Itronix T5200 User manual

T5200
User’s Manual

ii 77-0001-004 15 November 1999
T5200 Users Manual
Identification
T5200 Computer User’s Manual
15 November 1999 · Revision 004
Copyright Notice
© Copyright 1999 Itronix Corporation. All rights reserved. No part of this
document may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any other language or computer language in whole or in part, in
any form or by any means, whether it be electronic, mechanical, magnetic, optical,
manual, or otherwise, without the prior written consent of Itronix Corporation,
South 801 Stevens Street, Spokane, Washington 99204.
Disclaimer
Itronix Corporation reserves the right to revise the manual and make periodic
changes to the content without a direct or inferred obligation to Itronix to notify
any person of such revision or changes. Itronix Corporation does not assume
responsibility for the use of this manual, nor for any patent infringements or other
rights or third parties who may use the manual.
This document contains valuable trade secrets and proprietary information of
Itronix Corporation.
This product is available for purchase under the terms of the Itronix Hardware
Purchase and Software License Agreement. Itronix hardware products may be
reconditioned, or be manufactured from parts and components that may be new,
used, rebuilt or recycled, and in some cases, the hardware product may not be new
and may have been previously installed. In any event, Itronix warranty terms apply.
Philips Semiconductors, AltoCom, and their suppliers retain title to and ownership
of the V.34 modem software, regardless of the form or media in or on which the
original and other copies may exist.
Trademark Notice
Itronix is a registered trademark of Itronix Corporation.
Microsoft, MS, Windows, and MS-DOS are registered trademarks of Microsoft
Corporation.
AltoCom is a trademark of AltoCom, Inc.
Other company and product names mentioned herein may be the trademarks of
their respective owners.

iii77-0001-004 15 November 1999
Important Before using this manual and the product it
describes, read the Microsoft’s End User’s License Agreement
and the safety information.
Compliance Statements
The T5200 computer has been tested and found to compl with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequenc energ and, if not installed and used in accordance with the
instructions, ma cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined b turning the equipment off and on, the
user is encouraged to tr to correct the interference b one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
WARNING The Itronix Corporation Model T5200 Wireless
Mobile Workstation was found to be compliant with FCC RF
exposure requirements for the uncontrolled/general population
exposure environment with these operating conditions. While
the device is operating , its antenna must be at least 5.5cm
(2.16 inches) from all persons in order to comply with the FCC
RF exposure limit. Operators should ensure that when this
device operates, its antenna is at least 5.5cm (2.16 inches) from
nearby persons for meeting RF exposure limits.

iv 77-0001-004 15 November 1999
T5200 Users Manual
•Consult the dealer or an experienced radio/TV technician for help.
The T5200 computer complies with Part 68 of the FCC Rules. On the bottom
of this equipment is a label that contains, among other information, the FCC
registration number and ringer equivalence number (REN) for this equipment.
If requested, this information must be provided to the telephone compan .
The REN is used to determine the quantit of devices which ma be connected
to the telephone line. Excessive RENs on the telephone line ma result in the
devices not ringing in response to an incoming call. In most, but not all areas,
the sum of the RENs should not exceed five (5.0). To be certain of the number
of devices that ma be connected to the line, as determined b the total RENs,
contact the telephone compan to determine the maximum REN for the calling
area.
The T5200 computer ma be connected to the telephone network using the
RJ-11 jack provided.
If this equipment causes harm to the telephone network, the telephone
compan will notif ou in advance that temporar discontinuance of service
ma be required. If advance notice isnt practical, the telephone compan will
notif the customer as soon as possible. Also, ou will be advised of our right
to file a complaint with the FCC if ou believe it is necessar .
The telephone compan ma make changes in its facilities, equipment,
operations, or procedures that could affect the operation of the equipment. If
this happens, the telephone compan will provide advance notice in order for
ou to make the necessar modifications in order to maintain uninterrupted
service.
If trouble is experienced with this equipment, please contact the equipment
manufacturer for repair and/or warrant information. Do not attempt repairs of
this equipment ourself without obtaining manufacturer authorized parts and
documentation. If the trouble is causing harm to the telephone network, the
telephone compan ma request ou remove the equipment from the network
until the problem is resolved.
Compliance Statement for Canada
NOTICE: The Industr Canada label identifies certified equipment. This
certification means that the equipment meets certain telecommunications
network protective, operational and safet requirements as prescribed in the
appropriate Terminal Equipment Technical Requirements document(s). The
Department does not guarantee the equipment will operate to the users
satisfaction.

v77-0001-004 15 November 1999
Before installing this equipment, users should ensure that it is permissible to
be connected to the facilities of the local telecommunications compan . The
equipment must also be installed using an acceptable method of connection.
The customer should be aware that compliance with the above conditions ma
not prevent degradation of service in some situations.
Repairs to certified equipment should be made b a representative designated
b the supplier. An repairs or alterations made b the user to this equipment,
or equipment malfunctions, ma give the telecommunications compan cause
to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground
connections of the power utilit , telephone lines, and internal metallic water
pipe s stem, if present, are connected together. This precaution ma be
particularl important in rural areas.
CAUTION! Users should not attempt to make such connections themselves,
but should contact the appropriate electric inspection authorit , or electrician,
as appropriate.
The Ringer Equivalence Number (REN) for this device is located on the
Equipment Identification Label affixed to the bottom of the computer.
NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal
device provides an indication of the maximum number of terminals allowed to
be connected to a telephone interface. The termination on an interface ma
consist of an combination of devices subject onl to the requirement that the
sum of the Ringer Equivalence Numbers of all the devices does not exceed 5.
The T5200 computer ma be connected to the telephone network using the
RJ-11 jack provided.
Fax Branding
The Telephone Consumer Protection Act of 1991 makes it unlawful for an
person to use a computer or other electronic device to send an message via a
telephone fax machine unless such message clearl contains in a margin at
the top or bottom of each transmitted page or on the first page of the
transmission, the date and time it is sent and an identification of the business
or other entit , or other individual sending the message and the telephone
number of the sending machine or such business, other entit , or individual.
In order to program this information into our fax machine, ou should
complete the following:

vi 77-0001-004 15 November 1999
T5200 Users Manual
This information is entered through the FAX application
software you have installed. Consult your FAX software
documentation for instructions about entering this informa-
tion.
Federal Communication Commission (FCC) Regulations for t e
Intellic arger
The T5200 computer Intellicharger has been tested and found to compl with
the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and
can radiate radio frequenc energ and, if not installed and used in accordance
with the instructions, ma cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined b turning the equipment off and on, the
user is encouraged to tr to correct the interference b one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
WARNING It is important that onl authorized Itronix personnel attempt
repairs on Itronix equipment as this might void an maintenance
contract with our compan . Unauthorized service personnel might be
subject to shock hazard on some Itronix equipment if removal of
protective covers is attempted.

vii77-0001-004 15 November 1999
Contents
Section 1 Getting Started 1
Precautions 2
Introduction 3
Unpacking Your System 3
The First Time. . . 4
Installing the Battery 4
Connecting the AC Adapter 5
Turning the T5200 Computer On and Off 6
Things You Need to Do at Start-up 7
Start-up Problems? 9
Password Security 10
If You Have a Radio 11
Section 2 A Closer Look at t e T5200 Computer 13
Introduction 14
Standard Hardware 15
Standard Software (Speaker Phone) 16
T5200 Computer Keyboard 16
Basic Keys 17
Using the Stylus 19
Section 3 Customizing Settings 21
Introduction 22
Control Panel 22
Communications 23
Dialing 24
Display 25, 26
Gray Scale 26
Control Panel (Continued)

viii 77-0001-004 15 November 1999
T5200 Users Manual
Keyboard 27
Network 27
Owner 28
Password 28
Power 29
Regional Settings 31
Remove Programs 32
Stylus 32
System 33
T5200 Information 34
Volume and Sounds 34
Section 4 Operating Your T5200 Computer 37
Introduction 38
Connecting to a Desktop Computer 38
Installing Windows ActiveSync® on Your Desktop 38
Establishing a Connection 39
Copying and Converting Files 40
Printing Files from the T5200 Computer 41
PC Cards 41
Section 5 Power Management 43
Introduction 44
Practical Battery Tips 44
Low Battery Indicators 45
Checking Battery Power 45
Replacing Batteries 47
Charging Batteries 48
Battery Storage and Care 49
Disposing of Batteries 49

ix77-0001-004 15 November 1999
Section 6 Maintenance and Storage 51
Introduction 52
Care and Cleaning 52
Storing Your T5200 Computer 53
Section 7 Troubles ooting 55
Introduction 56
What to Try First 56
Operational Problems 57
Battery Problems 58
Display Problems 59
Keyboard Problems 60
Touch Screen Problems 60
Radio Problems 61
Desktop Communication Problems 62
Appendix A Expanding Your T5200 Computer 65
Introduction 66
Options 66
PC Card Socket 66
Expansion DRAM 66
Expansion Flash (Compact Flash) 66
Radio Modem 67
Peripherals 67
Vehicle Cradle 67
Vehicle Adapter 70
AC Adapter 71
Stand Alone Battery Charger 72

x77-0001-004 15 November 1999
T5200 Users Manual
Appendix B Hardware Specifications 73
Physical Features 74
Display 74
Processor and Memory 74
Input/Output 75
Power 75
Communications 76
Modems 76
Telephone Line Connector 76
Appendix C Keyboard Functions 77
Introduction 78
Power On/Off 79
Function Keys 80
Primary Keys 80
Numeric Keys 81
Customizing Keyboard Settings 82
Adjusting the Key Repeat Rate 82
Adjusting Audio Feedback 83
Appendix D Statements and Notices 85
Compliance Statements 90
Warnings and Cautions 93
Index 97

1
WE KNOW THE ROAD
TM
○○○○○○○○○○○○○○○○○○○○○○○○○
SECTION 1
Getting Started
Precautions 2
Introduction 3
Unpacking Your System 3
T e First Time. . . 4
Installing the Battery 4
Connecting the AC Adapter 5
Turning the T5200 Computer On and Off 6
Things You Need to Do at Start-up 7
Start-up Problems? 9
Password Security 10
If You Have a Radio 11

277-0001-004 15 November 1999
T5200 Users Manual
Precautions
Please be aware of the following important information before you
begin operating your T5200 computer.
•Data stored on PC Cards may be corrupted if the cards come in
close contact with the magnetic components of the computer.
Do not lay a PC Card on top of or under the computer.
•The internal components of the T5200 computer will be
damaged if exposed to contaminants. When the battery is
removed or when the PC card door is open, shield the unit from
all contaminants such as liquids, rain, snow, and dust.
•You can lose data if you remove the battery while the computer
is operating. Turn off the unit before you remove the battery.
You can also lose data if the battery is removed for more than
10 minutes.
•Use the stylus that comes with your T5200 computer. Don’t use
sharp implements such as keys, pens or mechanical pencils to
touch the screen because they can damage the screen.
•WARNING The T5200 computer is powered by a Lithium Ion
(Li-ion) battery. Disposing of these batteries improperly can
cause serious personal injury. Do not crush the batteries or
place them in a fire. The battery is recyclable and, under various
state and local laws, it may be illegal to dispose of these
batteries into the municipal waste stream. Check with your local
solid-waste officials for details on recycling options or proper
disposal.

377-0001-004 15 November 1999
Section 1. Getting Started
Introduction
The T5200 computer is a rugged handheld computer that uses the
Windows CE operating system. The T5200 computer is smaller
than a ruggedized laptop, but has many of the same features. It is
weather-sealed, resists bumps and drops, can connect with a variety
of peripherals and host computers, and is capable of
communicating over landline and wireless networks.
This section shows you the basics you need to do when you first
receive your computer and how to get started.
Unpacking Your System
Inside your packaging you will find:
•T5200 computer
•Power cord
•AC Adapter
•Lithium Ion battery
•T5200 User’s Manual
You may have additional components or peripherals if you ordered
these items separately. Check your packing slip for a complete list
of items included in your package.

477-0001-004 15 November 1999
T5200 Users Manual
T e First Time. . .
Using your T5200 computer for the first time involves:
•Installing the battery
•Connecting the AC Adapter to the computer to charge the
battery
Installing t e Battery
Make sure the T5200 computer is sheltered (away from liquids,
dirt, etc..) when you install the Lithium Ion battery; the computer is
not weather sealed until the battery is properly installed. The
battery should be fully charged before you operate the unit on
battery power. To get the most from your battery, follow the
guidelines in Section 5, “Power Management.”
To install the battery
1 Align the battery connectors and place the battery in the
computer.
2 Press down on the battery and slide the latches into place to
secure the battery. The computer will begin booting.
Battery
connectors
LatchLatch
BOTTOM VIEW

577-0001-004 15 November 1999
Section 1. Getting Started
Connecting t e AC Adapter
To connect the AC Adapter
1 Attach the power cord to the AC Adapter and connect the
appropriate end of the cord to an AC wall outlet.
2 Insert the appropriate end of the AC Adapter cable into the
power port on the back of the computer.
3 The T5200 computer will power on and start charging the
battery automatically. The battery charging icon appears on the
taskbar until the battery is fully charged, then the fully charged
icon appears.
Battery charging icon. Battery fully charged icon.
At moderate temperatures, approximately 70°F (21°C), the
battery should be fully charged in three to four hours. In warmer
or cooler temperatures, the battery may take longer to fully charge.
Power Port

677-0001-004 15 November 1999
T5200 Users Manual
Turning t e T5200 Computer On and Off
To turn on the computer
•Press the POWER button once, and then give the system time to
respond
To turn off the computer
•Press the POWER button once
When you power the computer back on, the system resumes from
where you left off.
If you need to leave the system for a short time and want to
conserve battery power, you can turn off the computer even if you
are running applications. You can resume where you left off by
pressing POWER.
Note If the computer does not power on, press and hold the
POWER button for at least ten seconds and then release the
button to restart the computer.
Note The computer automatically powers on when it is
connected to external power. Also, the computer does not
power off when it is connected to external power.
Press the POWER button
once to switch the
computer on or off

777-0001-004 15 November 1999
Section 1. Getting Started
T ings You Need to Do at Start-up
When you turn on your T5200 computer for the first time, you need
to perform these simple tasks:
•Calibrate the touch screen
•Adjust the screen to your own personal viewing preference
•Set the date and time
•Enter User Information
Calibrating t e Touc Screen
Calibrating the touch screen involves touching the screen with the
stylus in specific locations to align the background image with the
screen. The calibration screen is typically the first screen that
appears when you turn on the computer for the first time.
Simply position and briefly hold the stylus at the center of each
crosshair as it appears on the screen.
After this initial calibration, if you cannot select objects accurately
with the stylus, or if you notice later that the stylus is not accurate,
you may need to recalibrate the touch screen. To open the calibra-
tion screen, simultaneously press CTRL, ALT, EQUAL SIGN (=).
CAUTION Use the stylus that comes with your T5200
computer. Using sharp implements such as keys, pens or
mechanical pencils to touch the screen can cause damage to
the screen.

877-0001-004 15 November 1999
T5200 Users Manual
Adjusting t e Screen
You can toggle the backlight on if you need additional light to view
the screen. To conserve battery power, the backlight is defaulted to
switch off automatically after one minute of continuous idle time.
You can also adjust the display contrast for better viewing.
Use the following keys to make adjustments:
To Do This... Press
Toggle the backlight on and off SHIFT+A2
Lighten the display SHIFT+A5
Darken the display SHIFT+A6
Setting t e Date and Time
To set the date and time
1 Tap the Start button, tap Settings, and then double-tap Control
Panel (or simply double-tap the time on the task bar and skip
Step 2).
2 Double-tap the “World Clock”icon.
3 From the Date & Time menu, make changes to the Time and
Date, and then close this screen by tapping OK in the upper
right-hand corner of the window OK

977-0001-004 15 November 1999
Section 1. Getting Started
Setting Owner Properties
To set Owner Properties on your T5200 Computer:
1 Tap the Start button, tap Settings, and then double-tap Control Panel.
2 Double-tap the “Owner”icon and select the identification tab.
Record Owner information here, including your name, address, and
phone number(s). If you want the information to appear at startup,
check “Display Owner Identification”in the At Power On area.
You can also add more information in the Notes tab.
Start-up Problems?
If your T5200 computer does not operate, try these solutions.
•Check to make sure the battery is installed and charged properly
•Connect the AC adapter to charge the battery if it is not charged
•If the AC adapter is connected, make sure the electrical outlet works
•If the computer does not turn on, press and hold the POWER
button for at least 10 seconds, and then release the button
•If the battery doesn’t begin charging, remove the battery, and
connect the AC adapter, then reinstall the battery

10 77-0001-004 15 November 1999
T5200 Users Manual
•Verify that the LED light on the AC Adapter is on
Section 7, “Troubleshooting,”lists additional solutions you can try.
Password Security
If you are using the T5200 computer for the first time, enter the
default password provided by your company.
To set or change your password
1 Tap the Start Menu, select Settings, Control Panel, and then
double-tap the Password icon.
2 Set or change your password by entering a word of up to eight
characters—once in the Password box and again in the Confirm
Password box.
3 Check “Enable Password Protection.”
CAUTION If you forget your password, you won’t be able to
access information on your computer. You must reset (cold
boot) the system, which will erase any data that was not saved
to Compact Flash or PC Card..
