ITC T-6220 User manual

Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
MONITOR PANEL
OPERATION MANUAL
T-6220
PUBLIC ADDRESS SYSTEM
POWER
T-6220
MONITOR PANEL
VOLUME
5
0
1
2
3
4 6
7
8
9
10
CHANNEL
2 4 6810
OUTPUT LEVEL
ON
OFF

1. SAFETY PRECAUTIONS ....................................................................................... 3
2. GENERAL DESCRIPTION .................................................................................... 5
3. FEATURES ............................................................................................................... 5
4. NOMENCLATURE AND FUNCTIONS
4.1 Front Panel ..............................................................................................................6
4.2 Rear Panel.............................................................................................................. 7
5. ..........................................................................................8
6. APPLICATIONS ...................................................................................................... 9
7. SPECIFICATIONS ................................................................................................. 10
8. DIMENSIONAL DIAGRAM ....................................................................................11
MACHINE OPERATION
TABLE OF CONTENTS
2

Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the
unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your nearest dealer. Make no further
attempt to operate the unit in this condition as this
may cause fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure of
the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your nearest dealer.
ITC
ITC
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
Do not insert nor drop metallic objects or
flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric
shock.
1. SAFETY PRECAUTIONS
3

An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
When Installing the Unit
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
When the Unit is in Use
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
Make sure that the volume control is set to
minimum position before power is switched on.
Loud noise produced at high volume when power is
switched on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning. If dust
is allowed to accumulate in the unit over a long
period of time, a fire or damage to the unit may
result.
ITC
If dust accumulates on the power supply plug or in
the wall AC outlet, a fire may result. Clean it
periodically. In addition, insert the plug in the wall
outlet securely.
Switch off the power, and unplug the power supply
plug from the AC outlet for safety purposes when
cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric
shock.
SAFETY PRECAUTIONS
4

3. FEATURES
The T-6220 is a public address monitor panel with can provide an ideal public address solution from small to big
places such us mosques, schools, hotels and factories to train stadium and air stations.
2. GENERAL DESCRIPTION
1. Monitors up to 20 amplifiers or 20 speaker zones.
2. LED level meter and build-in loudspeaker.
3. Adjustable monitoring volume.
5

4. NOMENCLATURE AND FUNCTIONS
6
4.1 FRONT PANEL
1.
2. LEVEL
Level meters 6 output level indicators
3. CHANNEL
Channel display numeral
4. CHANNEL
Channel choose key-press
MONITOR SPEAKER 5. VOLUME
Volume control
6. POWER SWITCH
On top of the opening Power
Press the end, power shut down
7. POWER
Power indicator
7
4
3
15
2
6
POWER
VOLUME
5
0
1
2
3
4 6
7
8
9
10
CHANNEL
2 4 6810
OUTPUT LEVEL
ON
OFF

NOMENCLATURE AND FUNCTIONS
8. ~220-240V 50/60Hz POWER INPUT
4.2 REAR PANEL
9
8
7
CH 1 CH 6 CH 11 CH 16CH 2 CH 7 CH 12 CH 17CH 3 CH 8 CH 13 CH 18CH 4 CH 9 CH 14 CH 19CH 5 CH 10 CH 15 CH 20
MONITOR INPUTS
9. INPUT(CH1~CH20)
(CH1~CH20) sound input

5. MACHINE OPERATION
1. Connect to monitor the function of the equipment, the use of dual input, noninterference in each input channel.
2. The power switch to "ON" state, equipment connected to the power, the power indicator light lit, equipment
supervisor for by default the first channel, digital display to 1. As follows:
3. Manually choose to monitor the channel button switch ",SELECTOR "adjust according to the monitoring
or partition of the power output required output channel, digital tube display for the equipment in the listening
passage, listening to the speaker and then play the channel output signal (music).Level indicator light and
display the output level of the channel.
Such as: through key button to select channel 8, for "8" digital tube display, monitoring the speaker output
channel 8's music to level display for monitoring the output level of amplifier devices or partition 8 signal.
4. To monitor the volume size can be adjusted through the "VOLUME" potentiometer control panel.
5. Such as digital tube display shows, 1 means choose the listening passage 1 road, Digital tube display shows
to 2, said is 2 way to monitor the channel choice, so on.Is shown as 1...19, respectively 1...Channel 19 road,
when the digital tube display of 0, said choose listening passage is 20 road, at the same time listening to
speakers play music for the channel.
8

6. APPLICATIONS
REAR PANEL CONNECTIONS
MIXER AMPLIFIER MIXER AMPLIFIER
9
CH 1 CH 6 CH 11 CH 16CH 2 CH 7 CH 12 CH 17CH 3 CH 8 CH 13 CH 18CH 4 CH 9 CH 14 CH 19CH 5 CH 10 CH 15 CH 20
MONITOR INPUTS
T5AL250V
~230V 50Hz
AUX2 OUT
AUX1
MIC2 MIC3
MUTE EMC INPUT
MIC2 MIC3
LINE INPUT
OUTPUT
COM 4-16 70V 100V
T4AL250V
T5AL250V
~230V 50Hz
AUX2 OUT
AUX1
MIC2 MIC3
MUTE EMC INPUT
MIC2 MIC3
LINE INPUT
OUTPUT
COM 4-16 70V 100V
T4AL250V

7. SPECIFICATIONS
MODEL T-6220
INDICATORS
POWER REQUIREMENTS
DIMENSIONS(MM)
CONTROL
PROTECTION
POWER CONSUMPTION
NET WEIGHT
484X335X88
~220-240V 50/60Hz
Power switch
AC fuse,1A
20W
Power LED, LED level meter
5.2Kg
MORNITOR PANEL
10
GROSS WEIGHT 6.7Kg

8. DIMENSIONAL DIAGRAM
100
Over
100
Over
Over
100
UNIT :mm
84
88
94
335
484
UNIT :mm
6
84
25
335
330
11
POWER
VOLUME
5
0
1
2
3
4 6
7
8
9
10
CHANNEL
2 4 6810
OUTPUT LEVEL
ON
OFF
CH 1 CH 6 CH 11 CH 16CH 2 CH 7 CH 12 CH 17CH 3 CH 8 CH 13 CH 18CH 4 CH 9 CH 14 CH 19CH 5 CH 10 CH 15 CH 20
MONITOR INPUTS
POWER
VOLUME
5
0
1
2
3
4 6
7
8
9
10
CHANNEL
2 4 6810
OUTPUT LEVEL
ON
OFF

PUBLIC ADDRESS SYSTEM
VersionV0.1
