Isuzu TN0040A User manual

Index
1-Specification of the EUT
2-Button Function Spec
3-Radio operation procedure
4-Operating manual (Bluetooth/Handsfree)
5-FCC Operating manual Requirement
6P
Model name
Model No
Car Audio
TN0040A
Page
2P
3P
4P
5P
TN0040A
Operation Manual
(1/6)

1-Specification of the EUT
RATED VOLTAGE
BABTN0040A
-
Vehicle instllation
12.0V (10.5～16.0V) - ground
FCC ID
IC Number
Purpose of the equipment
Model name
TN0040A
Brand
ISUZU
FM TUNING RANGE
1mA or less
1.98Ａ or less
(Vcc=13.2V, 0.5W output)
522 - 1710 kHz (9kHz step)
LOAD IMPEDANCE
4Ω
BACK UP CURRENT
Equipment name
Car Audio
87.5 - 108 MHz (100kHz step)
Function
Broadcast radio receiver : AM/FM/RDS/DAB
Bluetooth : Hands Free and Audio
WiFi : For Wireless Carplay/AndroidAuto
GNSS : GPS, Galileo, GLONASS, QZSS
RATED CURRENT
AM TUNING RANGE
DAB TUNING RANGE
174.928 - 239.200 MHz
Rating of usage environment
- 30 to +65 °C
(Perfomance assured temperature range)
Size of Equipmet
D 178.15mm×W 253.89mm×H 174.49mm
Weghit of Equipmet
2050g
Software version
Hardware version
-
-
(2/6)

■AUDIO controls
⑦
VOLUME/POWER
Push knob: Audio ON/OFF
Rotate knob to the right: Adjust volume by +1
Rotate knob to the left: Adjust volume by -1
⑤
BACK
Transition to previous screen
⑥
VEHICLE
Transition to vehicle information screen.
④
HOME
Transition to home screen
2-Button Function Spec
Operation
Button Name
Button No.
③
TALK
Short Push: Transition to Dial screen
Long Push: Transition to Bluetooth pairing screen
Push knob: Transition to Mode selection screen
Rotate knob: Jump between preset channels
TUNE/MODE
①
Transition to MAP screen
NAVI
②
5
4
3
2
1
6
7
(3/6)

【操作手順】[Operation procedure]
①起動 (ACC-ON)
ACC-ON後、ISUZU画面が表示された事を確認。
After the ACC-ON, confirm that Isuzu screen is displayed.
②数秒後に"CAUTION"画面に遷移します。
The screen is changed to "CAUTION" screen after a few seconds.
*初回のACC-ON時はやや時間を要します。
Note: It takes a little longer for the first time of ACC-ON.
③数秒後に”Continue”ボタンを押して、MENU画面に遷移させます。
Press the "Continue" button on the face panel after a few seconds
to move MENU screen.
Menu Screen Display
④POWERボタンを押す。
画面内のラジオモードウィンドウを押すと、"FM1 "画面に遷移します。
Press the POWER button.
When the Radio Mode Window on the screen is pressed,"FM1" screen is displayed.
⑤下記画面に遷移したら、”<”釦 若しくは、”>”釦を押下してください。
これで、SEEKが始まります。
Confirm that the screen is changed as below,
Please push down the ”<”button or ”>”button.
This will start to SEEK.
※AM/DABモードも同様の手順です。
※Same as AM/DAB mode.
3-Radio operation procedure
Press anywhere in
this area
Push this button
Push this button
(4/6)

【操作手順】[Operation procedure]
①起動 (ACC-ON) ⑥画面の”Add Device”釦を押下してください。
ACC-ON後、ISUZU画が表示された事を確認。
Please press the ”Add Device” button of the screen
After the ACC-ON, confirm that Isuzu screen is displayed.
②数秒後に"CAUTION"画面に遷移します。
The screen is changed to "CAUTION" screen after a few seconds. ⑦画面の”Search Device”釦を押下してください。
*初回のACC-ON時はやや時間を要します。
Please press the ”Search Device” button of the screen
Note: It takes a little longer for the first time of ACC-ON.
③数秒後に”Continue”ボタンを押して、MENU画面に遷移させます。 ⑧下記画面に遷移したらBluetooth端末（iPhone、 iPodなど)をペアリング
Press the "Continue" button on the face panel after a few seconds
モードに設定してください｡
to move MENU screen.
Confirm if screen is changed as below,
Please set iPhone or iPod in pairing mode.
Menu Screen Display
④”Setting”ボタンを押して、SETTINGS画面に遷移させます。
Please press the "Setting" button on the face panel to move to Settings screen
※Displays when you have more than one pairing equipment
※複数のペアリング機器がある場合の表示
⑨接続したiPhone又はiPodを選択します。
Select the iPhone or iPod to connect.
⑤”Settings”画面に遷移することを確認し、画面上の"Bluetooth"釦を選択。
Confirm if ”Settings” screen is displayed, select the ”Bluetooth” button on the display.
※ 電話機の表示にしたがって操作してください
※ Operate the phone after the message on the screen
⑩完了すれば"Connection Completed"の画面になります｡
”Connection Completed” is displayed if completed.
4-Operating manual (Bluetooth/Handsfree)
Push this button
Push this button
Push this button
Push this button
Push this button
(5/6)

CAUTION: Radio Frequency Radiation Exposure
This equipment complies with FCC radiation exposure limits set forth for uncontrolled
equipment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment
should be installed and operated keeping the radiator at least 20cm or more away from
person's body.
Co-location: This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
5-FCC Operating manual Requirement
(6/6)
