INSTRUCTION BOOK
XB10
www.iriver.co.kr
© 1999~2016 IRIVER Limited. All rights reserved.
Bluetooth Headphone AMP

XB10 Detachable
clip
Warranty &
Instruction
Manual
Micro-USB
Cable
What’s Inside
The items listed herein are subject to change
without prior notice for the purpose of
performance improvement or due to the
manufacturer's circumstance.
ENGLISH

Overall Structure
Skip Next/Previous Song Key
Bluetooth Key
Volume Control Key
Power/Lock Key
Micro-USB Port
(for Recharging) 3.5 mm Port
Play/Pause and Multi-key
2.5 mm Balance Port
Built-In Microphone
Status LED
Mounting the Clip
2. Please insert one
side of the clip
first and then
do the same
with the
other side.
3. Push the two side
slightly for a
snug fit.
1. Please remove the
rubber cover on the
bottom of the
product.

Turning the Device On/Off
Balance Port
You can listen to music by connecting with
an earphone or headphone that support the
balance cable (2.5 mm).
Micro USB connector (only charging)
Connect the device with 5V 2A adapter (sold
separately) or PC using Micro USB cable.
Charging starts.
Built-In Microphone
Supports phone call functionality.
1. Push the power key on the side of the
device to the right for 3 seconds and you
will hear a beep sound and see a blue light
on the indicator before the power is on.
2. Push the power key on the side of the
device to the right for 3 seconds while
the device’s power is on and you will hear
a beep sound and see a red light on the
indicator before the power is off.
Skip Next/Previous Song Key
Replays the next/previous song.
Power Key
To the right: You can turn the device on/off
by pushing the key to the right side for
about 3 seconds.
To the left: You can lock all keys by pushing
the key to the left side.
Volume Control Key
You can control the volume by using the
[+]/[-] keys.
Bluetooth Key
You can pair this device with other devices
equipped with Bluetooth functionality.
Play/Pause and Multi-key
You can replay or pause music and turn on/off
the DCT mode in the middle of replaying music.
Status LED
You can check power on/off, Bluetooth
pairing, DCT mode on/off, recharging status
through the LED indicator light.
Earphone Jack
You can listen to music by connecting with a
general-purpose 3.5-mm earphone or headphone.

5. Once pairing is completed, you will hear
a beep sound and see a flashing blue
light on the indicator with an interval of
3 seconds. You can replay music from a
device connected through Bluetooth.
6. Press and hold the [ ] key while paired
to switch to pairing standby mode for
connection with other devices.
When connected first time the device
goes directly to the pairing mode
immediately after the power is turned on.
The Bluetooth key will be disabled when
music is replayed or you are talking on
the phone.
For instructions on how to pair this product
with your device, please refer to Bluetooth
pairing instructions on each device.
The XB10 automatically reconnects to
the last connected device. If the last
device is not automatic reconnected,
find the XB10 from the desired device
to establish a connection.
During playback, long press action on
[ / ] key may not function properly
depending on the specifications of the
device to use.
The XB10 supports Qualcomm® aptX™ and
Qualcomm® aptX™ HD audio codec standards.
Qualcomm® aptX™ and Qualcomm® aptX™ HD
audio codecs only work on smartphones and
audio devices that support the technology.
1. You can turn on the power by pushing the
power key on the side of the device to
the right for 3 seconds.
2. Press the Bluetooth key for 3 seconds
and you will hear a beep sound and see
flashing blue and red lights alternately
before pairing is ready.
3. Turn on Bluetooth of the device with
which you want to connect.
4. Select this device on the list of devices
available for Bluetooth connection for
pairing.
Setting up iOS>Bluetooth>Select “XB10”
Setting up Android>Bluetooth>Select
“XB10”
Bluetooth Pairing
Qualcomm® aptX™ / Qualcomm® aptX™ HD audio

Listening to Music
Press the [ ] key once lightly. Press the
[ ] key once while the music is played.
If you want to start replaying again, press
it again.
When replaying music first time, you may
have to activate the music player of the
device to which this product is connected.
To play previous/next song, press the
[ ]/[ ] key briefly.
To fast-forward or rewind, press the [ ]
/[ ] key at length.
You can adjust the volume by pressing
the [ ]/[ ] key while replaying.
You can hear a beep sound when you
control the volume and you reach a
minimum/maximum volume level.
Press and hold the [ / ] key to adjust
the volume in increments.
Multi pairing
1. Have two devices (A&B) for multi pairing
ready.
2. Connect the first device (A) and XB10.
3. Press the Bluetooth key to enter the
pairing mode. (At this time, A that is
paired will be disconnected.)
4. Connect XB10 and the second device (B).
5. Select XB10 from the Bluetooth items of
A that was connected first.
6. Pair XB10 with both A and B.
Multi pairing supports up to two devices.
When two devices are multi-paired, you
must stop playing music from one device
before you play music on the other.

Talking on the Phone
1. Once the phone rings, you can take the call
by pressing the [ ] key in the product.
You can reject an incoming phone call
by pressing the [ ] key for 3 seconds.
2. While talking on the phone, you can hang
up by pressing the [ ] key.
3. When making a phone call, you can cancel
the call by pressing the [ ] key.
Resetting
1. If you experience a malfunction or freeze, you
can reset the system by pushing the power
key on the side to the right for 8 seconds.
Lock
1. If you push the power/lock key on the
side to the left, all keys would be locked.
If you push the key to the opposite side, all
keys would be unlocked. With this lock, you can
keep keys from being operated accidentally.
Press the [ ] key for 4 seconds and you
can hear a beep sound with blue and green
alternating lights before the DCT mode
is turned on.
Press the [ ] key for 4 seconds when
the DCT mode is on and you can hear a
beep sound before the DCT mode is
turned off.
The XB10 supports Distinctive Clear
Technology (DCT), a digital noise removal
technology, so that you can enjoy clearer
and crispier sound.
The DCT mode is operational only when
music is played.
CAUTION
Please do not keep higher volume for a
long time in order to avoid any possible
damage to your ears. For your safety,
do not use this product while driving or
cycling. It may cause hazard due to sound
insulation.

Status Indicator Light
Power on
The light turns blue and then flashes
Power off
Flashing red light
Bluetooth connection standby
Blue light flashing twice every 2 seconds
(status not connecting with the master)
Pairing standby
Blue and red light flashing alternately
(status connection with the master available)
Pairing complete
Blue light flashing once every 3 seconds
(status fully connected with the master)
Music replaying state
DCT off
Blue light flashing once every 5 seconds
DCT on Blue and green light flashing
alternately once every 5 seconds
Phone calling status
Blue light flashing once every 5 seconds
Status of a call incoming
Blue light flashing once every 0.5 second
1. You can recharge the product by inserting a
Micro USB cable that comes with the package
in the USB port located on its side. The indicator
shows a red light if it is being recharged and
it shows a blue light if it is fully charged.
If the battery power remains below 10
percent, a red light will flash on all
operational modes with a beeping sound.
Recharging
In some devices, you can find out the
remaining battery power on the upper-
side bar together with Bluetooth indication.

Product Name
Bluetooth Version
Bluetooth Profile
Frequency Band
Receiver Sensitivity
Slide Key
Button Key
Audio Codec
Audio Port
Size
Weight
Battery Type
Charging Method
Hours of Operation
Standby Time
Charging Time
Range
Operating Temperature
Certifications
AK XB10
Bluetooth 4.1, Class2
A2DP (multi), AVRCP, HFP, HSP
2.4 - 2.4835 GHz ISM Band
[email protected]%BER (typical)
Power/Lock
Pairing, Fast Forward,
Rewind, Play/Pause,
Volume Up, Volume Down
SBC, AAC, aptX, aptX HD
2.5-mm Balanced, 3.5-mm
Unbalanced
Ø50 x 12.3 mm (thickness) (circular)
Approx. 23g
3.7V 350mAh lithium polymer
rechargeable battery
Micro USB 5 Pin (5V 2A)
Approximately 5 hours for
music playing and phone calls
Up to 300 hours
Approximately 2 hours
Maximum of 10 meters
-10°C - 45°C (23°F - 113°F)
KC, FCC, CE, SRRC, BT SIG
Specifications
If you keep pressing the XB10 Bluetooth
key for 2 seconds on Bluetooth connection
standby or pairing completed with the
master, you can change it to pairing
standby and connect with another device.
Since rechargeable batteries are consumables,
they may not last as long as indicated
depending on operating environment,
and battery life may be gradually reduced.
Bluetooth operating distances vary with
the usage environment.
The use of this device with products
other than the specified compatible AK
products may cause malfunctions.
Status of a call outgoing
Blue light flashing once every 0.5 second
Charging
Red light on
Charging completed
Blue light on
Low battery
Red light on during all operating conditions

Precautions
Do not put heavy objects on the product.
If the product gets wet from rain (water),
beverage, liquid medicine, sweat or moisture,
never turn it on. Wipe it with dry cloth, and get
it checked at the nearest iriver service center
(Water-damaged devices may not be available
for free repair regardless of warranty status).
Avoid places with excessive moisture,
dust, or smoke.
Never disassemble, repair or alter the product.
Avoid exposing the device to direct
sunlight or extreme temperatures.
Do not keep the product next to strongly
magnetic objects like magnets, TVs,
monitors and speakers.
As chemicals or detergents change the
surface of the product and removes the
paint, never use them.
Do not drop the product or give a strong
shock to the product (places where there
is strong vibration. etc.).
Do not press two or more keys at the same time.
Troubleshooting
1. The device won't turn on.
Please check whether the power
adaptor is connected properly.
Please check whether the device is charged.
Charge with 5V 2A output adapter.
We recommend the use of the Micro
USB cable that comes with the package.
2.
No sound comes out except static and noise.
Please check whether the volume set at [0].
Please check whether the earphones are
plugged in properly, and make sure dust
isn't obstructing the port connection.
Please check the volume of the device
to which it is connected.
Please make sure that the music file
is not corrupted.
Please check whether Bluetooth
pairing is properly made.
Please find out whether there is any device
causing frequency interference nearby.
Please find the best signal receiving
location by moving the device slowly.
3. Bluetooth connection is not made.
Please maintain the distance between the
product with a Bluetooth device (maximum
signal receiving distance is 10 meters)
