Itronix X-C 6250 Pro 300 NT User manual

X-C 6250 Pro (300)
NT User’s Manual
All manuals and user guides at all-guides.com
all-guides.com

ii
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
Identification
X-C 6250 Pro (300) NT Users Manual
January 2001 · Revision 001
Copyright Notice
© Copyright 2001 Itronix Corporation. All rights reserved. No part of this
do ument may be reprodu ed, transmitted, trans ribed, stored in a retrieval
system, or translated into any other language or omputer language in whole or
in part, in any form or by any means, whether it be ele troni , me hani al,
magneti , opti al, manual, or otherwise, without the prior written onsent of
Itronix Corporation, South 801 Stevens Street, Spokane, Washington 99204.
Disclaimer
This do ument is printed in the U.S.A. Itronix Corporation reserves the right to
revise the manual and make periodi hanges to the ontent without a dire t or
inferred obligation to Itronix to notify any person of su h revision or hanges.
Itronix Corporation does not assume responsibility for the use of this manual,
nor for any patent infringements or other rights or third parties who may use the
manual.
This do ument ontains valuable trade se rets and proprietary information of
Itronix Corporation.
This produ t is available for pur hase under the terms of the Itronix Hardware
Pur hase and Software Li ense Agreement. Itronix hardware produ ts may be
re onditioned, or be manufa tured from parts and omponents that may be
new, used, rebuilt, or re y led and in some ases, the hardware produ t may
not be new and may have been previously installed. In any event, Itronix
warranty terms apply.
Trademark Notice
Itronix is a registered trademark of Itronix Corporation.
Mi rosoft, MS, Windows, and MS-DOS are registered trademarks of Mi rosoft
Corporation.
IBM is a trademark of International Business Ma hines Corporation.
All manuals and user guides at all-guides.com

iii
79-0030-001 11 January 2001
Compliance Statements
The X-C 6250 Pro (300) omputer has been tested and found to omply with
the limits for a Class B digital devi e, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable prote tion against harmful
interferen e in a residential installation. This equipment generates, uses, and
an radiate radio frequen y energy and, if not installed and used in a ordan e
with the instru tions, may ause harmful interferen e to radio ommuni ations.
However, there is no guarantee that interferen e will not o ur in a parti ular
installation.
If this equipment does ause harmful interferen e to radio or television
re eption, whi h an be determined by turning the equipment off and on, the
user is en ouraged to try to orre t the interferen e by one or more of the
following measures:
•Reorient or relo ate the re eiving antenna.
•In rease the separation between the equipment and re eiver.
•Conne t the equipment into an outlet on a ir uit different from that to
whi h the re eiver is onne ted.
•Consult the dealer or an experien ed radio/TV te hni ian for help.
The X-C 6250 Pro (300) omputer omplies with Part 68 of the FCC Rules. On
the bottom of this equipment is a label that ontains, among other information,
the FCC registration number and ringer equivalen e number (REN) for this
equipment. If requested, this information must be provided to the telephone
ompany.
The REN is used to determine the quantity of devi es whi h may be onne ted
to the telephone line. Ex essive RENs on the telephone line may result in the
devi es not ringing in response to an in oming all. In most, but not all areas,
the sum of the RENs should not ex eed five (5.0). To be ertain of the number
of devi es that may be onne ted to the line, as determined by the total RENs,
onta t the telephone ompany to determine the maximum REN for the alling
area.
The X-C 6250 Pro (300) omputer may be onne ted to the telephone network
using the RJ-11 ja k provided.
If this equipment auses harm to the telephone network, the telephone
ompany will notify you in advan e that temporary dis ontinuan e of servi e
may be required. If advan e noti e isnt pra ti al, the telephone ompany will
notify the ustomer as soon as possible. Also, you will be advised of your right
to file a omplaint with the FCC if you believe it is ne essary.
The telephone ompany may make hanges in its fa ilities, equipment,
operations, or pro edures that ould affe t the operation of the equipment. If
All manuals and user guides at all-guides.com

iv
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
this happens, the telephone ompany will provide advan e noti e in order for
you to make the ne essary modifi ations in order to maintain uninterrupted
servi e.
If trouble is experien ed with this equipment, please onta t the equipment
manufa turer for repair and/or warranty information. Do not attempt repairs of
this equipment yourself without obtaining manufa turer authorized parts and
do umentation. If the trouble is ausing harm to the telephone network, the
telephone ompany may request you remove the equipment from the network
until the problem is resolved.
Compliance Statement for Canada
NOTICE: The Industry Canada label identifies ertified equipment. This
ertifi ation means that the equipment meets ertain tele ommuni ations
network prote tive, operational and safety requirements as pres ribed in the
appropriate Terminal Equipment Te hni al Requirements do ument(s). The
Department does not guarantee the equipment will operate to the users
satisfa tion.
Before installing this equipment, users should ensure that it is permissible to be
onne ted to the fa ilities of the lo al tele ommuni ations ompany. The
equipment must also be installed using an a eptable method of onne tion.
The ustomer should be aware that omplian e with the above onditions may
not prevent degradation of servi e in some situations.
Repairs to ertified equipment should be made by a representative designated
by the supplier. Any repairs or alterations made by the user to this equipment,
or equipment malfun tions, may give the tele ommuni ations ompany ause
to request the user to dis onne t the equipment.
Users should ensure for their own prote tion that the ele tri al ground
onne tions of the power utility, telephone lines, and internal metalli water
pipe system, if present, are onne ted together. This pre aution may be
parti ularly important in rural areas.
CAUTION! Users should not attempt to make su h onne tions themselves, but
should onta t the appropriate ele tri inspe tion authority, or ele tri ian, as
appropriate.
The Ringer Equivalen e Numbers (REN) are:
X-C 6250 Pro (300) non-radio: 0.5B
X-C 6250 Pro (300) Motient: 0.5B
X-C 6250 Pro (300) Cingular: 0.5B
X-C 6250 Pro (300) CDPD: 1.3B
All manuals and user guides at all-guides.com

v
79-0030-001 11 January 2001
NOTICE: The Ringer Equivalen e Number (REN) assigned to ea h terminal
devi e provides an indi ation of the maximum number of terminals allowed to
be onne ted to a telephone interfa e. The termination on an interfa e may
onsist of any ombination of devi es subje t only to the requirement that the
sum of the Ringer Equivalen e Numbers of all the devi es does not ex eed 5.
The X-C 6250 Pro (300) omputer may be onne ted to the telephone network
using the RJ-11 ja k provided.
ax Branding
The Telephone Consumer Prote tion A t of 1991 makes it unlawful for any
person to use a omputer or other ele troni devi e to send any message via a
telephone fax ma hine unless su h message learly ontains in a margin at the
top or bottom of ea h transmitted page or on the first page of the transmission,
the date and time it is sent and an identifi ation of the business or other entity,
or other individual sending the message and the telephone number of the
sending ma hine or su h business, other entity, or individual.
In order to program this information into your fax ma hine, you should
omplete the following:
This information is entered throu h the FAX application software
you have installed. Consult your FAX software documentation for
instructions about enterin this information.
Warnings and Cautions
WARNING It is important that only authorized Itronix personnel attempt
repairs on Itronix equipment as this might void any maintenan e ontra t with
your ompany. Unauthorized servi e personnel might be subje t to sho k
hazard on some Itronix equipment if removal of prote tive overs is attempted.
The produ t you have pur hased is powered by a re hargeable battery. The
battery is re y lable and, under various state and lo al laws, it may be illegal to
dispose of this battery into the muni ipal waste stream. Do not rush the
battery or pla e it in a fire. Che k with your lo al solid-waste offi ials for details
on re y ling options or proper disposal.
CAUTION Internal omponents of the X-C 6250 Pro (300) omputer will be
damaged if exposed to ontaminants. When dust overs, the PC ard door, or
the battery door are open on the omputer, shield the unit from all
ontaminants su h as liquids, rain, snow, and dust.
ederal Communication Commission ( CC) Regulations for the Stand Alone
Charger
This equipment has been tested and found to omply with the limits for a Class
B digital devi e, pursuant to part 15 of the FCC Rules. These limits are
All manuals and user guides at all-guides.com

vi
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
designed to provide reasonable prote tion against harmful interferen e in a
residential installation. This equipment generates, uses and an radiate radio
frequen y energy and, if not installed and used in a ordan e with the
instru tions, may ause harmful interferen e to radio ommuni ations.
However, there is no guarantee that interferen e will not o ur in a parti ular
installation. If this equipment does ause harmful interferen e to radio or
television re eption, whi h an be determined by turning the equipment off and
on, the user is en ouraged to try to orre t the interferen e by one or more of
the following measures:
•Reorient or relo ate the re eiving antenna.
•In rease the separation between the equipment and re eiver.
•Conne t the equipment into an outlet on a ir uit different from that to
whi h the re eiver is onne ted.
•Consult the dealer or an experien ed radio/TV te hni ian for help.
The equipment has been approved to [Commission Decision CTR21] for
pan-European sin le terminal connection to the Public Switched Telephone
Network (PSTN). However, due to differences between individual PSTNs
provided in different countries the approval does not, of itself, ive an uncondi-
tional assurance of successful operation on every PSTN network termination
point.
In the event of problems, you should contact your equipment supplier in the
first instance.
Safety Information
The following safety symbols are used in this manual to indi ate potentially
dangerous situations. Do not pro eed beyond a WARNING or CAUTION symbol
until the indi ated onditions are fully understood and met.
CAUTION This aution statement denotes a hazard. It alls attention to a
pro edure or pra ti e that ould result in damage to or destru tion of part
or all of the produ t if not performed orre tly.
WARNING This warning denotes a hazard. It alls attention to a pro e-
dure or pra ti e that ould result in personal injury if not performed
orre tly.
All manuals and user guides at all-guides.com
all-guides.com

vii
79-0030-001 11 January 2001
About This Manual
The X-C 6250 Pro (300) NT Users Manual provides information about
using the X-C 6250 Pro (300) omputer and some of its peripherals.
If youve never used this computer (or any computer) before, the first
three se tions ontain important information to get you started su ess-
fully. To help you be ome a profi ient user or just to make your daily
tasks easier, try using the tools that reside on your system listed on
page viii.
If youre an experienced computer user already familiar with Windows,
Se tion 3, Getting Started, provides important setup pro edures for
the omputer. Se tion 5 shows you how to ustomize system settings.
If you dont read anything else in this manual, turn to Section 6 and
read about batteries and power. Following the tips outlined in this
se tion an signifi antly in rease the life of your batteries.
nside
To Do This... Turn to This Section
See where we put the parts Features of the Computer, Page 17
Use the keyboard Keyboard Basi s, Page 24
Use the mouse Using the Mouse, Page 32
Set up your omputer orre tly Getting Started, Page 37
Register your radio modem If You Have a Radio Modem, Page 44
Customize settingsCustomizing Settings, Page 5
Charge and maintain batteries Managing Batteries and Power, Page 58
Use PC Cards Using PC Cards, Page 72
Conne t printers or external drives Optional Equipment and A essories,
Page 79
Find out about your modem Modems, Page 95
Maintain your omputer Maintenan e and Storage, Page 102
Corre t errors Error Messages, Page 107
Solve problems Troubleshooting, Page 115
All manuals and user guides at all-guides.com

viii
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
For More Help
If you need help, or if you want to learn more about your omputer, use
the following resour es already installed on your system.
•If you need help using an appli ation, refer to the appli ations online
Help. Start the appli ation, sele t Help from the menu bar, and then
hoose the item you want.
•For help using Windows NT, refer to the online Help on your system.
To a ess this information, sele t Help from the Start Menu.
All manuals and user guides at all-guides.com

ix
79-0030-001 11 January 2001
Contents
About This Manual .............................................................. vii
Inside.................................................................................. vii
For More Help ....................................................................viii
Section 1
Features of the Computer .......................................15
ntroduction .......................................................................16
ndividual Parts .................................................................. 17
Indicator Lights ................................................................... 19
Standard Hardware ............................................................. 20
O tional Hardware .............................................................. 20
Standard Software............................................................... 21
f You Have a Touch Screen ..................................................22
Section 2
Using the Keyboard and Mouse ...............................23
Keyboard Basics ................................................................. 24
Restarting the Com uter ...................................................... 24
Primary Keys ...................................................................... 24
Arrow Keys.......................................................................... 27
Numeric Key ad.................................................................. 28
FN Keys ............................................................................. 29
Function Keys ..................................................................... 30
Other Keys .......................................................................... 31
Using the Mouse................................................................. 32
General Guidelines .............................................................. 33
Changing the S eed of the Mouse.................................... 33
All manuals and user guides at all-guides.com

x
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
Section 3
Getting Started .....................................................35
ntroduction .......................................................................36
PRECAUTIONS .................................................................... 36
The First Time... ................................................................. 37
Connecting the AC Ada ter .................................................. 37
Installing and Charging the Battery ....................................... 38
Turning the Com uter On and Off ......................................... 40
Startu Problems?............................................................... 41
If You Have a Touch Screen .................................................. 42
Section 4
f You Have a Radio Modem ....................................43
ntroduction .......................................................................44
Before You Start: Register! ...................................................44
Motient or Cingular.............................................................. 44
Cellular CDPD ..................................................................... 44
GSM .................................................................................. 45
Wireless LAN (WLAN) ......................................................... 46
What Can Do with My Radio Modem?.................................. 47
Using the ntegrated Radio Modem .......................................48
Antenna Positioning ............................................................ 48
Serial Port Settings ............................................................. 48
Radio Indicator Light ........................................................... 49
Factory nstalled Windows NT 4.0 Mobile Computer Tools and
Radio Tools......................................................................... 50
User nstallable Cellular/CDPD Radio Software .......................51
GSM nternational Radio Software ........................................51
Wireless LAN .....................................................................52
Additional Documentation....................................................53
All manuals and user guides at all-guides.com

xi
79-0030-001 11 January 2001
Section 5
Customizing Settings .............................................55
ntroduction .......................................................................56
Using the System Configuration Utility .................................. 56
Accessing the SCU .............................................................. 57
Setting the COM4 RQs .......................................................58
Section 6
Managing Batteries and Power ................................61
ntroduction .......................................................................62
Practical Battery Tips .......................................................... 62
Conserving Power and Extending Battery Life .........................66
Low Battery Warnings .........................................................67
Power-saving Features ......................................................... 67
Sus end............................................................................. 67
Hard Disk Standby .............................................................. 68
Dis lay ............................................................................... 68
Backlight....................................................................... 68
MaxBright...................................................................... 69
Removing and Replacing Batteries ........................................69
Charging Batteries .............................................................. 71
Battery Storage and Care .....................................................72
Disposing of Batteries .........................................................73
Section 7
Using PC Cards .....................................................75
ntroduction .......................................................................76
nserting and Removing a PC Card ........................................76
Transferring Files Using PC Cards .........................................78
Using Bootable PC Cards ..................................................... 78
All manuals and user guides at all-guides.com
all-guides.com

xii
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
Section 8
Optional Equipment and Accessories .......................79
Connecting a Printer ........................................................... 80
Connecting an External Monitor ............................................ 81
Connecting an External Mouse.............................................. 81
PC Card External Floppy Disk Drive ....................................... 83
PRECAUTIONS .................................................................... 83
Booting from a PC Card External Flo y ................................ 84
Using an External CD-ROM ..................................................85
Stand Alone Charger ...........................................................86
Indicator Lights ................................................................... 87
Vehicle Adapter ..................................................................87
Vehicle Cradle ....................................................................91
PRECAUTIONS .................................................................... 91
Charging Batteries............................................................... 91
Communicating with Other Devices ....................................... 92
External Antennas .......................................................... 93
RF Antenna Placement ................................................... 93
Cleaning or Re lacing Cradle Contact Pins ............................ 94
Surge Protection .................................................................95
Selecting the Right Surge Protection..................................... 95
Surge Environment ......................................................... 95
Ty e of Equi ment to be Protected................................... 95
Quality of Electrical Wiring and Service ........................... 96
Selecting the Right Equi ment ............................................. 96
All manuals and user guides at all-guides.com

xiii
79-0030-001 11 January 2001
Section 9
Modems ...............................................................97
ntroduction .......................................................................98
Which Modem Do I Have?.................................................... 98
Using the nternal Landline Modem ......................................99
Transferring Files .............................................................. 100
Section 10
Maintenance and Storage..................................... 101
ntroduction .....................................................................102
f You Have a Touch Screen ................................................ 102
Hard Drive Care and Handling ............................................ 102
Internal Hard Drives .......................................................... 103
External PC Card Hard Drives ............................................. 104
Battery Maintenance and Storage ....................................... 105
Maintaining Batteries ........................................................ 105
Storing Batteries ............................................................... 105
Computer Maintenance and Storage ................................... 106
Maintaining Your Com uter ................................................ 106
Care and Cleaning ........................................................ 106
Storing Your Com uter ....................................................... 109
Appendix A
Error Messages ....................................................111
ntroduction .....................................................................112
POST Messages ................................................................112
Windows Messages ........................................................... 117
Application Messages ........................................................ 117
All manuals and user guides at all-guides.com

xiv
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
Appendix B
Troubleshooting ...................................................119
What to Try First ............................................................... 120
For More Hel ................................................................... 120
Common Solutions to Common Problems.............................121
A lications ..................................................................... 122
Batteries .......................................................................... 124
Dis lay ............................................................................. 126
Hard Disk ......................................................................... 128
I/O Ports ........................................................................... 128
Keyboard .......................................................................... 129
Landline Modems .............................................................. 130
Miscellaneous ................................................................... 133
Mouse .............................................................................. 136
PC Cards .......................................................................... 136
Pen/Touch Screen.............................................................. 138
Radio Modems .................................................................. 138
Appendix C
Glossary .............................................................141
ndex.................................................................. 147
All manuals and user guides at all-guides.com

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
WE KNOW THE ROAD
TM
S E CT ON 1
Features of the
Computer
ntroduction 16
ndividual Parts 17
Indi ator Lights 19
Standard Hardware 20
Optional Hardware 20
Standard Software 21
f You Have a Touch Screen 22
All manuals and user guides at all-guides.com

16
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
ntroduction
The X-C 6250 Pro (300) mobile omputer is a ruggedized, weather-
sealed omputer system built for the demanding environment of the
mobile worker. Designed for use by large mobile workfor es, this
omputer is one of the most pra ti al work tools for olle ting,
managing, and ommuni ating information in the field.
The following pages des ribe the external and internal features of your
X-C 6250 Pro (300) omputer.
All manuals and user guides at all-guides.com
all-guides.com

17
Section 1. Features of the Computer
79-0030-001 11 January 2001
Antenna
Dis lay
Indicator Lights
Keyboard
Power Port
Battery Door
USB Port
Audio Port
Micro hone
Mouse Pointer
and Buttons
Serial Port
RJ-11 Connector
S eaker
(on the bottom of
the com uter)
Video Port
Parallel Port
PC Card Ejector
Buttons
PC Card Sockets
Dust Cover (o en)
PC Card Door (o en)
ndividual Parts
These diagrams and des riptions provide an overview of the omputer.
All manuals and user guides at all-guides.com

18
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
The labeled omponents are des ribed below.
•9-Pin Serial Port This port an be used for serial ommuni ations,
bar ode input, onne tion to a printer, or other purposes.
•15-Pin Video Port This port an be used to onne t an external
monitor (see Se tion 9 of this manual for more information).
•25-Pin Parallel Port This port an be used to onne t optional
devi es su h as a printer.
•Antenna If you have a radio modem installed in your omputer, the
antenna sends and re eives radio waves for this modem.
•Audio Port A ustom port designed to onne t to an adapter su h as
a tel o or multimedia adapter.
•Battery Door and Latches This door overs the Ni kel Metal-Hydride
(NiMH) battery. If you unlat h the battery door before turning off the
omputer first, the system automati ally powers off the unit to
prote t data on the hard disk.
•Display Display options in lude mono hrome, olor, or tou h
s reen. The s reen an be illuminated in low-light onditions by
turning on the ba klight or MaxBright (FN+F1).
•Dust Covers These overs provide added prote tion for the serial,
parallel, USB/Audio, and video ports when they are not being used.
•Key oard The keyboard is environmentally sealed and designed
with 93 per ent standard key spa ing.
•Microphone The mi rophone allows a user to talk to another person
using the internal modem.
•Mouse Pointer and Buttons The integrated mouse pointer is lo ated
dire tly below the spa ebar on the keyboard. The left and right
mouse buttons are lo ated on either side of the mouse.
•PC Card Door This door overs the PC ard so kets. When this door
is open, shield the unit from all ontaminants su h as liquids, rain,
snow, and dust.
•PC Card Sockets PC ards are inserted into these so kets. To
remove a ard, press the ejector button lo ated to the left of the
ea h so ket.
All manuals and user guides at all-guides.com

19
Section 1. Features of the Computer
79-0030-001 11 January 2001
•Power Port This port is used to onne t the external power supply
to the omputer.
•RJ-11 Connector This port is used by the internal modem to
ommuni ate over standard voi e grade telephone lines.
•Speaker Lo ated on the bottom of the omputer, the speaker
provides sound for the unit. Use the FN+F6 and FN+F7 keys to
adjust speaker volume.
•USB Port The Universal Serial Bus port is a series Type A USB
onne tor (NT 4.0 does not support USB).
ndicator Lights
Lo ated below the display, these lights blink or remain on or off to
indi ate a tivity on the system.
The On/Off light illuminates when you power on the omputer; it blinks
to indi ate a low battery.
The External Power light illuminates when external power is onne ted
to the omputer. It blinks while the external power supply is harging
the battery and remains on when the battery is fully harged.
The Disk Activity light omes on when the hard disk is spinning or
pro essing data.
The Radio On/Off light illuminates when the radio modem is powered
on (if your omputer is equipped with a radio modem).
POWER ON / LOW BATT RADIO ON / MESSAGE
EXTERNAL POWER / CHRG HARD DRIVE ACTIVE
All manuals and user guides at all-guides.com

20
X-C 6250 Pro (300) NT Users Manual
79-0030-001 11 January 2001
Standard Hardware
•National Semi ondu tor® 300 megahertz (MHz) GXm® pro essor
•64, 128, or 256 Megabytes (MB) of Random A ess Memory (RAM)
•2 MB of internal video RAM
•Chips & Te hnology 69000 video hip
•Mono hrome, olor, or tou h s reen display that opens to 180
degrees
•Internal hard disk
•Weather sealed keyboard with 93 per ent standard key spa ing
•Video port with a standard 15-pin D onne tor
•USB port that is a series Type A USB onne tor
•2 PC ard so kets supporting two Type I or II ards, or one Type III
ard
•Ni kel Metal Hydride (NiMH) battery
•Speaker volume adjustment keys
•Ba klight toggle key and adjustment keys and display ontrast
(mono hrome display)
•Ba klight adjustment keys ( olor display)
•MaxBright toggle key (10.4-in h olor display only)
•Automati temperature ompensation of display ontrast
•Integrated mouse pointer
•AC adapter
Optional Hardware
•Stand Alone Charger
•Vehi le Adapter
•Vehi le Cradle (with or without external radio antenna)
•RF modem
•Bar ode wand
All manuals and user guides at all-guides.com
