Ivation IVAWM50FPB User manual

Wall Mount
Electric Fireplace
User Guide
Thank you for purchasing the Ivation Wall Mount Electric Fireplace. This User Guide is intended to provide you with guidelines to ensure that operation
of this product is safe and does not pose risk to the user. Any use that does not conform to the guidelines described in this User Guide may void the
limited warranty.
Please read all directions before using the product and retain this guide for reference. This product is intended for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions. See warranty for details.
Box Contents
Wall mount firebox
Mounting bracket
Mounting hardware
Remote control unit
User guide
IMPORTANT SAFETY INFORMATION!
WARNING
Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
WARNING
• Read all instructions before using this heater!
• This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. Do not attempt to move the heater while it is
operating. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the
front of the heater, and keep them away from the sides and rear.
• Extreme caution is necessary when any heater is used by or near children or invalids and whenever the heater is left operating
and unattended.
• DO NOT operate any heater with a damaged cord or plug or after the heater malfunctions, has been dropped or damaged in any manner.
Discard heater, or return to authorized service facility for examination and/or repair.
• DO NOT run power cord under carpeting. DO NOT cover power cord with throw rugs, runners, or similar coverings. DO NOT route power
cord under furniture or appliances. Arrange power cord away from traffic area, and where it will not be tripped over.
• Connect to properly grounded outlets ONLY.
• DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening, as this may cause electric shock or fire, or damage
the heater.
• To prevent a possible fire, DO NOT block air intakes or exhaust in any manner. Doing so could cause a fire. DO NOT use on soft surfaces,
like a bed, where openings may become blocked.
• A heater has hot and arcing or sparking parts inside. DO NOT use it in areas where gasoline, paint, or flammable liquids are used or stored.
1
CAUTION
Keep this owner’s manual for future reference. If you sell or give this product away, make sure this manual accompanies this product.
253158

• Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or
injury to persons.
• ALWAYS plug heaters directly into a wall outlet/receptacle. NEVER use with an extension cord or movable power tap (outlet/power strip).
• DO NOT place the heater near a bed because objects such as pillows or blankets can fall off the bed and be ignited by the heater.
• NEVER use this heater in bathrooms, laundry rooms, or any other location where the heater could fall into a bathtub or pool, become
damp, or come in contact with water.
• AVOID FIRE! Regularly inspect all air vents to make sure they are free from dust, lint, or other blockage. Unplug the unit and clean with a
vacuum ONLY. DO NOT rinse or get wet.
• NEVER hang this unit on a wall directly below an electrical outlet.
• NEVER permanently install in a recessed area of the wall. This may result in blocked air flow, overheating, or fire.
• ALWAYS mount to wall bracket before use. DO NOT set on the floor, or other surface, to use.
• NEVER use a wall mount bracket from another manufacturer.
WARNING
• For residential use only! NOT for commercial use! Any commercial or public use of this heater voids all warranties, and could cause injury.
• This product is not intended to be a primary heat source. It is for supplemental heat only.
• INDOOR use only! NEVER use this heater outdoors! Doing so may result in electric shock!
• Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside!
• NEVER modify this heater. Doing so could result in personal injury or property damage. Modification of this fireplace completely voids
all warranties.
• ALWAYS turn this heater off before unplugging it from the outlet.
• ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace.
• NEVER leave this heater unattended. ALWAYS unplug this heater when not in use.
• ALWAYS store this heater in a dry location. NEVER use the fireplace if it has become wet.
• Place the heater near a wall outlet so an extension cord is not needed. If an extension cord is needed, the gauge of the cord must be at
least 14AWG, and the rating must be at least 1875 Watts. NEVER use a smaller gauge cord with a lower rating. Doing so may result in
fire or electric shock.
• ONLY use this heater on a 120V AC circuit. NEVER overload the circuit. If this heater trips the circuit breaker, unplug all other appliances
on the same circuit before the next use. Avoid plugging other appliances into the same circuit as this heater.
• NEVER plug this heater into an outlet that is old, cracked, or has any loose wires or connections. Plugging this heater into a faulty outlet
could result in electric arcing within the outlet that could cause the outlet to overheat or catch fire.
• ALWAYS check your heater cord and plug connections with each use!
• MAKE SURE the plug fits tight in the outlet! Faulty wall outlet connections or loose plugs can cause the outlet to overheat.
• Heaters draw more current than small appliances. Overheating may occur even if it has not occurred with the use of other appliances.
• During use check frequently to see if the plug outlet or face plate is HOT! If the outlet or face plate is HOT, discontinue use immediately
and have a qualified electrician inspect and/or replace the faulty outlets.
The power cord supplied with the heater has three prongs: two flat blades (live and neutral)
and one round pin (ground). If a 3-slot receptacle is not available, an adapter MUST be used.
The adapter MUST be properly grounded to the outlet box (see figure at right). [NOTE: Adapter
NOT INCLUDED.]
SAVE THESE INSTRUCTIONS!
This product includes a GLASS panel! Always use extreme caution when handling glass. Failure to do so could result in personal injury
or property damage.
Preparation
Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Parts and assembly steps are grouped for free-standing
or wall-hanging use. Check the parts list to make sure nothing is missing. Dispose of packaging materials properly. Please recycle whenever possible.
You will need the following tools (not included): Phillips screwdriver; stud finder; level; tape measure; electric drill; 1/4” wood drill bit, hammer.
2

Parts and Hardware
Installation and Assembly
Step 1.
Find a safe location.
Minimum clearance on each side: 19.7” (50 cm).
Minimum clearance below: 19.7” (50 cm).
Minimum clearance above: 39.4” (100 cm).
Minimum clearance from the front and sides: 3 feet (90 cm).
Choose a location near an outlet so an extension cord
is not required.
DO NOT position the unit directly below a power outlet.
See Safety Information on pages 1 and 2 for warnings about
safe placement, safe installation, and proper use of this product.
NOTE: The wall mount fasteners included with this fireplace are for use ONLY with a
wood-framed wall covered in drywall (sheet rock). For concrete walls, cinder blocks,
or other wall types, consult a professional for the best attachment methods.
STEP 2.
A. Locate the wall studs using an
electronic stud-finder. Mark the hole
locations with a pencil. The holes should
be 8” (20.3 cm) apart, and level. The
minimum height from the surface below
must be 19.7” (50 cm).
B. Three screws should be screwed
directly into wall studs. Then, no drywall
anchors are needed. C. If only two studs
are available, two screws MUST be
screwed directly into studs, and the
other screws must be screwed into the
drywall anchors.
ALWAYS unplug this fireplace heater before assembly or cleaning, or before relocating. Failure to do so could result in electric shock,
fire, or personal injury.
A – Fireplace ( 1 )
E - Wall Bracket (1) — Fixed on back of fireplace box
B – Wood Screws ( 5 )
D – M4x8 Metal Screws (2) RC – Remote Control
C – Drywall anchors (5)
Rear View of Fireplace
19.7”
(50 cm)
Minimum 39.4”
(100 cm)
Minimum 19.7”
(50 cm)
19.7”
(50 cm)
A
f
Drywall
Studs
AVOID INJURY and DAMAGE! Three screws should be screwed directly into wall studs. If only two studs are available, two screws must
be screwed directly into the wall studs, and additional screws must also be screwed into the drywall anchors.
3

STEP 3.
Drill a pilot hole into each mark using a
1/4” wood drill bit.
A. If screws will go into three studs, no
drywall anchors are needed.
B. Tap the drywall anchor(s) (C) carefully
into the drywall holes until they are flush
with the drywall surface. Use care to
avoid damage.
STEP 4.
Align the holes in the wall bracket (E)
with the pilot holes and drywall anchors.
Thread wood screws (B) through washers
and holes in the wall bracket, then directly
into the wall studs and/or drywall anchors.
Make sure bracket is level. Tighten all
screws securely with a screwdriver.
Mounting into three wall studs Mounting into two wall studs and drywall anchors
STEP 5.
A. With the help of a capable adult, lift
the fireplace (A) and align the hooks on
the back of the fireplace with the slots
on the wall bracket. Carefully set the
hooks into the slots.
B. Secure the fireplace to the wall bracket
with two M4x8 metal screws (D), one on
each side. Thread the screws through the
fireplace and into the wall bracket side
tabs. Tighten both screws with a Phillips
screwdriver. The unit may now be
plugged in.
ALWAYS unplug this fireplace heater before assembly or cleaning, or before relocating. Failure to do so could result in electric shock,
fire, or personal injury.
A
f
C
CC
B
B
B
B
BB
E E
B
B
A
A
E
D
4

Operation
Power
Make sure the ON/OFF switch, located on the left side panel, is in the OFF position. Plug the power cord into a 110~120 Volt 15 Amp grounded outlet
(see IMPORTANT SAFETY INFORMATION on Pages 1 and 2). Make sure the outlet is in good condition and that the plug is not loose. NEVER exceed
the maximum amperage for the circuit. DO NOT plug other appliances into the same circuit.
Methods of Operation
This electric fireplace can be operated by the CONTROL PANEL, located on the right side panel of the fireplace (see figure below), or by the battery-
powered REMOTE CONTROL.
The operation and functions of the two methods are the same.
Before operating, please review the IMPORTANT SAFETY INFORMATION on Pages 1 and 2, and heed all warnings.
NOTE: When the heater is first turned on, a slight odor may be present. This is normal and should not occur again unless the heater is not used for a
long period of time.
Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so
could result in electric shock, fire, serious injury, or death.
c
\
Hot Air
Vents
Front View
Rear View Left Side View
Top View
5

Remote Control & Control Panel Operation
(Control panel POWER switch must be ON to use remote control.)
Temperature Limiting Control
This heater is equipped with a Temperature Limiting Control. Should the heater reach an unsafe temperature (212°F / 100°C), the heater will
automatically turn OFF. To reset:
1. Unplug the power cord from the outlet.
2. Turn the ON/OFF switch on the CONTROL PANEL to OFF. Wait 5 minutes.
Inspect the fireplace to make sure no vents are blocked, or clogged with dust or lint. If they are, use a vacuum to clean the vent areas.
3. With the POWER switch in the OFF position, plug the power cord back into the outlet.
4. If the problem continues, have your outlet and wiring inspected by a professional.
Remote Control Battery Information
This remote control uses two AAA batteries (not included).
NOTE: To improve operation, aim the remote control at the front of the fireplace. DO NOT press the buttons too quickly. Give the unit time to respond
to each command.
BUTTON ACTION and INDICATION
ON
OFF
POWER
HEATER
FLAME
TIMER
1. Press ON (I). Power turns on. All functions are enabled.
2. Press OFF (O). Power, flame effect, and all functions turn off.
1. Press once. Beep. Flame effect and indicator turn on.
2. Press again. Beep. Power and all functions turn off.
1. Press once. Small indicator lights up. Fan blows cool air. 750W heater turns
on and blows warm air.
2. Press again. Large indicator lights up. 1500W heater turns on and blows hot air.
3. Press again. Heaters turn off. Fan blows cool air to allow heater to cool down,
then turns off.
1. Press +. Flame effect gets brighter. Press again until desired setting is reached.
2. Press -. Flame effect gets dimmer. Press again until desired setting is reached.
1. Press once. ½ h light turns on. Timer is set to ½ hour.
2. Press again. 1h light turns on. Timer is set to 1 hour.
3. Press until desired setting is reached. Timer setting increases by ½ hour up to 7½ h.
Examples: 3 hours = 2h+1h; 7½ hours = 4h+2h+1h+½h.
4. Press again. Timer setting increases by ½ hour until desired setting is reached, or until timer turns off.
5. Press again to restart timer from ½h.
NEVER dispose of batteries in fire. Failure to observe this precaution may result in an explosion. Dispose of batteries at your local
hazardous material processing center.
6

Cleaning
Metal:
• Buff using a soft cloth, slightly dampened with a citrus oil-based product.
• DO NOT use brass polish or household cleaners as these products will damage the metal trim.
Glass:
• Use a good quality glass cleaner sprayed onto the cloth or towel. Dry thoroughly with a paper towel or lint-free cloth.
• NEVER use abrasive cleansers, liquid sprays, or any cleaner that could scratch the surface.
Vents:
• Use a vacuum or duster to remove dust and dirt from the heater and vent areas.
Plastic:
• Wipe gently with a slightly damp cloth and a mild solution of dish soap and warm water.
• NEVER use abrasive cleansers, liquid sprays, or any cleaner that could scratch the surface.
Maintenance
Electrical and Moving Parts:
• The fan motors are lubricated at the factory and will not require lubrication.
• Electrical components are integrated in the fireplace and are not serviceable by the consumer.
Storage:
• Store heater in a clean dry place when not in use.
Specifications:
Heater: 750W / 1500W
Heat settings: High, low, no heat (flame effect only)
Voltage: 110-120V, 60Hz
Power consumption: 2.5W per hour (flame effect only)
BTU rating: 5,100
Timer: Up to 7 1/2 hrs. in 1/2 hr. increments
Brightness adjustment: 4 levels
Remote control power source: 2 AAA batteries, not included
Safety device: Overheat protection automatic shutoff
Dimensions: 50.4" x 5.5" x 21.65" (1280 x 140 x 550mm)
Weight: 39.68 lbs. (18kg)
Customer Service:
[e-mail]
866-849-3049
ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace.
Failure to do so could result in electric shock, fire, or personal injury.
NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury.
Risk of electric shock! DO NOT OPEN any panels. No user-serviceable parts inside!
ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace.
Failure to do so could result in electric shock, fire, or personal injury.
7
Distributed by
C&A Marketing
2 Bergen Turnpike
Ridgefield Park, NJ 07660
[email protected]
Made in China
Ivation is a trademark of C&A IP
Holdings, LLC
©2016 All rights reserved
