General Description
General Description
The emu3/emu3ACO updates the previous IPE eMu2 PDU range.
The emu3/emu3ACO is a twelve-output power distribution unit with an embedded web server to allow IP control.
The standard model, in intelligent mode, can be set as a Master or Slave; the Automatic Changeover (ACO) model can
failover between redundant supplies.
All units contain an embedded web server, that enables continuous remote control and monitoring via the IPE
Dashboard. They can be daisychained to other emu3 units to provide up to 48 outputs via a single IP connection.
In the event of a Master unit failure, simply move the Ethernet connection to a secondary unit, which then
automatically becomes the new Master.
Units covered by this document
This document describes hardware versions v1 and v2 of the following units:
• emu3
• emu3ACO: 12-PMU Redundant power unit with automatic switchover (ACO)
Features
• Sequential Switch On: Each unit can be set up to have sequential switch on to prevent switch-on power surge.
• Power Shedding: Each output can be programmed to switch o when the unit is in a power saving mode.
• Remote Control: All outputs can be switched on or o via the IPE Dashboard web page.
• Output Monitoring: Front panel and web monitoring of status of output and fuse.
• Temperature Sensor: Rear panel connector for optional linked external temperature sensors. Critical
temperature alerts can be sent via email.
• Current Measurement: Overall current consumption can be monitored via the IPE Dashboard web page.
• Auto Changeover: In addition to all the features above the emu3ACO units have automatic changeover on
input failure, as well as a font panel switch for manual selection of input. LEDs show selected default input and
status of each input.
• Telnet protocol: Units can be accessed via Telnet; status & sensor values can be read, and switch outlets can be
programmed.

6 emu3/emu3ACO Operation Guide
Version 2.1
Front panel features
Front panel features
• Output channels: ON LEDs: There is one ON LED for each output channel on the front panel. :
LED state Meaning
On Output OK
O Output remotely switched o
Flashing Output switched on, but fuse failed
• LAN LED: This shows network activity and status.
LED state Meaning
On Network connected, no trac
O No network connection
Flashing Network trac
• ON LED: This shows mains power status.
LED state Meaning
On Mains on
O Mains o
• ACTIVE/ON LEDs (emu3ACO only): These show the status of the A/B power inputs.
ACTIVE LED Meaning ON LED
On Input selected On Mains on
O Input not selected O Mains o
Flashing Input selected but one of the inputs
has no mains applied; the unit has
defaulted to the input whose ON LED
is illuminated
• C/O switch (emu3ACO only): Press this to change over between the A and B power modules.
• RESET switch:
• USB ports: There are two USB ports available. See “Performing a software upgrade”on page 23 for details.
• Fuses:
–12 x Cartridge Fuse, F, 6.3A, 5 x 20mm tted as standard
–1 (emu3) or 2 (emu3ACO) 16A Antisurge 1.25in

emu3/emu3ACO Operation Guide 7
Version 2.1
Rear panel features
Rear panel features
• LINK IN/OUT ports: RJ45 ports, used to link from Master to Slave unit
• SENSOR port: RJ45 port, used to connect temperature sensors
• LAN port: RJ45 port. Main network connection: only the rst unit in a chain should be connected via this port.
• GPI 1–6 port: 15-way D-type connector, for GPI signals
• MAINS / MAINS A B connectors: powerCON lockable 3-pole NAC3 sockets. Single (emu3) or dual (emu3ACO)
mains power inputs.
• IEC Power outlets: 12 x IEC power outlets.
LINK GPI 1-6 12 11 10 9 8 7 6 5 4 3 2 1
SENSOR LAN 220-240VAC ~ 16A 50Hz
MAINS A MAINS B
IN
OUT
LINK GPI 1-6 12 11 10 9 8 7 6 5 4 3 2 1
SENSOR LAN 220-240VAC ~ 16A 50Hz
MAINS A MAINS B
IN
OUT

8 emu3/emu3ACO Operation Guide
Version 2.1
Installation Instructions
Installation Instructions
This section explains how to install and connect your emu3 system.
Changing the Master emu3 IP address
By default, all emu3 units are congured with an IP address of 192.168.0.209. This address is in the space reserved
for private networks. If you are daisychaining multiple emu3 units in a Master/Slave setup, only the Master unit is
directly connected to your LAN (the Slave units are controlled from the Master’s LINK OUT port).
You will only need to change the default IP address of your Master emu3 unit in the following cases:
• There is already a machine on your network with the IP address 192.168.0.209
• Your LAN uses a dierent IP address space
If neither of the above applies, you can go straight to the next section, “Install the units and make earth connections”
on page 10.
To change the IP address space of your Master unit:
1. Congure a standalone PC (i.e. one not connected to your LAN) with the IP address 192.168.0.1.
2. Connect a CAT5e cable from the standalone PC to the LAN connector on the rear panel of your Master unit.
3. Connect an IEC mains power cable to the MAINS connector on the rear panel.
4. Plug the cable into a wall outlet and switch on.
If you are using an emu3ACO, you only need to connect one power cable, e.g. to the MAINS A connector.
5. Open a web browser on the standalone PC and enter the url 192.168.0.209
The Login web page should be displayed. If it does not, wait a few moments and refresh the web page.
6. Enter the user name and password these are both set to admin by default) and click Login. This will display the
Overview page of the IPE Dashboard.

emu3/emu3ACO Operation Guide 9
Version 2.1
Installation Instructions
7. Click on the gear icon to display the unit’s Conguration page.
8. Click on the down arrow to expand the Network Settings panel.
9. Enter the settings appropriate for your network’s IP address space:
–Host Name: If required, enter a text string to identify your Master unit.
–Mode: Choose from Static or DHCP.
–If you chose Static, enter an appropriate IPv4 Address, IPv4 Network Mask and IPv4 Gateway machine for
your LAN.
10. Click OK.
11. Once the unit has rebooted, remove the power and LAN cables.
12. If necessary, recongure your standalone PC to its original IP address settings.
13. Go to the next section, “Install the units and make earth connections”on page 10.

10 emu3/emu3ACO Operation Guide
Version 2.1
Installation Instructions
Install the units and make earth connections
To install the units:
1. If required, slide the units into your 19" rack and secure with standard rack-mount bolts.
2. Make earth connections to all the units.
Make the LAN and LINK connections
The Master unit is the only unit directly connected to your LAN. Slave units do not have a direct network connection
to your LAN, but are controlled from the Master unit’s LINK OUT port.
IMPORTANT!!: Do NOT plug a network cable into a Slave unit’s LAN port if it is already connected to a Master unit.
Note: Master and Slave units can be either emu3 or emu3ACO. In the picture below, we show the Master as an
emu3ACO, connected to two emu3 Slave units.
To make the LAN connection:
1. Connect a CAT5e cable from your network hub to the LAN connector on the rear panel of your Master unit.
2. Connect a CAT5e cable from the LINK OUT connector on the rear panel of the Master unit to the LINK IN
connector on the rst Slave unit in your chain.
3. Connect any additional Slave units using CAT5e cables, going from the LINK OUT connector of the previous unit
to the IN connector of the next unit.
4 3 2 1
LINK GPI 1-6 12 11 10 9 8 7 6 5 4 3 2 1
SENSOR LAN 220-240VAC ~ 16A 50Hz
MAINS A MAINS B
IN
OUT
LINK GPI 1-6 12 11 10 9 8 7 6 5 4 3 2 1
SENSOR LAN 220-240VAC ~ 16A 50Hz
MAINS A MAINS B
IN
OUT
LINK GPI 1-6 12 11 10 9 8 7 6 5 4 3 2 1
SENSOR LAN 220-240VAC ~ 16A 50Hz
MAINS A MAINS B
IN
OUT
To next Slave unit
Master
Slave 1
Slave 2
To LAN

emu3/emu3ACO Operation Guide 11
Version 2.1
Installation Instructions
GPI function
See “Setting up power shedding”on page 19 for details of controlling power shedding from the IPE Dashboard.
GPI 1-6 (15-way D-type) connector
The pinout for the 15-pin D-type GPI 1–6 connector on the unit is shown in the table below:
PIN FUNCTION
1 Input Opto Isolator 1
2 Input Opto Isolator 2
3 Input Opto Isolator 3
4 Input Opto Isolator 4
5 Input Opto Isolator 5
6 Input Opto Isolator 6
7 0v
8 0v
9 Input Opto Isolator 1
10 Input Opto Isolator 2
11 Input Opto Isolator 3
12 Input Opto Isolator 4
13 Input Opto Isolator 5
14 Input Opto Isolator 6
15 Fused +5V dc
• The opto isolator inputs are NOT polarity dependent. Operating voltage is 5Vdc to 30Vdc (12Vdc nominal).
• The 5Vdc output available on the connector is current limited and is designed to only operate the input opto
isolators.
• The absolute minimum operating voltage is around 3.6V, so driving them from a 5V supply via an open collector
output is not reliable.
• Since the minimum operating voltage is low it is possible that, for a high DC supply (e.g. 15V and above), driving
the opto via an open collector output may cause the opto to not turn o reliably, due to the residual voltage
within the circuit.

12 emu3/emu3ACO Operation Guide
Version 2.1
Installation Instructions
Connect any sensors
You can connect up to four temperature or humidity sensors (available from IPE) to each emu3/emu3ACO unit:
Note: See “read sensor command”on page 31 for details on using Telnet to read sensor values.
1. Connect a sensor to the SENSOR port on the rear panel of an emu3/emu3ACO unit using a standard CAT5e RJ45
cable.
2. Daisychain additional sensors as as required.
Connect mains power
emu3 and emu3ACO units use powerCON locking 3-pole power connectors.
Note: emu3 units do not have dedicated ON/OFF switches. They power up as soon as mains power is applied.
1. Connect IEC mains power cables from the MAINS ports on the rear panels of your emu3 units to suitable mains
outlets.
For emu3ACO units, connect power cables to both MAINS A and MAINS B ports.
2. Connect any devices to be powered by your emu3 system to the mains outlet ports (1-12) on the rear of the
units.
3. Switch on mains power at the wall.
4. Allow a few moments for the units to power up and connect to your LAN.
LINK GPI 1-6 12 11 10 9 8 7 6 5 4 3 2 1
SENSOR LAN 220-240VAC ~ 16A 50Hz
MAINS A MAINS B
IN
OUT
emu3 or emu3ACO
Sensors

emu3/emu3ACO Operation Guide 13
Version 2.1
Using the IPE Dashboard
Using the IPE Dashboard
This section explains how to use the IPE Dashboard web interface for your emu3 system. For details on status
information, switching and conguration options, see the sections later in this manual, starting with “Overview page:
Status and control”on page 16.
Logging into the IPE Dashboard
This section explains how to open the IPE Dashboard web interface for your emu3 system. From here you can
view status information about all currently connected devices, switch between supplies on an emu3ACO, switch
individual outlets on and o, and make conguration changes.
1. If they aren’t already powered up, switch on power to the Master unit and any Slave units.
2. On a PC on your LAN, open a web browser and enter the IP address for your Master unit (e.g. 192.168.0.209).
The Login web page should be displayed. If it does not, wait a few moments and refresh the web page.
3. Enter a valid user name and password (these are both admin by default) and click Login. This displays the
Overview page, which lists all the units currently connected and shows status information.
Note: To manage user accounts, see “Authentication: Managing users”on page 20).
4. In the top section, enter any appropriate System Information for your emu3 setup (such as a unique system
name, and the email address of the administrator).

14 emu3/emu3ACO Operation Guide
Version 2.1
Using the IPE Dashboard
Overview page
The Overview page has the following controls:
A. Click Log Out to exit the web interface.
B. Click arrows to change the order in which devices are displayed.
C. Click a gear icon to display the device-specic Device page.
D. Click to show/hide details for a particular device.
Device pages
Note: This functionality is only availabe to accounts assigned the Administrator role (see“Authentication: Managing
users”on page 20).
The Device pages have the following controls:
A. Click Log Out to exit the web interface.
B. Click the Overview link to display the Overview page.
C. Hover over the Units link and click on a device name to display the relevant Device page.
D. Click to show/hide details for a particular conguration panel (e.g. Power Shedding).
E. Click to edit the device name.

emu3/emu3ACO Operation Guide 15
Version 2.1
Using the IPE Dashboard
Toggling between the Overview and Device pages
Note: This functionality is only availabe to accounts assigned the Administrator role (see“Authentication: Managing
users”on page 20).
When you log into the web interface, by default the Overview page will be displayed.
To switch from the Overview page to a specic Device page:
1. Click on the gear icon in the header row for the device you want to view.
To display a dierent Device page:
1. Hover over the Units link to display the list of Master and Slave devices.
2. Click on a device name.
To switch to the Overview page from a Device page:
1. Click on the Overview link.

16 emu3/emu3ACO Operation Guide
Version 2.1
Overview page: Status and control
Overview page: Status and control
The Overview page is displayed by default when you rst log into the IPE Dashboard. It contains the following
collapsible panels:
A. System Information: Use this to enter details for your entire emu3 system
B. Device Status: One panel for every currently connected Master/Slave unit; title displays unit name (if congured)
and hardware version (v1 or v2)
Each Device Status panel has the following features:
C. ACO status and control (emu3ACO only): Shows which internal supplies are active and enabled. Click to change
over between supplies (or press the C/O button on the front panel).
D. Power Meter:
–v1 hardware: Displays the current draw for this unit
–v2 hardware: Displays current draw, power, voltage, VA, power factor and frequency
E. Sensor status: One indicator for each sensor connected to this unit (can be up to four)
F. Power Outlet control: One for each of the 12 outlets on the rear of the unit. Displays the current status. Click on
the OI switch to toggle the outlet on or o.
G. GPI status: Displays the current status of the GPI signal on each of the GPI 1-6 inputs.
Note: If a slave unit is oine, its Device Status panel will be greyed out. If there is an overcurrent issue, the Device
Status panel will be highlighted in yellow (warning state) or red (countdown or tripped states). See pages page 24
and page 25.

emu3/emu3ACO Operation Guide 17
Version 2.1
Device Details: Conguring and controlling devices
Device Details: Conguring and controlling devices
While you can perform some actions from the Overview page in the IPE Dashboard, you will need to display a
specic Device Details page to congure any settings, such as the power-up sequence or IP addressing.
Note: This functionality is only availabe to accounts assigned the Administrator role (see“Authentication: Managing
users”on page 20).
For details on toggling between the Overview page and a specic Device Details page, see page 14.
Each Device Details page contains the following collapsible panels:
• Unit Information: You can enter the following details for a unit:
–Name (in the panel’s title bar)
–Location: Textual description of the physical location of the unit
–Notes: Any other relevant information
• Unit Status: This mirrors the status and control information shown on the unit’s tab in the Overview page. See
“Overview page: Status and control” on page 16.
• Power Up Sequence: Allows you to specify the order in which equipment attached to this unit is powered up.
See “Setting the power up sequence” on page 18.
• Power Shedding: see“Setting up power shedding” on page 19
• Network Settings (Master unit only): Use this panel to change the IP addressing used by the Master unit and
any connected Slave units
• Telnet Settings: Use this to congure Telnet access; see “Telnet commands”on page 27
• Authentication (Master unit only): see“Authentication: Managing users”on page 20
• SNMP (Master unit only): Use this panel to enable or disable SNMP on this unit. emu3 units use SNMP v2c
protocol. The MIB (supplied by IPE Ltd) details all the available traps.
• Web Server (Master unit only): Congures the web server on this unit (which controls whether the IPE
Dashboard information is made available). Allows you to choose between the HTTP and HTTPS protocols.

18 emu3/emu3ACO Operation Guide
Version 2.1
Setting the power up sequence
Setting the power up sequence
Note: This functionality is only availabe to accounts assigned the Administrator role (see“Authentication: Managing
users”on page 20).
You can control the order in which devices attached to a particular emu3 unit power up (this can be when you
initially switch on your emu3 system, or after a power failure). This avoids a power surge caused by multiple devices
starting up simultaneously.
To modify the power-up sequence:
1. Log into the IPE Dashboard as a user with Administrator privileges (the default admin user has this
automatically).
2. In the IPE Dashboard, display the Device Details page for the emu3 unit you want to congure.
3. Expand the Power Up Sequence panel.
4. For each power outlet, choose an option from the DELAY OR ACTION drop-down menu.
–Previous State: The power outlet remains in the same state as it was before power was restored to the emu3
unit
–O: The power outlet is switched o on power-up, irrespective of whether it was previously on or o
–On Immediately: The power outlet is switched on as soon as power is restored to the emu3 unit.
–On after (n)s: The power outlet is switched on n seconds after power is restored to the emu3 unit.
5. Click OK

emu3/emu3ACO Operation Guide 19
Version 2.1
Setting up power shedding
Setting up power shedding
Note: This functionality is only availabe to accounts assigned the Administrator role (see“Authentication: Managing
users”on page 20).
When there is a requirement for power shedding, you can set particular devices (or groups of devices) to shut down
in a specied order after a power shedding signal has been received on a GPI pin.
To congure power shedding:
1. Log into the IPE Dashboard as a user with Administrator privileges (the default admin user has this
automatically).
2. In the IPE Dashboard, display the Device Details page for the emu3 unit you want to congure.
3. Expand the Power Shedding panel.
4. Set the Trigger type using the drop-down menu:
–Linked Power Shedding: Power shedding is triggered by the approriate GPI on the parent unit (i.e. the
previous unit in the LINK chain).
–Input Pin n: Power shedding is triggered when a signal is detected on the specied GPI pin on this emu3
unit. Use the adjacent drop-down menu to specify whether the signal is Active High or Active Low.
5. For each Power Outlet on this unit, use the ACTIVE drop-down menu to specify what happens when power
shedding is triggered while power saving is currently active:
–Do Nothing: The power outlet remains in the same state as it was before power shedding was triggered
–O Immediately: The power outlet is switched o as soon as power shedding is triggered.
–O after (n)s: The power outlet is swtched o n seconds after power shedding is triggered.
6. For each Power Outlet on this unit, use the INACTIVE drop-down menu to specify what happens when power
shedding is triggered while power saving is currently inactive:
–Previous State: The power outlet remains in the same state as it was before power shedding was triggered
–On Immediately: The power outlet is switched on as soon as power is restored to the emu3 unit.
–On after (n)s: The power outlet is switched on n seconds after power is restored to the emu3 unit.
7. Click OK

20 emu3/emu3ACO Operation Guide
Version 2.1
Authentication: Managing users
Authentication: Managing users
Note: This functionality is only availabe to accounts assigned the Administrator role (see“Authentication: Managing
users”on page 20).
By default, the IPE Dashboard has one user (admin) set up, with the default password set to admin.
• We recommend that you change the default password as soon as possible
• You can create more users, and assign a role (User or Administrator) to each user
–User role: Such users can only view the Overview page and use its associated controls
–Administrator role: Such users have access to all the IPE Dashboard functionality.
Changing a user’s password
To change a user’s password:
1. Log into the IPE Dashboard as a user with Administrator privileges (the default admin user has this
automatically).
2. In the IPE Dashboard, display the Device Details page for the Master emu3 unit.
3. Expand the Authentication panel.
4. Select the User Name whose password you want to change from the drop-down menu:
5. Enter a new password.
6. Click OK.
