ITC CM004 Quick guide

WIFI ANTENNA CONFIGURATION
DATA SHEETDATA SHEET
CM004-Configuración_wifi_antena_R0-EN
CM004
CONNECTING UNITS TO
THROUGH WIFI NANOSTATION LOCO M2
www.itc-cloud-manager.com
NOTE
The NANOSTATION LOCO M2 is pre-configured by ITC to:
IP Address: 172.17.245.1
User: Itc
Password: fertic
Configure Ethernet adapter in your PC
to get IP adress automatically
Open your internet browser and go to
address.
Enter the username and password (Itc/fertic).
http://172.17.245.1
Go to “Wireless” “SSID” and click
“Select…” button
Select Wifi Network you want to connect,
and click “Select” button
12
Connect NANOSTATION LOCO M2 to
100-240V Power
Connect Your Laptop/PC through
Ethernet cable
34
56

WIFI ANTENNA CONFIGURATION
DATA SHEETDATA SHEET
CM004-Configuración_wifi_antenna_R0-EN
CM004
NOTE
The GATE is pre-configured by ITC to work directly
with NANOSTATION LOCO M2 configuration.
Go to “Main” tab, and check if signal is stable and
associated. Click on DHCP Client and if Wifi
Network has assigned an IP Address to Wifi Antenna
check Connect Ethernet cable between GATE and
NANOSTATION LOCO M2. Turn on the GATE
(With UNIT Controller Connected through USB/RS485)
and wait about 3 minutes
Go to
to see your UNIT connected
http://www.itc-cloud-manager.com
78
Enter the Wifi password, if needed,
and click “Change” button
Click on “Apply” button
910
11
