Pulizzi IPC34XX-NET Series User manual

Intelligent Power Control™ IPC34XX-NET Series
Enclosure Power Distribution Units (ePDU™)

© 2008 Eaton Corporation. All Rights Reserved. All specifications are subject to change without notice.
www.pulizzi.com • [email protected] • 800-870-2248 • Fax: [phone]
2
• Remote access via WAN/LAN, TCP/IP, Modem, or Direct RS-232:
Prevent costly site visits with remote-reboot and power management.
• Sequence power up and down with Pulizzi’s
®
patented Multiple Time Delay
TM
circuitry:
Prevent inrush current problems such as system lock-ups and automatically control the order in which equipment within
your network powers up or down.
• Strap up to 10 IPC34XX systems together for control of 80 outlets:
Use one IPC34XX-NET unit as the main system and strap (nine) less expensive IPC34XX (non-NET) units together to save
money and increase overall control of your network equipment.
• 100-240VAC / 15A or 20A input (IPC3401 or IPC3401-NET):
One unit to purchase, stock and utilize worldwide.
• Remote access disable and Local on/off control:
When you need to work locally with the IPC34XX systems, the push of a button will
prevent anyone from coming in remotely and the individual outlet on/off switches are also
located on the front panel.
• Cross platform compatible with Telnet and Browser Control:
You can easily access and control the IPC34XX with either PC, Mac, Linux or Unix platforms
running Telnet or via your web browser.
Equipment
Network
Equipment
Modem
Modem
Rear
Up To 10 IPC
Units Can Be Stacked
Together
Ethernet Strapping Switch
RS485 Strapping Connectors
RS232 Serial (DB9 Connector)
IPC3402-2756 Rear
IPC3402-NET Rear
IPC3401-NET Rear
Front

© 2008 Eaton Corporation. All Rights Reserved. All specifications are subject to change without notice.
www.pulizzi.com • [email protected] • 800-870-2248 • Fax: [phone]
3
CHASSIS
• 19” x 1.72” (1U) x 9.5”
• Weight approximately 12 lbs. (IPC3401 & 02)
• Weight approximately 15 lbs. (IPC3402-2756
& IPC2930)
• Detachable mounting brackets allow for
several mounting options
NEMA or IEC 320 OUTLETS
• IPC3401 has 8 IEC 60320 Type C13
– Rated by UL/CSA 125V~/15A
– Rated by UL/CSA/VDE 250V~/10A
• IPC3402 has 8 NEMA 5-15R
• IPC3402-A2 has 8 NEMA 5-20R
• IPC3402-2756 has 4 NEMA 5-20R
and 4 NEMA 5-15R
• IPC3402-2930 has 8 NEMA 5-15R
(11) INDICATOR LIGHTS
• Main power to system-CB “on”
• Individual power “on” to outlets 1-8
• Data acquisition and remote disable
REMOTE or LOCAL CONTROL
• Serial RS232 port (DB9 Male) for direct
computer or modem connection
• RS485 input/output for strapping up to
10 systems together over CAT.5 cable
• Local: one on/off switch for each outlet
• -NET SYSTEMS ONLY: RJ45 for
network connections (Ethernet)
REMOTE DISABLE
• With the push of a button, disable
remote access to the IPC when needed
POWER SUPPLY
• The IPC3401 series features a full range
power supply for operation at
100-240VAC input/output
BAUD RATE
• Default: 9600 baud
EMI/RFI FILTERING
• Common Mode - Line to Ground
• Differential Mode - Line to Line
• Filtered inlet isolates noise before
entering the system
• IPC3402-2756 and IPC3402-2930
do not have filtering
SPIKE/SURGE SUPPRESSION (TVSS)
• Line to Line
• Multi-stage, both MOVs and SAPs
BRANCH CIRCUIT PROTECTION
• UL498 Listed Main Disconnect Breaker
and guard, with a long time delay curve
provides manual on/off switching and
trips in an overload condition
POWER INPUT
• IEC 60320 Type C20 EMI/RFI Filtered Inlet
• Mating power cables must be ordered
separately
• IPC3402-2756: attached 10’ cable and
NEMA L5-30P
OUTLET STATUS
• Query the IPC for Outlet and Watch Dog
status, i.e. outlets are “on” or “off”
STRAPPING
• Strapping allows up to 10 IPCs
(80 outlets) to be controlled at one address
• Units are connected together via the
RS485 “IN” and “OUT” connectors
UNIT NAME / PASSWORD
• The IPC comes with a default name
@@@@, which can be changed to
any four alphanumeric characters
• Optional 3 character password
MULTIPLE TIME DELAYTM (MTDTM)
• Sequence power up and power down to
outlets with a one second time delay
(factory set)
• User Programmable:
– Set power “on” sequence to any
combination of outlets
– Set the MTDTM timing from 1 second
to 999 seconds, i.e. 009 = 9 seconds
AUTO-EVENT COMMAND RESPONSE
• The IPC will automatically update the status
of outlets (“on” or “off”) via serial or telnet
SOFTWARE CONTROLS
• Multi-platform compatible
• Control via Terminal Emulation Software
• Web interface for browser control
COMMANDS AVAILABLE
• All outlets on/off
• Specific outlets on/off
• Set up and Sequence on/off all outlets
• Create password and unit address
• Outlet naming (8 characters)
• Set up, enable or disable Watchdog
•Display outlet and Watchdog Timer status
• Automatically receive update outlet
status whenever there’s a change
• Auto-reboot outlet 1 with a five second
delay on restart
SPECIFICATIONS: IPC3401 IPC3401-NET IPC3402 IPC3402-NET IPC3402-A2 IPC3402-A2-NET IPC3402-2756 IPC3402-2930
Approvals UL/cUL, CE, GS, FCC UL/cUL, FCC UL/cUL, FCC UL/cUL, FCC UL/cUL, FCC UL/cUL UL/cUL
Voltage (50/60Hz) 100-240V~ 100-240V~ 120V~ 120V~ 120V~ 120V~ 120V~ 120V~
Current Input 20A @ 120V~
16A @ 240V~
20A @ 120V~
16A @ 240V~
20A 20A 20A 20A 30A 30A
Current Output 16A 16A 16A 16A 16A 16A 24A 24A
Full Load VA 1920VA @ 120V~
3840VA @ 240V~
1920VA @ 120V~
3840VA @ 240V~
1920VA 1920VA 1920VA 1920VA 2880VA 2880VA
Outlets (IEC or NEMA) Type C13 Type C13 5-15R 5-15R 5-20R 5-20R (4) 5-20R, (4) 5-15R (8) 5-15R
Circuit Breaker 20/20A 20/20A 20A 20A 20A 20A 20/10A 20/10A
EMI/RFI Filter 20A 20A 20A 20A 20A 20A N/A N/A
Surge Suppression 270V 270V 270V 270V 270V 270V 270V 270V
Power Input Type C20 Inlet Type C20 Inlet Type C20 Inlet Type C20 Inlet Type C20 Inlet Type C20 Inlet L5-30P L5-30P
Power Cord Power cables must be ordered separately. 10/3AWG 10’ 10/3AWG 10’
Ethernet Control NO YES NO YES NO YES YES YES
Serial Control (RS232) YES YES YES YES YES YES YES YES

© 2008 Eaton Corporation. All Rights Reserved. All specifications are subject to change without notice.
www.pulizzi.com • [email protected] • 800-870-2248 • Fax: [phone]
4
TVSS (Transient Voltage Surge Suppression)
MOV SPECIFICATIONS
Continuous AC Voltage 150VAC 270VAC 320VAC
Continuous DC Voltage 200VDC 360VDC 420VDC
Max. DC Leakage 200µA 200µA 200µA
Low Varistor Voltage Limit 212VDC 389VDC 462VDC
High Varistor Voltage Limit 243VDC 453VDC 540VDC
Nominal Varistor Voltage 236VDC 424VDC 503VDC
Current For Varistor Voltage 1mA 1mA 1mA
Max. Clamp Voltage 8x20µs 360V 680V 810V
Max. Clamp Voltage Test Current 100A 100A 100A
Peak Current Rating (1 Pulse) 12000A 10000A 10000A
Peak Current Rating (2 Pulse) 9000A 6500A 6500A
Energy Rating (10x1000µs) 170J 325J 385J
Energy Rating (8x20µs) 170J 325J 385J
Capacitance 1700pF 970pF 820pF
Impulse Response Time 50ns 50ns 50ns
Environmental
Operating Temperature is 0 to 50 C
Storage Temperature is -40 to 70 C
Altitude Maximum 10,000 ft.
Relative Humidity is 95% Max Non-Condensing
EMI/RFI FILTERING COMMON MODE INSERTION LOSS
Mhz. .01 1 10 20 50 100
dB. 8 2940506840
DIFFERENTIAL INSERTION LOSS
Mhz. .01 1 10 20 50 100
dB. 8 2345583228

© 2008 Eaton Corporation. All Rights Reserved. All specifications are subject to change without notice.
www.pulizzi.com • [email protected] • 800-870-2248 • Fax: [phone]
5
Front Flush
Front Recessed
Center Mount
Rear Flush
Mounting Brackets
Are Detachable With
Several Mounting
Options Shown
Optional
Zero-U
Bracket
(001-1928-1)
KIT-CABLRES-01
TRANSVERSE MOUNTING
• Prevent downtime and accidental disconnection
• Secure cables/plugs to Power Distribution Unit
• Cable ties provide highest level of retention
Accessories
Optional Cable Restraint and Management
Adjustable Mounting Options
HOLE SPECIFICATION TABLE
Rack Mounting Hole Specification Table
19.00”Y
A
Z
AYZ
1.75 .25 1.25
010-9334:
C19 to NEMA 5-15P
125V, 15A Straight Blade
8 foot, 14AWG/3wire
010-9335:
C19 to NEMA 5-20P
125V, 20A Straight Blade
8 foot, 12AWG/3wire
010-9339:
C19 to NEMA L5-20P
125V, 20A Twist-Lock
8 foot, 12AWG/3wire
010-9341:
C19 to NEMA L6-20P
250V, 20A Twist-Lock
8 foot, 12AWG/3wire
010-0025: 8 foot
C13 to C14 Harmonized, 1mm/3wire
100-240V rated
010-9343:
CEE7-7 to C19
250V, 16A EUROPE (Schuko)
2.5M, 1.5mm/3wire Harmonized

© 2008 Eaton Corporation. All Rights Reserved. All specifications are subject to change without notice.
www.pulizzi.com • [email protected] • 800-870-2248 • Fax: [phone]
6
IPC3401
IPC3402
Drawings are
not shown to scale
Dimensions
are in inches
