Iskratel SI2000 Ganymede 822+ User manual

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 1/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
SI2000 GANYMEDE 822+ ROUTER
USER GUIDE
Copyright©2006 Iskratel, Ltd.
A
ll rights reserved.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 2/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
INDEX:
1 GETTING STARTED 3
1.1 Package contents 3
1.2 Installation of hardware 3
1.2.1 Ports 3
WAN 3
RES (Reset button) 3
4 Ethernet 10Base-T/100Base-T ports 4
AC power socket 4
1.2.2 Light indicators 4
1.3 Preliminary setup 6
1.3.1 LAN and TCP/IP setup 6
User defined IP address 6
Obtain an IP automatically 7
1.4 WEB management connection 8
2 MANAGING SI2000 GANYMEDE 822+ ROUTER 10
2.1 Current status 10
2.2 Addressing 11
2.2.1 Changing the IP address of the SI2000 Ganymede822p 12
2.2.2 Changing the DHCP Server settings 15
2.3 Port Configuration 17
2.4 Advanced Security 20
2.4.1 PC names 21
2.4.2 Enabling and disabling applications 24
2.4.3 Default applications 26
2.4.4 Creating custom applications 27
2.4.5 Adding port ranges 30
2.5 Internet Access 31
2.5.1 Types of Internet Access 32
2.5.2 Automatically searching for a link 32
2.5.3 Manual Internet Access settings 33
2.5.4 PPP usernames and passwords 33
2.5.5 VPI and VCI values 34
2.5.6 MAC address spoofing 34
2.5.7 MAC addresses 35
2.6 DSL Port 36
2.7 Password 37
2.7.1 What are the requirements for the username? 40
2.7.2 What are the requirements for the password? 40
2.8 Reset to Defaults 41
2.8.1 When would I want to reset to defaults? 41

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 3/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
1 GETTING STARTED
1.1 Package contents
SI2000 Ganymede 822+ Router package comes with following items:
1. SI2000 Ganymede 822+ Router unit
2. AC adapter
3. Ethernet RJ-45 UTP cord
4. Phone RJ-11 cord
5. CD-ROM containing user's guide
1.2 Installation of hardware
1.2.1 Ports
The following figure shows the rear panel of your SI2000 Ganymede 822+ Router.
The rear panel of the SI2000 Ganymede 822+ Router
There are several data connectors and an AC power socket on the rear panel of the router.
WAN
This port is used for connecting the ADSL cable to your phone jack. Connect the SI2000 Ganymede
822+ Router to the ADSL port to access the Internet.
RES (Reset button)
This button is used to reset the configuration of the router to factory default values. You must hold
this button while the router is starting-up until ALM led will start flashing fast (about 30 seconds).
Ganymede 822+will use factory default settings only for the time it is running. If you want to
preserve factory default settings save the configuration.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 4/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
4 Ethernet 10Base-T/100Base-T ports
Use a straight-through or crossover ethernet cable (2.1.3Ethernet (UTP) cables) to connect your
SI2000 Ganymede 822+ Router to a computer or any other device. Up to four devices can be
connected to the router without using external ethernet switch. It is possible to manage the settings
of the router with telnet connection using this port. The factory setting for IP address is 192.168.1.1.
AC power socket
Plug the power cable to ensure power to the SI2000 Ganymede 822+ Router.
1.2.2 Light indicators
The following figure shows the front panel of your SI2000 Ganymede 822+ Router.
There are four LEDs on the front panel of the router that indicate the status of your SI2000
Ganymede 822+ Router. The description is given in table 1.
table 1: LEDs description
LED Status Description
PWR on Power on.
off Power off or fatal malfunction.
The front panel of the SI2000 Ganymede 822+ Router

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 5/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
LAN on At least one ethernet link is established. No ethernet
activity.
off No ethernet links established.
blinking Ethernet activity.
WAN on ADSL line is established.
off ADSL interface is not functional.
blinking slow ADSL interface is in handshake mode looking for
DSLAM
blinking fast ADSL interface detected DSLAM on the other side and
negotiating link parameters.
ALM on/blinking malfunction

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 6/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
1.3 Preliminary setup
1.3.1 LAN and TCP/IP setup
This section of the manual provides important information to keep in mind when setting up the first
connection between your computer and SI2000 Ganymede 822+ Router.
The factory default settings of the SI2000 Ganymede 822+ Router have values listed bellow:
Local IP address: 192.168.1.1
Subnet mask: 255.255.255.0
DHCP server: Disabled
User defined IP address
The default option is to set up the connection by yourself. In this case you must specify the IP
address of your system. Be careful that the subnet values of your system and the router are the
same, e.g. 192.168.1.0 (IP address 192.168.1.1 for router and IP address 192.168.1.2 for computer).
Example is shown on the picture bellow.
F
igure 1: User defined IP address set up for Local Area Connection on
computer

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 7/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
The IP address of the router can also be changed, you can learn about that under the WEB
management connection sections of the manual.
Obtain an IP automatically
If you enable DHCP server in Ganymede 822+, is the easiest way to set up a connection to
configure the LAN adapter on your system to obtain an IP automatically. This can be done in your
operational system by managing the Local Area Connection Properties. The TCP/IP protocol must
be installed on your system and set to obtain an IP address automatically. Example is shown on the
figure 7.
F
igure 2: IP obtain automatically set up for Local Area connection on computer

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 8/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
1.4 WEB management connection
SI2000 Ganymede 822+ Router has embedded WEB server included in the firmware. This section
of the document describes the basic principles on how to manage the settings of the SI2000
Ganymede 822+ Router using WEB management connection with any web browser.
To access Web management connection enter the URL at your web browser:
http://<ipaddress>
e.g. http://192.168.1.1
where <ipaddress> is the Local IP address of the SI2000 Ganymede 822+ Router, e.g.
192.168.1.1 for factory default settings. The IP addresses of router and computer must be
parts of the same IP network (e.g. 192.168.1.0).
You are asked to enter username and password:
Enter the user name user and password user. Click OK to continue.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 9/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
The Welcome page is displayed:

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 10/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
2 MANAGING SI2000 GANYMEDE 822+ ROUTER
2.1 Current status
The Current Status page displays useful current information about Ganymede822p. The page shows
the network addresses being used by Ganymede822p to connect to your PCs, and for your Internet
connection, as well as the version information for Ganymede822p.
The hardware version information is set by IskraTEL so the make and model of your device can be
quickly identified in the unlikely even that you need assistance.
The firmware version indicates what features are available on Ganymede822p. Occasionally, newer
versions of firmware are released which you can install by Checking for Updates.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 11/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
2.2 Addressing
An IP address is a unique value that identifies Ganymede822p. A subnet mask defines a range of IP
addresses for a given IP address.
Both IP addresses and subnet masks consist of four numbers. Each number in an IP address and
subnet mask is a value between 0 and 255.
More information about IP addresses and subnet masks can be found in the Ganymede822p User
Guide.
The Addressing page displays the IP address and subnet mask for Ganymede822p. These provide a
unique address for Ganymede822p, as well as giving it the range of addresses to use for other PCs
that are connected to Ganymede822p. Ganymede822p's default IP address and subnet mask is
suitable for most networks.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 12/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
2.2.1 Changing the IP address of the SI2000 Ganymede822p
You must provide an IP address for Ganymede822p and a local subnet mask. To continue click on
the Next button.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 13/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
The following page is displayed:
To confirm this setting, click on the Confirm Changes button below. If you do not wish to apply
this setting, click on the Cancel button.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 14/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
The following page is displayed:
Your router's IP address is being changed.
There will be a short pause while the address is changed, and then you will be redirected to the new
address. If you have not been redirected within 30 seconds, click on the link “the new address”

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 15/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
2.2.2 Changing the DHCP Server settings
The DHCP Server Configuration page allows you to enable or disable DHCP Server running on
your Ganymede822p
DHCP Server can automatically configure your PCs connected to Ganymede822p to be able to
connect to the Internet. You must enable DHCP Client (Automatically configure IP address) on
your computer.
Select whether you want DHCP Server to automatically configure your PCs. To continue click on
the Next button.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 16/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
The following page is displayed:
To confirm this setting, click on the Confirm Changes button below. If you do not wish to apply
this setting, click on the Cancel button.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 17/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
2.3 Port Configuration
The Port Configuration page allows you to change the way local ports of Ganymede822p are used.
Depending on device type connected to the port you can choose between four possible options:
-data (computer connected to this port)
-video (Set Top Box connected to this port)
-voice (VoIP phone connected to this port)
-nothing (select this if you do not want to use this port)
In order Ganymede822p to function properly you must correctly configure all local ports.
Click on the ethernet port you wish to configure.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 18/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
The following page is displayed:
Select one of available options bellow for selected port. To continue click on the Next button.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 19/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
The following page is displayed:
To confirm this setting, click on the Confirm Changes button below. If you do not wish to apply
this setting, click on the Cancel button.

SI2000 Ganymede 822+ Router User Guide
KSS5316B0-EDE-010 20/41
© The contents of this document is the property of ISKRATEL KRANJ, SLOVENIA, and may not be copied, reproduced or disclosed to a third party without written consent of the owner
2.4 Advanced Security
Ganymede822p contains advanced security features that prevent other computers on the Internet
from connecting to your PCs. You should only change the default security settings if you have
experience in network configuration. In most cases you will not need to make any changes.
You can configure Ganymede822p to allow PCs on your network to accept connections from other
computers on the Internet. You need to do this if you want to access certain applications from that
PC, such as some network games, chat or file sharing software. Ganymede822p already knows
about certain Internet applications.
To allow an application to send packets to a PC on your network, Ganymede822p needs to know:
• which protocol the application uses, e.g., NetMeeting (h323) uses TCP
• which ports the applications uses, e.g., NetMeeting (h323) uses TCP port 1720
• which applications require triggers to open secondary ports in order to transport packets,
e.g., NetMeeting (h323) requires secondary port 30000
Ganymede822p already knows the protocol, port and trigger information necessary to allow many
applications to access PCs on your network, so you do not have to enter this information manually.
Once you enable one of the common applications from the list, Ganymede822p automatically uses
the correct port, protocol and (if necessary) trigger settings to allow the application to pass traffic.
