ATZ AC-2CT User manual

pg. 1 All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ AC-2CT
Description: Digital 2-Way Audio Converter (Coaxial<=>Toslink)

pg. 2 All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ AC-2CT
Description: Digital 2-Way Audio Converter (Coaxial<=>Toslink)
 Introduction
The Digital 2- ay audio converter is a Coaxial / Toslink audio converter, compact
and convenient. It accepts S/PDIF audio signal input through either Coaxial cable or
Toslink cable, and passes the signal (as is) to both its coaxial and Toslink output ports.
With its built-in amplification feature, It can also serve as a repeater of audio signal and
extend (double) the transferring distance.
 Features
1. Supports t o- ay conversion: Coaxial to Toslink or Toslink to Coaxial.
2. Supports amplification of S/PDIF audio and extends the transferring distance,
through coaxial and/or Toslink cables.
3. Select one input from Coaxial or Toslink input ports, and send S/PDIF audio
4. signal to both Coaxial and Toslink output ports simultaneously.
5. Compact size and easy to install.
 Package
1. Digital 2- ay audio converter
2. 5V DC Po er Supply Adaptor
3. Operation Manual
 Specifications
Input Ports 1 x Coaxial RCA Jack and 1 x Toslink (optical fiber) port
Output Ports
1 x Coaxial RCA Jack and 1 x Toslink (optical fiber) port
Dimension
66mm x 55mm x 20 mm
Weight 40g
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F
R
elative Humidity
20 ~ 90% RH (Non
-
condensing)
Po er Consumption (Max) 1W

pg. 3 All specifications are subject to change without prior notice.
© Copyright ATZ 2016
Model : ATZ AC-2CT
Description: Digital 2-Way Audio Converter (Coaxial<=>Toslink)
Operation controls and Functions
1. Optical IN: Connect the Optical input to an Optical digital audio source, such as a DVD.
2. Coaxial IN: Connect the Coaxial input to an Coaxial digital audio source, such as a
DVD.
. DC IN: Plug the 5V DC po er supply into the unit.
4. USB Power: Connect the USB po er port to any po ered USB ith a Mini-USB cable
or Mini-USB to AC adaptor.
5. Input switch: Select the Optical or Coaxial input.
6. Power LED: The LED ill illuminate hen connected to po er
7. Coaxial output: Connect the output ports to the Coaxial input port of audio
8. Optical output: Connect the output ports to the TOSLink (Optical Fiber) input port of
audio
Application Example
