ITWell XPDA-S PCI User manual

Mobile POS XPDA-S PCI
Technical Manual
Revision: V2.0E
January 2012
ITWell Co.,Ltd.
#505 Gayang Techno Town, 1487 Gayang-Dong, Gangseo-Gu, Seoul
Tel [phone] | Fax [phone]
www.itwell.co.kr

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •2/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
Index
1. Overview ...............................................................................5
2. Overall Features ....................................................................5
3. Device ...................................................................................6
3.1 Hardware Description.................................................................. 6
3.1.1 Platform ............................................................................................................ 6
3.1.2 Operating System.............................................................................................. 6
3.1.3 Display............................................................................................................... 7
3.1.4 Keypad............................................................................................................... 8
3.1.5 Magnetic Card Reader ...................................................................................... 8
3.1.6 Printer ............................................................................................................... 9
3.1.7 Smart Card Reader.......................................................................................... 10
3.1.8 USIM................................................................................................................ 11
3.1.9 SAMs ............................................................................................................... 11
3.1.10 Expansion Slot............................................................................................... 12
3.1.11 Audio............................................................................................................. 13
3.1.12 Battery........................................................................................................... 13
3.1.13 Barcode Scanner ........................................................................................... 15
3.1.14 GPS ................................................................................................................ 15
3.2 General Description ................................................................... 16
3.2.1 Dimension ....................................................................................................... 16
3.2.2 Weight............................................................................................................. 16
3.2.3 Operating Temperature .................................................................................. 16

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •3/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
4. Communication ...................................................................17
4.1 Modem...................................................................................... 17
4.2 USB............................................................................................ 18
4.3 WiFi ........................................................................................... 18
4.4 Bluetooth................................................................................... 18
4.5 RFID........................................................................................... 19
5. Accessories ..........................................................................19
5.1 Optional Accessories.................................................................. 20
5.1.1 Cradle .............................................................................................................. 20
5.1.2 AC Power Adapter........................................................................................... 21
5.1.3 Battery Pack .................................................................................................... 21
5.2 Included Accessories.................................................................. 22
5.2.1 Others ............................................................................................................. 22
6. Support ...............................................................................22
6.1 SDK and APIs ............................................................................. 22
6.2 Testers....................................................................................... 22
6.3 Maintenance ............................................................................. 22
6.4 Quick Starting............................................................................ 23

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •4/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
Version History
Version Date Description of Changes Author
V0.92E April 28, 2010 2nd Draft K Han
V1.0E April 29, 2010 3rd Draft K Han
V1.1E April 30, 2010 4th Draft K Han
V1.2E August 19, 2010 Janus V2.0 Specification K Han
V1.3E July 13, 2011 Added CDMA Modem ports
description K Han
V2.0E January 16, 2012 CPU type, RFID, Modem and Cradle
specification have been changed K Han

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •5/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
1Overview
XPDA-S PCI is a secure all-in-one mobile computer that satisfies PCI PED security
standard and EMV. Based on Windows CE.net 5.0, XPDA-S PCI has integrated printer,
barcode scanner, and secure PIN-PAD with smart card reader and magnetic stripe
reader. Complex business applications that need to collect data and perform real-
time communication is easy and fast with XPDA-S PCI. In addition, PCI PED certified
PIN PAD will allow you process credit card securely and effortlessly. As, printer,
barcode scanner, GSM and PIN PADs are all integrated in to a single device, there is
no need to purchase additional accessories or device to handle printing or payment.
2Overall Features

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •6/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
3Device
3.1Hardware Description
3.1.1 Platform
Characteristics XPDA-S PCI
CPU Marvell Xscale 806Mhz PXA320
Memory Flash 512MB (1GB optional)
Memory RAM 256MB
External Memory Micro SD(T-Flash) up to 32GB
USIP Innova Card secure module
MAXIM secure chip provides a secure logic for XPDA-S PCI. It means that XPDA-S
PCI can protect customer’s precious information and data within XPDA-S PCI using
MAXIM secure module.
3.1.2 Operating System
Operating System WinCE.net 5.0 Professional
WinCE 5.0 is used and spread out all over the world. It is compatible with various
applications and development languages.

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •7/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
3.1.3 Display
Characteristics XPDA-S PCI
Type TFT Transmissive color (QVGA)
Screen Size 3.5 inch(89 mm)
Display Area 53.28(W) X 71.04(H)
Number of Colors 262K(262,000 Colors)
Touch Screen Analog Resistance Type
Resolution(W X H) 240 X 320
Viewing Direction 12 o’clock
Backlight White LED
The XPDA-S PCI’s Transmissive LCD can be used by a finger and a stylus pen as well.
Also, Transmissive LCD is brighter than Transflective LCD under sunlight.

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •8/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
3.1.4 Keypad
Characteristics XPDA-S PCI
Number of Keys
-12 Numeric Keys
-3 Programmable keys(F1,F2 and F3)
-TAB, ESC and Enter
-Power
-Backspace
Triggers -1 programmable Trigger(set TAB as default)
-2 Scanner Triggers(left and right)
Type Plastic hard keys
Backlit No
Braille bumps Point on 5
The XPDA-S PCI numeric key pads are PIN Entry key pad for PIN when it needs to
be encrypted.
3.1.5 Magnetic Card Reader
Characteristics XPDA-S PCI
Reader Type Manual
Tracks ISO Track 1,2 and 3
Card format accepted ISO7811
Read Direction Bi-directional
Reading Method F2F(FM)
Card Thickness Plastic 0.76±0.08mm
Jitter Card Less than 18%
Card Swiping Speed 20 to 120cm/sec

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •9/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
For more MSR information,
Track used Track 1(ISO 1 IATA) Track2(ISO2 ABA) Track3 ISO3(MINTS)
Reading Density 210 BPI 75 BPI 210 BPI
Reading Capacity 79 Characters 40 Characters 107 Characters
Reading Bits 7-bit code 5-bit code 5-bit code
3.1.6 Printer
Characteristics XPDA-S PCI
Type of Print Thermal
Color Black and white
Length of Print 58mm
Loading and Opening System Easy loading and Easy opening system
Printing Speed 70 mm/sec
Printing Column -English Alphabet/Number: 32 Column
- Asian Character: 16 Column
Resolution 203dpi/8dots per mm
Maximum roll size
-Paper Width: 58mm
-Max roll Diameter: 24mm
-Max roll length: 6~7meter
Fonts -English Characters
-Chinese simplified
Character Size -ASCII 12X24(as a default setting)
-Chinese Simplified 24X24(as a default setting)
Dot Matrix Buffer
5000 dot lines
-
Keep printing about 200 lines of 24X24
Chinese characters once.
Barcodes -1D barcode types will be supported soon
Images YES(up to 384 dots)
Black Mark Detection YES
Paper Detection YES
Life Span 30Km
Every basic font can be programmed to double the size in height and width,
underline, margined in the center, right and left, and bold at the same time. For
more information, please refer to the API document.

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •10/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
-Pull up the cover to open the lid of printer.
-Load the paper roll with correct direction.
3.1.7 Smart Card Reader
Characteristics XPDA-S PCI
ISO Standard ISO 7816 EMV level 1 certified
Contact Principle Friction Technology
Switch Blade contact, Normal open
Durability Up to 100,000 inserted
Rate of 600 inserts per hour
Material -Data Contact: Copper alloy
-Insulation: Thermoplastic, UL94V-0
Card Insertion Force 15N Maximum
Card Withdraw Force 1n Minimum
Normal Contact Force 0.2N ~ 0.6N
Contact Retention Force 0.3Kg Minimum
The smart card reader is located on the right side of XPDA-S PCI as shown below.
The card needs to be inserted with the card facing up.

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •11/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
3.1.8 USIM
Characteristics XPDA-S PCI
Number of Slot 1
SIM Slot is located under Battery pack. The SIM slot is Unlocked when SIM Slot
cover is shifted to the left.
3.1.9 SAMS
Characteristics XPDA-S PCI
Number of Slot 2
SAM Slots are located under Battery pack. The SAM1 slot is unlocked when SAM1
Slot cover is shifted to the left. Reversely, The SAM2 slot is unlocked when SAM2
Slot cover is shifted to the right.

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •12/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
3.1.10 Expansion Slot
Characteristics XPDA-S PCI
Micro SD (T-Flash) Up to 32GB
Micro SD slot is located under the battery pack. First, Open slot first then insert a
Micro SD in the slot and vice versa for locking the slot.

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •13/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
3.1.11 Audio
Characteristics XPDA-S PCI
Type Mono Audio speaker
Audio-in Built in microphone
Audio-out Earpiece
Audio is located on the back side of XPDA-S PCI
3.1.12 Battery
Characteristics XPDA-S PCI
Type of Battery 7.4V 1900mAh Li-Ion Rechargeable battery
Package Type Replaceable battery hard pack
Nominal Capacity 1,900mAh
Minimum Capacity 1850mAh
Nominal Voltage 7.4V
Cells 2 Cells of 3.7V
Standard Charge Constant Current(CC) a
nd Constant
Voltage(CV)
MAX Charge Current 2775mA
Standard Discharge
Constant Current(CC)
-Current: 370mA
-End Voltage: 6.0V
Weight 81g
Operating Temperature -Charge: 0 to 45℃
-Discharge: -20 to 60℃
Storage Temperature
-1month: -20 to 60℃
-3month: -20 to 45℃
-1 year: -20 to 20℃
Backup Battery YES, Li-polymer 190mA
Lifespan Depending on user usage
Speaker

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •14/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
Charging
Use direct port located on the left of the
device. Charging indicator is located in the
front of the device.
-Charging (Red)
-Fully Charged (Green)
Push the lock upward to release the battery.
Charging Port

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •15/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
3.1.13 Barcode Scanner(Optional)
Characteristics XPDA-S PCI
Type Laser type barcode scan engine
Or 2D CMOS Imager
Type of Barcode
-General 1D barcodes can be read (Laser
Option)
-Ge
neral 1D and 2D barcodes can be read
(COMS Imager Option)
3.1.14 GPS(Optional)
Characteristics XPDA-S PCI
Module MTK3318F
Channels 32 channels
Barcode scanner is located at the
top of XPDA-S PCI. (Same as the
camera location)
Also
, there are two scanner
triggers on the left and right side.
GPS is located on the back side of
XPDA-S PCI. GPS is foldable.
Unfold the GPS in use for GPS
connectivity. GPS maps are not
provided.

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •16/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
3.2General Description
3.2.1 Dimension
Characteristics XPDA-S PCI
A 75mm
B 205mm
C (if GPS featured) 47mm
D 31mm
3.2.2 Weight
Characteristics XPDA-S PCI
Weight 500g
Including Battery Pack and Printer roll 560g
3.2.3 Operating Temperature
Characteristics XPDA-S PCI
Operating Temperature -5℃~ 40℃
Storage Temperature -20℃~ 60℃
Operating Humidity 90% RH

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •17/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
4Communication
4.1Modem
Characteristics XPDA-S PCI
Frequency WCDMA Dual band 850/1900Mhz
GSM/GPRS/EDGE 850/900/1800/1900Mhz
Data Transfer
GSM CS: UL 9.6kbps/DL 9.6kbps
GPRS/EDGE: Multi-slot Class 12, Class B
WCDMA CS: UL 64kbps/DL 64kbps
WCDMA PS: UL 384kbps/DL 384kbps
HSDPA: DL 3.6Mbps
USB Driver is supported. Please see the table below.
Port Type Speed Functions
COM 1 Serial Up to 115200bps Serial Communication
COM 8 USB Depends on the
network provider AT only
COM 9 USB Depends on the
network provider Data Communication
COM 10
(invisible) USB Depends on the
network provider Diagnostics
* Some of network providers disconnect the data connection by force if there is no packet
transmission between the device and the provider for 30 minutes.
* COM 1 can be used with both data and voice. However, data and voice can’t be used
concurrently.
Ex) if there is an incoming call during data transmission, the data transmission will be held during
the call.

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •18/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
4.2USB
Characteristics XPDA-S PCI
USB Host & Client Supported (Switching available by software)
Host and Client mode can be switched by software placed in the control panel.
4.3 WiFi
Characteristics XPDA-S PCI
Standard IEEE WiFi 802.11 b/g/n
Radio link encryption W E P, TKI P, A ES
Security type WEP, WPA, WPA2
Band 2.4Ghz
4.4 Bluetooth
Characteristics XPDA-S PCI
Standard compliance Bluetooth V2.1+EDR Class 2
Bluetooth Manager Adeneo licensed manager provided
WiFi and Bluetooth Power control program is supported on the control panel
< Power On > < Power Off >< Control Panel >

Secure Mobile POS XPDA-S PCI
Technical Manual V2.0E •19/28
XPDA-S PCI ITWell Confidential
Copyright©2012 ITWell
4.5 RFID
Characteristics XPDA-S
Frequency 13.56MHz
Cards Accepted
Mastercard PayPass
Visa PayWave
14443 A/B type
Near Field Communication supports
Landing Zone ITWell Contactless reader named UM-100F is
attached on the back of XPDA-S PCI
Certification
EMV Contactless L1 approved
Mastercard PayPass L2 approved
Visa PayWave L2 approved
Mastercard TQM approved
Landing zone of UM-100F

Secure Mobile POS XPDA-S PCI 
TechnicalManualV2.0E 20/28
XPDA-SPCI ITWellConfidential
Copyright©2012 ITWell
5 Accessories
5.1Optional Accessories
5.1.1 Cradle
Characteristics XPDA-S PCI
USB Connector Mini type B USB port
Charging Slot 1 Extra battery Charging slot at the bottom
AC Power 10V, 3A input
Charging Indicators Device and Extra battery
Maximum Charging Time 5 Hours
Dimension 180mm X 103mm X 73mm (L X W X H)
Charging port
USB port
can't used
