IRO IKR1520DABBT User manual

IKR1520DABBT
DAB+ and FM Digital Radio with Bluetooth and NFC Technology
Instruction Manual

IKR1520DABBT THE CLASSIC LINE
2
Safety Instructions
Important Safety Instructions. Please read the
instructions carefully and keep them for later use.
CAUTIOU
N
The lightning flash with arrow head within
an equilateral triangle is intended to alert
the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of
electric shock to persons and animals.
The exclamation point within an
equilateral triangle is intended to alert the
user to the presence of important
operating and maintenance instructions in the literature
accompanying the device.
To reduce the risk of fire or electric shock, do not expose
the device to rain or moisture. Do not expose the device
to splashes or moisture. Do not place liquid filled objects,
e.g. vases, on top of the device.
For safety reasons, this class II appliance
is provided with double or reinforced
insulation as indicated by this symbol.
lThis product is only intended for audio
entertainment. Do not use the product for any other
purpose than described in this manual in order to
avoid any hazardous situation.
lImproper use is dangerous and will void any
warranty claim.
lFor household use only. Do not use outdoors.
lDanger! Excessive sound pressure from
earphones and headphones can cause hearing
loss. If you listen to loud music for a long time, your
hearing may be impaired. Set to a moderate
volume.
lDanger of suffocation! Keep all packaging
material away from children.
lOnly use under normal room temperature and
humidity conditions.
lThe product is only suitable for use at moderate
degrees of latitude. Do not use in the tropics or in
particularly humid climates.
lOutdoor antennas should be located away from
power lines.
lDo not move the product from cold into warm
places and vice versa. Condensation an cause
damage to the product and electrical parts.
lDo not use attachments or accessories other than
recommended by the manufacturer or sold with this
appliance. Install in accordance with this user
manual.
lWhen installing the product, leave sufficient space
for ventilation. Do not install in bookcases, built-in
cabinets or the like.
lThe ventilation should not be impeded by covering
the ventilation openings with items, such as
newspapers, table-cloths, curtains, etc. Do not
insert any objects into the product. Do not place
any electronic equipment or toys on the product.
Such items could fall from the top and cause
product damage and/or personal injury.
lDo not install near any heat sources such as
radiators, heat registers, stoves or other appliances
(including amplifiers) that produce heat.
lDo not apply excessive force to the front or top, as

IKR1520DABBT THE CLASSIC LINE
3
this could ultimately overturn the product.
lDo not shift or move the product when powered on.
lDo not touch, push or rub the surface of the product
with any sharp or hard objects.
lDanger! To reduce the risk of fire or electric shock,
do not expose this product to rain or moisture.
lThe product shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the product.
lCare should be taken so that no objects or liquids
enter the enclosure through openings.
lNo naked flame sources, such as lighted candles,
should be placed on the product.
lRefer all servicing to authorised service agent. Do
not attempt to repair the product yourself. Servicing
is required when the product has been damaged in
any way, such as the supply cord or plug are
damaged, liquid has been spilled, objects have
fallen into the product, the enclosure is damaged,
the product has been exposed to rain or moisture,
does not operate normally, or has been dropped.
lBefore connecting the product to a socket outlet,
make sure the voltage indicated on the product
corresponds to your local mains.
lIf the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or similarly
qualified person in order to avoid hazard.
lRegularly check if the supply cord, product or
extension cable is defective. If found defective, do
not put the product into operation. Immediately pull
the plug.
lPlace the supply cord and, if necessary, an
appropriate extension cable in such a way that
pulling or tripping over it is impossible. Do not allow
the supply cord to hang down within easy reach.
lDo not jam, bend or pull the supply cord over sharp
edges.
lOnly use the provided adaptor.
lThe adaptor power plug is used as the disconnect
device; the disconnect device shall remain readily
operable. To completely disconnect the power input,
disconnect the adaptor power plug.
lThe product may not function properly or not react
to the operation of any control due to electrostatic
discharge. Switch off and disconnect the appliance;
reconnect after a few seconds.
lProtect the supply cord from being walked on or
pinched particularly at the plug, convenience
receptacles and the point where it exits from the
product.
lNever pull the adaptor power plug by the supply
cord or with wet hands.
lDisconnect the adaptor power plug in case of faults
during use, during lightning storms, before cleaning
and when not using the product for a longer period
of time.
lDanger! Before cleaning, switch the product off
and disconnect the adaptor power plug from the
socket.
lWhen the product has reached the end of its
service life, make it defective by disconnecting the
adaptor power plug from the socket and cutting the
cord in two.

IKR1520DABBT THE CLASSIC LINE
4
Parts
A. Carrying loop
B. VOLUME –button
C. MODE button
D. INFO/MENU button
E. VOLUME + button
F. Display
G. TUNE –button
H. PRESET button
I. SELECT button
Accessories
1 x DAB/FM radio and Bluetooth speaker
1 x Power adaptor with DC cable and plug
1 x AUX cable
1 x Instruction manual
1 x Quick start guide
J. TUNE + button
K. NFC chip
L. ON/OFF button
M. Audio-IN (AUX IN)
N. Headphone jack (3.5 mm)
O. Micro USB power input
P. Stand feet (not shown)
Q. Loudspeaker
R. Antenna (not shown)

IKR1520DABBT THE CLASSIC LINE
5
Connections
CHARGING BATTERY
1) Plug the Micro USB connector into the Micro USB
charging socket on the radio. Connect the USB A
connector with an active USB port or to the provided
adaptor. Plug the adaptor to an outlet.
Note: The radio can be operated via the in-built
batteries. Playing time is dependent on parameters
such as mode, volume, etc.
HEADPHONES
2) Headphones with a 3.5 mm jack can be connected
to the headphone output.
Note: When headphones are connected the
loudspeaker will be silent.
AUX IN
3) You can also listen to external audio devices by
connecting the cable (not included in delivery) into
the AUX IN jack.
Settings
ADJUSTING THE AERIAL
4) Pull out the aerial, turn and swivel it so it faces
upwards for best reception.
VOLUME
5) You can adjust the volume of the speaker or
headphones (if connected) using the VOL–/+
button.
LANGUAGE
6) You can set the language for the menu navigation
here.
1. Press and hold the INFO/MENU button, using
the TUNE +/-button switch to System appears in
the display and confirm by pressing SELECT.
2. Using the TUNE +/– button, scroll down the
menu until you reach Languages and confirm by
pressing SELECT.
3. Choose the language required using the TUNE
+/–button and confirm by pressing SELECT. Press
the INFO/MENU button to exit settings mode.
CLOCK
7) You can set the time and date here.
1. Press and hold the INFO/MENU button until
System appears in the display and confirm by
pressing SELECT.
2. Using the TUNE +/–button, scroll down the
menu until you reach Time and confirm by pressing
SELECT.
3. Choose the required sub-menu and confirm by
pressing SELECT.
lSet 12/24 hour: Choose between 12/24 hour
format
lSet time: manual setting,
lAuto update: Choose between Update from
Any, Update from DAB, Update from FM and
No update,
lSet date format: Choose between
DD-MM-YYYY and MM-DDYYYY Choose
your settings by using the TUNE +/–button
and confirm by pressing SELECT.
Press the INFO/MENU button to exit settings
mode.

IKR1520DABBT THE CLASSIC LINE
6
SOUND
8) The sound settings can be accessed in each mode.
1. Press and hold the INFO/MENU button, using
the TUNE +/- button switch to System appears in
the display and confirm by pressing SELECT.
2. Scroll through the menu using the TUNE +/–
button until you reach Equaliser and confirm by
pressing SELECT.
lNormal, Classic, Jazz, Pop, Rock, Speech
l< My EQ...>: here you can individually adjust
the treble and bass. Confirm your selection by
pressing SELECT.
3. Press the INFO/MENU button to exit settings
mode.
FACTORY RESET
9) This section allows you to restore all original
settings.
1. Press and hold the INFO/MENU button, using
the TUNE +/- button switch to System appears in
the display and confirm by pressing SELECT.
2. Scroll through the menu using the TUNE +/–
button until you reach Factory Reset and confirm by
pressing SELECT.
3. Using the TUNE +/–button, choose between
<Yes> and <No> and confirm by pressing
SELECT.
OPERATION
10) To use the device, press the on/off switch.
Operation in various modes
AUX IN
11) This mode allows you to use the radio as a speaker
for an external device (e.g. mobile phone or MP3
player). Warning! Observe the relevant safety
information for use with other devices when
connecting an external device. Press the MODE
button several times until Auxiliary Input is shown
on the display. The device is now in AUX IN mode.
BLUETOOTH PLAYBACK MODE
This mode allows you to use the radio as a speaker for
an external device (e.g. mobile phone or MP3 player).
The signal is transmitted wirelessly via Bluetooth.
Note
Before playback, you must pair the radio (in this case the
Bluetooth receiver) and the device (transmitter).
COMPATIBILITY
This product is compatible with Bluetooth enabled mobile
phones and music devices. It features Bluetooth version
2.1+EDR. It also works with devices featuring other
Bluetooth versions that support e.g.
Wireless stereo listening
lA2DP (Advanced Audio Distribution Profile)
Wireless music control
lAVRCP (Audio/Video Remote Control Profile)

IKR1520DABBT THE CLASSIC LINE
7
PLAYBACK DEVICES WITH NFC
12) 1. Press the MODE button until Smart Device
appears on the display. The device is now in
Bluetooth mode.
2. If your playback device has an NFC chip, turn on
NFC and Bluetooth on your playback device.
3. Place your playback device’s NFC chip near the
NFC chip on the radio. A Bluetooth connection
between both devices will be automatically
established.
4. Begin playback.
Note:
By pressing the INFO/MENU button, information is
displayed about the track being played.
5. To end the Bluetooth connection, once again
place your playback device’s NFC chip next to the
NFC chip on the radio. The connection and
playback through the radio will be suspended.
PLAYBACK DEVICES WITH NFC
13) 1. If your playback device does not contain an NFC
chip, turn on Bluetooth only on your playback
device.
2. Press and hold the SELECT button on the radio
for 2 seconds until Discoverable appears on the
display.
3. Start your playback device or begin a search for
Bluetooth devices.
4. Pair your playback device with unit. The devices
will now be connected.
5. Begin playback.
Note:
By pressing the INFO/MENU button, information is
displayed about the track currently being played.
6. To end the Bluetooth connection, turn off
Bluetooth on the playback device.
DAB RADIO MODE
14) In this mode, the radio receives a digital signal and
displays information about the radio station, music
title, etc.
1. Press and hold the MODE button until DAB
appears on the display.
Note
When you turn on the radio for the first time, an
automatic DAB channel search is carried out. The
channel list is saved so that a new search does not
need to be carried out when you next turn on the
radio. Once the search is completed, the channels
are saved in alphabetical order. The first available
channel will be selected.
Note
If no DAB reception is currently available, change
the position of your device or adjust the aerial.
Press and hold the TUNE + button to start a new
search.
2. In DAB mode, press the TUNE + button to
navigate through the available DAB channels.
3. You can store the DAB channels in the program
memory. In DAB/channel list mode, press and
hold the PRESET button for 2 seconds. Use the
TUNE +/–button to select a program memory
between 1 and 10 and then press the SELECT
button to assign the channel.
4. Using the PRESET button, you can choose
between your saved program list and the
automatically created channel list.

IKR1520DABBT THE CLASSIC LINE
8
5. For additional settings in DAB radio mode, press the
INFO/MENU button. Choose the required menu item
by pressing the TUNE +/–button and confirm your
chosen settings by pressing SELECT.
lFull Scan: Automatic channel search of all
channels in the channel list
lManual tune: Frequencies can be manually
selected
lDRC (Dynamic Range Control): Adjust and
change the dynamic range
lPrune: Removes all invalid channels from the
channel list
lSystem: see section on Settings
VHF RADIO MODE
15) In this mode, the radio receives a VHF signal and
displays information about the radio station, etc.
1. Press and hold the MODE button until FM
appears on the display.
2. Press the TUNE +/–button to search through the
entire frequency band.
Note
If you hold the TUNE +/–for longer, this begins a
search which stops automatically once the next
station has been found.
3. Assign your chosen channel to the program
memory between 1 and 10. In FM mode, press and
hold the PRESET button for 2 seconds. Using the
TUNE +/–button, choose a program memory
between 1 and 10 and press the SELECT button to
assign the channel.
4. Using the PRESET button, you can switch
between your saved program list and the VHF
frequency band.
Cleaning and care
lUnplug the adaptor from the socket before cleaning
the unit.
lAttention! Do not let water penetrate into the unit.
lClean the housing with a lightly dampened cloth.
lDo not use sharp, scouring or aggressive cleaners.
lDo not use chemicals (such as gasoline or alcohol)
to clean the housing.
Disposal
Do not dispose of this appliance as unsorted
municipal waste. Return it to a designated
collection point for the recycling of WEEE. By
doing so, you will help to conserve resources and protect
the environment. Contact your retailer or local authorities
for more information.
Please dispose of batteries in an
environmentally friendly manner Do not put
batteries into the household waste. Please use
the return and collection systems in your community or
contact the dealer where you purchased the product.

IKR1520DABBT THE CLASSIC LINE
9
Specifications
POWER ADAPTOR
AC/DC adaptor
Input
Output
Radio
Lithium Battery
Input
Power consumption
DAB-Tuner
Tuning range
FM tuner
Tuning range
Tuning grid
Speaker
Output power (RMS)
Sound system
Connection
USB
AUX IN
Headphone
Bluetooth
Bluetooth Profile
Bluetooth Range
Bluetooth Version
Dimension (W x H x D)
Weight
: 100 - 240 V~, 50/60 Hz, 0.3 A
: 5 V 1.5A, USB-A
: 3.7 V 2100 mAh
: 5 V 1.5A
: 7 W
: 174 - 240 MHz
: 87.5-108 MHz
: 0.05 MHz
: 2 X 1.2 W
: Mono/Stereo
: Micro-USB
: 3.5 mm-jack
: 3.5 mm-jack
: A2DP and AVRCP
: Min. 8m
: v2.1+EDR, class 2
: Approx. 250 x 137 x 50 mm
: 733g (unit only)
