ITG-IO 990-ITG-IO-UCT-02B Operator's manual

UltraCade Technologies
1281 Wayne Avenue
San Jose, CA 95131
Ph: [phone] Fax: [phone]
www.ultracade.com [e-mail]
UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
ITG-IO™
User Documentation
Generic Input / Output JAMMA Interface
Part Number 990-ITG-IO-UCT-02B
Version 02B
May 16, 2005

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
2
Table of Contents
!!! IMPORTANT NOTE !!! 3
Legal Statement 3
Package Contents 3
Overview 3
Board Image 4
Board Layout 5
Power 6
USB 6
Digital Outputs 7
Video 8
JAMMA Interface 9
Connector Interface 10
PCB Connectors 11
Revision History 12
Contact Information 12

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
3
!!! IMPORTANT NOTE !!!
This document refers to version 02B of the ITG-IO board. 02B is the combination of PCB
version 02 and firmware version 3.0.0.0. Other versions of the PCB and firmware may differ from
the details presented in this document. Please refer to the correct documentation for your specific
hardware (see ‘Revision History’ on page 12).
Legal Statement
The ITG-IO PCB is copyright © & trademark ™ 2003-05 by UltraCade Technologies, All Rights
Reserved. The ITG-IO PCB and algorithms are Patent Pending. ITG-IO is a trademark of
UltraCade Technologies.
Package Contents
• User Documentation • ITG-IO PCB
• Video Cable (VGA) 3ft • Audio Cable (3.5mm jack) 6ft
• USB Cable 6ft • HDD Power Cable Male Housing
• HDD Power Cable Female Housing • 4 x HDD Power Cable Male Pins
• 4 x HDD Power Cable Female Pins • Free Gift Offer Card
Overview
The ITG-IO interface card is part of UltraCade Technologies’ series of JAMMA compatible PC
interface cards. For more information and a full list of current products, please go to
www.ultracade.com.
The ITG-IO provides a standard JAMMA interface for simple replacement of arcade motherboards
with a more reliable, configurable and upgradeable PC system.
The ITG-IO provides 32 I/Os (16 of each) including one optically decoupled output for complete
isolation. The remaining 15 outputs are designed for +12v operation and include surge protection
for electro-mechanical devices. +5v devices may be used; however, care is required as the surge
protection will be minimal.
Conversions are provided for PC video (0.7vpp) to Arcade video (5vpp) and PC audio (3.5mm jack)
to Arcade audio (two mono RCA jacks).

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
4
Board Image

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
5
Board Layout

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
6
Power
The ITG-IO has two potential sources of power which must not be connected simultaneously. The
source of power depends on the application. Some JAMMA harnesses are self-powered, while
others require power to be supplied from the ITG-IO. In the former case, the ITG-IO is powered
from the JAMMA connector and the PC HDD (hard disk drive) connector must not be connected. In
the latter case, the ITG-IO is powered from a standard PC HDD connector, which then powers the
JAMMA harness. NOTE: be sure the JAMMA harness is not self-powered before connecting
the PC HDD power connector to the ITG-IO.
Another potential power source is the USB connector; however, no power from the USB connector
is used on the ITG-IO.
Irrespective of the method of connecting power, the ITG-IO is protected from the power source by
5A fuses on both the +12v and +5v lines. If power is connected using the PC HDD power
connector, then the ITG-IO and the JAMMA harness are independently protected from the power
source (J1); there are four fuses, for the +5v and the +12v lines to both the ITG-IO and the JAMMA
harness. If the JAMMA harness is the power source, the +5v and +12v lines each pass through 2
fuses to get to the ITG-IO proper.
The ITG-IO does not support the -5v JAMMA connection. If the JAMMA harness is the power
source, then the -5v signal is simply unused. However, if the PC HDD power connector is the
power source, then the -5v JAMMA connection is left unconnected, and hence not powered.
USB
Bringing up a USB design with the ITG-IO is made simple by the inclusion of shareware device
drivers for Windows and Linux along with the device driver source code and sample application
code. The only data that may need updating is the USB VendorID and ProductID in the device
driver. For backward compatibility with previously released products, these values are: VendorID
07C016 and ProductID 158416. It is recommended that a unique ProductID is requested from
UltraCade Technologies for each new product application.
With the device drivers installed, simply plug in the ITG-IO. The first time a USB device is plugged
into a Windows PC, the USB device will automatically “enumerate”. This process is basically the
USB device and the PC automatically configuring themselves.
The ITG-IO supports 16 inputs from the outside world (joystick, buttons, etc) and 16 outputs to the
outside world (lights, coin counter, etc). The 16 ITG-IO inputs are sent to the PC via a standard
“isochronous USB pipe on Endpoint 1”. The 16 ITG-IO outputs are set by a standard “Set Report”
command followed by the data on “Endpoint 0”. This is the standard USB configuration, and the
device driver may abstract away even this level of detail.
Once installed, the ITG-IO will send any changes monitored on the inputs at a minimum of 10ms
intervals. However, the changes to the inputs are monitored every 1ms, with all changes being
buffered so that no changes are missed, even if a button is pressed and released within the 10ms
reporting period. If no changes are detected in the 10ms reporting period, then the ITG-IO will not
waste time sending unchanged data. Output data sent to the ITG-IO is reflected on the output pins
of the board within 2ms of it being received.

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
7
Digital Outputs
An application sets the ITG-IO outputs using the USB Set Report command (BMRequestType 2116
and BMRequest 0916). All of the other fields in the command are ignored. The command is sent
down the control pipe (Endpoint 0) first, followed by the data packet. Only the first 2 bytes of the
data packet are used, and they are written directly to the outputs without parsing. The first byte is
written to microprocessor port 0, and the second byte to port 1. See the section on the connector
interface for a list of the assignment of the USB bits to the output connectors.
The ITG-IO supports 16 outputs. 15 outputs are decoupled ground enables using FET transistors.
The final output is completely isolated using an optocoupler. Setting an output simply enables the
corresponding circuit, either to ground or optically. Conversely, clearing the output simply disables
the circuit, either to ground or optically.
When connecting a device, connect the positive terminal to the relevant voltage supply, and the
negative (or ground) terminal to the relevant output pin on the ITG-IO. Enabling that output will
enable the circuit, and therefore the device.
Decoupling with FETs enables the only limitation on the current draw to be from the power supply
itself (the FETs used have maximum ratings of 1.6 amps continuous and 10 amp pulse). In
addition, a +12v surge protector is included as part of each output; this enables the safe use of +12v
electro-mechanical devices. NOTE: the surge protector has a lesser effect on +5v devices.
The isolated output is sent in the last bit of the second USB byte. This is routed out of
microprocessor port 1.7 to an optocoupler. Using an optocoupler means that the current is
completely isolated from the ITG-IO power supply.
The optocoupler used is low-power, and has the following ratings:
• Maximum current of 80mA continuous or 3 amp pulses
• Maximum voltage of +30v forward or +3v reverse
• Forward voltage drop of 1.2v

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
8
Video
The ITG-IO accepts video input from either a DB25 (standard PC VGA video connector) or a 6-pin
156mil Molex (standard arcade video connector). Video is then produced on the relevant pins of the
JAMMA connector.
The ITG-IO does not do any scaling of the video. The video must already be in a resolution
compatible with the target monitor. If rescaling is required, the video signal can be routed through
an UltraCade uVC video converter (see www.ultracade.com).
Two forms of video processing are performed by the ITG-IO. The 0.7vpp PC video signal is
amplified to the 5vpp arcade levels, and the synchronization method is ensured to be in composite
format.
All current main stream monitors use +5v synchronization signals, however, the red, green and blue
signals are different voltages in VGA monitors and arcade monitors. Only the 0.7vpp RGB signals
produced by a PC need to be amplified to 5vpp. Therefore the video arriving from the PC video
connector (J3) is amplified, whereas the video arriving from the arcade video connector (J2) is not
amplified.
Synchronization signals used can vary. Most arcade monitors support both composite and separate
horizontal and vertical synchronization signals. However, the JAMMA connector requires just the
composite synchronization signal. The ITG-IO therefore combines separate synchronization
signals, from either the PC video input connector (J3) or the arcade video connector (J2), into a
composite signal. If the input video signal is already in composite format, the signal is unchanged.
Details on the JAMMA interface, including which pins are used for the video output, can be found in
the section entitled “JAMMA Interface”.

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
9
JAMMA Interface
The JAMMA interface is the standard interface for arcade motherboards. To simplify the
replacement of single game non-upgradeable arcade machines with PC based systems, the ITG-IO
allows the old motherboard to simply be unplugged and the PC plugged in. All the old controls will
flow through the same JAMMA interface and be converted by the ITG-IO into USB packets.
The table below shows the standard use for each of the JAMMA pins, and how it is attached to the
ITG-IO. For example, the video green pin on JAMMA pin S12 is produced from the video green
input; player 1’s start button on JAMMA pin C17 is sent to the PC via USB in the fifth bit of the
second byte. The only ITG-IO output routed through the JAMMA connector is the primary coin
counter, which is written from the PC via USB in the seventh bit of the second output byte.
PCB
Side Pin Standard
Usage Connect or USB Byte.Bit PCB Side Pin Standard Usage Connect or USB Byte/Bit
Solder 1 Gnd Gnd Component 1 Gnd Gnd
Solder 2 Gnd Gnd Component 2 Gnd Gnd
Solder 3 +5v +5v Component 3 +5v +5v
Solder 4 +5v +5v Component 4 +5v +5v
Solder 5 -5v n/c Component 5 -5v n/c
Solder 6 +12v +12v Component 6 +12v +12v
Solder 7 KEY KEY Component 7 KEY KEY
Solder 8 coin counter 2 n/c Component 8 coin counter 1 Output 1.6
Solder 9 coin lock 2 n/c Component 9 coin lock 1 n/c
Solder 10 left speaker - n/c Component 10 left speaker + n/c
Solder 11 right speaker - n/c Component 11 right speaker + n/c
Solder 12 green green Component 12 red red
Solder 13 comp sync comp sync Component 13 blue blue
Solder 14 service 1 USB 1.6 Component 14 video ground video ground
Solder 15 tilt USB 1.6 Component 15 test 1 USB 1.6
Solder 16 p2 coin USB 1.7 Component 16 p1 coin USB 1.7
Solder 17 p2 start USB 1.3 Component 17 p1 start USB 0.4
Solder 18 p2 up USB 0.7 Component 18 p1 up USB 0.0
Solder 19 p2 down USB 1.0 Component 19 p1 down USB 0.1
Solder 20 p2 left USB 1.1 Component 20 p1 left USB 0.2
Solder 21 p2 right USB 1.2 Component 21 p1 right USB 0.3
Solder 22 p2 button 1 n/c Component 22 p1 button 1 n/c
Solder 23 p2 button 2 USB 1.4 Component 23 p1 button 2 USB 0.5
Solder 24 p2 button 3 USB 1.5 Component 24 p1 button 3 USB 0.6
Solder 25 p2 button 4 n/c Component 25 p1 button 4 n/c
Solder 26 service 2 USB 1.6 Component 26 test 2 USB 1.6
Solder 27 Gnd Gnd Component 27 Gnd Gnd
Solder 28 Gnd Gnd Component 28 Gnd Gnd

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
10
Connector Interface
All of the inputs into the ITG-IO are through the JAMMA connector. Therefore, all of the additional
connectors are used for outputs. When a USB packet is sent by the PC to the ITG-IO, the two data
bytes are written directly to the microprocessor’s outputs. Setting an output bit enables the circuit to
ground, while clearing the bit disables the circuit ground.
The exception is connector J4, which is the isolated output. The collector and emitter are
connected directly to the optocoupler. Enabling and disabling this circuit is done through USB 1.7
(eighth bit of the second byte).
In the table below, the two output bytes are numbered 0 and 1, while the eight bits are numbered 0
through 7.
Connector Pin Usage Note Connector Pin Usage Note
J5 1 n/c J6 1 n/c
J5 2 USB 1.0 J6 2 n/c
J5 3 USB 1.1 J6 3 n/c
J5 4 USB 1.2 J6 4 Gnd
J5 5 USB 1.3 J6 5 Gnd
J5 6 USB 1.4 J6 6 USB 0.4
J5 7 USB 1.5 J6 7 USB 0.5
J5 8 n/c J6 8 USB 0.6
J5 9 n/c J6 9 USB 0.7
J5 10 Gnd J6 10 Gnd
J8 1 n/c J4 1 Collector circuit enabled by USB 1.7
J8 2 n/c J4 2 Emitter circuit enabled by USB 1.7
J8 3 n/c J4 3 Earth
J8 4 Gnd J4 4 Earth
J8 5 Gnd J4 5 Earth
J8 6 USB 0.0
J8 7 USB 0.1
J8 8 USB 0.2
J8 9 USB 0.3
J8 10 Gnd

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
11
PCB Connectors
This section provides the part numbers and pin assignments for the mating connectors to all of the
connectors on the PCB.
PCB
Ref PCB Connector Description Required Mate Description Parts Required Supplier Part Number Inc. in packet
J1 Power - PC HDD Female
PC HDD connector
Pin1 - +12vdc
Pin2 - Ground
Pin3 - Ground
Pin4 - +5vdc
1 x Extension 2ft
OR
1 x Female housing
4 x Female terminal
4 x Wire
1 x Male housing
4 x Male terminal
UltraCade
AMP
AMP
{any}
AMP
AMP
115-HDDPWR-CBL
1-480424-0
60617-1
n/a
1-480426-0
61618-1
no
yes
yes
no
yes
yes
J2 Video input Female, 6-pin
156mil header
Pin1 - Red
Pin2 - Green
Pin3 - Blue
Pin4 - Ground
Pin5 - V-sync
Pin6 - C/H-sync
1 x Custom from uVC
1 x Custom from std
OR
2 x Female housing
12 x Female terminal
6 x Wire
UltraCade
UltraCade
Molex
Molex
{any}
115-UVCSTR-CBL
115-UVCMIR-CBL
09-50-8061
08-50-0106
n/a
no
no
no
no
no
J3 Video input Male, D-Sub 15-pin
Standard PC video Std PC video 3ft Extension Cable UltraCade
Assmann 115-VGA3MM-CBL AK322-2 yes no
J4 Strobe output Female - 5-pin
100mil header** 1 x Female housing
2 x Female terminal Molex Molex 22-01-2057 08-50-0108 no no
J5 Digital outputs Female - 10-pin
100mil header** 1 x Female housing
7 x Female terminal Molex Molex 22-01-2107 08-50-0108 no no
J6 Digital outputs Female - 10-pin
100mil header** 1 x Female housing
7 x Female terminal Molex Molex 22-01-2107 08-50-0108 no no
J7 USB uplink USB-B plug
(USB-A = PC plug) USB A to B 6ft USB A to B 10ft
USB-A extension
UltraCade
UltraCade
usbgear
115-USB06AB-CBL
115-USB10AB-CBL
USBG-3FTE
yes
no
no
J8 Digital outputs Female - 10-pin
100mil header** 1 x Female housing
7 x Female terminal Molex Molex 22-01-2107 08-50-0108 no no
J9 Audio input Male, stereo
3.5mm jack 1 x PC audio 6ft UltraCade 115-AUDMINI-CBL yes
J10 Audio output Male, mono
RCA/Phono plugs
Red - Right channel
Black - Left channel
1 x red plug
1 x black plug
RCA extension
RCA to 3.5mm cable
CUI
CUI
Assmann
Happ
RCP-012
RCP-011
AKCHMF-2
96-0541-00
no
no
no
no
** for pin connection details, see section entitled “Connector Interface”

UltraCade Technologies - ITG-IO User Documentation version 02B - 7/23/2005
Document 040-ITGIOMA-UCT © & ™ 2003-05 UltraCade Technologies. All Rights Reserved
12
Revision History
• Version 02B. PCB version 02. Firmware version 3.0.0.0:
o 05/16/2005, DT. First release of the user documentation.
Contact Information
UltraCade Technologies
1281 Wayne Avenue
San Jose, CA 95131
Ph: [phone] Fax: [phone]
WEB: http://www.ultracade.com E-MAIL: [e-mail]
Document Number: 040-ITGIOMA-UCT
