IQ 1200 User manual

-1-
MODEL 1200 - USER MANUAL
The IQ model 1200 is a dual process trip
amplifier (sometimes called a dual alarmer)
which provides two adjustable relay outputs
from an analogue process signal (eg.
4~20mA). They offer an inexpensive method
of providing alarm and/or trip functions.
Changes have been made to the design over
the years, including the addition of extra
features, however new units may be used as
direct replacement for older units and are
totally pin compatible.
Amodel 1210 was produced for a short period
for special applications. This unit featured
programmable fail safe operation for 4-20mA
systemsbut the relay operation was limited to
de-energise on rise. The latest version of the
model 1200 now has this feature and the
model 1210 has been discontinued.
BASIC MODE OF OPERATION
Each relay output is associated with a set point knob on the front of the unit. The
set point knob may be calibrated directly in measured units (eg. 0-5volts) or,
more usually, as a percentage of the input signal (eg. 0-100% representing
4-20mA).
When the input signal exceeds either set point the related relay will change state.
When the input signal falls below the set point the relay will change back.
Whether the relay energises or de-energises on rise will depend on the setting of
DIP switches either on the front of the unit (newer models) or inside, accessed by
un-clipping the base (older models).
The hysteresis between relay energising and de-energising is typically 1.5% of
span.
Because the set point potentiometers are standard commercial types and the
scales on the knobs are small the absolute accuracy of the set point cannot be
guaranteed better than 5% of full scale. The repeat accuracy is however better
than 1% of full scale.
-2-
POWER SUPPLY
The majority of units are supplied for 230V 50Hz or 110V 50/60Hz operation and
are fitted with miniature transformers. A 24V DC supply is generated internally
and this is made available on pin 6 to power 4-20mA loops or other equipment.
The maximum rating for this output is 30mA and later model units have a current
limiter set at around 25mA to prevent this from being exceeded. Some earlier
models were not current limited and it is possible to damage these units by
drawing excess current from this pin.
Asmall number of units have been supplied with 24V DC power supplies, usually
for voltage inputs. In the case of a 24V DC unit, pin 10 (power supply negative)
is internally connected to pin 7 (input negative). This is not usually a problem for
voltage inputs where the 0V rail is normally the common, however is not
recommendedforcurrentinputs(eg.4-20mA)where+24Visusuallythecommon
as it is almost certain to lead to ground loop problems.
Units supplied with a 24V DC power supply have pin 6 (+24V out) connected to
pin 2 (+24V supply), either directly or through a current limiter.
RELAY OUTPUTS
The model 1200 is fitted with two independent SPDT relays with a contact rating
of 10A at 250VAC. Voltages up to 400V AC may be switched provided the total
VA rating does not exceed 2500VA.
The manufacturer’s specification on the relays is 105operations at full load and
107operations at no load, so for maximum life we recommend using an external
relay or contactor if the current is greater than 5 amps.
SELECTING RELAY OPERATION
Because both relays have SPDT contacts many electricians assume that their
required function can be achieved merely by the choice of the NO or NC
contacts. This approach, although reasonable in a perfect world, makes no
allowance for the possibility of unit failure.
The best choice of operating conditions is that both relays should be energised
during normal operation and should de-energise in a fault condition. This ensures
that should the unit or one of its relays fail, or should the unit lose power, a fault
condition will be indicated. Usually fault conditions are on rising signals (eg.
Over-temperature, high vibration) however sometimes low levels can indicate
faults (eg. Under-temperature, low pH). For that reason the relays of the model
1200 are independently programmable.

-3-
Relay Convention
Relay 1 is connected to pins 1, 3, 4 and is controlled by the upper set point knob.
Relay 2 is connected to pins 11, 9, 8 and is controlled by the lower set point knob.
Switch Programming
Old Models (Switch inside on PCB - unclip base). Side label IQ1200.0
Relay 1 - Switch 1 0 (down) = energise on rise 1(up) = de-energise on rise
Relay 2 - Switch 2 0 (down) =-energise on rise 1(up) = de-energise on rise
Later Models (Switch on front) without failsafe. Side label IQ1200.1
Relay 1 - Switch 1 0 (left) = energise on rise 1(right) = de-energise on rise
Relay 2 - Switch 2 0 (left) = energise on rise 1(right) = de-energise on rise
Models with Failsafe. Side Label IQ1200.2
Relay 1- Switches 1 & 3
Switch 1 Switch 3 Function
0 0 energise on rise - no failsafe
0 1 de-energise on rise - no failsafe
1 0 de-energise on rise - failsafe
1 1 energise on rise - failsafe
Relay 2 - Switches 2 & 4
Switch 2 Switch 4 Function
0 0 energise on rise - no failsafe
0 1 de-energise on rise - no failsafe
1 0 de-energise on rise - failsafe
1 1 energise on rise - failsafe
AN EXPLANATION OF “FAILSAFE” MODE.
The failsafe option only works for process signals with live zero eg. 4-20mA and
1-5V.
-4-
With failsafe off, the relay will be in one state above the set point and a different
state below it.
Let us consider an application where a set point must give an alarm when the
signal is greater than 50%. With a 4-20mA loop, currents over 12mA (50%) will
give an alarm and currents less than 12mA will not. 0% is represented by 4mA.
If the current loop were to break there would be 0mA in the loop which would not
give an alarm as it is still below 50%.
By selecting the failsafe option the alarm condition would be generated if the
current falls below 4mA as well as above 12mA, thereby providing a warning of
loop failure.
Failsafe action may be selected for either or both relays. Usually it would only be
used on one.
During installation and testing of 4-20mA loops, failsafe operation may cause
confusing results. We recommend that failsafe options be disabled until system
integrity has been confirmed.
HOW TO CONNECT THE INPUTS
There are three pins available on the input side, which sometimes causes
confusion as normally only two are used. Because of the limited space on the
connection label fitted to the unit it is impossible to show all possible options.
Pin 5 This is the positive signal input. For voltage inputs this normally feeds
into a high impedance potential divider. Current inputs have a low value
(usually 250ohm) resistor connected internally between pin 5 and pin 7
through which the signal current passes. This pin is always used.
Pin 6 This is usually a 24V DC output which is used to drive 4-20mA current
loops. It is not normally used for voltage inputs.
Pin 7 This is the common pin which is connected to the 0V rail of the
electronics. This pin is used for voltage inputs and externally sourced
current inputs.
Note that pin 7 is always at the lowest potential. Pin 5 is positive with respect to
pin 7 but negative with respect to pin 6. Pin 6 is positive with respect to both pins
5 & 7.

-5-
Generally speaking the pins to use are as follows:-
Voltage inputs and externally sourced current inputs. Pin 5 + Pin 7 -
Internally sourced current inputs Pin 6 + Pin 5 -
eg. Two- wire transmitters powered from this unit.
INPUT INFORMATION
Voltage inputs are high impedance, typically better than 50kohms/volt. Units may
be connected in parallel to obtain more set points.
Current inputs are 250 ohm as standard. This allows a high impedance 1-5V
voltmeter to be connected across terminals 5 & 7 when indication is required.
Units may be connected in series to obtain more set points. When using the
internal 24V power supply, only one unit should power the loop (from pin 6). The
other units must be wired for external supply operation. (See drawings on page 7)
When connecting units in series, each unit will drop 5 volts at 20mA. As most
4-20mA loops are powered from 24V DC there is the possibility of having
insufficient voltage available to power everything in the loop. Lower impedance
units are available to special order in 100ohm, 47ohm & 22ohm. These can be
identified by their part numbers, ie. 1200-100 is the 100ohm version.
-6-
CONNECTION DIAGRAM
VOLTAGE INPUTS

-7-
CURRENT INPUTS
-8-
SPECIFICATIONS
INPUT SIGNAL
Options 4-20mA 0-20mA
0-5V DC
1-5V DC
0-10V DC
or to customer order
INPUT IMPEDANCE 4-20mA/0-20mA 250ohm
other values to order
0-5V/1-5V/0-10V >250kohm
RELAY RATING 10A 400V 2500VA
10A 30V DC
POWER SUPPLY
Options 110V 50/60Hz. 230V 50 Hz.
POWER CONSUMPTION 4VA approx. (old models 6VA).
TEMPERATURE LIMITS -5/+60°C
HUMIDITY LIMITS 0-90% RH
non condensing
SETTING ACCURACY 5% Typical
REPEATABILITY < 0.5%.
I.Q Instruments CC P.O. Box 1411 Randburg 2125
Tel. [phone] Fax. [phone]
http://www.iqinstruments.com [email protected]
