Copyright 2011-2012. 1 C-47
Specifications & appearance are subject to change without notice. R201208-V20
6 Input to 12 Output BNC Video Distributor
Model: VD6212BNC
Features:
6 channel video signal input and 12 channel video signal output
Power: 12V DC
Application Diagram:
Panel View:
USER MANUAL
Copyright 2011-2012. 2 C-47
Specifications & appearance are subject to change without notice. R201208-V20
Specification:
Model
VD6212BNC
Connection Properties
Input Video
6x BNC, 0.7~1.4Vp-p, 75 Ohms
Output Video
12x BNC, 0.7~1.4Vp-p, 75 Ohms
Protection
Anti-Surge Capability
6000V 1.2/50 µS
Video Properties
Frequency Response
10MHz + 1dB
Gain Control
0 + 0.5dB
Differential Gain
< 1%
Differential Phase
< 1°
S/N
> 60dB
Power Properties
Power
12V DC + 5%
Physical Properties
Dimension L x W x H
143 x 58 x 37 mm / 5.63 x 2.28 x 1.46 inches
Weight
300 g / 10.6 oz
Environment
Operation Temperature
25°C ~ 70°C / 77°F ~ 158°F
Humidity
0~95% (non-condense)
*Specifications are subject to change without notice
Package Contents:
One (1) BNC Video DistributorAmplifier
One (1) User Manual
Caution:
Do not connect this device to any power source other than what is supplied.
Do not handle the unit with wet hands.
The unit is not waterproof and should not be used outdoors.
Limited Warranty:
LIMITED ONE (1) YEAR WARRANTY AND EXCLUSIONS
Manufacturer warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its
sale by Manufacturer is free of defects in materials and workmanship under normal and proper use for one (1) year from the
purchase date. Manufacturer's only obligation is to correct such defects by repair or replacement, at its option, if within such one (1)
year period the product is returned prepaid, with proof of purchase date, and a description of the problem. This warrant excludes
and there is disclaimed liability for labor for removal of this product or reinstallation. This warranty is voided if this product is
installed improperly or in an improper environment, overloaded, misused, opened, abused, or altered in any manner, or is
not used under normal operating conditions or not in accordance with any labels or instructions. There are no other
implied warranties of any kind, including merchantability and fitness or a particular purpose, but if any implied warranty is
required by the applicable jurisdiction, the duration of any such implied warrant, including merchantability and fitness of or a
particular purpose, is limited to one (1) year. Manufacturer is not liable for incidental, indirect, special, or consequential
damages, including without limitation, damage to, or loss of use of, any equipment, loss sales or profits or delay or failure
to perform this warranty obligation. The remedies, provided therein are the exclusive remedies under this warranty, whether
based on contract, tort or otherwise.
