Iwatsu VOAC760 User manual

Remote Control Manual
Digital Multimeter
VOAC7602
VOAC7502

Ⓒ2013_2015 IWATSU TEST INSTRUMENTS CORPORATION．All rights reserved．

i
Introduction
◇Thank you for purchasing this instrument. We appreciate your continued patronage of
Iwatsu’s instrument.
◇Please read this manual carefully before using the instrument, and keep it handy for future
reference.
◇In this manual, it explains based on VOAC7602. Especially, handle VOAC7502 based on it
as long as it doesn't refuse.
Safety Precautions
To ensure safe operation of this instrument and to prevent personal injury or damage to
property, read and carefully observe the warnings and cautions in the following section and
associated symbols marked on the panels.
Precautions
◇Parts of the contents of this manual may be changed without notice following improvements
in performance and function.
◇Reproduction or reprinting of the contents of this manual without prior permission from
Iwatsu is prohibited.
◇Since the display panel of this instrument contains a fluorescent tube, when discarding it, be
sure to comply with the appropriate dumping regulations.
◇Microsoft & MS-DOS are trademarks of Microsoft Corporation in the U.S.
◇Windows is registered trademark of Microsoft Corporation in the U.S.and / or other
countries.
◇The names of actual companies and instruments mentioned herein may be the trademarks
of their respective owners.
◇For questions about this instrument, contact IWATSU TEST INSTRUMENTS
CORPORATION listed at the end of this manual or our sales distributors.
◇Use a LAN cable to connect this instrument to a computer.
Note: A cable for noise reduction (shielding) may be required and is recommended when
operating this instrument through remote controls using a LAN in a problematic noise
environment. For more information, contact an Iwatsu sales representative or a service
center.
Revision History
◇October 2013 : 1st edition
◇May 2014 : 2nd edition
◇August 2014 : 3rd edition
◇February 2015 : 4th edition
◇November 2015 : 5th edition
KML090251 A717-722400(N)

ii
Memo

Remote control - 1
Table of Contents
Introduction........................................................................................................................................................i
Safety Precautions............................................................................................................................................i
1. General........................................................................................................................................................ 1
2. Remote Control........................................................................................................................................... 1
2.1 Restrictions of remote control.................................................................................................................. 1
2.2 Remote/local control................................................................................................................................ 1
2.3 Remote control using USB ...................................................................................................................... 4
2.3.1 Settings for this instrument ............................................................................................................... 4
2.3.2 Remote/local controls ....................................................................................................................... 4
2.4 Remote control using a LAN.................................................................................................................... 5
2.4.1 Settings for this instrument ............................................................................................................... 5
2.4.2 Communication settings on computer............................................................................................... 6
2.4.3 Connect to network........................................................................................................................... 6
2.4.4 Check IP connection......................................................................................................................... 6
2.4.5 Communication mode....................................................................................................................... 8
2.4.6 Remote/local control ......................................................................................................................... 8
2.5 Remote control through RS-232 interface............................................................................................... 9
2.5.1 Settings for this instrument ............................................................................................................... 9
2.5.2 Connection with external instruments............................................................................................. 10
2.5.3 Communication mode..................................................................................................................... 11
2.5.4 Synchronization............................................................................................................................... 11
2.5.5 Remote/local control ....................................................................................................................... 11
2.6 Remote control through GPIB interface................................................................................................. 12
2.6.1 Settings for this instrument ............................................................................................................. 12
2.6.2 Interface functions........................................................................................................................... 13
2.6.3 Connections .................................................................................................................................... 13
2.6.4 Remote/local control ....................................................................................................................... 14
2.6.5 GET (Group Execute Trigger)......................................................................................................... 15
2.6.6 DCL・SDC...................................................................................................................................... 15
2.6.7 Handshake...................................................................................................................................... 15
3. Remote Control Commands...................................................................................................................... 16
3.1 Command system.................................................................................................................................. 16
3.2 Message rules........................................................................................................................................ 16
3.2.1 Input/output buffer........................................................................................................................... 17
3.2.2 Message format .............................................................................................................................. 18
3.2.3 Multi-commands.............................................................................................................................. 18
3.2.4 Query .............................................................................................................................................. 20
3.2.5 Mnemonic........................................................................................................................................ 20
3.2.6 Data format ..................................................................................................................................... 21
3.3 Status report structure ........................................................................................................................... 24
3.3.1 Service requests (SRQ).................................................................................................................. 24
3.3.2 Status byte register......................................................................................................................... 25

Remote control - 2
3.3.3 Service request enable register ...................................................................................................... 26
3.3.4 Standard event status register........................................................................................................ 27
3.3.5 Standard event status enable register............................................................................................ 28
3.3.6 Output queue .................................................................................................................................. 28
3.3.7 Instrument specific error occurrence event status register............................................................. 29
3.3.8 Instrument specific error occurrence event enable register............................................................ 30
3.3.9 Measurement event status register................................................................................................. 31
3.3.10 Measurement event enable register ............................................................................................. 32
3.3.11 Operation condition status register............................................................................................... 32
3.3.12 Operation event status register..................................................................................................... 33
3.3.13 Operation event enable register.................................................................................................... 33
3.3.14 Questionable condition status register.......................................................................................... 34
3.3.15 Questionable event status register ............................................................................................... 35
3.3.16 Questionable event enable register.............................................................................................. 36
3.4 Common commands.............................................................................................................................. 37
3.4.1 List of Common Commands ........................................................................................................... 37
3.4.2 IDN? query (Identification Number)............................................................................................... 38
3.4.3 RST command (Reset) ................................................................................................................. 38
3.4.4 TST? query (Test)......................................................................................................................... 38
3.4.5 OPC/OPC? command/query (Operation Complete)................................................................... 39
3.4.6 WAI command (Wait).................................................................................................................... 39
3.4.7 CLS command (Clear Status) ....................................................................................................... 39
3.4.8 ESE/ESE? command/query (Event Status Enable).................................................................... 40
3.4.9 ESR? query (Event Status Register)............................................................................................. 41
3.4.10 PSC/PSC? command/query (Power on Status Clear) .............................................................. 42
3.4.11 SRE/SRE? command/query (Service Request Enable) ........................................................... 43
3.4.12 STB? query (Status Byte) ........................................................................................................... 44
3.4.13 TRG command (Trigger)............................................................................................................. 44
3.4.14 RCL command (Recall)............................................................................................................... 45
3.4.15 SAV command (Save)................................................................................................................. 45
3.5 Instrument-specific commands (SCPI conforming form)....................................................................... 46
3.5.1 List of Instrument-specific Commands............................................................................................ 46
3.5.1.1 List of Instrument-specific Commands (Math calculation relation) .......................................... 46
3.5.1.2 List of Instrument-specific Commands (Graph display relation) .............................................. 47
3.5.1.3 List of Instrument-specific Commands (Trigger relation)......................................................... 48
3.5.1.4 List of Instrument-specific Commands List (Measurement/measured value setting relation) . 48
3.5.1.5 List of Instrument-specific Commands (DCV - direct current voltage measurement relation). 49
3.5.1.6 List of Instrument-specific Commands (ACV - alternating current voltage measurement
relation) ................................................................................................................................................ 49
3.5.1.7 List of Instrument-specific Commands (DCI - deirec current measurement relation).............. 50
3.5.1.8 List of Instrument-specific Commands (ACI - alternating current measurement relation)....... 50
3.5.1.9 List of Instrument-specific Commands (2WΩ - 2 terminal register measurement relation)..... 50
3.5.1.10 List of Instrument-specific Commands (4WΩ - 4 terminal register measurement relation)... 51
3.5.1.11 List of Instrument-specific Commands (CONT - continuity test measurement relation)........ 51

Remote control - 3
3.5.1.12 List of Instrument-specific Commands (FREQ - frequency measurement relation) .............. 51
3.5.1.13 List of Instrument-specific Commands (PER - period measurement relation)....................... 52
3.5.1.14 List of Instrument-specific Commands (TEMP - temperature measurement relation)........... 52
3.5.1.15 List of Instrument-specific Commands (DIOD - diode measurement relation) ...................... 52
3.5.1.16 List of Instrument-specific Commands (Other commands).................................................... 53
3.5.1.17 List of status register control related commands ................................................................... 54
3.5.2 Route command.............................................................................................................................. 55
3.5.2.1 ABORt command ..................................................................................................................... 55
3.5.2.2 INITiate[:IMMediate] command................................................................................................ 55
3.5.2.3 FETCh? query.......................................................................................................................... 56
3.5.2.4 READ? query ........................................................................................................................... 56
3.5.2.5 R? query................................................................................................................................... 57
3.5.3 CALCulate subsystem .................................................................................................................... 58
3.5.3.1 CALCulate1:LIMit subsystem................................................................................................... 58
3.5.3.1.1 CALCulate[1]:LIMit:LOWer:STATe command/query......................................................... 58
3.5.3.1.2 CALCulate[1]:LIMit:LOWer[:DATA] command/query........................................................ 59
3.5.3.1.3 CALCulate[1]:LIMit:UPPer:STATe command/query ......................................................... 59
3.5.3.1.4 CALCulate[1]:LIMit:UPPer[:DATA] command/query......................................................... 60
3.5.3.2 CALCulate1:SMOothing subsystem ........................................................................................ 61
3.5.3.2.1 CALCulate[1]:SMOothing:STATe command/query........................................................... 61
3.5.3.2.2 CALCulate[1]:SMOothing:POINts command/query .......................................................... 61
3.5.3.3 CALCulate1:SCALing subsystem ............................................................................................ 62
3.5.3.3.1 CALCulate[1]:SCALing:STATe command/query............................................................... 62
3.5.3.3.2 CALCulate[1]:SCALing:MODE command/query............................................................... 62
3.5.3.3.3 CALCulate[1]:SCALing:VALA command/query................................................................. 63
3.5.3.3.4 CALCulate[1]:SCALing:VALB command/query................................................................. 63
3.5.3.3.5 CALCulate[1]:SCALing:VALC command/query ................................................................ 64
3.5.3.3.6 CALCulate[1]:SCALing:VALD command/query ................................................................ 64
3.5.3.4 CALCulate1:DB subsystem...................................................................................................... 65
3.5.3.4.1 CALCulate[1]:DB:STATe command/query........................................................................ 65
3.5.3.4.2 CALCulate[1]:DB:MODE command/query........................................................................ 66
3.5.3.4.3 CALCulate[1]:DB:RELative:STATe command/query........................................................ 66
3.5.3.4.4 CALCulate[1]:DB:RELative:VALue command/query ........................................................ 67
3.5.3.4.5 CALCulate[1]:DBM:REFerence command/query.............................................................. 67
3.5.3.4.6 CALCulate[1]:DBV:REFerence command/query .............................................................. 68
3.5.3.5 CALCulate1:AVERage subsystem........................................................................................... 69
3.5.3.5.1 CALCulate[1]:AVERage:STATe command/query............................................................. 69
3.5.3.5.2 CALCulate[1]:AVERage:CLEar command........................................................................ 69
3.5.3.5.3 CALCulate[1]:AVERage:COUNt query ............................................................................. 69
3.5.3.5.4 CALCulate[1]:AVERage:AVERage query......................................................................... 70
3.5.3.5.5 CALCulate[1]:AVERage:MAXimum query ........................................................................ 70
3.5.3.5.6 CALCulate[1]:AVERage:MINimum query.......................................................................... 70
3.5.3.5.7 CALCulate[1]:AVERage:SDEViation query....................................................................... 71
3.5.3.5.8 CALCulate[1]:AVERage:PTPeak query ............................................................................ 71

Remote control - 4
3.5.3.6 CALCulate2:TRANsform:HISTogram subsystem .................................................................... 72
3.5.3.6.1 CALCulate2:TRANsform:HISTogram:CLEar command ................................................... 72
3.5.3.6.2 CALCulate2: TRANsform: HISTogram:COUNt query....................................................... 72
3.5.3.6.3 CALCulate2:TRANsform:HISTogram:ALL query.............................................................. 72
3.5.3.6.4 CALCulate2:TRANsform:HISTogram:DATA query........................................................... 73
3.5.3.6.5 CALCulate2:TRANsform:HISTogram:POINts command/query........................................ 73
3.5.3.6.6 CALCulate2:TRANsform:HISTogram:RANGe:MODE command/query ........................... 74
3.5.3.6.7 CALCulate2:TRANsform:HISTogram:RANGe:CENTer command/query ...................... 74
3.5.3.6.8 CALCulate2:TRANsform:HISTogram:RANGe:BWIDth query........................................... 75
3.5.3.6.9 CALCulate2:TRANsform:HISTogram:RANGe:SPAN command/query.......................... 75
3.5.3.7 CALCulate2:TRANsform:TCHart subsystem........................................................................... 76
3.5.3.7.1 CALCulate2:TRANsform:TCHart:CLEar command .......................................................... 76
3.5.3.7.2 CALCulate2:TRANsform:TCHart:RANGe:MODE command/query .................................. 76
3.5.3.7.3 CALCulate2:TRANsform:TCHart:RANGe[:UPPer] command/query ................................ 77
3.5.3.7.4 CALCulate2:TRANsform:TCHart:RANGe:OFFSet[:DIV] command/query ....................... 77
3.5.3.7.5 CALCulate2:TRANsform:TCHart:RANGe:OFFSet:VALue command/query .................... 78
3.5.3.8 CALCulate2:TRANsform:AMETer subsystem ......................................................................... 79
3.5.3.8.1 CALCulate2:TRANsform:AMETer:RANGe:MODE command/query................................. 79
3.5.3.8.2 CALCulate2:TRANsform:AMETer:RANGe[:UPPer] command/query............................... 79
3.5.3.8.3 CALCulate2:TRANsform:AMETer:RANGe:OFFSet[:DIV] command/query...................... 80
3.5.3.8.4 CALCulate2:TRANsform:AMETer:RANGe:OFFSet:VALue command/query................... 81
3.5.3.8.5 CALCulate2:TRANsform:AMETer:RANGe:LOG:MAX command/query........................... 82
3.5.3.8.6 CALCulate2:TRANsform:AMETer:RANGe:LOG:MIN command/query............................ 83
3.5.3.8.7 CALCulate2:TRANsform:AMETer:TITLE:MODE command/query................................... 84
3.5.3.8.8 CALCulate2:TRANsform:AMETer:TITLE:TEXT command/query..................................... 84
3.5.3.9 CALCulate2:TRANsform:METEr subsystem ........................................................................... 85
3.5.3.9.1 CALCulate2:TRANsform:METEr:RANGe:AUTO command/query ................................... 85
3.5.3.9.2 CALCulate2:TRANsform:METEr:RANGe:MODE command/query................................... 86
3.5.3.9.3 CALCulate2:TRANsform:METEr:RANGe[:UPPer] command/query................................. 86
3.5.3.9.4 CALCulate2:TRANsform:METEr:RANGe:OFFSet[:DIV] command/query........................ 87
3.5.3.9.5 CALCulate2:TRANsform:METEr:RANGe:OFFSet:VALue command/query..................... 88
3.5.3.9.6 CALCulate2:TRANsform:METEr:RANGe:LOG:MAX command/ query............................ 89
3.5.3.9.7 CALCulate2:TRANsform:METEr:RANGe:LOG:MIN command/ query............................. 90
3.5.4 TRIGger subsytem.......................................................................................................................... 91
3.5.4.1 TRIGger:SOURce command/query ......................................................................................... 92
3.5.4.2 TRIGger:COUNt command/query............................................................................................ 93
3.5.4.3 TRIGger:DELay command/query............................................................................................. 94
3.5.4.4 TRIGger:SLOPe command/query............................................................................................ 94
3.5.5 SAMPle subsytem........................................................................................................................... 95
3.5.5.1 SAMPle:COUNt command/query............................................................................................. 95
3.5.5.2 SAMPle:TIMer command/query............................................................................................... 95
3.5.6 CONFigure subsystem.................................................................................................................... 96
3.5.6.1 CONFigure[:VOLTage][:DC] command ................................................................................... 97
3.5.6.2 CONFigure[:VOLTage]:AC command...................................................................................... 98

Remote control - 5
3.5.6.3 CONFigure:CURRent[:DC] command ..................................................................................... 99
3.5.6.4 CONFigure:CURRent:AC command...................................................................................... 100
3.5.6.5 CONFigure:RESistance command ........................................................................................ 101
3.5.6.6 CONFigure:FRESistance command...................................................................................... 102
3.5.6.7 CONFigure:CONTinuity command......................................................................................... 102
3.5.6.8 CONFigure:FREQuency command........................................................................................ 103
3.5.6.9 CONFigure:PERiod command............................................................................................... 104
3.5.6.10 CONFigure:TEMPerature command.................................................................................... 104
3.5.6.11 CONFigure:DIODe command.............................................................................................. 105
3.5.6.12 CONFigure query................................................................................................................. 105
3.5.7 MEASure subsystem .................................................................................................................... 106
3.5.8 SENSe subsystem........................................................................................................................ 107
3.5.8.1 [SENSe]:FUNCtion[:ON] command/query ............................................................................. 108
3.5.8.2 SENSe:VOLTage:DC subsystem .......................................................................................... 109
3.5.8.2.1 [SENSe]:VOLTage[:DC]:NPLCycles command/query.................................................... 109
3.5.8.2.2 [SENSe]:VOLTage[:DC]:SRATE command/query.......................................................... 110
3.5.8.2.3 [SENSe]:VOLTage[:DC]:APERture command/query...................................................... 111
3.5.8.2.4 [SENSe]:VOLTage[:DC]:RESolution command/query.................................................... 112
3.5.8.2.5 [SENSe]:VOLTage[:DC]:RANGe:AUTO command/query .............................................. 112
3.5.8.2.6 [SENSe]:VOLTage[:DC]:RANGe[:UPPer] command/query............................................ 113
3.5.8.2.7 [SENSe]:VOLTage[:DC]:ZERO:AUTO command/query................................................. 114
3.5.8.2.8 [SENSe]:VOLTage[:DC]:NULL:STATe command/query ................................................ 114
3.5.8.2.9 [SENSe]:VOLTage[:DC]:NULL:VALue command/query................................................. 115
3.5.8.2.10 [SENSe]:VOLTage[:DC]:IMPedance:AUTO command/query....................................... 115
3.5.8.3 SENSe:VOLTage:AC subsystem........................................................................................... 116
3.5.8.3.1 [SENSe]:VOLTage:AC:NPLCycles command/query ...................................................... 116
3.5.8.3.2 [SENSe]:VOLTage:AC:SRATE command/query............................................................ 117
3.5.8.3.3 [SENSe]:VOLTage:AC:APERture command/query........................................................ 118
3.5.8.3.4 [SENSe]:VOLTage:AC:RANGe:AUTO command/query................................................. 119
3.5.8.3.5 [SENSe]:VOLTage:AC:RANGe[:UPPer] command/query.............................................. 120
3.5.8.3.6 [SENSe]:VOLTage:AC:NULL:STATe command/query................................................... 121
3.5.8.3.7 [SENSe]:VOLTage:AC:NULL:VALue command/query................................................... 121
3.5.8.3.8 [SENSe]:VOLTage:AC:BANDwidth command/query...................................................... 122
3.5.8.3.9 [SENSe]:VOLTage:AC:FREQuency command/query .................................................... 122
3.5.8.4 SENSe:CURRent:DC subsystem........................................................................................... 123
3.5.8.4.1 [SENSe]:CURRent[:DC]:NPLCycles command/query.................................................... 123
3.5.8.4.2 [SENSe]:CURRent[:DC]:SRATE command/query.......................................................... 124
3.5.8.4.3 [SENSe]:CURRent[:DC]:APERture command/query...................................................... 125
3.5.8.4.4 [SENSe]:CURRent[:DC]:RESolution command/query.................................................... 126
3.5.8.4.5 [SENSe]:CURRent[:DC]:RANGe:AUTO command/query .............................................. 126
3.5.8.4.6 [SENSe]:CURRent[:DC]:RANGe[:UPPer] command/query............................................ 127
3.5.8.4.7 [SENSe]:CURRent[:DC]:ZERO:AUTO command/query................................................. 128
3.5.8.4.8 [SENSe]:CURRent[:DC]:NULL:STATe command/query ................................................ 128
3.5.8.4.9 [SENSe]:CURRent[:DC]:NULL:VALue command/query................................................. 129

Remote control - 6
3.5.8.5 SENSe:CURRent:AC subsystem........................................................................................... 130
3.5.8.5.1 [SENSe]:CURRent:AC:NPLCycles command/query ...................................................... 130
3.5.8.5.2 [SENSe]:CURRent:AC:SRATE command/query............................................................ 131
3.5.8.5.3 [SENSe]:CURRent:AC:APERture command/query........................................................ 132
3.5.8.5.4 [SENSe]:CURRent:AC:RANGe:AUTO command/query................................................. 133
3.5.8.5.5 [SENSe]:CURRent:AC:RANGe[:UPPer] command/query.............................................. 134
3.5.8.5.6 [SENSe]:CURRent:AC:NULL:STATe command/query................................................... 135
3.5.8.5.7 [SENSe]:CURRent:AC:NULL:VALue command/query................................................... 135
3.5.8.5.8 [SENSe]:CURRent:AC:BANDwidth command/query...................................................... 136
3.5.8.6 SENSe:RESistance subsystem ............................................................................................. 137
3.5.8.6.1 [SENSe]:RESistance:NPLCycles command/query......................................................... 137
3.5.8.6.2 [SENSe]:RESistance:SRATE command/query............................................................... 138
3.5.8.6.3 [SENSe]:RESistance:APERture command/query........................................................... 139
3.5.8.6.4 [SENSe]:RESistance:RESolution command/query......................................................... 140
3.5.8.6.5 [SENSe]:RESistance:RANGe:AUTO command/query ................................................... 140
3.5.8.6.6 [SENSe]:RESistance:RANGe[:UPPer] command/query................................................. 141
3.5.8.6.7 [SENSe]:RESistance:ZERO:AUTO command/query...................................................... 142
3.5.8.6.8 [SENSe]:RESistance:NULL:STATe command/query ..................................................... 142
3.5.8.6.9 [SENSe]:RESistance:NULL:VALue command/query...................................................... 143
3.5.8.7 SENSe:FRESistance subsystem........................................................................................... 144
3.5.8.7.1 [SENSe]:FRESistance:NPLCycles command/query....................................................... 144
3.5.8.7.2 [SENSe]:FRESistance:SRATE command/query............................................................. 145
3.5.8.7.3 [SENSe]:FRESistance:APERture command/query......................................................... 146
3.5.8.7.4 [SENSe]:FRESistance:RANGe:AUTO command/query................................................. 147
3.5.8.7.5 [SENSe]:FRESistance:RANGe[:UPPer] command/query .............................................. 148
3.5.8.7.6 [SENSe]:FRESistance:NULL:STATe command/query................................................... 149
3.5.8.7.7 [SENSe]:FRESistance:NULL:VALue command/query ................................................... 149
3.5.8.8 SENSe:CONTinuity subsystem.............................................................................................. 150
3.5.8.8.1 [SENSe]:CONTinuity:THReshold command/query......................................................... 150
3.5.8.9 SENSe:FREQuency subsystem............................................................................................. 151
3.5.8.9.1 [SENSe]:FREQuency:APERture command/query.......................................................... 151
3.5.8.9.2 [SENSe]:FREQuency:NULL:STATe command/query..................................................... 152
3.5.8.9.3 [SENSe]:FREQuency:NULL:VALue command/query..................................................... 152
3.5.8.9.4 [SENSe]:FREQuency:VOLTage:RANGe:AUTO command/query.................................. 153
3.5.8.9.5 [SENSe]:FREQuency:VOLTage:RANGe[:UPPer] command/query ............................... 154
3.5.8.9.6 [SENSe]:FREQuency:ACV command/query................................................................... 155
3.5.8.10 SENSe:PERiod subsystem.................................................................................................. 156
3.5.8.10.1 [SENSe]:PERiod:APERture command/query ............................................................... 156
3.5.8.10.2 [SENSe]:PERiod:NULL:STATe command/query.......................................................... 157
3.5.8.10.3 [SENSe]:PERiod:NULL:VALue command/query .......................................................... 157
3.5.8.10.4 [SENSe]:PERiod:VOLTage:RANGe:AUTO command/query ....................................... 158
3.5.8.10.5 [SENSe]:PERiod:VOLTage:RANGe[:UPPer] command/query..................................... 159
3.5.8.10.6 [SENSe]:PERiod:ACV command/query........................................................................ 160
3.5.8.11 SENSe:TEMPerature subsystem......................................................................................... 161

Remote control - 7
3.5.8.11.1 [SENSe]:TEMPerature:NPLCycles command/query .................................................... 161
3.5.8.11.2 [SENSe]:TEMPerature:SRATE command/query.......................................................... 162
3.5.8.11.3 [SENSe]:TEMPerature:APERture command/query...................................................... 163
3.5.8.11.4 SENSe]:TEMPerature:NULL:STATe command/query.................................................. 164
3.5.8.11.5 [SENSe]:TEMPerature:NULL:VALue command/query................................................. 164
3.5.8.11.6 [SENSe]:TEMPerature:ZERO:AUTO command/query................................................. 165
3.5.8.11.7 [SENSe]:TEMPerature:TRANsducer:TYPE command/query....................................... 166
3.5.8.11.8 [SENSe]:TEMPerature:TRANsducer:TC:TYPE command/query ................................. 166
3.5.8.11.9 [SENSe]:TEMPerature:TRANsducer:TC:CJUNCtion command/query......................... 167
3.5.8.11.10 [SENSe]:TEMPerature:TRANsducer:RTD:TYPE command/query............................. 168
3.5.8.11.11 [SENSe]:TEMPerature:TRANsducer:FRTD:TYPE command/query .......................... 168
3.5.9 DISPlay subsystem....................................................................................................................... 169
3.5.9.1 DISPlay[:WINDow[1|2][:STATe]] command/query................................................................. 169
3.5.9.2 DISPlay:WINDow[1|2]:BACKground:COLor command/query ............................................... 169
3.5.9.3 DISPlay:WINDow[1]:MODE command/query........................................................................ 170
3.5.9.4 DISPlay:WINDow2:MODE command/query.......................................................................... 170
3.5.9.5 DISPlay:MENU:ANIMation[:STATe] command/query............................................................ 171
3.5.9.6 DISPlay:NUMeric:DIGIts command/ query............................................................................ 171
3.5.9.7 DISPlay:NUMeric:FONT command/ query ............................................................................ 172
3.5.9.8 DISPlay:NUMeric:SIZE command/ query .............................................................................. 172
3.5.10 SYSTem subsystem ................................................................................................................... 173
3.5.10.1 SYSTem:BEEPer[:IMMediate] command............................................................................ 173
3.5.10.2 SYSTem:BEEPer:LIMit:STATe command/query................................................................. 173
3.5.10.3 SYSTem:BEEPer:KEY:STATe command/query.................................................................. 173
3.5.10.4 SYSTem:BEEPer:CAUTion:STATe command/query.......................................................... 174
3.5.10.5 SYSTem:LFRequency:AUTO command/query ................................................................... 174
3.5.10.6 SYSTem:LFRequency:ACTual query .................................................................................. 175
3.5.10.7 SYSTem:LFRequency command/query .............................................................................. 175
3.5.10.8 SYSTem:PRESet command................................................................................................ 176
3.5.10.9 SYSTem:HEADer:TYPE command/query........................................................................... 176
3.5.10.10 SYSTem:DATEtime command/query ................................................................................ 177
3.5.11 OUTPut subsystem..................................................................................................................... 178
3.5.11.1 OUTPut[:STATe] command/query....................................................................................... 178
3.5.12 HCOPy subsystem...................................................................................................................... 179
3.5.12.1 HCOPy[:SDUMp]:DATA query............................................................................................. 179
3.5.12.2 HCOPy[:SDUMp]:DATA:STORe:DIRectory command/query.............................................. 179
3.5.12.3 HCOPy[:SDUMp]:DATA:STORe command......................................................................... 180
3.5.12.4 HCOPy[:SDUMp]:DATA:FORMat command/query............................................................. 180
3.5.12.5 HCOPy[:SDUMp]:DATA:COLor command/query................................................................ 181
3.5.13 MEMory subsystem .................................................................................................................... 182
3.5.13.1 MEMory:NSTates query....................................................................................................... 182
3.5.13.2 MEMory:STATe:CATalog query........................................................................................... 182
3.5.13.3 MEMory:STATe:NAME query.............................................................................................. 182
3.5.13.4 MEMory:STATe:RECall:AUTO command/query ................................................................. 183

Remote control - 8
3.5.13.5 MEMory:STATe:RECall:SELect command/query................................................................ 183
3.5.14 SETUP subsystem...................................................................................................................... 184
3.5.14.1 SETUP:NAME command/query........................................................................................... 184
3.5.14.2 SETUP:LOAD:DIRectory command/query .......................................................................... 185
3.5.14.3 SETUP:LOAD command...................................................................................................... 185
3.5.14.4 SETUP:STORe:DIRectory command/query........................................................................ 186
3.5.14.5 SETUP:STORe command ................................................................................................... 186
3.5.14.6 SETUP:TRANsfer command/query ..................................................................................... 187
3.5.15 DATA subsystem ........................................................................................................................ 188
3.5.15.1 DATA:MODE command/query............................................................................................. 188
3.5.15.2 DATA:REMove query........................................................................................................... 189
3.5.15.3 DATA:LAST query................................................................................................................ 189
3.5.15.4 DATA:POINts query............................................................................................................. 190
3.5.15.5 DATA:DELete command...................................................................................................... 190
3.5.15.6 DATA:BULK:LENGth command/query ................................................................................ 190
3.5.15.7 DATA:BULK:POST command/qury ..................................................................................... 191
3.5.15.8 DATA:BULK:EVENt command/query .................................................................................. 191
3.5.15.9 DATA:BULK:LEVel[:VALue] command/query...................................................................... 192
3.5.15.10 DATA:BULK:LEVel:SLOPe command/query..................................................................... 192
3.5.15.11 DATA:BULK:LIMit command/query ................................................................................... 193
3.5.15.12 DATA:BULK:STATe query................................................................................................. 194
3.5.15.13 DATA:DIRectory command/query...................................................................................... 194
3.5.15.14 DATA:COPY command...................................................................................................... 195
3.5.16 STATus subsystem..................................................................................................................... 196
3.5.16.1 STATus:OPERation:CONDition query................................................................................. 196
3.5.16.2 STATus:OPERation[:EVENt] query ..................................................................................... 196
3.5.16.3 STATus:OPERation:ENABle command/query..................................................................... 197
3.5.16.4 STATus:OPERation:CONDition query................................................................................. 197
3.5.16.5 STATus:QUEStionable[:EVENt] query ................................................................................ 198
3.5.16.6 STATus:QUEStionable:ENABle command/query................................................................ 198
3.5.17 Status register control related command of instrument-specific................................................. 199
3.5.17.1 DDER query......................................................................................................................... 199
3.5.17.2 DDEE command/query ........................................................................................................ 199
3.5.17.3 MESR query......................................................................................................................... 200
3.5.17.4 MESE command/query........................................................................................................ 200
3.5.18 Lists of compatible commands in other instruments................................................................... 201
3.6 Adjustment by Remote ........................................................................................................................ 204
3.6.1 Remote adjustment command/query List ..................................................................................... 204
3.6.2 Shift to adjustment mode and return to normal (measurement) mode......................................... 206
3.6.3 Adjusted value writing................................................................................................................... 206
3.6.4 Each adjustment menu ................................................................................................................. 206
3.6.5 Adjustment menu required parameter .......................................................................................... 206
3.7 Instrument-specific command (VOAC752x series compatible)........................................................... 207
3.7.1 Main differences............................................................................................................................ 207

Remote control - 9
3.7.1.1 Expanded functions................................................................................................................ 207
3.7.1.2 Limited function...................................................................................................................... 208
3.7.1.3 Non-supported function.......................................................................................................... 208
3.7.1.4 Setting item for each measurement function ......................................................................... 209
3.7.1.5 Deffernce of data store/recall function ................................................................................... 209
3.7.2 MAIN related commands .............................................................................................................. 210
3.7.3 SUB-related commands................................................................................................................ 212
3.7.4 Measurement function-related commands ................................................................................... 212
3.7.5 DUAL-relate commands................................................................................................................ 212
3.7.6 Other commands........................................................................................................................... 213
3.7.7 Measures for sampling rate .......................................................................................................... 215
3.7.8 About temperature measurement................................................................................................. 215
3.7.9 Response message of measurement result ................................................................................. 216
3.7.9.1 Short format............................................................................................................................ 216
3.7.9.2 Long format............................................................................................................................ 216

Remote control - 10
MEMO

1
1. General
This instrument can be operated by remote control through an external controller (usually a personal
computer) in almost the same way as when you operate it manually using buttons.
Data on measurement results and panel setup can also be transferred by remote control. So you can
collect data using a personal computer and configure the automatic measurement system.
2. Remote Control
There are four methods for operating this instrument by remote control:
(1) Remote control by using the standard USB with which this instrument is equipped
(2) Remote control by using the standard LAN (TCP/IP) with which this instrument is equipped
(3) Remote control by using the RS-232 interface
(4) Remote control by using the GPIB interface
The following interfaces are factory options.
RS-232LAN interface ：SC-361
GPIB interface ：SC-363
Interfaces used remotely are set by using REMOTE from the SYSTEM menu of this instrument. Refer
to the following sections for the setting and control methods of each interface.
USB interfaces are standard on the majority of personal computers and are therefore a useful method
of remote control. However, note that the connection cable length poses a limitation.
LAN interfaces are also standard on the majority of personal computers, and can be used by
connecting to an existing network environment instead of by directly connecting a cable. However,
this method requires a unique IP address to be assigned to this instrument.
2.1 Restrictions of remote control
It is possible to remotely control almost all of the functions provided on this instrument.
However, the power switch ON/OFF, various settings about remote interface in the SYSTEM menu,
offline browse function and VALUE TO USBMEM function etc. cannot be controlled remotely.
For details about functions operated through the remote control and control commands, see Chapter
3, Remote control commands.
2.2 Remote/local control
A state, in which each function of this instrument is remotely controlled by messages sent through the
interface, is called “remote mode”. On the contrary, a state, in which the instrument is operated by
panel key entries, is called “local mode.”
In the remote mode, all panel keys except for the LOCAL(SHIFT]) key become invalid. At this time,
the REMOTE indicator is displayed in the annunciator.

2
Shift to remote mode
< SCPI conforming >
When the command system shifts to remote mode in accordance with SCPI (When "SCPI" has
been selected with COMMAND of the SYSTEM-REMOTE menu), this instrument does the
following behavior.
- It becomes a measurement halt state. Use the command (INITiate command and READ? query,
etc.) that changes to the trigger waiting state when measuring. (Refer to "3.5.4 TRIGger
subsystem" for details.)
- Offline browse state is released.
- If the bulk log is being executed, the bulk log is stopped.
- The setting of an external trigger is changed according to the remote setting of the trigger
source.
< VOAC752x series conforming >
When the command system shifts to remote mode in accordance with IWATSU (When "IWATSU"
has been selected with COMMAND of the SYSTEM-REMOTE menu), this instrument does the
following behavior.
- It is changed to the value that can be set for the item to which use remotely in accordance with
the VOAC752x series like a part of sampling rate and the bulk log, etc. is limited. (Refer to
"3.7.1.2 Limited function " for details.)
- The preservation of the log (Depend on the SAVE:STAT command) is changed according to the
ON/OFF setting of the data store.
Shift to local mode
Execute after confirming the action of all command/query transmitted till then is completed by
using * OPC? query (Refer to section 3.4.5) etc. when switching to the local mode. The
unanticipated operation may be caused when shifting to the local mode without waiting for the
completion of processing.
< SCPI conforming >
When the command system shifts to local mode in accordance with SCPI (When "SCPI" has been
selected with COMMAND of the SYSTEM-REMOTE menu), this instrument does the following
behavior.
- The setting of an external trigger returns to the state when not depending on the setting of the
trigger source remotely, and having set it in the local at the end.
< VOAC752x series conforming >
When the command system shifts to local mode in accordance with IWATSU (When "IWATSU"
has been selected with COMMAND of the SYSTEM-REMOTE menu), this instrument does the
following behavior.
- It doesn't depend on the ON/OFF setting of the store of data (Depend on the SAVE:STAT
command), and it becomes log mode NORMAL operation (always preservation operation).
In the method of switching local mode / remote mode, there are different parts in each interface.

3
Refer to the following for details.
- USB : Section 2.3.2
- LAN : Section 2.4.6
- RS-232 : Section 2.5.5
- GPIB : Section 2.6.4

4
2.3 Remote control using USB
This instrument can be operated through remote controls by using a USB interface by
connecting the USB port on the back panel and a computer. You can obtain the driver and
sample application that can be used with the computer from the Iwatsu website (URL:
http://www.iti.iwatsu.co.jp). See the website for details.
Use a USB 2.0 A/B cable to connect this instrument to a computer.
Note: A cable for noise reduction (shielding) may be required and is recommended when operating
this instrument through remote controls using a LAN in a problematic noise environment. For more
information, contact an Iwatsu sales representative or a service center.
2.3.1 Settings for this instrument
From the SYSTEM menu, set REMOTE to “USB”.
2.3.2 Remote/local controls
a. Local mode
In local mode, the instrument is operated by using keys from a panel.
REMOTE icon is off.
This instrument is in local mode when the power is turned on.
There are three ways to return to an instrument that is running in remote mode to local mode.
Restart the power.
Press the LOCAL ([SHIFT]) key.
Close the corresponding COM port on the computer.
b. Remote mode
In remote mode, this instrument is remotely controlled by messages sent through an interface. All
panel keys except for the LOCAL ([SHIFT]]) key become invalid.
The REMOTE icon is ON during the remote period.
This instrument switches to remote mode when the COM port described above has been opened
and a message has been received from a computer.
c. Local lock out mode
This instrument does not support local lock out mode other than for the GPIB interface. When a
lock out operation is necessary, use the GPIB interface.

5
2.4 Remote control using a LAN
This instrument’s remote control can be used with a LAN interface when connected to a computer via
the Ethernet port on the rear panel. The driver and sample application that can be used with a
computer are available at the Iwatsu website (URL: http://www.iti.iwatsu.co.jp). See the website for
details.
This instrument can be plugged into a network or connected directly to a host computer.
This instrument has an Auto-MDIX function, so a cross or straight Ethernet cable can be used to
connect it.
Note: A cable for noise reduction (shielding) may be required and is recommended when operating
this instrument through remote controls using a LAN in a problematic noise environment. For more
information, contact an Iwatsu sales representative or a service center.
LAN interface is a factory option (RS-232LAN interface: SC-361).
2.4.1 Settings for this instrument
In the SYSTEM menu, set REMOTE to “LAN”.
When set to LAN, the following settings can be entered (these settings cannot be modified by remote
control).
Table 2-1. Communication Settings when LAN is Selected for REMOTE
Setting
Function
IP ADDRESS
The IP address can be set when DHCP is “OFF”.
The default setting is 10.102.102.102.
The IP address allocated can be confirmed when DHCP is “ON”.
SUBNET
MASK
The subnet mask can be set when DHCP is “OFF”.
The default setting is 255.255.255.0.
The subnet mask allocated can be confirmed when DHCP is “ON”.
DEFAULT
GW
The default gateway can be set when DHCP is “OFF”.
The default setting is 10.102.102.100.
The default gateway allocated can be confirmed when DHCP is “ON”.
DHCP
Sets the DHCP function to “On” or “Off”.
When set to “On”, the required connection information is obtained automatically.
When set to “OFF”, set the “IP ADDRESS”, “SUBNET MASK”, and “DEFAULT GW” separately.
The default setting is “OFF”.
MAC
ADDRESS
The MAC address value that is unique to each instrument unit can be confirmed.
This MAC address is an instrument-specific value and cannot be modified.
When settings have been changed, new LAN settings become valid when the power supply to this
instrument is turned back ON.
For details of the settings, check with the administrator of the network to be connected.

6
2.4.2 Communication settings on computer
The communication settings for control software when using remote control with the TCP/IP interface
are described below.
Table 2-2. Communication Settings when LAN is Selected for REMOTE
Item
Setting
TCP/IP port number (connect to)
5198
Delimiter (transmit Note 1)
LF or CR+LF
Delimiter (receive Note 2)
LF or CR+LF
Note 1) This means a computer sends data to this instrument.
Note 2) This means a computer receives data from this instrument.
2.4.3 Connect to network
Before this instrument is connected to a network, a query for information must be sent to the network
administrator. If an incorrect address is specified for the network, unexpected operations may occur
both on the network and in this instrument.
Note) If the computer and this instrument are included in the different networks (i.e. not exist on the
same subnet), it is necessary to set the gateway correctly.
To check the physical connection between this instrument and a computer, perform the following
steps.
1. When a cable has not been connected, set the network connection settings correctly, and
turn OFF the power temporarily
2. Leave the power OFF and connect the cable.
Use a cable to connect to the network terminal such as a hub on this instrument or a
computer. This instrument has an Auto-MDIX function, and either a cross or straight cable
can be used for this connection.
3. Turn ON the power to this instrument.
2.4.4 Check IP connection
A “ping” command from the computer can be used to check connections on the IP network. This
command sends IP packets to the network equipment, and normal status of the IP network is
confirmed when the corresponding response is received.
The “ping” command can be used in a Windows or UNIX environment. In the case of Windows, enter
a command such as the following at the command prompt.
C:¥>ping 10.102.102.102 ()
() The arguments that follow “ping” in this command specify the network equipment whose
connection will be checked, so enter the IP address assigned to this instrument. In this input example,
“10.102.102.102” is used, but this part should be replaced to match the target use environment. Also,
