Ironton 79032 User manual

READ & SAVE THESE INSTRUCTIONS
1/3 HP Air Mover
with Power Outlets and Timer
Owner’s Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #79032

Page 2 of 12
Thank you very much for choosing an Ironton™product!
For future reference, please complete the owner’s record below:
Serial Number/Lot Date Code (if applicable): _____________________
Purchase Date: ____________________________________________
Save the receipt, warranty, and this manual. It is important that you read
the entire manual to become familiar with this product before you begin
using it.
This air mover is designed for certain applications only. Northern Tool
and Equipment is not responsible for issues arising from modification or
improper use of this product such as an application for which it was not
designed. We strongly recommend that this product not be modified
and/or used for any application other than that for which it was designed.
For technical questions, please call 1-800-222-5381.

Page 3 of 12
Table of Contents
Intended Use..........................................................................................................................................4
Packaging Contents..............................................................................................................................4
Technical Specifications......................................................................................................................4
Important Safety Information...............................................................................................................4
Specific Operation Warnings...............................................................................................................6
Grounding..............................................................................................................................................7
Before Each Use....................................................................................................................................7
Operating Instructions..........................................................................................................................8
After Each Use.......................................................................................................................................8
Maintenance ..........................................................................................................................................8
Troubleshooting....................................................................................................................................9
Parts Diagram......................................................................................................................................10
Parts List..............................................................................................................................................10
Replacement Parts..............................................................................................................................10
Limited Warranty.................................................................................................................................11

Page 4 of 12
Intended Use
The Ironton 1/3 HP Air Mover is intended to move air to dry floors, walls, furniture, and other areas.
It’s durable and easy to operate with a static pressure and airflow balance making it ideal for a variety
of applications. It features:
•3 speeds with 4-angle drying positions (0°, 20°, 45°, 90°)
•Continuous and 3-hour timer settings
•Built-in outlets for connecting multiple units
•Stack up to four units for space-saving storage
•Easy-grip handle and wrap-around power cord design
Packaging Contents
•Air Mover
•Owner’s Manual
Technical Specifications
Property
Specification
Electric Motor
115 Volts / 60 Hz
Power
1/3 HP
Amp
3.8 Amps
Rated Airflow (on High)
2000 CFM
RPM (Low/Medium/High)
1000/1350/1600
Speeds
3
Important Safety Information
⚠WARNING
•Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
•The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
•Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
•Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
•Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use

Page 5 of 12
this equipment for a purpose for which it was not intended.
•Industrial or commercial applications must follow OSHArequirements.
⚠WARNING
WORK AREA SAFETY
•Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit.
Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas
may put you dangerously close to cutting tools and rotating parts.
•Do not use the product where there is a risk of causing a fire or an explosion; e.g., in the presence
of flammable liquids, gases, or dust. The product can create sparks, which may ignite the
flammable liquids, gases, or dust.
•Do not allow the product to come into contact with an electrical source. The tool is not insulated
and contact will cause electrical shock.
•Keep children and bystanders away from the work area while operating the tool. Do not allow
children to handle the product.
•Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your
work area. Some of these hazards may be hidden from your view and may cause personal injury
and/or property damage if contacted.
⚠WARNING
PERSONAL SAFETY
•Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use
the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating the tool may result in serious personal injury.
•Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts.Air vents on the tool often cover moving parts and should be avoided.
•Wear the proper personal protective equipment when necessary. Use ANSI Z87.1 compliant safety
goggles (not safety glasses) with side shields, or when needed, a face shield. Use a dust mask in
dusty work conditions. Also use non-skid safety shoes, hardhat, gloves, dust collection systems,
and hearing protection when appropriate. This applies to all persons in the work area.
•Do not overreach. Keep proper footing and balance at all times.
⚠CAUTION
AIR MOVER USE AND CARE
•Do not force the air mover. Products are safer and do a better job when used in the manner for
which they are designed. Plan your work and use the correct product for the job.
•Check for damaged parts before each use. Carefully check that the product will operate properly

Page 6 of 12
and perform its intended function. Replace damaged or worn parts immediately. Never operate the
product with a damaged part.
•Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with
the power switch is dangerous and must be repaired by an authorized service representative
before using.
•Disconnect the power/air supply from the product and place the switch in the locked or off position
before making any adjustments, changing accessories, or storing the tool. Such preventive safety
measures reduce the risk of starting the tool accidentally.
•Store the product when it is not in use. Store it in a dry, secure place out of the reach of children.
Inspect the tool for good working condition prior to storage and before re-use.
•Use only accessories that are recommended by the manufacturer for use with your product.
Accessories that may be suitable for one product may create a risk of injury when used with
another tool. Never use an accessory that has a lower operating speed or operating pressure than
the tool itself.
•Keep guards in place and in working order. Never operate the product without the guards in place.
•Do not leave the tool running unattended.
Specific Operation Warnings
⚠WARNING
•Electric shock hazard. DO NOT expose the unit to water.
•Risk of electric shock. Connect to a properly grounded outlet equipped with a Ground Fault Circuit
Interruption device (GFCI).
•Risk of fire. DO NOT operate in areas with flammable fumes. The fumes can spark, igniting fumes.
•DO NOT use the unit with any Solid-State Speed Control Device.
•DO NOT run the cord under carpeting. DO NOT cover the cord with throw rugs, runners, or similar
coverings.
•DO NOT route the cord under furniture or appliances. Arrange the cord away from traffic area and
where it will not be tripped over.
•DO NOT exceed 12 amps through the attached GFCI outlet.
•DO NOT allow more than 2 identical air movers (item #73032) to be connected to each other at
one time.
•DO NOT use an extension cord.
•Disconnect from the power supply before servicing.
•DO NOT block the air inlet or exhaust.
•DO NOT modify the grounded plug.
•DO NOT use if the cord or other parts are damaged.
•Ensure the power switch is off prior to plugging the air mover in power supply.

Page 7 of 12
Grounding
⚠WARNING
•This machine must be grounded while in use to protect the operator from electrical shock. This
unit is equipped with an electrical cord that has an equipment grounding conductor and a
grounding plug. The plug MUST be plugged into a matching receptacle that is properly installed
and grounded in accordance with ALL local codes and ordinances.
•DO NOT MODIFY THE PROVIDED PLUG. If it will not fit the receptacle, have the proper
receptacle installed by a qualified electrician.
•CHECK with a qualified electrician or service person if you do not completely understand the
grounding instructions, or if you are not sure the tool is properly grounded.
Grounded Tools: Tools with 3-Prong Plugs
Tools marked with Grounding Required have a 3-wire cord and 3-prong grounding plug. The plug
must be connected to a properly grounded outlet. If the tool should electrically malfunction or break
down, grounding provides a low resistance path to carry electricity away from the user, reducing the
risk of electric shock. (See Figure A.)
The grounding prong in the plug is connected through the green wire inside the cord to the grounding
system in the tool. The green wire in the cord must be the only wire connected to the tool’s grounding
system and must never be attached to an electrically live terminal.
Your tool must be plugged into an appropriate outlet, properly installed and grounded in accordance
with all codes and ordinances. The plug and outlet should look like those in the following illustration.
Double Insulated Tools: Tools with Two-Prong Plugs
Tools marked Double Insulated do not require grounding. They have a special double insulation
system which satisfies OSHA requirements and complies with the applicable standards of
Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code.
(See Figure B.)
Double insulated tools may be used in either of the 120-volt outlets shown in the following illustration.
Before Each Use
⚠WARNING
•Always inspect power cords for damage before operating.
•All air movers in operation must be supervised at all times.
•Do not allow more than 2 identical air movers (item #73032) to be connected to each other at one
time.

Page 8 of 12
This air mover is shipped ready-to-use. Prior to plugging the unit into the power source, completely
inspect it for any shipping damage.
Operating Instructions
1. Plug the electrical cord into the power outlet. To reduce the risk of electric shock, connect only to
an outlet provided with a Ground Fault Circuit Interrupter device.
2. Carefully place the air mover on a stable, flat, dry surface.
The unit has four position options to aim airflow across flat surfaces or angle it upward.
3. Turn the switch to select the desired speed, while making sure the unit operates properly.
All air movers in operation must be supervised at all times.
After Each Use
Always disconnect the air mover from its power source and wrap the cord around the handle. When
not in use, store the air mover in a dry, indoor space that is out of reach of children. Air movers can be
stacked up to 4 on their sides for storage.
Maintenance
⚠WARNING
•NEVER directly clean the air mover with water.
•ALWAYS disconnect air mover from its power source before performing any maintenance or
cleaning.

Page 9 of 12
Maintain the air mover by adopting a program of conscientious repair and maintenance in accordance
with the following recommended procedures. It is recommended that the general condition of any tool
be examined before it is used. Keep your tool in good repair. Keep handles dry, clean, and free from
oil and grease. The following chart is based on a normal operation schedule.
Maintenance Interval (NA)
Maintenance Point (NA)
Daily before operating
Check if the grill covers are clean. Remove dirt or any other
objects that could block the air inlet and air outlet.
After the first 50 operating hours or
every week
Use a damp cloth to wipe the surface of the housing. Do not
clean the unit with water directly.
Check if the grill covers are clean. Remove dirt or any other
objects that could block the air inlet and air outlet.
When not in use
Unplug and store the air mover in a dry and cool indoor area.
Make sure it’s out of reach of children.
Do not stack more than four units.
Troubleshooting
Use the table below to troubleshoot problems before contacting service personnel or your local
dealer. If the problem continues after troubleshooting, call your local dealer for assistance.
Failure
Possible Cause
Corrective Action
Air mover will not
run.
No power input.
Plug in the air mover. Check the circuit
breaker.
Switch is not turned on.
Turn the switch to ON.
Air mover fan has a wheel jammed.
Remove any material jamming the fan
wheel.
Intake or exhaust is blocked.
Turn the unit off and allow it to cool.
Remove the blockage.
Air mover
vibrates.
Accumulation of dirt on the fan blades.
Clean the air mover’s fan blades.

Page 10 of 12
Parts Diagram
Parts List
Reference
Number
Part Description
Availability
Quantity
1
Left Housing
No
1
2
Grid Cover (motor side)
Yes
1
3
Timer and Switch Plate
No
1
4-1
Switch Knob
Yes
1
4-2
Timer Knob
Yes
1
5-1
Switch
Yes
1
5-2
Timer
Yes
1
6
Motor
Yes
1
7
Right Housing
No
1
8
Power Cord
Yes
1
9
Fan
Yes
1
10
Grid Cover (fan side)
Yes
1
11
Air Outlet Grid Cover
Yes
1
12
Kick Stand
Yes
1
13
Rubber Feet (not shown)
Yes
4
14
Screws and Nuts (not shown)
Yes
41
15
Capacitor
YEs
1
Replacement Parts
•For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.
•Not all product components are available for replacement. The illustrations provided are a
convenient reference to the location and position of parts in the assembly sequence.
•When ordering parts, the following information will be required: item description, item model
number, item serial number/item lot date code, and the replacement part reference number.
•The distributor reserves the rights to make design changes and improvements to product lines
and manuals without notice.

Page 11 of 12
Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only
(''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both
materials and workmanship, normal wear and tear excepted, for a period of one year from date of
purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in
accordance with product instructions. There are no other warranties, express or implied, including the
warranty of merchantability or fitness for a particular purpose. If the product does not comply with this
limited warranty, Your sole and exclusive remedy is that We will, at our sole option and within a
commercially reasonable time, either replace the product or product component without charge to You
or refund the purchase price (less shipping). This limited warranty is not transferable.
Limitations on the Warranty
This limited warranty does not cover: (a) normal wear and tear; (b) damage through abuse, neglect,
misuse, or as a result of any accident or in any other manner; (c) damage from misapplication,
overloading, or improper installation; (d) improper maintenance and repair; and (e) product alteration
in any manner by anyone other than Us, with the sole exception of alterations made pursuant to
product instructions and in a workmanlike manner.
Obligations of Purchaser
You must retain Your product purchase receipt to verify date of purchase and that You are the original
purchaser. To make a warranty claim, contact Us at 1-800-222-5381, identify the product by make
and model number, and follow the claim instructions that will be provided. The product and the
purchase receipt must be provided to Us in order to process Your warranty claim. Any returned
product that is replaced or refunded by Us becomes our property. You will be responsible for return
shipping costs or costs related to Your return visit to a retail store.
Remedy Limits
Product replacement or a refund of the purchase price is Your sole remedy under this limited warranty
or any other warranty related to the product. We shall not be liable for: service or labor charges or
damage to Your property incurred in removing or replacing the product; any damages, including,
without limitation, damages to tangible personal property or personal injury, related to Your improper
use, installation, or maintenance of the product or product component; or any indirect, incidental or
consequential damages of any kind for any reason.
Assumption of Risk
You acknowledge and agree that any use of the product for any purpose other than the specified
use(s) stated in the product instructions is at Your own risk.
Governing Law
This limited warranty gives You specific legal rights, and You also may have other rights which vary
from state to state. Some states do not allow limitations or exclusions on implied warranties or
incidental or consequential damages, so the above limitations may not apply to You. This limited
warranty is governed by the laws of the State of Minnesota, without regard to rules pertaining to
conflicts of law. The state courts located in Dakota County, Minnesota shall have exclusive jurisdiction
for any disputes relating to this warranty.

Page 12 of 12
Distributed by:
Northern Tool & Equipment Company, Inc.
Burnsville, Minnesota 55306
www.northerntool.com
Made in China
