IP ONE AirGate Series User manual

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
1
AirGate 2000K
2003. 09
IPone Inc

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
2
Contents
1. AP Overview⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯4
1.1 General⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯4
1.2 Configuration Diagram⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 4
1.3 AP Structure⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯5
1.4 AP Components⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯6
2. H/W, S/W Structure⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯7
2.1 Internal Block Diagram⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯7
2.2 S/W Hierarchical Structure⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯8
3.Console, Telnet Setup⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯9
3.1 : Setting Terminal Emulator for Console⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯9
3.2 : Connecting Telnet ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 12
3.3 : AirGate2000K Setup⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 12
3.4 : Status ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 13
3.5 : Config⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯13
3.6 : Util⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯24
3.7 : Reboot⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 25
3.8 : Quit………………………………………⋯⋯⋯……………………………………………25
4. Web-based Management ……………………………… 26
4.1 : Web-based Management……………………………………………………… 26
4.2 : Status…………………………………………………………………………………………………… 26
4.3 : Network Settings…………………………………………………………………………27
4.4 : WLAN Settings…………………………………………………………………………… 29
4.5 : Authentications and Billing Configuration …………………………… 30
4.6 : Other Setting for Authentications and Billing……………………… 31
4.7 : SNMP Setting………………………………………………………………………………32
4.8 : DHCP Setting………………………………………………………………………………33
4.9 : Log………………………………………………………………………………………………34
4.10 : System Reboot………………………………………………………………………… 35
4.11 : AP Management Tool Login Password Change …………………36
4.12 : Firmware Upgrade……………………………………………………………………36
4.13 : Other Setting…………………………………………………………………………… 37
4.14 : Quick Installation……………………………………………………………………… 39

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
3
5. Service Opening Method ……………………………… 41
5.1 Checkpoints before Installation…………………………………………………41
5.2 Installation……………………………………………………………………………………… 41
5.3 Work Procedures……………………………………………………………………………41
5.4 Configuration Method……………………………………………………………………42
5.5 Considerations………………………………………………………………………………42
6. Maintenance and Fault Handling …………………… 43

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
4
1. AP Overview
1.1.1 Overview of Wireless LAN (WLAN)
Wireless LAN(WLAN) refers to a LAN that uses high frequency radiowave instead of
cables for inter-node communication. WLAN operation is defined in IEEE 802.11b. WLAN
transmits high-speed data up to 11 Mbps. WLAN can keep high speed in rural
environment (country area) as well as in buildings and campuses, and supports data
communication with high reliability. In addition, it is easy and fast installs it. It is possible to
install WLAN even in places where it is impossible to install wired LANs, and also possible
to install it temperately. Currently connected to ADSL network used for companies or
houses, it aims to provide the wireless LAN service through Access Point
(Integrated Access Point: hereinafter referred to as “The integrated AP”) which
combines ADSL with wireless LAN. The integrated AP, composed of ADSL Access
device and 11M Wireless Access Point, is designed to provide the wireless LAN
service over the high-speed Internet served via ADSL line.
The integrated AP, equipped with 10/T base wired port as 1 port, is designed to
configure 10/T base wired LAN without the help of other equipments. In medical
and education fields, WLAN has shown a rapid growth.
1.2.2 Network Configuration Diagram
The configuration diagram illustrates how WIMS server (authentication server),
DHCP server, NAS system and DSLAM system used by ISP can interwork with the
integrated AP in order to provide the wireless LAN service.
1.1 General
1.2 Configuration Diagram
DSLAMNAS
DHCP server
AP
INTERNET

The instructions furnished the user shall include the following or
similar statement, placed in a prominent location in the text of the
manual.
INFORMATION TO THE USER (Part 15.105(b))
For Class B digital device
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one more of the following
measures:
－Reorient or relocate the receiving antenna.
－Increase the separation between the equipment and receiver.
－Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
－Consult the dealer or an experienced radio/TV technician for help.
WARNING (Part 15.21)
Changes or modifications not expressly approved by the manufacturer could void the user’s
authority to operate the equipment.
“Note: The manufacturer is not responsible for any Radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.”
“CAUTION: RF Exposure to Radio Frequency Radiation.
This equipment must be installed and provided minimum seperatiom distance of 20cm from the body of user and
near by person. In addition to seperation distance, this device cannot be transmitted and operating in conjuction with
any other transmitter or antenna.

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
5
1.3.1 AP Structure
1.3.1.1 AP Front View
① ② ③ ④ ⑤
AP LED LAYOUT
No. LED Name Color LED Operation State
On Wireless LAN is connected
① Wireless Green Off Wireless LAN connection is
stopped
On/Off Repeat WLAN Data Communication
② WLAN Green Off No WLAN Data Communication
On Power is already supplied
③ Power Green Off Power is not supplied
On/Off 반복 Ethernet data communication
④ Ethernet Green Off Ethernet data communication is
stopped
⑤ WLAN Green On Ethernet is connected
1.3 AP Structure

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
6
Off Ethernet connection is stopped
1.3.1.2 AP Rear View
①Dipole Antenna Connector
②DC Power Connector
③RJ-45 Ethernet Connector
④RJ-45 Ethernet Connector
⑤RJ-45 Serial Port
1.4.1 AP Components
Check AP products components before installing the AP
①Access Point Set
②Outer Antenna
③Power Adaptor
④RS- 232 Cable
⑤Manual CD-ROM
1.4 AP Components
①②③④ ⑤

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
7
2. H/W, S/W Structure
2.1 Internal Block Diagram
The figure below shows Internal hardware block diagram.
2.1 Internal Block Diagram
SDRAM 16MByte
CPU
S5N8947
Reset & Clock
ROWER
1.8V/3.3V To Need To Need
Data 0~32
RJ-45 Connector
MII Interface
RS-232
Driver RJ-45 Connector
PCMCIA
WLAM Module
100/10BaseT
Ethernet SW
RJ-45 Connector

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
8
2.2.1 S/W Hierarchical Structure
The figure blow shows software hierarchical structure of our AP.
2.2 S/W Hierarchical Structure
802.11b Interface Ethernet ControllerSerial Interface
Wireless LAN Device Driver
Console Device Driver Ethernet Device Driver
802.1x EAP-MD5
802.1d Bridge
IP
UDP
DHCP
Server
RADIUS
TCP
WEB/
HTTP
Telnet
FTP TFTP
SNMP
System Management Function
PC Console WLAN LAN Terminal Ethernet Terminal
Ethernet Controller
Ethernet
Device
Driver
WAN

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
9
3. Console, Telnet Setup
3.1 : Setting Terminal Emulator for Console
There are various terminal emulators as commercial products. Among them, this chapter
describes ‘Hyper Terminal’ embedded in Window that is the most widely used.
If you want to execute Hyper Terminal, click ‘Start’ -> ‘Program’-> ‘Auxiliary Program’->
‘Communication’->’Hyper Terminal’ in order.
3.1.1 Hyper Terminal Execution Screen
: If you execute hyper terminal, name dialog box for ‘Connection’ appears as shown in the
figure below. At this time, set a desired name.
3.1.2 Connection Target
: In Connection Target dialog box, enter Serial port to be connected. In general,
Com1/Com2 are used, and Com1 is used in most cases.

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
10
3.1.2 Entry Information Dialog Box
: After Entry Information Dialog box appears, fill out the following items.
iBit/Sec : 57600
iDatabit : 8
iParity : None
iStopbit : 1
iFlow Control : None

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
11
3.1.4 Login
: After setting, login screen appears as shown below. An initial Username/Password are as
follows.
iInitial Username : admin
iInitial Password : admin

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
12
3.2 : Connecting Telnet
iIf you want to connect to AP through Telnet for the purpose of management, be sure
to know AP IP address. AP’s default IP Address is 10.0.0.2 and default port number is
No. 23 (Telnet default port). Example of connection is as follows.
Example) Enter the following command in Command Prompt.
C:\>telnet 10.0.0.2
To Provide wireless LAN service by installing APs, you have to be provided with the following items by the
network manager.
① AP Operation Mode: Bridge mode, Routed mode, PPPoE mode
② External Network Connection Mode: Fixed IP, DHCP, or ADSL(PPPoE)
③ AP IP address and network mask address
④ Basic gateway address of AP, and DNS server address
⑤ Wireless LAN SSID, channels used, and encryption status
⑥ Authentication/billing Information, radius server address, port, and secret key
Network management server address
3.3 : AirGate 2000K Setup
AirGate2000K has physical interface such as one wireless interface and two Ethernet
interfaces. One of the two Ethernet interfaces is ‘WAN’ interface, and the other is ‘LAN’
interface. When installing AirGate2000K, connect backbone network coming from the
outside to ‘WAN’ port. If ‘WAN’ port and ‘LAN’ port are changed when installed, it might
cause serious effects on some functions. Thus, be sure to check ‘WAN’ port and ‘LAN’ port
before installation.
Example) If there is an UTP cable connected through Kornet network, connect it to ‘WAN’
port, and connect internal LAN user’s (wired) PC to ‘LAN’ port.
WAN LAN Console
Internet User PC

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
13
3.4 : Status
In ‘Status’, you can view system setup information. If you normally log on through
Console and Telnet, the page below appears first. If you want to see ‘Status’, enter ‘s’ or
‘status’.
Ex : cms>s or cms>status
In ‘Status’ as shown in the figure below, you can search firmware version (ex: FW
1.2.4), system uptime, ADSL, network setup, wireless LAN setup, interface information
and the status of DHCP Server. After setting to subscriber’s environment, you can check
the results in ‘Status’. For further information on setup, refer to 3.5 ‘Config’.
3.5 : Config
In ‘Config’, you can set up all AP functions. If you want to set up AP in ‘Config’, enter ‘c’ or
‘config’.
Ex: cms>c or cms>config
If you want to set the appropriate menu in ‘Config’, enter the appropriate menu number, and
enter ‘Y’ if current setup status for ‘Change Setup’ appears, and then set according to each
step. If you enter wrong number by mistake, enter ‘n’ if ‘Change Setup’ is shown.
Note! Before you set up AP in ‘Config’ menu, be sure to be familiar to this manual. If
you change a part of settings without permission, the system might be in malfunction.

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
14
3.5.1 Basic Configuration
: If you want to set Basic Configuration, enter ‘1’(the appropriate menu), and enter ‘Y’ if you
are asked whether to change the current setup.
When setting, value in brace ([ ]) means current set value, and press Enter key if you want to
maintain it without changing.
iAdmin Login Name[admin] : AP Admin login name. Default is ‘admin’ (value in the brace
([ ]), and if you log in Admin, you can execute AP setting, setup change, setup inquiry and
other functions.
iAdmin Password[*****] : Password for AP Admin login. Default is ‘admin’. Do not change.
iUser Login Name[user] : User Login Name [user]: AP user login name. Default is ‘user’, and
if you log in user, you can search AP setup information and reboot the system only.

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
15
iUser passwd[******] : Password forAP user login. Default is ‘ipone’.
iSystem Mode(Bridge|Routed|PPPoE)[Bridge] : System mode setting
- Bridge : Bridge all physical interfaces.
-Routed:Routing mode between ADSL interface and wireless& Ethernet interface.
- PPPoE : AP closes PPPoE session, and IP Address is assigned to AP. Set ID and
Password for PPPoE session.
iDHCP Client Enable[N] : DHCP Client Enable [N]: Used to assign AP IP address as
flexible IP. Default is ‘N’. If it is set to ‘Y’, you do not have to execute IP setting. If
you install AP through authentication mode, be sure to set to ‘N’ and set IP in the
next item.
iWAN IP Address[10.0.0.2] : WAN interface IP address. Enter IP address assigned to AP.
If you do not know IP address, contact with administrator and then enter correct IP
address. Default is ’10.0.0.2’.
iWAN Network Mask[255.255.255.0] : Subnet mask by WAN interface IP address. If you
do not know Subnet mask, contact with administrator and then enter correct subnet
mask. Default is ‘255.255.255.0 (24bit)’.
iDefault Gateway[10.0.0.1] : Default Gateway setting. If you do not know Gateway,
contact with administrator and then enter correct Gateway. Default is ’10.0.0.1’.
iDNS Server[168.126.63.1] : DNS server setting. Default is ‘168.126.63.1’.
iEnhanced Security for LAN station[N] : Separation between LAN users
(wired/wireless). If you set this function to ‘Y’, communication between LAN users is
no performed. Default is ‘N’.
3.5.2 Wireless LAN Configuration
: In Wireless LAN Configuration’, you can execute wireless LAN-related setting.
If you want to set Wireless LAN Configuration, enter ‘2’, and enter ‘Y’ if you are asked
whether to change the current setup, and go on according to each step.
- Enter the new configuration!
SSID[IPONE] :
802.11b Channel Num(Auto|1|2|3|4|5|6|7|8|9|10|11)[AUTO] :
AuthType–Open System[Y] :
AuthType–Shared Secret[N] :
Allow ‘ANY’SSID[Y] :
Encryption Method(non|wep64|wep128|Dynamic64|Dynamic128)[none]:
Beacon Period (ms)(1-10000)[100]:
BasicRateof1Mb/s[Y]:
BasicRateof2Mb/s[Y]:
Basic Rate of 5.5 Mb/s[Y]:
Basic Rate of 11 Mb/s[Y]:
Operation Rate of 1 Mb/s[Y]:
Operation Rate of 2 Mb/s[Y]:

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
16
Operation Rate of 5.5 Mb/s[Y]:
Operation Rate of 11 Mb/s[Y]:
RTS Threshold(0-3000)[2432]:
Fragmentation Threshold (256-2346)[2346]:
Transmission Power(Default=70mW)(Default|10mW|30mW|50mW|100mW)[100mW]:
iSSID[IPONE]: Set ESSID. Set to ‘IPONE’. Default is ‘IPONE’.
! Note: Enter an SSID value, discriminating between large and small letters. If you set to
‘ipone’, thus, IPONE wireless terminal is not connected.
i802.11b Channel Num(Auto|1|2|3|4|5|6|7|8|9|10|11|)[Auto]:
Set wireless LAN channel. If you want to fix channel, enter a desired channel number,
and enter ‘auto’ if you use ‘Auto Setting’ function through which AP can search
optimal channel by itself. Default is IPONE.
iAuthType - Open System[Y]: Set 802.11b authentication method. Default is ‘Y’.
iAuthType - Shared Secret[N]: Set 802.11b authentication method. Default is ‘N’.
iAllow 'ANY' SSID[Y]: Set terminal ‘ANY’ SSID allowance. If you set to ‘Y’, it allows the
terminal to search AP or enables wireless connection of the terminal set to ‘ANY’. If you
set to ‘N’, it is possible to connect the terminal wirelessly if you enter SSID identical to AP in
the terminal. Default is ‘Y’.
iEncryption Method(none|wep64|wep128|Dynamic64|Dynamic128)[none]: Setting data
encryption in wireless section. For data encryption in wireless section, be sure to set
encryption key value and key index. If it is not Dynamic WEP Encryption, in addition,
communication is in normal status if AP is the same as terminal encryption key and key index.
Default is ‘none’ (unused).
- wep64 : Set to 64bit data encryption mode. When using wep64, set encryption key and
key index, and also AP should have the same encryption key and key index.
- wep128 : Set to 128bit data encryption mode. When using wep128, set encryption key and
key index, and also AP should have the same encryption key and key index.
- Dynamic64 : The terminal is assigned with session key through authentication, and
performs 64bit data encryption. For Dynamic64, do not set encryption key and key index.
- Dynamic128 : The terminal is assigned with session key through authentication, and
performs 128bit data encryption. For Dynamic128, do not set encryption key and key
index.
iBeacon Period (ms)(1-10000)[100]: Beacon Set transmission period of Beacon packet.
Default is ‘100’.
iBasic Rate & Operation Rate : Indicates transmission rate in wireless LAN section. In case of

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
17
802.11b wireless LAN, it is possible to automatically adjust transmission rate according to
signal strength, environment and noise. Transmission rate such as 11Mbps, 5.5Mbps, 2Mbps
and 1Mbps is supported. Under the environment of good signal strength and less noise,
communication is performed at a rate of 11Mbps, however, if not, communication is carried
out at a different rate of transmission according to the environment. Basic Rate means
transmission rate of communication not through negotiation with terminal like Broadcast;
Operation Rate does transmission rate through negotiation with terminal like Unicast. For basic
rate, default (1Mbps/2Mbps) is set to ‘Y’, and for Operation Rate, it is set to ‘Y’. Do not
change setting but wireless LAN technician.
iRTS Threshold(0-3000)[2432]: Set RTS Threshold value. Default is ‘2432’.
iFragmentation Threshold(256-2346)[2346]: Set Fragmentation Threshold value. Default is
‘2346’.
iTransmission Power(Defalut=70mW)(Default|10mW|30mW|50mW|100mW)[100mW]: Set
output power. Default is ‘100mW’.
3.5.3 DHCP Server Configuration
: In ‘DHCP Server Configuration’, you can set DHCP Server and Relay. If you want to set DHCP
Server and Relay, enter ‘4’, and enter ‘Y’ if current setup status for ‘Change Setup’ appears,
and then set according to each step.
iDHCP Server Enable[N] : Start and set DHCP Server. When running DHCP Server, enter the
first IP address and last IP address. Default is ‘N (unused)’.
iDHCP Relay Enable[N] : Start and set DHCP Relay. When running DHCP Relay, enter Relay
Server IP address. Default is ‘N (not used)’.
3.5.4 802.1x Configuration (Primary)
: In ‘802.1x Configuration (Primary)’, you can execute major setting related to authentication. If
you want to set 802.1x Configuration (Primary), enter ‘5’, and enter ‘Y’ if current setup status for
‘Change Setup’ appears, and then set according to each step.

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
18
i802.1x Authentication(none|e8021x|mac8021x)[mac8021x]:Setting for 802.1x
authentication method.
- e8021x : If 802.1x EAP-MD5 only is authenticated.
- mac8021x : If MAC/802.1x EAP-MD5 are all authenticated.
iPrimary Auth Server[61.78.54.2] :
Set up Primary Auth Server IP address. Default is ‘61.78.54.2’.
iPrimary Auth Port(1-65535)[1812]:
Set up Primary Auth. Server Auth. Server. Default is ‘1812’.
iPrimary Auth Shared Key[megapass]:
Secret key for authentication between Primary Auth. Server and AP. Default is ‘megapass’.
iSecondary Auth Server[0.0.0.0]:
Set up Secondary Auth Server IP address. Default is ‘0.0.0.0’.
iSecondary Auth Port(1-65535)[1812]:
Set up Secondary Auth Port IP address. Default is ‘1812’.
iSecondary Auth Shared Key[megapass]:
Secret key for authentication between Secondary Auth Server and AP. Default is ‘megapass’.
iRadius Auth Request Retrans. Interval(ms)(10-65535)[15000]:
If authentication packet transmission fails, set retransmission interval. Default is ‘15000’.
iRadius Auth Request Retrans. Number(1-65535)[3]:
If authentication packet transmission fails, set the number of retransmission. Default is ‘3’.
iPrimary Acct Server[61.78.54.2]:
Set Primary Acct Server IP address. Default is ‘61.78.54.2’.
iPrimary Acct Port(1-65535)[1813]:
Set up Primary Acct Server Auth port. Default is ‘1813’.
iPrimary Acct Shared Key[megapass]:

IPOne AirGate Wireless Series
IPOne
www.IPOne.co.kr
19
Secret key for authentication between Primary Acct Server and AP. Default is ‘megapass’.
iSecondary Acct Server[0.0.0.0]:
Set Secondary Acct Server IP address. Default is ‘0.0.0.0’.
iSecondary Acct Port(1-65535)[1813]:
Set up Secondary Acct Server Auth port. Default is ‘1813’.
iSecondary Acct Shared Key[megapass]:
Secret key for authentication between Secondary Acct server and AP. Default is ‘megapass’.
iRadius Acct Request Retrans. Interval(ms)(10-65535)[15000]:
If authentication packet transmission fails, set retransmission interval. Default is ‘15000’.
iRadius Acct Request Retrans. Number(1-65535)[3]:
If authentication packet transmission fails, set the number of retransmission. Default is ‘3’.
3.5.5 802.1x Configuration (Additional)
: In ‘8021x Configuration (Additional)’, you can execute additional setting related to
authentication. If you want to set 8021x Configuration (Additional), enter ‘5’, and enter ‘Y’ if you
are asked whether to change the current setup, and then go on according to each step.
i802.1x Authentication (none|e8021x|mac8021x)[mac8021x] :
Setting for 802.1x authentication method. Default is ‘mac8021x’.
iAuthentication to Ethernet Interface(None|Equal|New)[None] :
Set 8021x authentication of a wired terminal. Default is ‘none’.
- Equal: Authentication of a wired terminal is performed the same as wireless terminal.
- New: Wired and wireless terminals are classified for authentication.
iWeb Redirection Enable[Y] : If an unauthenticated terminal attempts to access the Internet
through Web browser, it is connected to the Web Page that is designated by force. Default is
‘Y’.
