Itronix GoBook XR-1 User manual

POWERFUL
For Today and Years to Come
Intel® Core Duo; FSB 667 MHz, 1.83 GHz
ATI RADEON Mobility X300 128M HyperMemory External
Graphics Controller
Up to 4 GB RAM
RUGGED
Providing for Computing Anywhere, Anytime
Meets and exceeds MIL-STD 810F
Sealed against water and dust intrusion (IP54)
Magnesium alloy casing and impact absorbing bumpers
Crash-tested for in-vehicle safety
Hazardous Location Class 1 Division 2 (UL 1604)
WIRELESS
Unparalleled Performance and Flexibility
WWAN, WLAN, PAN, and GPS available all in one system
Leading edge, high speed data transfer
Coverage even in fringe areas











Worldwide 2.5G and 3G cellular support
Switchable WWAN and WLAN for in-vehicle applications
Seamless roaming for uninterrupted coverage
CRMA™ Express for field upgrade ability to new WWAN
technologies
ERGONOMIC
Built for Rugged Mobility
Smallest and lightest full-size rugged notebook (6.8 lbs)
DynaVue™ patent-pending touchscreen display for unmatched
sunlight viewability
Desktop quality, full-sized, sealed keyboard
Intuitive design for easy operation
SECURITY
Unmatched Data and Asset Protection
Multiple user and network authentication options
Fingerprint, SmartCard, TPM, file/folder locking
Configurable access to all input/output devices for data transfer
restrictions
Multiple asset protection features












GoBook®XR-1
Dual-Core Fully Rugged Notebook

Durability Features:
Meets and exceeds MIL-STD 810F
Water/Dust tight (IP54/IEC 60529)
Die-cast magnesium chassis
Sealed I/O ports
Optional Compliance with UL 1604 Class I,
Division 2, Group A, B, C and D for
Hazardous Locations
SAE J1455 vehicle crash tested (when used
with an Itronix certified vehicle dock)
CPU:
Intel®Core Duo (T2400)
1.83 GHz Processor speed
FSB 667 MHz
2MB L2 Cache
Memory:
512 MB-4GB DDRII DRAM*
Video Graphics:
ATI RADEON Mobility X300 128M
HyperMemory external graphics controller
64MB dedicated memory, 64MB shared
memory for a total of 128MB graphics
memory
Display:
12.1” TFT XGA outdoor viewable DynaVue™
patent-pending display
DynaVue™ exceeds the minimum contrast
ratio as required for bright sunlight per
DOD-STD-3009.
Display heater (standard)
XGA through external VGA port
Storage:
Choice of 80 GB or 120 GB shock mounted
2.5 in. (6.35cm) ruggedized, removable
5400 RPM SATA HDD**
HDD heater (standard)



















Fully-Rugged, Multi-Wireless, State-Of-The-Art
Notebook... Beautiful!!
As the newest member of the General Dynamics line of rugged
computers, the GoBook® XR-1 differentiates itself in six key
categories — size and weight, performance, ergonomics, ruggedness,
wireless capabilities, and security — and raises the bar for mobile
computing performance. The handsomely innovative GoBook® XR-1
notebook is as powerful and rugged as it is ergonomic and portable,
sporting the lightest and smallest footprint of any fully-rugged
notebook. Designed for anywhere, anytime mission-critical computing
the GoBook XR-1 integrates the new Intel® Core Duo 1.83-GHz
processor - and ATI X300 Mobility™ Radeon® X300 128M
HyperMemory external graphics controller - to give it the power to
leverage multi-threaded applications and boost overall speed and
performance. It also incorporates the innovative, patent-pending
outdoor viewable DynaVue™ technology, which exceeds the minimum
contrast ratio as required for bright sunlight per DOD-STD-3009.
The GoBook® XR-1 offers an incredible array of industry leading
wireless capabilities, and can simultaneously deploy four integrated
radios – including GPS - for the ultimate in wireless coverage.
Designed with data security in mind, the GoBook® XR-1 incorporates
a much sought after assortment of secure computing features, includ-
ing a TPM 1.2, SmartCard Reader, integrated fingerprint scanner,
removable hard disk drive and a combination of user-enabled password
security options, making it the perfect choice for uncompromising
secure data collection work environments.
GoBook XR-1 Product Specifications
Integrated Wireline
Communications:
56 Kbps V. 92 fax/modem
10/100/1000M bit Ethernet LAN standard
Integrated Wireless
Communications:
Up to 3 RF modems and a GPS receiver can
be integrated at one time
Engineered for minimum radio desense to
get maximum wireless coverage
Superior wireless power management
MobilityXE™ software for secure wireless
access and seamless roaming between
your wireless or wired WAN and LAN
coverage areas
Wireless LAN (Options):
Intel®PRO/Wireless 3945ABG
801.11 a/b/g network connections
2.4, 5.0 GHz dualband diversity antennas
Authentication: WPA and WPA2, 802.1X
(EAP-TLS, TTLS, MD5, PEAP, LEAP, EAP-
FAST), EAP-SIM
Encryption: 64-bit and 128-bit WEP, AES-
CCMP, CKIP, TKIP
Wireless WAN (Options):
Choice of EV-DO/1xRTT/CDMA or HSDPA/
UMTS/EDGE/GSM
Common Radio Module Architecture
(CRMA) Express with fully integrated, field
replaceable WWAN radio modules
Integrated 800 - 2500 Ultra-Wideband
antennas
Wireless PAN (Options):
Bluetooth V.1.2
Class 1 (100m (328ft) line-of-sight)
Integrated antenna
















GPS (Options):
Fully integrated GPS
Di-electrically loaded high performance
quadrifilar helix antenna
SiRFXTrac high sensitivity GPS software for
increased acquisition and tracking
Keyboad & Input:
Full-sized, 87-key sealed keyboard
Choice of NiteVue™ glow-in-the-dark or
backlit keyboard
Localized versions available
Audio:
Internal microphone and (2) speakers PCI
HD Audio with AC97 compliance
Expansion Slots:
Type II PC Card Slot (standard)
Optional SmartCard reader or Express54™
card reader
Media Bay:
Swappable media bay accepts: Combo
DVD-ROM/CD-RW, MULTI DVD-RW/CD-RW,
or secondary battery
I/OInterface:
RJ-11 (wireline modem), and RJ-45
(ethernet LAN), 3x USB 2.0, serial port
(9-pin), external video (15-pin), FireWire™
(IEEE 1394a), audio headphone (mini jack),
microphone (mini jack)
Power Supply:
7200 mAH (79.9W) Lithium Ion main battery
Optional 3800 mAH (41.1W) Lithium Ion
media bay battery pack
Battery life of 4-6 hours with main battery,
5.5 -7 hours with secondary battery
GoBook Power Saver for user selectable
power management optimization















Operating System Software:
Microsoft®Windows®XP Professional, SP2
Enhanced Security & Protection:
Password security: Pre-boot, Supervisor,
User
Trusted Platform Module security chip
(TPM v1.2)
Fingerprint scanner (optional)
Smart Card (CAC Card) Reader (optional)
Cable lock slot
SuperPassword: To selectively disable I/O
devices (optional)
Stealth mode: To boot-up without sound/
light emissions
Computrace®theft recovery and data
protection agent in BIOS (optional)***
Dimensions & Weight:
1.98” (H) x 11.8” (W) x 9.65” (D) (50mm (H) x
300mm (W) x 245mm (D)
6.8lbs (3.1 kg )
Accessories:
Vehicle Cradle with or w/o RF Connectors
Office Dock
AC Adapter & Cord (90W )
Vehicle Adapter - 12V - 24V (90W)
External battery chargers
RF contacts for external vehicle-mounted
antennas
Protective keyboard and display overlays
Choice of carry handles and/or shoulder
strap
Warranty:
3 year warranty
* Total available memory will be less than 4GB. To fully
utilize 4GB memory, a 64-bit enabled processor and
operating system are required.
** Actual formatted capacity varies based on preloaded
devices and operating system.
*** Requires software and activation to enable theft protection.




















