InWin Jupiter AJ120 Series User manual

User Manual V2

Product Video Information
Jupiter Series Product Video
Jupiter Series Installation Video

Product Story
Specially designed for RGB enthusiasts who
desire superior performance from their case fans.
The Jupiter AJ120 fans feature seven blades,
sleeve bearings with a long lifespan, ARGB LEDs
with 16.8 million color options and a one-click RGB
Controller.

Package Contents
Triple Pack
1. Jupiter AJ120 Fans x 3
2. ARGB One-Click Controller v1.1 x 1
3. Screws x 12
Single Pack
1. Jupiter AJ120 Fan x 1
2. Screws x 4

Cable Information
ARGB One-Click Controller
ver. 1.1
Addressable RGB Fan Cable, Addressable
RGB Y-Cable
Note: Only in Triple Pack
Addressable RGB Fan Cable
Addressable RGB Y-Cable
GND KEY D 5V+
GND
KEY
D
5V+

Installation
1. Please make sure the power is off.
2. Install the fans in your PC case and mount
them in the designated areas.
3. The fan cable, Addressable RGB Y-Cable and
their counterparts are attached to each fan.
Please connect as followed:
Connect the fan’s Addressable RGB Y-Cable
to a motherboard’s 3-pin addressable RGB
header. Connect the attached fan cable to the
motherboard’s fan header.
Installing the 2nd fan: Connect the Addressable
RGB Y-Cable and connect it to the available
3-pin Addressable RGB header on the previous
fan. Connect the fan to the available fan header
from the previous fan.
4. Installing the 3rd fan: Repeat
a
b
c
d
cd
Motherboard’s 3-pin
addressable RGB header
a
Motherboard’s
Fan Header
b
c
d
2nd fan’s
addressable RGB
Y-Cable
2nd fan’s fan
cable

Installation
*If your motherboard does not support an
addressable header, please use the included
Addressable RGB Controller to connect to your
PSU’s SATA cable and the fan’s Addressable
RGB Y-Cable in order to use the 14 different
lighting effects. (Only in Triple Pack)
1st fan’s addressable
RGB Y Cable
2nd fan’s addressable
RGB Y Cable
PSU’s
SATA
cable
ARGB One-Click
Controller ver. 1.1
Hold the button to turn on or off the lights.
Tap the button to change the lighting
modes.
1Rainbow 8Two-Tone Ring
2LED-Red Breathing 9Diagonal Transition
3LED-Green 10 Rotating LED Trio
4LED-Blue 11 Full Circle
5LED-Purple 12 Flow-Red
6LED-White 13 Flow-Green
7
Light at the endof the
Tunnel 14 Flow-Blue
* InWin reserves the right to change the lighting
modes.

Troubleshooting
If your fan does not operate properly,
please follow the instructions below:
1. Please check your system’s power.
2. Please make sure all the connectors are
connected properly.
Important Notes
1. Please install the fans by following our
instructions.
2. When storing the fans, please keep this product
away from high temperatures. Keep it away from
machines such as heaters that might cause high
temperatures.
3. Please do not put anything in the impeller.
4. Please do not modify the wires or the connectors
provided by InWin.
5. Please do not touch the fan blades when the fan
is in operation.
6. Please only use your fan in a computer case.
7. Please keep this product away from any liquids.

Product Name Jupiter AJ120
Quantity Included Single Pack Triple Pack
Model Number IW-FN-AJ120-1PK IW-FN-AJ120-3PK
Colors Black
Fan Size 120 x 120 x 25mm
Materials PC, PBT
Rated Voltage 12V
Rated Power 2.4W
Rated Current 0.20A
ADD RGB Rated Voltage 5V
ADD RGB Rated Power 1.1W
ADD RGB Rated Current 0.22A
Speed Mode PWM 500~1800 RPM
Air Flow 70.32 CFM
Air Pressure 2.62mm/ H2O
LED Addressable RGB
Connector (Fan to Fan) Original Cable
Connector to M/B 4 Pin (PWM, 12V), 3 Pin (ARGB, 5V)
Noise Level 35 dB(A)
Bearing Type Long Lifespan Sleeve Bearing
Gross Weight 200g 600g
Package Dimensions
(L x W x H)
Single Pack 185 x
125 x 30mm
Triple Pack 185 x
125 x 80 mm
Warranty 2 years
Specifications
120mm
120mm
25mm
* Specications may vary based on different regions.
* Our products comply with RoHS regulations.
