IPLINX IPEX2001 User manual

11675 Ridgeline Dr.
Colorado Springs, CO 80921
Rev 160714 Toll-Free: 800-530-8998
Fax: 719-260-0075
supportlibav@libav.com
IPEX2000 Series Installaon Guide


IPEX2000 Series Installaon Guide
3
1. Read these instrucons – All the safety and operang instrucons should be read before this product is operated.
2. Keep these instrucons – The safety and operang instrucons should be retained for future reference.
3. Heed all warnings – All warnings on the appliance and in the operang instrucons should be adhered to.
4. Follow all instrucons – All operang and use instrucons should be followed.
5. Do not use this apparatus near water – The appliance should not be used near water or moisture – for example, in a wet
basement or near a swimming pool, and the like.
6. Clean only with a dry cloth.
7. Do not block any venlaon openings. Install in accordance with the manufacturer’s instrucons.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers)
that produce heat.
9. Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one wider than the other.
The wide blade or the third prong is provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched parcularly at the plugs, convenience receptacles, and at the
point where it exits from the apparatus.
11. Only use aachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the
apparatus. When a cart or rack is used, use cauon when moving the cart/ apparatus combinaon to avoid injury
from p-over.
13. Unplug the apparatus during lighng storms or when unused for long periods of me.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any
way, such as; the power-supply cord or plug is damaged, liquid has been spilt or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. CAUTION: Servicing instrucons are for use by qualied service personnel only. To reduce the risk of electric shock, do
not perform any servicing other than that contained in the operang instrucons unless you are qualied to do so.
16. Do not install this equipment in a conned or built-in space such as a book case or similar unit. The equipment must
remain in well venlaon condions. Venlaon should not be impeded by covering the venlaon openings with items
such as newspaper, table-cloths, curtains etc.
17. WARNING: Only use aachments/accessories (such as the baery etc.) specied or provided by the manufacturer.
18. WARNING: Refer to the informaon on the underside of the enclosure for electrical and safety informaon before
installing or operang the apparatus.
19. WARNING: To reduce the risk of re or electric shock do not expose this apparatus to rain or moisture. The apparatus
shall not be exposed to dripping or splashing and objects lled with liquids, such as vases, shall not be placed on apparatus.
20. CAUTION: Danger of explosion if baery is incorrectly replaced. Replace only with the same or equivalent type.
21. WARNING: The baery shall not be exposed to excessive heat such as sunshine, re or the like.
22. WARNING: The all-pole mains switch located on rear panel is used as the disconnect device, the switch shall remain
readily operable.
23. WARNING: DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD.
24. Keep new and used baeries away from children. If the baery compartment does not close securely, stop using the
product and keep it away from children.
25. If you think baeries might have been swallowed or placed inside any part of the body, seek immediate medical
aenon.
Important Safety Instrucons

IPEX2000 Series Installaon Guide
4
26. When the apparatus is not in use or during its relocaon, take care of the power cord and plugs; e.g. e up the power
cord with cable e or similar. The e must be free from sharp edges and the like that might cause abrasion of the power
cord. When put into use again ensure the power cord and plugs are not damaged. If any damage is found the power cord
and plugs should be replaced by items either specied by the manufacturer or that have same characteriscs as the original
items.
27. This lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sucient magnitude to
constute a risk of electric shock.
28. WARNING: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts
inside. Refer servicing to qualied personnel.
29. The exclamaon point within an equilateral triangle is intended to alert the user to the presence of important
operang and maintenance instrucons in the literature accompanying the appliance.
30. Protecve earthing terminal. The apparatus should be connected to a mains socket outlet with a protecve
earthing connecon.
31. CAUTION: To prevent electric shock hazard, replace grille. (CSA 60065, clause 5.3A)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR

IPEX2000 Series Installaon Guide
5
Table of Contents
Important Safety Instrucons ��������������������������������������������������������������������������������������������������������������������������� 3
Product Overview��������������������������������������������������������������������������������������������������������������������������������������������� 6
IPEX2001 Encoder ����������������������������������������������������������������������������������������������������������������������������������������������� 6
IPEX2002 Decoder����������������������������������������������������������������������������������������������������������������������������������������������� 6
Package Contents per Device ���������������������������������������������������������������������������������������������������������������������������� 6
Front and Rear Panels��������������������������������������������������������������������������������������������������������������������������������������� 7
IPEX2001 Front Panel������������������������������������������������������������������������������������������������������������������������������������������ 7
IPEX2001 Rear Panel������������������������������������������������������������������������������������������������������������������������������������������� 7
IPEX2002 Front Panel������������������������������������������������������������������������������������������������������������������������������������������ 8
IPEX2002 Rear Panel������������������������������������������������������������������������������������������������������������������������������������������� 8
System Consideraons�������������������������������������������������������������������������������������������������������������������������������������� 9
Gigabit Switch Features �������������������������������������������������������������������������������������������������������������������������������������� 9
Gigabit Switch Size(s) ������������������������������������������������������������������������������������������������������������������������������������������ 9
System Bandwidth ���������������������������������������������������������������������������������������������������������������������������������������������� 9
Gigabit Switch Expansion������������������������������������������������������������������������������������������������������������������������������������ 9
LAN Cabling������������������������������������������������������������������������������������������������������������������������������������������������������� 10
IPEXCB Controller ���������������������������������������������������������������������������������������������������������������������������������������������� 10
System Control �������������������������������������������������������������������������������������������������������������������������������������������������� 10
Heat and Venlaon ����������������������������������������������������������������������������������������������������������������������������������������� 10
Backup Power ��������������������������������������������������������������������������������������������������������������������������������������������������� 10
HDMI CEC���������������������������������������������������������������������������������������������������������������������������������������������������������� 10
Source Content Resoluon �������������������������������������������������������������������������������������������������������������������������������� 10
Installaon Instrucons���������������������������������������������������������������������������������������������������������������������������������� 11
Basic Installaon����������������������������������������������������������������������������������������������������������������������������������������������� 11
RS232 Connecons�������������������������������������������������������������������������������������������������������������������������������������������� 11
Audio Output Connecons �������������������������������������������������������������������������������������������������������������������������������� 11
General Operaon������������������������������������������������������������������������������������������������������������������������������������������ 13
Matrix, Switch, Distribuon Amplier��������������������������������������������������������������������������������������������������������������� 13
Video Wall��������������������������������������������������������������������������������������������������������������������������������������������������������� 14
Updates and Troubleshoong������������������������������������������������������������������������������������������������������������������������� 15
Firmware Updates �������������������������������������������������������������������������������������������������������������������������������������������� 15
Device Reset������������������������������������������������������������������������������������������������������������������������������������������������������ 15
Troubleshoong ������������������������������������������������������������������������������������������������������������������������������������������������ 15
No Picture................................................................................................................................................... 15
No Audio..................................................................................................................................................... 15
IPEX2001 Technical Specicaons������������������������������������������������������������������������������������������������������������������� 17
IPEX2002 Technical Specicaons������������������������������������������������������������������������������������������������������������������� 18

IPEX2000 Series Installaon Guide
6
The IPLinx IPEX2001 transmits HDMI video and audio over a gigabit IP network using CBR or VBR h.264 AVC
encoding with a congurable data rate up to 30 Mbps. The IPEX2001 supports video signals up to 1920x1200
at 60 Hz. The IPEX2001 outputs two video streams: one large IP stream at the nave content resoluon and a
smaller video stream at 352x288 at 5 Hz to easily view a preview of the content on the IPLinx Control soware for
Windows and iPad. Up to 999 encoders may be used to create an incredible matrix or switching system within a
single installaon. An analog audio output port de-embeds the audio from the HDMI content, while sll streaming
the audio with the video content.
The IPEX2001 supports PoE and can be powered remotely by compable power source equipment, such as a
PoE Ethernet switch, eliminang the need for a nearby power outlet. Encoding control provides adjustments for
encoding bit rate and quality. The RS232 port operates in a pass-through capacity to control a third party device
such as a projector.
The IPEX2001 requires an IPEXCB control box and is compable with IPEX2002 and IPEX2003MV streaming
decoders.
The IPLinx IPEX2002 receives HDMI video and audio over a gigabit IP network using CBR or VBR h.264 AVC encoding
with a congurable data rate up to 30 Mbps. The IPEX2002 supports video signals up to 1920x1200 at 60 Hz. The
IPEX2002 outputs video up to 1920x1200 at 60 Hz and will scale the content based on the nave resoluon of
the connected display while seemlessly switching between sources. Up to 999 decoders may be used to create
an incredible matrix or distribuon system within a single installaon. Depending on the needs of the installaon,
mulple IPEX2002 devices can be congured to make a video wall up to a 16x16 conguraon. An analog audio
output port de-embeds the audio from the HDMI content, while sll passing the audio to the HDMI output.
The IPEX2002 supports PoE and can be powered remotely by compable power source equipment, such as a
PoE Ethernet switch, eliminang the need for a nearby power outlet. Encoding control provides adjustments for
encoding bit rate and quality. The RS232 port operates in a pass-through capacity to control a third party device
such as a projector.
The IPEX2002 requires an IPEXCB control box and is compable with the IPEX2001 streaming encoders.
Product Overview
Package Contents per Device
1. Installaon Guide
2. Power Supply with US, UK, EU, and AU adapters
3. 3-pin Removable Screw Terminal (2 ea)
4. Mounng Ears (2 ea)
IPEX2001 Encoder
IPEX2002 Decoder

IPEX2000 Series Installaon Guide
7
Front and Rear Panels
IPEX2001 Front Panel
12
1. Power indicator
2. Status indicator
IPEX2001 Rear Panel
A. 12V DC power input
B. RS232 Connecon
C. HDMI input
D. Analog audio output
E. LAN connecon with PoE support
F. Ground screw
A B C D E F

IPEX2000 Series Installaon Guide
8
IPEX2002 Front Panel
12
1. Power indicator
2. Status indicator
IPEX2002 Rear Panel
A. 12V DC power input
B. HDMI input
C. Local HDMI output
D. Analog audio output
E. RS232 connecon
F. Ground screw
A B C D E F

IPEX2000 Series Installaon Guide
9
System Consideraons
Gigabit Switch Features
Gigabit Switch Expansion
Gigabit Switch Size(s)
System Bandwidth
A high quality, managed Level 2 gigabit switch with a high bandwidth backplane should be used in the installaon,
preferably with PoE support. The two primary features to look for in the switch are support for mulcast with
jumbo frames and support for IGMP snooping, which are required technologies for stable video signals.
Be sure to verify the PoE gigabit switch can provide 15.4 was to each output under full load. Some switches
support 15.4 was per output but do not have enough available power under full load. For a 24 port switch, it
should be able to provide about 370 was to the LAN ports (24 x 15.4 = 369.6) plus power for the switch.
Quite oen, a switch will not have enough ports for a complete installaon. There are two methods to connect
switches together to expand the number of ports: cascading and stacking.
Cascading refers to connecng the copper LAN port from one switch to another. This is a low cost method of
expanding the number of ports, but the bandwidth is limited to the speed of the LAN port, which will become an
issue if there are more than 25 sources.
Stacking refers to connecng the ber SFP port from one switch to another. This is a slightly more expensive
opon, but it does not interfere with the number of LAN ports needed for the installaon. The SFP port on modern
switches will oen support 10 Gbps, which should be enough bandwidth for approximately 250 sources.
When calculang the size of switch needed, the following devices need to be considered:
If the installaon requires 14 sources and 10 displays, a 24 port switch will not have enough ports for the installaon,
because there are no open ports for the IPEXCB.
1. Number of sources
2. Number of displays
3. IPEXCB
4. Wireless access point for iPad app or Windows app (oponal)
5. Hardwire port for Windows app (oponal)
40 Mbps should be considered when calculang the bandwidth for the highest quality video seng. This value
covers the maximum quality 30 Mbps encoded stream plus packet overhead. Six 1080p sources using the highest
quality video seng will be using approximately 240 Mbps of eecve bandwidth on the backplane.
When conguring the IPEX2001 in the IPEXCB, the encoding method (CBR or VBR) can be changed as well as the
bandwidth of the signal. CBR is Constant Bit Rate. In a CBR h.264 stream, the encoder uses the same amount of
bits for every second of video. If you set the IPEX2001 to CBR at 10 megabits per second, every second of video will
use 10 megabits per second of bandwidth regardless of the content. A sll image will use the same bandwidth as
a moving image.
VBR is Variable Bit Rate. In a VBR h.264 stream, the encoder will transmit dierent bit rates of data depending on
how much informaon is present or has changed from frame to frame of video, while averaging the stream to the
bandwidth set. If you set the IPEX2001 to VBR at 10 megabits per second, every frame of video will use varying
bandwidth based on how much informaon has changed from frame to frame. A sll image will use less bandwidth
than a moving image.

IPEX2000 Series Installaon Guide
10
IPEXCB Controller
System Control
Heat and Venlaon
Backup Power
HDMI CEC
LAN Cabling
Source Content Resoluon
In addion to the gigabit switch, the IPEXCB is required for the encoders and decoders to communicate with each
other regardless of system layout, such as one to many.
There are mulple ways to control the system once installaon is complete. There is the IPLink Control soware for
iPad and Windows. While not recommended, the IPEXCB can be controlled through a web browser. A third party
controller can communicate directly with the IPEXCB via the LAN (CONTROL) port or via RS232.
All electronics generate heat, and excessive heat can cause electronic devices to fail prematurely. The IPEX2001
and IPEX2002 devices are passively cooled and should not be stacked on top of each other or other devices. Please
leave at least 1 ½ inches (approximately 35-40 mm) of open space by the side vents to provide adequate airow.
The gigabit switch will likely have acve cooling. Please follow the manufacturer’s installaon instrucons for
proper mounng in an equipment rack.
It is always a good pracce to install a high quality UPS (uninterrupble power supply) with line ltering with
expensive electronics. The UPS can provide “clean” power to all the devices in the equipment rack while also
providing enough me to properly shut down connected devices in the event of an extended power failure.
The IPEX2002 can turn on and turn o connected displays via CEC. This technology has been a part of the HDMI
specicaon for years. The IPLinx Control soware for Windows and iPad can turn on and o the displays for easy
end user control.
For all LAN cabling, the EIA/TIA-568B crimp paern must be used on Category 5e or greater cable. In areas with
large amounts of electromagnec (EM) or radio frequency (RF) interference, a shielded variety of Category 5e or
greater cable is recommended with shielded connectors on both ends of the selected cable.
Even though the IPEX2000 series devices support 1080i, this resoluon may cause arfacts through the encoding
process. Please set the output resoluon of devices showing 1080i content to 720p or 1080p.
TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8

IPEX2000 Series Installaon Guide
11
Installaon Instrucons
Basic Installaon
1. Congure the gigabit switch for IP video operaon. Liberty has guides for many common switch manufacturers
on the IPEXCB page on the Liberty website (www.libav.com).
2. Turn o power and disconnect the audio/video equipment by following the manufacturer’s instrucons.
3. Turn o power to the congured switch.
4. Connect Category 5E or greater twisted pair cable with the TIA/EIA-568B crimp paern between the LAN
port on the encoder(s) (IPEX2001) and the gigabit switch.
5. Connect Category 5E or greater twisted pair cable with the TIA/EIA-568B crimp paern between the LAN
port on the decoder(s) (IPEX2002) and the gigabit switch.
6. If the gigabit switch cannot provide power or enough power to the IPEX2001 or IPEX2002, connect the
included power supply to the 12V DC power input of the device. If the gigabit switch cannot provide enough
power, disable the PoE funcon of the connected LAN ports on the switch.
7. Connect an HDMI cable between the display and the decoder (IPEX2002).
8. Connect an HDMI cable between the source and the encoder (IPEX2001).
9. Power on aached audio/video devices.
10. Apply power to the gigabit switch.
11. If the gigabit switch cannot provide power to the IPEX2001 or IPEX2002, connect the included power supply
connected to the encoders and decoders to an AC outlet.
RS232 Connecons
Audio Output Connecons
To use the RS232 control transport capabilies of the IPEXCB or the RS232 extension capabilies of the IPEX2001
or IPEX2002, connect the TX, RX, and ground control signal wires to the removable 3-pole terminal block. Consult
the manual of the source or display device(s) to determine which pins the TX and RX signals are carried on. Be sure
to always connect TX to RX and RX to TX.
To use the analog audio outputs of the IPEX2001 or IPEX2002, connect the L, R, and ground wires to the removable
3-pole terminal block. Connect the other end of the cable to an audio amplier.
TX
G
RX
RXD
TXD
GND
IPEX2001 or
IPEX2002
Source or
Display
L
R
G
L+
L-
R-
R+
IPEX2001 or
IPEX2002 Amplier

IPEX2000 Series Installaon Guide
12
Laptop Computer with
IPLinx Control
Media Player
Switch
Display
Amplifier
IPEX2001 IPEX2002
IPEXCB
Audio/Video Input
Device Control
System Control
System Control
Audio/Video Output
Streaming Media
Streaming Media
Amplifier
iPad with
IPLinx Control
Wireless Access
Point
Video Ethernet RS232 / USB / IR Analog Audio

IPEX2000 Series Installaon Guide
13
General Operaon
Matrix, Switch, Distribuon Amplier
With mulple encoders and decoders, an IPEX2000 series installaon can be congured to be a video matrix, video
switch, and a distribuon amplier. The video conguraons and signal routes can be easily changed through the
IPLinx Control soware for Windows and iPad or through a third party controller.
Please see the IPEXCB user manual for conguring this funconality.
IPEXCB
IPEX2001
IPEX2002
IPEX2002
IPEX2002
IPEX2001
IPEX2001
IPEX2001
Third Party Controller
Windows PC with
IPLinx Control
Switch
Apple TV
Set top box
Media player
Workstation
Display
Audio/Video Input
System Control
Audio/Video Output
iPad with
IPLinx Control
Wireless Access
Point
Amplifier
Display
Display
IPEX2002
Display
Video Ethernet RS232 Analog Audio

IPEX2000 Series Installaon Guide
14
Video Wall
In addion to matrix conguraons, mulple IPEX2002 devices can be congured to make a video wall up to 16x16
in size. This funconality is also managed through the IPLinx Control soware for Windows and iPad or through a
third party controller.
Please see the IPEXCB user manual for conguring this funconality.
IPEXCB
IPEX2001
IPEX2002
IPEX2002
IPEX2002
IPEX2001
IPEX2001
IPEX2001
Third Party Controller
Windows PC with
IPLinx Control
Switch
Apple TV
Set top box
Media player
Workstation
Display
2x2 Video Wall
Audio/Video Input
System Control
Audio/Video Output
iPad with
IPLinx Control
Wireless Access
Point
Video Ethernet RS232 Analog Audio
Amplifier
IPEX2002
Display

IPEX2000 Series Installaon Guide
15
Firmware Updates
Device Reset
Troubleshoong
No Picture
No Audio
Firmware updates for the IPEX2001 and IPEX2002 are handled through the IPLinx Updater soware, which can
be found on the IPEXCB page of the Liberty website. Please see the documentaon included with the soware to
update the encoders and decoders.
Reseng the IPEX2001 and IPEX2002 is handled through the IPLinx Cong soware. Please see the documentaon
included with the soware to reset the encoders and decoders to factory defaults.
1. Verify all devices are powered on.
2. Verify LAN cable connuity between devices.
3. Verify the STATUS LED is lit on the encoders and decoders.
4. Verify the encoders and decoders are congured properly in the IPLinx Cong soware.
5. Verify the source and display devices work correctly without signal extension.
6. Verify the display is set to the correct input.
7. If the source content is HDCP encrypted, verify the display supports HDCP.
8. Verify the output resoluon of the decoder matches the display resoluon in the IPLinx Cong soware.
9. Verify that only one power source is used with the encoders and decoders. using the included power supplies
with a PoE switch that is providing PoE will cause stability issues.
1. Verify all devices are powered on.
2. Verify LAN cable connuity between devices.
3. Verify the STATUS LED is lit on the encoders and decoders.
4. Verify the encoders and decoders are congured properly in the IPLinx Cong soware.
5. Verify the source and display devices work correctly without signal extension.
6. Verify the source audio output is set to Stereo output.
7. If the source content is HDCP encrypted, verify the display supports HDCP.
8. Verify the output resoluon of the decoder matches the display resoluon in the IPLinx Cong soware.
9. Verify that only one power source is used with the encoders and decoders. using the included power supplies
with a PoE switch that is providing PoE will cause stability issues.
Updates and Troubleshoong

IPEX2000 Series Installaon Guide
16

IPEX2000 Series Installaon Guide
17
IPEX2001 Technical Specicaons
Input/Output Connecons
HDMI Input One (1) HDMI Type A Receptacle
LAN One (1) 8P8C port (Shielded RJ45)
Power One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel
RS232 Port One (1) 3-pin Removable Terminal Block Connector
Audio Output One (1) 3-pin Removable Terminal Block Connector
Supported Audio, Video and Control
Video Resoluons SMPTE: 480p, 576p, 720p, 1080i, 1080p
VESA: Resoluons up to 1920x1200
Color Depth: 24, 30, 36 bit
Video Compliance HDMI 1.3 and HDCP 1.3
Embedded Audio PCM 2 channel
ARC (Audio Return Channel) No
HEC (HDMI Ethernet Channel) No
CEC (Consumer Electronics Control) Yes
Supported Baud Rates 2400, 4800, 9600, 19200, 38400, 57600, 115200
Streaming Signal Characteriscs
Maximum Distance (point to point) 100 m (328 )
Cable Requirements Category 5e or greater with TIA/EIA-568B crimp paern
Encoding Data Rate 2 Mbps to 30 Mbps
Encoding Method CBR or VBR
End to End Latency Low Latency/Quality Mode: 79 ms
High Quality Mode: 250 ms
Maximum Supported Encoders 999
Maximum Video Wall Size 16 x 16
Chassis and Environmental
Construcon Black Steel
Dimensions (H x W x D) 25 mm x 237 mm x 94.3 mm (0.98in x 9.33 in x 3.71 in)
Operang Temperature 0° to +40° C (+32° to +104° F)
Operang Humidity 20% to 90%, Non-condensing
Storage Temperature -10° to +60° C (+14° to +140° F)
Storage Humidity 20% to 90%, Non-condensing
Power and Regulatory
Power Input 12V DC 1A or 48V DC PoE (Power over Ethernet)
Power over Ethernet (PoE) Compability 802.3af Alternave A
Power Consumpon 10 was
ESD Protecon 8kV air, 4kV contact
Regulatory FCC, CE, RoHS
Other
Warranty 2 years
Diagnosc Indicators Power and Status
Included Accessories Installaon Guide, Power Supply with US, UK, EU, and UK adapters, 3-pin Removable Screw
Terminal (2 ea), Mounng Ears (2 ea)
IP Controller IPEXCB
Compable Decoders IPEX2002, IPEX2003MV
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF and electrical interference, and cable
patches.

IPEX2000 Series Installaon Guide
18
IPEX2002 Technical Specicaons
Input/Output Connecons
HDMI Output One (1) HDMI Type A Receptacle
LAN One (1) 8P8C port (Shielded RJ45)
Power One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel
RS232 Port One (1) 3-pin Removable Terminal Block Connector
Audio Output One (1) 3-pin Removable Terminal Block Connector
Supported Audio, Video and Control
Video Resoluons SMPTE: 480p, 576p, 720p, 1080i, 1080p
VESA: Resoluons up to 1920x1200
Color Depth: 24, 30, 36 bit
Video Compliance HDMI 1.3 and HDCP 1.3
Embedded Audio PCM 2 channel
ARC (Audio Return Channel) No
HEC (HDMI Ethernet Channel) No
CEC (Consumer Electronics Control) Yes
Supported Baud Rates 2400, 4800, 9600, 19200, 38400, 57600, 115200
Streaming Signal Characteriscs
Maximum Distance (point to point) 100 m (328 )
Cable Requirements Category 5e or greater with TIA/EIA-568B crimp paern
Encoded Data Rate 2 Mbps to 30 Mbps
Encoded Method CBR or VBR
End to End Latency Low Latency/Quality Mode: 79 ms
High Quality Mode: 250 ms
Maximum Supported Decoders 999
Maximum Video Wall Size 16 x 16
Chassis and Environmental
Construcon Black Steel
Dimensions (H x W x D) 25 mm x 266.2 mm x 111.3 mm (0.98in x 10.48 in x 4.38 in)
Operang Temperature 0° to +40° C (+32° to +104° F)
Operang Humidity 20% to 90%, Non-condensing
Storage Temperature -10° to +60° C (+14° to +140° F)
Storage Humidity 20% to 90%, Non-condensing
Power and Regulatory
Power Input 12V DC 1A or 48V DC PoE (Power over Ethernet)
Power over Ethernet (PoE) Compability 802.3af Alternave A
Power Consumpon 10 was
ESD Protecon 8kV air, 4kV contact
Regulatory FCC, CE, RoHS
Other
Warranty 2 years
Diagnosc Indicators Power and Status
Included Accessories Installaon Guide, Power Supply with US, UK, EU, and UK adapters, 3-pin Removable Screw
Terminal (2 ea), Mounng Ears (2 ea)
IP Controller IPEXCB
Compable Encoder IPEX2001
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF and electrical interference, and cable
patches.

IPEX2000 Series Installaon Guide
19

IPLinx is a brand of:
11675 Ridgeline Drive
Colorado Springs, Colorado
80921 USA
Phone: 719-260-0061
Fax: 719-260-0075
Toll-Free: 800-530-8998
Email: supportlibav@libav.com
This manual suits for next models
1
Table of contents
