ITC Audio T-6210 User manual

Please follow the instructions in this manual to obtain the optimum resultsfrom this unit.
We also recommend that you keep this manual handyfor future reference.
TELEPHONE INTERFACE
OPERATION MANUAL
AUDIOAUDIO
PUBLIC ADDRESS SYSTEM
T-6210
POWER
T-6210
TELEPHONE INTERFACE
ON
OFF
AUDIO
MANUAL
AUTO
MONITORPHONE
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
10
7
8
9

TABLE OFCONTENTS
T-6210 2
1. SAFETYPRECAUTIONS .......................................................................................3
2. GENERALDESCRIPTION ....................................................................................5
3. FEATURES ...............................................................................................................5
4. NOMENCLATUREAND FUNCTIONS
4.1 Front Panel.............................................................................................................6
4.2 RearPanel............................................................................................................. 7
5. ....................................................................................... 8
6. APPLICATIONS ......................................................................................................9
7.SPECIFICATIONS ................................................................................................. 10
8.DIMENSIONAL DIAGRAM ....................................................................................11
MACHINE OPERATION

Be sure to read the instructions in this sectioncarefully before use.
Make sure to observe the instructions inthis manual as the conventions of safety symbols andmessages
regarded as very important precautions are included.
We also recommend you keep this instructionmanual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the
unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your nearest dealer. Make no further
attempt to operate the unit in this condition as this
may cause fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure of
the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your nearest dealer.
ITC
ITC
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
Do not insert nor drop metallic objects or
flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric
shock.
3
1. SAFETY PRECAUTIONS
T-6210

An all-pole mainsswitch with acontact separation ofat least 3mm in eachpole shall beincorporated in
the electrical installationof the building.
When Installing the Unit
Never plug in nor remove the power supply plug
with wet hands, as doing so maycause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
When the Unit is in Use
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
Make sure that the volume control is set to
minimum position before power is switched on.
Loud noise produced at high volume when power is
switched on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning. If dust
is allowed toaccumulate in the unit over a long
periodof time,a fire or damage to the unit may
result.
ITC
Ifdust accumulates onthe power supply plugor in
the wall AC outlet, a fire may result. Clean it
periodically.In addition, insertthe plug inthe wall
outletsecurely.
Switchoff the power, andunplug thepower supply
plug from the ACoutlet for safety purposes when
cleaning or leaving theunit unused for 10 days or
more.Doingotherwise maycause afire or electric
shock.
1. SAFETY PRECAUTIONS
4
T-6210

5
3. FEATURES
The T-6210 is a public address telephone interface with can provide an ideal public address solution from small
to big places such us mosques, schools, hotels and factories to train stadium and air stations.
2. GENERAL DESCRIPTION
=Receives phone calls to broadcast over PA system.
=Talk-back feature, automatic or manual operation.
=Directly enter into the broadcast system.
=Necessary for conference call.
T-6210

6
4. NOMENCLATUREAND FUNCTIONS
2
4.1 FRONT PANEL
1. POWER
Power indicator
2. POWER SWITCH
On top of the opening Power
Press the end, power shut down
3. FANNER
4. MANUL/AUTO
Manul/auto Buttons
5. MANUL/AUTO
Manul/auto indicator
6. PHONE
Phone volume control
7. MONITOR
Monitor volume control
15 43
POWER
T-6210
TELEPHONE INTERFACE
ON
OFF
PHONE MONITOR
MANUAL
AUTO
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
6 7
T-6210

RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRICUS
-NE PAS QUVRIR
AVIS:
PUBLIC ADDRESS SYSTEM
SERIAL NO:
TEL
OUTPUT
MIC
ACTIVE OUT ~220V 50Hz
T1AL250V
NOMENCLATURE ANDFUCTIONS
7
8. TEL
Telephone connector
9. OUTPUT
Audio output
10.MIC
Mic input
11.ACTIVE OUT
12. ~220V /50Hz AC POWER INPUT
4.2 REAR PANEL
8910 11 12
T-6210

5. MACHINE OPERATION
8
T-6210
1 Auto mode
Made connections as shown in the figure of rear
panel completely, the unit will hold on a telephone
call automatically while it comes in, and will hang
up automatically when the phone call ended.
2 Manual mode
Press down the manual button on the front panel
will hold on a phone-calmanually.
3 Monitoring
There is a monitor speaker inside. For adjusting
monitor volume, use the monitor knob on the
front panel.
4 Acknowledgment
There is an inner microphone in the rear side. It
can pickup sound signal from the live and make
some acknowledge to the phone call maker. You
can also make communications with it or a MIC
plugged in on the rear panel if necessary.

7. APPLICATIONS
REAR PANEL CONNECTIONS
7
5
3
10 11 12 13 14 15 16
86
4
21
9
~220V 50Hz
T1AL250V
ALARM IN ALARM OUT
CORTROL OUT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRICUS
-NE PAS QUVRIR
AVIS:
PUBLICADDRESS SYSTEM
SERIAL NO:
AB
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRICUS
-NE PAS QUVRIR
AVIS:
PUBLIC ADDRESS SYSTEM
SERIAL NO:
TEL
OUTPUT
MIC
ACTIVE OUT ~220V 50Hz
T1AL250V
MIC 2
MIC 4 MIC 3 MIC 2 MIC 1 EMC1 EMC 2
OUTPUT
AUX 3 AUX 2 AUX 1
INPUT
INPUT
~220V 50Hz
T1AL250V
MIC 4MIC 5 MIC 3 MIC 2 MIC1 EMC 1 EMC 2
LINE INPUT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRICUS
-NE PAS QUVRIR
AVIS:
PUBLIC ADDRESS SYSTEM
SERIAL NO:
TEL INPUT
MIXER AMPLIFIER 16-CHANNEL POWER SEQUENCER
9T-6210

8. SPECIFICATIONS
MODEL T-6210
INDICATORS
POWER REQUIREMENTS
DIMENSIONS(MM)
CONTROL
PROTECTION
POWER CONSUMPTION
NET WEIGHT
484X368X88
110~120VACor 220~240VAC50/60Hz
24V DC(optional)
Power switch
AC fuse,1A
50W
5.2Kg
Power LED,Manul/autoindicator
3.9Kg
GROSS WEIGHT
TELEPHONE INTERFACE
10
T-6210

9. DIMENSIONALDIAGRAM
100
Over
100
Over
Over
100
UNIT :mm
84 88
94
436
484
UNIT :mm
6
84
25
335
330
11 T-6210
POWER
T-6210
TELEPHONE INTERFACE
ON
OFF
PHONE MONITOR
MANUAL
AUTO
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRICUS
-NE PAS QUVRIR
AVIS:
PUBLIC ADDRESS SYSTEM
SERIAL NO:
TEL
OUTPUT
MIC
ACTIVE OUT
~220V 50Hz
T1AL250V
POWER
T-6210
TELEPHONE INTERFACE
ON
OFF
PHONE MONITOR
MANUAL
AUTO
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10

AUDIOAUDIO
Guangzhou ITC Electronic Technology Limited
Http://www.itc-pa.com.cn
PUBLIC ADDRESS SYSTEM
2008-02 Version1.1
