iXsystems TrueNAS ES24 Manual

TrueNAS®ES24 Expansion Shelf
Basic Setup Guide
Version 1.6

Copyright © 2019 iXsystems, Inc. All rights reserved. All trademarks are the property of their respective owners.
1ES24ExpansionShelfThe TrueNAS®ES24 is a 4U, 24-bay, SAS3 (12 Gb/s) expansion shelf with dual expansion controllers and redundant
power supplies.
TrueNAS®units are carefully packed and shipped with trusted carriers to arrive in perfect condition. If there is
any shipping damage or any parts are missing, please take photos and contact iXsystems support immediately at
[email protected]or 855-GREP4-iX (855-473-7449) or 408-943-4100.
Please locate and record the hardware serial numbers on the back of each chassis for quick reference.
Carefully unpack the shipping boxes and locate the ES24 expansion shelf (#1), rail kit(#2), a total of 24 drive trays
and empty bay fillers (#3), two 3-meter Mini SAS HD cables (#4), a serial cable (#5), two IEC C13 to NEMA 5-15P power
cords and two IEC C13 to IEC C14 power cords (#6), and a set of hardware (#7).
Support: 855-473-7449 or 408-943-4100 Page 1 Email [email protected]

1.1BecomeFamiliarWiththeES24The ES24 has front panel buttons for power (#1), alarm mute (#2), and locate ID (#3). There are lights for power
(#1), locate ID (#3), and fault (#4). The fault light illuminates during the initial power-on self-test (POST) or when the
TrueNAS®software has issued an alert. See the Alert section in the Additional Options chapter of the TrueNAS®
User Guide (https://www.ixsystems.com/documentation/truenas).
Fig. 1: Back Panel
On the back panel is a serial number (#1), two redundant power supplies (#2), and two expansion controllers (#5).
Each expansion controller has two HD Mini SAS3 connectors (#3) for connection to a host, and another HD Mini
SAS3 connector for expansion (#4).
Support: 855-473-7449 or 408-943-4100 Page 2 Email [email protected]

1.2ES24andM-SeriesRailAssembly1.2.1RemoveCabinetRailsfromRackRailsExtend the inner rack rail until it locks in place (1). Slide out the cabinet rail until it stops (2).
Remove the cabinet rail by sliding the white release tab away from the inner rack rail (3), then pull the cabinet rail
free (4).
1.2.2MountCabinetRailsThe cabinet rails are mounted on both sides of the system cabinet. Align the cabinet rail keyholes with the three
posts (ES24) or four posts (M-Series) on the side of the chassis and slide the rail until the post is secured in the
keyhole slot of the rail.
Align the rail hole with the screw hole and secure the rail with one M4x4L screw. Repeat this process to mount
and secure the second cabinet rail on the other side.
Support: 855-473-7449 or 408-943-4100 Page 3 Email [email protected]

1.2.3MounttheRackRailsA TrueNAS®M-Series or ES24 requires 4U of vertical rack space. The rack rails are installed in the bottom 2U of
the total 4U height.
The inner rack rail must be unlocked and retracted before installing the rail in the rack. Rotate the release lever on
the back of the inner rail clockwise as shown on the arrow label (1). Push the inner rail toward the back of the rail
assembly until it stops (2).
Place the rail in the rack with the front end toward the front of the rack, aligning the pins with the mounting holes
in the front of the rack. Push the pins into the holes until the latch clicks.
At the rear end of the rail, align the pins with the rack holes, making sure the rail is level. Swing the gray latch han-
dle outward (1) and pull it to extend the rail rearwards until the rail pins are fully seated in the rack holes (2). Re-
lease the latch to allow it to lock into place. Repeat the process for the second rack rail.
Support: 855-473-7449 or 408-943-4100 Page 4 Email [email protected]

1.2.4MounttheUnitintheRackCaution: Two people are required to safely lift the chassis for rack installation or removal. Do not install
drives until after the chassis has been installed in the rack, and remove all drives before removing the chassis
from the rack.
Extend both inner rack rails outward from the rack until they lock in place. Align the cabinet rails with the inner
rack rails and slide them into the rack rails until they are fully seated.
When both cabinet rails are secured in the rack rails, gently push the chassis until it stops halfway in. Slide the
blue release tabs on both cabinet rails toward the front of the system (1) while pushing the unit into the rack.
Push the chassis into the rack until it is flush with the front of the rack (2).
Anchor the unit in the rack on both sides with long M5 screws. On the M-Series, the screw hole is behind a small
door on each ear.
Support: 855-473-7449 or 408-943-4100 Page 5 Email [email protected]

1.3InstallDriveTraysDrives are mounted in drive trays, which are then installed in drive bays in the ES24 or M-Series chassis.
Each drive bay in the chassis has two indicator lights to the right of the tray. The upper light is blue when the drive
is active. The lower light is solid red if a fault has occurred. Both lights blink to identify drives that are hot spares.
Press the silver button on the drive tray to open the latch. Carefully slide the tray into a drive bay until the right
side of the latch touches the metal front edge of the chassis, then gently swing the latch closed until it clicks into
place.
All drive bays must be filled to maintain proper airflow for cooling. If fewer than 24 drives are connected, filler
blanks must be placed in the empty bays.
1.4ConnectPowerCordsDo not plug the power cords into a power outlet yet. Connect a power cord to the back of one power supply.
Place the cord into the plastic clamp and press the tab into the latch to lock it in place. Repeat the process for the
second power supply and cord.
Support: 855-473-7449 or 408-943-4100 Page 6 Email [email protected]

1.5ConnectTheExpansionShelfPlug the ES24 power cords into power outlets. Wait two minutes for the drives to start.
If the TrueNAS®system is on, it can remain on while the expansion shelf is connected.
The ES24 is compatible with several TrueNAS®systems. Typical SAS cable connections for connecting one or two
ES24 units to TrueNAS®High Availability (HA) systems are shown here. When a TrueNAS®unit with only a single
storage controller is used, only cables #1 and #3 are connected.
X-Series
M40
M50
Support: 855-473-7449 or 408-943-4100 Page 7 Email [email protected]

The SAS cables from the TrueNAS®system connect to these ports on the ES24:
• Connect cable #1 to the first ES24, expansion controller 1 SAS 0 port.
• Connect cable #2 to the first ES24, expansion controller 2 SAS 0 port.
If a second ES24 is present:
• Connect cable #3 to the second ES24, expansion controller 1 SAS 0 port.
• Connect cable #4 to the second ES24, expansion controller 2 SAS 0 port.
Support: 855-473-7449 or 408-943-4100 Page 8 Email [email protected]

1.6UserGuideThe TrueNAS®User Guide has complete software configuration and usage instructions. It is available by clicking
Guide in the TrueNAS®web interface or going directly to https://www.ixsystems.com/documentation/truenas/.
2ContactingiXsystemsFor assistance, please contact iX Support:
Contact Method Contact Options
Web https://support.ixsystems.com
Email [email protected]Telephone Monday - Friday, 6:00AM to 6:00PM Pacific Standard Time:
• US-only toll-free: 855-473-7449 option 2
• Local and international: 408-943-4100 option 2
