Iron & Oak MBHH2013F User manual

1
MBHH2013F
MODELS:
BHH2013GX
BHH3013GX
BHH3013GXF
Owner’s Manual
Instructions for Assembly, Testing, Operation,
Servicing and Storage
20 and 30 Ton Log Splitter: Outdoor hydraulic powered machine that
splits wood logs.
WARNING
READ and UNDERSTAND this manual completely before using log splitter.
All operators of this equipment must read and completely understand all safety information, operating instructions, maintenance
and storage instructions. Failure to properly operate and maintain the log splitter could result in serious injury to the operator and
bystanders from moving parts that can crush or cut, flying objects, burns, fire or explosion, escaping high pressure hydraulic fluid,
or carbon monoxide poisoning in particular, be aware of the following hazards.
Crush and Cut Hazards
Moving parts can crush and cut hands and fingers. Keep hands clear of ram, wedge, and logs while splitting.
High Pressure Hydraulic Fluid Hazards
High fluid pressures and temperatures are developed in hydraulic log splitters. Hydraulic fluid escaping through even a pin-
size hole opening can puncture skin and cause severe blood poisoning. Inspect hydraulic system regularly for possible leaks.
Never check for leaks with your hand while the system is pressurized. Seek medical attention immediately if injured by
escaping fluid.
Fire Hazards
If your log splitter is intended for use near an ignitable forest, brush, or grassy covered land, the engine exhaust should be
equipped with a spark arrestor. See the "Specifications" section of this manual to determine if your splitter already has a spark
arrestor. If not equipped, call Iron & Oak Product Support for ordering information.
Keep a fire extinguisher with you that is rated for ordinary combustibles and flammable liquids.
STOP!
ADD OIL TO ENGINE BEFORE USING: Engine is shipped without oil. DO NOT start log splitter without first adding oil.
ADD HYDRAULIC OIL: Your log splitter was shipped without hydraulic oil. Refer to Periodic Maintenance section of this manual
for instructions on filling the hydraulic reservoir.
PRIME THE PUMP: The pump on your log splitter needs to be primed before use. Refer to Initial Setup section for instructions.
INSPECT COMPONENTS: Closely inspect to make sure no components are missing or damaged.
See Initial Unpacking and Set-up for instructions and for whom to contact to report missing or damaged parts.
Any Questions, Comments, Problems or Parts Orders
Call Iron & Oak Product Support 1-800-817-1005
ITEM NUMBER: _____________________
SERIAL NUMBER: ___________________

2
Hazard Signal Word Definitions

3
Table of Contents
Hazard Signal Word Definitions................................................................................................................................................................2
Table of Contents.......................................................................................................................................................................................3
About Your Log Splitter............................................................................................................................................................................4
Safety Label Locations ..............................................................................................................................................................................5
Machine Component Identification ...........................................................................................................................................................7
Initial Setup................................................................................................................................................................................................8
Moving and Towing to the Job Site.........................................................................................................................................................10
Before Each Use –Inspection/Maintenance ............................................................................................................................................14
Before Each Use –Fueling ......................................................................................................................................................................17
Before Each Use –Work Site Selection and Set-Up ...............................................................................................................................18
Splitting Operation...................................................................................................................................................................................19
Storage.....................................................................................................................................................................................................24
Periodic Maintenance...............................................................................................................................................................................25
Troubleshooting.......................................................................................................................................................................................27
Specifications...........................................................................................................................................................................................28
Parts Breakdown –Exploded View –Rev E ...........................................................................................................................................29
Summary of Important Safety information for Operation........................................................................................................................31
Assembly Instructions..............................................................................................................................................................................36
Limited Warranty.....................................................................................................................................................................................47

4
About Your Log Splitter
Thank you for purchasing your Iron & Oak log splitter!
About Your Log Splitter:
This log splitter is a machine designed to split wood logs using a hydraulically powered moving ram.
The log splitter's gasoline engine is used to pressurize the hydraulic system.
This log splitter is designed to split logs lengthwise with the grain only.
This log splitter model is capable of splitting logs up to 24”long and 18”in diameter.
Your splitter can be used in the horizontal splitting position only:
When the splitter is set up to operate in the horizontal splitting position, a log is placed on the
horizontal beam and the ram moves horizontally into the end of the log to split it.
The technical specifications for your log splitter are provided in the Specifications section of this manual.
WARNING
This log splitter uses a high-pressure hydraulic system to generate a very strong splitting
force.
Read the manual completely before using the machine to understand how to safely operate
and maintain it.
Follow all safety precautions presented throughout this manual. A summary of important safety
information can be found at the end of this manual.
Contact Iron & Oak Product Support at 1-800-817-1005 for any questions about the appropriate
use of this log splitter and/or optional accessories.
Warranty Registration:
Please fill out and submit the warranty registration card so that we have your contact information for any
future product literature or replacement parts you may need.
Attention: All Rental Companies and Private Owners who loan this
equipment to others!
All persons to whom you rent/loan the log splitter must have access to and read this manual. Keep this owner's
manual with the splitter at all times and advise all persons who will operate the machine to read it. You must
provide instruction on how to safely operate the splitter and remain available to answer any questions a
renter/borrower might have.

5
Safety Label Locations
Always make sure safety labels are in good condition. If a safety label is missing or not legible, order new
labels or unsafe operation could result. Contact Iron & Oak Product Support at 1-800-817-1005
Ref#
Part #
Description
QTY
1
778609
Split Control Directions
1
2
787944
Small Pinch Point Warning
2
3
BR002653
Speed Limit
1
4
793025
Moving/Towing Instructions
1
5
BR002652
Hydraulic Fluid Notice
1
6
BR002621
Made in USA
1
7
N/A
Nameplate/Serial Number
1
8
777891
Escaping Fluid Warning
1
9
777896
Operation Instructions
1
10
786635
Burn Hazard Warning
1
11
39259
Carbon Monoxide Warning
1
12
777890
Fire Hazard Warning
1
13
778610
Log Splitter Warning
1
14
777888
Stuck Log Warning
1
15
788935
Fuel Fire Explosion Warning
1

6
Safety Label Locations
1
2
3
5
4
6
7
9
8
10
11
12
13
14
15
ESCAPING HIGH PRESSURE HYDRAULIC FLUID HAZARD
High fluid pressures and temperatures are developed in the
hydraulic system. Hydraulic fluid escaping through even a pin-size hole opening can puncture skin and cause blood poisoning.
Inspect hydraulic system regularly for leaks Never check for leaks with your hand while system is pressurized. Seek medical attention immediately if injured by escaping fluid.
©Northern Tool + Equipment Co. 1-800-270-0810
WARNING
PN 777891
POISONOUS GAS
This product's use gives off carbon
monoxide, an odorless gas that can kill you.
ONLY use outdoors and away
from air intakes.
NEVER use inside homes, garages,
or sheds. EVEN IF you run a fan or open doors and windows.
See product manual for more details.
©Northern Tool + Equipment Co. 1-800-270-0810 PN 39259
WARNING
Moving parts can crush and cut. Pieces can fly out while
splitting. Follow safety rules for operating the log splitter or serious injury could result.
READ the Owner's Manual completely before operating. Only one person should operate the log splitter. If an
assistant is helping to load logs, the operator should not actuate controls until the assistant is at least 10 ft away.
Stay in the designated OPERATOR POSITION while
actuating the controls.
Split wood in direction of the grain only. Hold bark side of logs when loading. Keep hands away from wedge, endplate/ram, and partly
split logs.
Never leave log splitter unattended during operation. Stay off slopes and slippery surfaces.
See additional safety rules in the Owner's Manual.
©Northern Tool + Equipment Co. 1-800-270-0810 PN 778610
WARNING
LOG STRIPPER
RETRACT WEDGE
TO REMOVE
STUCK WOOD
PINCH POINT
Keep hands clear of
wedge and
log stipper
©Northern Tool & Equipment Co. 1-800-270-0810
SPLIT CONTROL LEVER OPERATION

7
Machine Component Identification
Ref #
Description
Ref #
Description
1
Fender
8
Safety Chains
2
Cylinder
9
Hydraulic Oil Cap
3
Split Control Lever
10
Engine
4
Ram
11
Fuel On/Off
5
Beam
12
Support Leg
6
Wedge
13
Engine On/Off
7
2” Coupler
14
Return Line Filter

8
Initial Setup
IMPORTANT!
Engine is shipped without oil. DO NOT start the engine before adding oil.
See Assembly Instructions section of this manual to assemble the log splitter before setup.
Step One:
Inspect Log Splitter
Components
Closely inspect all log splitter components.
(See Machine Components section of this manual for diagram of components.)
If you have missing or damaged components, please contact Product Support at
1-800-817-1005.
Step Two:
Add Oil to Engine
Add oil to the engine. Using a funnel, add SAE 10W-30 oil up to the FULL mark
on the dipstick. (See engine Owner's Manual for oil capacity and location of fill cap.)
Step Three:
Add Hydraulic Oil
to Reservoir
WARNING: High fluid pressures and temperatures are developed in hydraulic log
splitters. Hydraulic fluid escaping through a pin-hole sized opening can burn or puncture
skin, resulting in wounds that could cause blood poisoning, infection, disability, gangrene,
amputation, or death. Therefore, the following instructions should be heeded at all times
when inspecting or servicing the hydraulic components of the log splitter.
NEVER check for leaks with your hand. Leaks can be located by holding a piece of
cardboard or wood (at least two feet long) with your hand at one end and passing the
other end near the suspected area (wear eye protection). Look for discoloration of the
cardboard or wood.
NEVER adjust the pressure of the pump or valve.
If injured by escaping fluid, no matter how small the wound is, see a doctor at once. A
typical injection injury may be a small wound that does not look serious. However,
severe infection or reaction can result if proper medical treatment is not administered
immediately by a doctor who is familiar with injection injuries.
IMPORTANT
The hydraulic system oil filter for your log splitter is not factory installed. Make sure the
filter is installed before attempting to fill the hydraulic tank or start the engine.
(Installation instructions are provided in the “Assembly Instructions” section and are also
printed on the side of the filter).
1. Remove hydraulic oil cap.
2. Refer to the Specifications section for approximate hydraulic oil capacity.
3. Fill reservoir with 10 wt AW32, ASLE H-150, or ISO 32 oil. Use a funnel
4. Check that oil level is full. Oil level should be approximately one inch from the top
of the tank. Replace oil fill cap once oil level is full.
Oil Fill Cap
Hydraulic oil

9
Initial Setup
Step Three:
Add Hydraulic Oil
to Reservoir
(continued)
5. Disconnect the spark plug wire from the spark plug. This prevents the engine from
starting until the hydraulic pump and cylinder are completely filled with oil. Make
sure the spark plug wire is held away from the spark plug with string or other
nonconductive material.
6. Push the valve control handle with one hand to the forward (extend) position
(towards the front of the cylinder). Pull on the starter grip recoil at least 20 times so
that hydraulic fluid has cycled through the pump.
7. Reconnect the spark plug wire to the spark plug.
8. Start engine and use control valve handle to extend and retract ram five (5) times to
remove air from the high pressure lines.
9. With ram retracted, check oil level again. Fill if necessary.
10. Replace hydraulic oil fill/vent cap.
WARNING: NEVER remove the hydraulic oil fill cap when the engine is
running or hot. Hot oil can escape causing severe burns. Allow log splitter to
cool completely before removing hydraulic oil fill cap.
Note: If the log splitter will be run for long periods of time in outdoor temperatures
above 70°F, we recommend changing the hydraulic oil to DEXRON III.
Step Four:
Lubricate Beam
Lubricate the surface of the beam with grease. This will help prevent wear between the ram
keepers and the beam.
Apply grease to the top of the beam and underneath the edge of the
beam, where the wear pads travel.

10
Moving and Towing to the Job Site
WARNING
The log splitter is heavy. It can crush and cause serious injury if it rolls out of control or
tips over.
Follow the instructions below for safely moving and towing the log splitter.
Moving the log splitter:
1. Engine Off
IMPORTANT: Make sure log splitter engine is off.
Never move the log splitter with its engine running.
2. Fuel Valve Off
(if equipped)
Turn fuel valve off to prevent carburetor flooding and reduce the chance of fuel
leakage. Refer to Engine owner's manual for fuel valve location.
3. Lock Support
Leg DOWN
Lock support leg in DOWN position before you move the log splitter.
4. Move Log
Splitter to
Work Site
Move log splitter by hand either directly to chosen work site or to vehicle hitch
for towing.
(See Step Three: Before Each Use - Work Site Selection and Set-Up)
Important Safety Instructions:
Hills. Do not move the log splitter up or down hills by hand—use a towing
vehicle.
No riding. Never allow anyone to sit or ride on the log splitter.
No cargo. Never transport cargo or wood on the log splitter.
