andenterthesettingpage.Followbelowsteps.













2/5

‐Whichareshownbelow,changingthelistedParametersinREDwordsandleave  restasdefault
value.
ParameterSettingValue
NetModeWiFi‐STA
SSIDNameofyourhomeWiFi(Youneedtochooseorkeyin)
PasswordYourhomeWIFI`spassword(Youneedtokeyin)
Networkmodeclient

‐Afterthesettingisdone,ClicktheSavebutton,nowitmeansthatWIFI200isconnectedto
yourroutersuccessfully,andthenexittheAPP

Now,youhavecompletedthesettingoftheWIFI200bySmartphoneAPP


2. Registeringauser(throughtheWebsiteofINVT)
‐Turnonyourlaptop,andhasthelaptopaccesstotheinternet.
‐InyourbrowserIE/Chrome/Firefox,keyinthehttp://www.invt‐solar.com/Youwillseebelowpage.
‐



ClickMonitoringonthetoprightcornerandbelowpicturewillbeshowed.



ClickRegister,enterintotheregistrationinterface.

3/5




Fillintheinformationaccordinglyandsubmitit.
ThenthewebsitewillbacktotheLoginpage.
PleasekeyintheusernameandpasswordthenLogin.
Thebelowpagewillbeshowedinyourbrowser.


Giveyoursolarsystemanamebyfillinthe”Plantname”
CompletethispagethenclickConfimandbelowpicturewillpop‐up.Followtheinstruction.



Nowyoucreatedaplantbutnodevicesunderit.

4/5




Gotothispage,click,click
thenbelowpagewillbeshowed.

FillintheinformationofWIFI200(dongle)



SeriesnumberandSecretKeycanbefoundontheboxofWIFI200asbelowpicture.


ThenclickConfimbutton.
Thenwaitamomentaround5minutes,thedatafrominverterwillbetransferredtomyserverin
ChinathroughWIFI200,thenalltheinformationwillbeshowedinyourcreatedaccount.

Congratulations,thewholesettingforremotemonitoringiscompleted;you 
cancheckyourPVsystembyusingbylaptopandAPPonSmartphoneboth.

5/5

BelowpicturesshowthathowtocheckyoursolarsystemremotelybyAPP.


 









ResettheWIFI200
ThereisaresetbuttononthetopofWIFI200,youcanresetitbypressingitmorethan15 
seconds(underthesituationthatitisconnectedtotheInverterandDCon),thenthelight 
ofitwillflashveryfast,itmeansthatresetissuccessful.Ifnotsuccessful,pleasetryagain
untildone.
