NEC Express5800/T120a-E N8100-1531F User manual

N8100-1531F/1532F/1533F
N8100-1566F/1567F/1568F
NEC Express5800/T120a-E
User's Guide
3rd Edition
10-2009
ONL510_010_04-T120a-E-100-99-0910

PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is the
valuable property of NEC Corporation (NEC) and /or its licensors. NEC and/or its licensors, as
appropriate, reserve all patent, copyright and other proprietary rights to this document, including all
design, manufacturing, reproduction, use, and sales rights thereto, except to the extent said rights are
expressly granted to others.
The NEC product(s) discussed in this document are warranted in accordance with the terms of the
Warranty Statement accompanying each product. However, actual performance of each such
product is dependent upon factors such as system configuration, customer data, and operator control.
Since implementation by customers of each product may vary, the suitability of specific product
configurations and applications must be determined by the customer and is not warranted by NEC.
To allow for design and specification improvements, the information in this document is subject to
change at any time, without notice. Reproduction of this document or portions thereof without prior
written approval of NEC is prohibited.
First Printing, February 2009
Revised, October 2009
Copyright 2009
NEC Corporation
7-1 Shiba 5-Chome, Minato-Ku
Tokyo 108-8001, Japan
All Rights Reserved
Printed in Japan

Keep this manual at hand for quick reference at anytime necessary.
SAFETY INDICATIONS
Follow the instructions in this manual for your safety to use the NEC Express server.
Your server contains components with possible danger, hazards that may cause by ignoring
warnings, and preventive actions against such hazards.
Server components with possible danger are indicated with a warning label placed on or around them
as well as described in this manual.
In this manual or warning labels, "WARNING" or "CAUTION" is used to indicate a degree of danger.
These terms are defined as follows:
WARNING Indicates the presence of a hazard that may result in death or serious
personal injury if the instruction is ignored.
CAUTION Indicates the presence of a hazard that may cause minor personal injury,
including burns, or property damage if the instruction is ignored.
Precautions and notices against hazards are presented with one of the following three symbols. The
individual symbols are defined as follows:
This symbol indicates the presence of a hazard if the instruction is ignored.
An image in the symbol illustrates the hazard type. (Attention)
This symbol indicates prohibited actions. An image in the symbol
illustrates a particular prohibited action. (Prohibited Action)
This symbol indicates mandatory actions. An image in the symbol
illustrates a mandatory action to avoid a particular hazard. (Mandatory
Action)
(Example)
Symbol to draw attention
Term indicating a degree of danger
CAUTION
Plug in to a proper power source.
Use a proper wall outlet of the specified voltage. Use of an improper power
source may cause a fire or a power leak.
Symbol indicating a prohibited
action (may not always be
indicated)
Description of a danger

SYMBOLS USED IN THIS MANUAL AND WARNING LABELS
Attentions
Indicates that improper use may cause an electric shock.
Indicates that improper use may cause fingers to be caught.
Indicates that improper use may cause personal injury.
Indicates that improper use may cause personal injury.
Indicates that improper use may cause fumes or fire.
Indicates that improper use may cause loss of eyesight due to laser beam.
Indicates that improper use may cause explosion.
Indicates a general notice or warning that cannot be specifically identified.
Prohibited Actions
Do not disassemble, repair, or modify the server. Otherwise, an electric shock or fire
may be caused.
Do not place the server near the fire. Otherwise, a fire may be caused.
Do not touch the component specified by this symbol. Otherwise, an electric shock or
burn may be caused.
Do not use the server in the place where water or liquid may pour. Otherwise, an
electric shock or fire may be caused.
Do not touch the server with wet hand. Otherwise, an electric shock may be caused.
Indicates a general prohibited action that cannot be specifically identified.
Mandatory Action
Unplug the power cord of the server. Otherwise, an electric shock or fire may be
caused.
Be sure to provide earthing. Otherwise, an electric shock or fire may be caused.
Indicates a mandatory action that cannot be specifically identified. Make sure to follow
the instruction.

FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Warning
This is a Class A product. In domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Momentary voltage drop prevention:
This product may be affected by a momentary voltage drop caused by lightning. To prevent a
momentary voltage drop, an AC uninterruptible power supply (UPS) unit should be used.
BSMI Statement

Trademarks
NEC ESMPRO and NEC EXPRESSBUILDER are trademarks of NEC Corporation.
Microsoft, Windows, Windows Server, and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in
the United States and other countries.
Intel, Pentium, and Xeon are registered trademarks of Intel Corporation.
PCI Express is a trademark of Peripheral Component Interconnect Special Interest Group.
Datalight is a registered trademark of Datalight, Inc.
ROM-DOS is a registered trademark of Datalight, Inc.
AT is a registered trademark of International Business Machines Corporation in the United States and other countries.
Adaptec and its logo is a registered trademark of Adaptec, Inc. of United States.
LSI and the LSI logo design are trademarks or registered trademarks of LSI Corporation.
Adobe, Adobe logo, and Acrobat are trademarks of Adobe Systems Incorporated.
DLT and DLTtape are trademarks of Quantum Corporation of the United States.
AVOCENT and DVC (Dambrackas Video Compression) are registered trademarks or trademarks of AVOCENT in the
United States and other countries.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their
respective trademark owners.
Windows Server 2008 stands for Microsoft® Windows Server® 2008 Standard operating system and Microsoft® Windows
Server® 2008 Enterprise operating system. Windows Vista stands for Microsoft® Windows Vista® Business operating
system. Windows Server 2003 x64 Editions stands for Microsoft® Windows Server® 2003 R2, Standard x64 Edition
Operating system and Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition operating system, or Microsoft®
Windows Server® 2003, Standard x64 Edition operating system and Microsoft® Windows Server® 2003, Enterprise x64
Edition operating system. Windows Server 2003 stands for Microsoft® Windows Server® 2003 R2, Standard Edition
operating system and Microsoft® Windows Server® 2003 R2, Enterprise Edition operating system, or Microsoft® Windows
Server® 2003, Standard Edition operating system and Microsoft® Windows Server® 2003, Enterprise Edition operating
system. Windows XP x64 Edition stands for Microsoft® Windows® XP Professional x64 Edition operating system.
Windows XP stands for Microsoft® Windows® XP Home Edition operating system and Microsoft® Windows® XP
Professional operating system. Windows 2000 stands for Microsoft® Windows® 2000 Server operating system and
Microsoft® Windows® 2000 Advanced Server operating system, and Microsoft® Windows® 2000 Professional operating
system. Windows NT stands for Microsoft® Windows NT® Server network operating system version 3.51/4.0 and
Microsoft® Windows NT® Workstation operating system version 3.51/4.0. Windows Me stands for Microsoft® Windows®
Millennium Edition operating system. Windows 98 stands for Microsoft® Windows®98 operating system. Windows 95
stands for Microsoft® Windows®95 operating system. WinPE stands for Microsoft® Windows® Preinstallation
Environment.
Notes:
(1) No part of this manual may be reproduced in any form without the prior written permission of
NEC Corporation.
(2) The contents of this manual may be revised without prior notice.
(3) The contents of this manual shall not be copied or altered without the prior written permission
of NEC Corporation.
(4) All efforts have been made to ensure the accuracy of all information in this manual. If you
notice any part unclear, incorrect, or omitted in this manual, contact the service representative
where you purchased this product.
(5) NEC assumes no liability arising from the use of this product, nor any liability for incidental or
consequential damages arising from the use of this manual regardless of Item (4).

i
PREFACE
Congratulations on the purchase of your NEC Express server.
Purchase of this server is your assurance of receiving state-of-the-art, high quality hardware to meet
your needs, both now and in the future.
Read this User's Guide thoroughly to fully understand handling of the NEC Express server and
appreciate its functions to the maximum extent.

ii
ABOUT THIS USER'S GUIDE
This manual is a guide for proper setup and use of your server.
This manual also covers useful procedures for dealing with difficulties and problems that may arise
during setup or operation of your server.
Keep this manual for future use.
The following describes how to proceed with this manual.
How to Use This Manual
To aid you in finding information quickly, this manual contains the following information:
Chapter 1 Notes on Using Your Server
includes information that needs attention to use the server. Make sure to read this chapter before
setting up and using the server. It also includes requirements and advisory information for
transfer and disposal of the server.
Chapter 2 General Description
includes information necessary to use the server, such as names and functions of its
components, handling of the optical disk drive.
Chapter 3 Setting Up Your Server
tells you how to select a site, unpack the system, make cable connections, and power on your
system.
Chapter 4 Configuring Your Server
tells you how to configure the system and provides instructions for running the BIOS SETUP
Utility and the RAID configuration utility, which is used to configure RAID drives in your system.
This chapter also provides information on mother board jumper settings.
Chapter 5 Installing the Operating System with Express Setup
describes how to install the operating system.
Chapter 6 Installing and Using Utilities
describes how to install the utilities for the server. It also includes a description on using the
attached "NEC EXPRESSBUILDER" DVD.
Chapter 7 Maintenance
provides you with all the information necessary to maintain successful operation of the server.
This chapter also includes a description on relocating and storing the server.
Chapter 8 Troubleshooting
contains helpful information for solving problems that might occur with your system.
Chapter 9 Upgrading Your Server
provides you with instructions for upgrading your system with an additional processor, optional
memory, optional add-in cards, hard disk drives, peripheral devices, and power supply.
Chapter 10 Internal Cabling Diagram
includes cabling information for the SAS/SATA2 controller, 5.25-inch device, and the power
supply.
Appendix A Specification
provides specifications for your server.

iii
Appendix B Other Precautions
provides supplementary notes on using the server.
Appendix C IRQ and I/O Port Address
provides a list of factory-set IRQs and I/O port addresses assigned.
Appendix D Installing Windows Server 2008
describes how to install Microsoft Windows Server 2008 without using Express Setup. Using the
Express Setup tool is recommended for installing Windows Server 2003 x64 Editions. See
Chapter 5 for details.
Appendix E Installing Windows Server 2003 x64 Editions
describes how to install Microsoft Windows Server 2003 x64 Editions without using Express
Setup. Using the Express Setup tool is recommended for installing Windows Server 2003 x64
Editions. See Chapter 5 for details.
Appendix F Installing Windows Server 2003
describes how to install Microsoft Windows Server 2003 without using Express Setup. Using the
Express Setup tool is recommended for installing Windows Server 2003. See Chapter 5 for
details.
Appendix G Using a Client Computer Which Has a CD Drive
describes how to install the management software of EXPRESSBUILDER to the client
computer without the DVD drive.
Appendix H Product Configuration Record Table
provides a table to be filled with your server configuration.
Text Conventions
The following conventions are used throughout this manual. For safety symbols, see "SAFETY
INDICATIONS" provided earlier.
IMPORTANT: Items that are mandatory or require attention when using the server
NOTE: Helpful and convenient piece of information
IN THE PACKAGE
The carton contains various accessories, as well as the server itself. See the packing list to make
sure that you have everything and that individual components are not damaged. If you find any
component missing or damaged, contact your service representative.
Store the provided accessories in a designated place for your convenience. You will need
them to install an optional device or troubleshoot your server, as well as to set it up.
Make a backup copy of each provided floppy disk, if any. Store the original disk as the
master disk in a designated place, and use its copy.
Improper use of any provided DVD/CD-ROM may alter your system environment. If you
find anything unclear, immediately ask your service representative for help.

iv
CONTENTS
Preface ..............................................................................................................................................i
About This User's Guide..................................................................................................................ii
In the Package.................................................................................................................................iii
Chapter 1 Notes on Using Your Server........................................................................ 1-1
Warning Labels.............................................................................................................................1-2
Safety Notes..................................................................................................................................1-3
General .....................................................................................................................................1-3
Power Supply and Power Cord Use .........................................................................................1-4
Installation, Relocation, Storage, and Connection....................................................................1-6
Cleaning and Working with Internal Devices...........................................................................1-8
During Operation .....................................................................................................................1-9
For Proper Operation ..................................................................................................................1-10
Transfer to Third Party ...............................................................................................................1-11
Disposal and Consumables .........................................................................................................1-12
Regarding the Transportation of this System..............................................................................1-12
User Support...............................................................................................................................1-13
Chapter 2 General Description ..................................................................................... 2-1
Overview ......................................................................................................................................2-2
System Chassis .............................................................................................................................2-3
Front View................................................................................................................................2-3
Rear View.................................................................................................................................2-6
Internal View ............................................................................................................................2-9
Mother Board .........................................................................................................................2-12
Standard Features .......................................................................................................................2-13
Peripheral Bays ......................................................................................................................2-14
AC LINK Feature...................................................................................................................2-14
Security ..................................................................................................................................2-14
NEC EXPRESSBUILDER ....................................................................................................2-15
NEC ESMPRO.......................................................................................................................2-16
Maintenance Tools .................................................................................................................2-16
System Diagnostic Utility ......................................................................................................2-16
Remote Management..............................................................................................................2-17
Using Your Server.......................................................................................................................2-18
POWER Switch......................................................................................................................2-18
Power Off ...............................................................................................................................2-22
SLEEP Switch ........................................................................................................................2-22
Optical Disk Drive .................................................................................................................2-23

v
Chapter 3 Setting Up Your Server ................................................................................ 3-1
Setup Flow....................................................................................................................................3-2
Unpacking the System ..................................................................................................................3-3
Installing Optional Devices ..........................................................................................................3-3
Selecting Server Site.....................................................................................................................3-4
Connecting Peripheral Devices.....................................................................................................3-6
Connecting Power Cord..............................................................................................................3-10
Turning On the Server ................................................................................................................3-11
Installing Operating System .......................................................................................................3-13
Installing Utilities .......................................................................................................................3-13
Making Backup Copies of System Information..........................................................................3-13
Chapter 4 Configuring Your Server.............................................................................. 4-1
System BIOS (SETUP) ................................................................................................................4-1
Starting SETUP Utility.............................................................................................................4-2
Description on On-Screen Items and Key Usage .....................................................................4-3
Menu and Parameter Descriptions ...........................................................................................4-4
RAID System Configuration ......................................................................................................4-23
RAID......................................................................................................................................4-23
Configuration by Onboard RAID Controller (3.5-inch Disk Model).....................................4-30
LSI Software RAID Configuration Utility and Universal RAID Utility................................4-45
Configuration by Internal RAID Controller (2.5-inch Disk Model) ......................................4-48
Before Using WebBIOS .........................................................................................................4-53
Using WebBIOS.....................................................................................................................4-56
Configuring Virtual Drive ......................................................................................................4-72
Operation of Various Features ................................................................................................4-88
Locate.....................................................................................................................................4-99
Slow Initialize ......................................................................................................................4-100
WebBIOS and Universal RAID Utility ................................................................................4-101
Configuring Mother Board Jumpers .........................................................................................4-105
Chapter 5 Installing the Operating System with Express Setup............................... 5-1
About Express Setup ....................................................................................................................5-2
Windows Server 2008...................................................................................................................5-3
Notes on Windows Installation.................................................................................................5-3
Flow of Setup ...........................................................................................................................5-8
Installing the Windows Server 2008.........................................................................................5-9
Installing and Setting Device Drivers.....................................................................................5-23
The procedure to set PAE option............................................................................................5-31
Setting for Solving Problems .................................................................................................5-31
Windows Server 2003.................................................................................................................5-32
Notes on Windows Installation...............................................................................................5-32
Flow of Setup .............................................................................................................................5-37
Installing Windows Server 2003.................................................................................................5-38

vi
Installing and Setting Device Drivers.........................................................................................5-47
PROSet...................................................................................................................................5-47
Network Driver ......................................................................................................................5-48
Optional Network Board Driver.............................................................................................5-49
Adapter Fault Tolerance (AFT)/Adaptive Load Balancing (ALB).........................................5-50
Setting WOL ..........................................................................................................................5-52
Graphics Accelerator Driver...................................................................................................5-54
Installing SCSI Controller Driver (N8103-75/95/107)...........................................................5-54
Installing SAS Controller Driver (N8103-104A) ...................................................................5-54
Installing RAID Controller Driver (N8103-115)....................................................................5-55
The procedure to set PAE option............................................................................................5-56
Setting for Solving Problems .................................................................................................5-57
Setting for Solving Problems......................................................................................................5-58
Memory Dump (Debug Information).....................................................................................5-58
How to Create a User-mode Process Dump File....................................................................5-63
Network Monitor....................................................................................................................5-65
Re-installing the Operation System if Multiple Logical Drives Exist....................................5-67
Installing Maintenance Utilities..................................................................................................5-69
Updating the System...................................................................................................................5-69
Making Backup Copies of System Information..........................................................................5-70
Installing with the OEM-Disk for Mass Storage Device........................................................5-71
Chapter 6 Installing and Using Utilities ....................................................................... 6-1
NEC EXPRESSBUILDER...........................................................................................................6-2
Autorun Menu ..........................................................................................................................6-6
Parameter File Creator..................................................................................................................6-7
Parameter File ..........................................................................................................................6-8
NEC ESMPRO ...........................................................................................................................6-20
Functions and Features...........................................................................................................6-20
Universal RAID Utility...............................................................................................................6-21
Setup with Express Setup.......................................................................................................6-21
Manual Setup .........................................................................................................................6-22
Using Universal RAID Utility via Network...........................................................................6-23
Easy Configuration.................................................................................................................6-23
Creating Logical Drive of RAID 6.........................................................................................6-23
NEC Product Info Collection Utility ..........................................................................................6-24
Installation..............................................................................................................................6-24
Using Utility...........................................................................................................................6-25
Uninstallation .........................................................................................................................6-25
Chapter 7 Maintenance.................................................................................................. 7-1
Making Backup Copies ................................................................................................................7-1
Cleaning........................................................................................................................................7-2
Cleaning the Server ..................................................................................................................7-2
Cleaning the Interior.................................................................................................................7-3
Cleaning the Keyboard/Mouse.................................................................................................7-4
Cleaning Disc ...........................................................................................................................7-5

vii
System Diagnostics.......................................................................................................................7-6
Test Items .................................................................................................................................7-6
Startup and Exit of System Diagnostics ...................................................................................7-7
Notes on Using Power Control Feature..................................................................................7-10
Relocating/Storing The Server....................................................................................................7-12
Chapter 8 Troubleshooting ........................................................................................... 8-1
System Viewers ............................................................................................................................8-2
Lamps ...........................................................................................................................................8-3
POWER/SLEEP Lamp.............................................................................................................8-7
Status Lamp..............................................................................................................................8-7
DISK Access Lamp ..................................................................................................................8-9
LAN Access Lamp (1) / (2)......................................................................................................8-9
LINK/ACT Lamp.....................................................................................................................8-9
1000/100/10 Lamp ...................................................................................................................8-9
100/10 Lamp ............................................................................................................................8-9
Hard Disk Drive Lamp...........................................................................................................8-10
Error Messages ...........................................................................................................................8-12
Error Messages after Power-on ..............................................................................................8-12
POST Error Messages ............................................................................................................8-13
Messages displayed by RAID Controller during POST.........................................................8-17
Beep Codes.............................................................................................................................8-21
Error Messages on Virtual LCD .............................................................................................8-22
Solving Problems........................................................................................................................8-24
Problems with NEC Express Server.......................................................................................8-24
Problems with Windows.........................................................................................................8-29
Problems with RAID System Configuration..........................................................................8-36
Problems with NEC EXPRESSBUILDER ............................................................................8-40
Problems with Express Setup .................................................................................................8-41
Problems with Parameter File Creator ...................................................................................8-43
Problems with RAID System Configuration..........................................................................8-44
Problems with Autorun Menu ................................................................................................8-46
Collecting Event Log .............................................................................................................8-47
Collect Configuration Information.........................................................................................8-48
Collecting Dr. Watson Diagnostic Information ......................................................................8-48
Memory Dump .......................................................................................................................8-48
Recovery for Windows System...................................................................................................8-49
Maintenance Tools......................................................................................................................8-50
Starting Maintenance Tools....................................................................................................8-50
Function of Maintenance Tools ..............................................................................................8-52
Maintenance Tools with Remote Console ..............................................................................8-54
Resetting the Server....................................................................................................................8-56
Forced Shutdown........................................................................................................................8-56

viii
Chapter 9 Upgrading Your Server ................................................................................ 9-1
Safety Notes..................................................................................................................................9-2
Static Precautions .........................................................................................................................9-3
Preparing for Installation and Removal........................................................................................9-4
Installation or Removal Procedure ...............................................................................................9-5
Left Side Cover ........................................................................................................................9-5
Front Mask ...............................................................................................................................9-8
3.5-inch Hard Disk Drive (3.5-inch Disk Model) ..................................................................9-10
2.5-inch Hard Disk Drive (2.5-inch Disk Model) ..................................................................9-14
Use of Internal Hard Disk Drives in the RAID System..........................................................9-17
Hot-Swap Power Supply Unit ................................................................................................9-23
PCI Board...............................................................................................................................9-26
Additional Battery Unit for RAID Controller ........................................................................9-32
DIMM ....................................................................................................................................9-36
Processor (CPU).....................................................................................................................9-49
File Device .............................................................................................................................9-57
Optical Disk Drive .................................................................................................................9-60
Internal USB Floppy Disk Drive............................................................................................9-62
Additional Fans ......................................................................................................................9-67
Chapter 10 Internal Cabling Diagrams....................................................................... 10-1
Interface Cables ..........................................................................................................................10-2
Addition of Hard Disk Drive..................................................................................................10-2
Connection of 5.25-inch Device.............................................................................................10-5
Power Cables ..............................................................................................................................10-7
Appendix A Specifications............................................................................................A-1
Appendix B Other Precautions.....................................................................................B-1
Transfer Rate of the On-board LAN Controller ...................................................................... B-1
Server Management Software ................................................................................................. B-1
Floppy Disk............................................................................................................................. B-1
DVD/CD-ROM ....................................................................................................................... B-4
Tape Media.............................................................................................................................. B-4
Keyboard ................................................................................................................................. B-5
Mouse...................................................................................................................................... B-6
Appendix C IRQ..............................................................................................................C-1

ix
Appendix D Installing Windows Server 2008 ..............................................................D-1
Notice ..........................................................................................................................................D-1
Optional Board Supported by NEC EXPRESSBUILDER......................................................D-1
Service Pack Which EXPRESSBUILDER Supports ..............................................................D-2
Installing Service Pack ............................................................................................................D-2
Updating System .....................................................................................................................D-2
Installing on the Mirrored Volume ..........................................................................................D-2
Mounting MO Device .............................................................................................................D-2
About Removable Media ........................................................................................................D-2
Floppy Disk Drive...................................................................................................................D-2
About the System Partition Size..............................................................................................D-3
Installing Windows Server 2008..................................................................................................D-5
Preparations for Installation ....................................................................................................D-5
Creating "Windows Server 2008 OEM-Disk for EXPRESSBUILDER"................................D-5
Windows Server 2008 Clean Installation ................................................................................D-8
Procedure for License Authentication ...................................................................................D-26
Updating the System .............................................................................................................D-26
Driver Installation and Advanced Settings ................................................................................D-29
LAN Driver and PROSet.......................................................................................................D-29
Network Driver .....................................................................................................................D-31
Optional Network Board Driver (N8104-112/119/120/121/125) ..........................................D-31
Adapter Fault Tolerance (AFT)/Adaptive Load Balancing (ALB)........................................D-32
Setting WOL .........................................................................................................................D-34
Graphics Accelerator Driver..................................................................................................D-35
Installing SCSI Controller Driver (N8103-75/95/107)..........................................................D-35
Installing SAS Controller Driver (N8103-104A) ..................................................................D-35
Installing RAID Controller Driver (N8103-115)...................................................................D-36
About Windows Activation ...................................................................................................D-37
The procedure to set PAE option...........................................................................................D-41
Setting for Solving Problems.....................................................................................................D-42
Appendix E Installing Windows Server 2003 x64 Editions........................................E-1
Notice .......................................................................................................................................... E-1
Optional Board Supported by NEC EXPRESSBUILDER...................................................... E-1
Service Pack Which EXPRESSBUILDER Supports .............................................................. E-2
Installing Service Pack ............................................................................................................ E-2
Updating System ..................................................................................................................... E-2
Re-installing to the Hard Disk Drive which has been upgraded to Dynamic Disk ................. E-2
Mounting MO Device ............................................................................................................. E-2
About Removable Media ........................................................................................................ E-2
Floppy Disk Drive................................................................................................................... E-2
About the System Partition Size.............................................................................................. E-3
Installing Windows Server 2003 x64 Editions............................................................................. E-4
Creating "Windows Server 2003 x64 Edition OEM-Disk for EXPRESSBUILDER" ............ E-4
Windows Server 2003 x64 Editions Clean Installation ........................................................... E-7
Procedure for License Authentication ................................................................................... E-10
Updating the System - Applying Service Pack - ................................................................... E-11

x
Driver Installation and Advanced Settings ................................................................................ E-18
PROSet.................................................................................................................................. E-18
Network Driver ..................................................................................................................... E-20
Optional Network Board Driver............................................................................................ E-21
Adapter Fault Tolerance (AFT)/Adaptive Load Balancing (ALB)........................................ E-22
Setting WOL ......................................................................................................................... E-24
Graphics Accelerator Driver.................................................................................................. E-26
Installing SCSI Controller Driver (N8103-75/107)............................................................... E-26
Installing SCSI Controller Driver (N8103-95)...................................................................... E-26
Installing SAS Controller Driver (N8103-104A) .................................................................. E-26
Installing RAID Controller Driver (N8103-115)................................................................... E-27
About Windows Activation ................................................................................................... E-28
Setting for Solving Problems..................................................................................................... E-30
Appendix F Installing Windows Server 2003 .............................................................. F-1
BEFORE INSTALLING WINDOWS SERVER 2003 ................................................................ F-1
Optional Board Supported by NEC EXPRESSBUILDER...................................................... F-1
Service Pack Which EXPRESSBUILDER Supports .............................................................. F-2
Application of Service Pack.................................................................................................... F-2
Updating System ..................................................................................................................... F-2
Re-installing to the Hard Disk which has been upgraded to Dynamic Disk ........................... F-2
Mounting MO Device ............................................................................................................. F-2
About Removable Media ........................................................................................................ F-3
Floppy Disk Drive................................................................................................................... F-3
About the Upgrade to Windows Server 2003 R2 .................................................................... F-3
About the System Partition Size.............................................................................................. F-4
Installing Windows Server 2003..................................................................................................F-6
Creating "Windows Server 2003 OEM-Disk for EXPRESSBUILDER"................................ F-6
Windows Server 2003 Clean Installation ................................................................................ F-8
Procedure for License Authentication ................................................................................... F-12
Updating the System - Applying Service Pack - ................................................................... F-13
Driver Installation and Advanced Settings ................................................................................ F-19
PROSet.................................................................................................................................. F-19
Network Driver ..................................................................................................................... F-20
Adapter Fault Tolerance (AFT)/Adaptive Load Balancing (ALB)........................................ F-21
Setting WOL ......................................................................................................................... F-21
Graphics Accelerator Driver.................................................................................................. F-23
Installing SCSI Controller Driver (N8103-75/95/107).......................................................... F-23
Installing SAS Controller Driver (N8103-104A) .................................................................. F-23
Installing RAID Controller Driver (N8103-115)................................................................... F-24
About Windows Activation ................................................................................................... F-25
The procedure to set PAE option........................................................................................... F-27
Setting for Solving Problems..................................................................................................... F-28
Appendix G Using a Client Computer Which Has a CD Drive...................................G-1
Appendix H Product Configuration Record Table......................................................H-1
Hardware.................................................................................................................................H-1
Software ..................................................................................................................................H-3

Chapter 1
Notes on Using Your Server
This chapter includes information necessary for proper and safe operation of your server.

1-2 Notes on Using Your Server
WARNING LABELS
The warning label is attached to components with possible danger or their vicinity in your server to
inform the user that a hazardous situation may arise when operating the server. (Do not intentionally
remove or damage any of the labels.)
If you find any labels totally/partially removed or illegible due to damage, contact your service
representative.

Notes on Using Your Server 1-3
SAFETY NOTES
This section provides notes on using your server safely. Read this section carefully to ensure proper
and safe use of the server. For symbols, see "SAFETY INDICATIONS" provided earlier.
General
WARNING
Do not use the server for services where critical high availability may directly
affect human lives.
Your server is not intended to be used with or control facilities or devices
concerning human lives, including medical devices, nuclear facilities and
devices, aeronautics and space devices, transportation facilities and devices;
and facilities and devices requiring high reliability. NEC assumes no liability
for any accident resulting in personal injury, death, or property damage if the
server has been used in the above conditions.
Do not use the server if any smoke, odor, or noise is present.
If smoke, odor, or noise is present, immediately turn off the server and
disconnect the power plug from the outlet, then contact your service
representative. Using the server in such conditions may cause a fire.
Keep needles or metal objects away from the server.
Do not insert needles or metal objects into ventilation holes in the server or
openings in the floppy disk or optical disk drive. Doing so may cause an
electric shock.
CAUTION
Keep water or foreign matter away from the server.
Do not let any form of liquid (water etc.) or foreign matter (e.g., pins or paper
clips) enter the server. Failure to follow this warning may cause an electric
shock, a fire, or a failure of the server. When such things accidentally enter
the server, immediately turn off the power and disconnect the power plug
from the outlet. Do not disassemble the server. Contact your service
representative.

1-4 Notes on Using Your Server
Power Supply and Power Cord Use
WARNING
Do not hold the power plug with a wet hand.
Do not disconnect/connect the plug while your hands are wet. Failure to
follow this warning may cause an electric shock.
Do not connect a ground wire to gas pipe.
Never attempt to connect a ground wire to gas pipe. Failure to follow this
warning may cause an explosion.
CAUTION
Plug in to a proper power source.
Use a grounded wall outlet of specified voltage. Use of an improper power
source may cause a fire or a power leak.
Do not install the server where you need an extension cord. Use of a cord that
does not meet the power specifications of your server may heat up the cord
and cause a fire.
Do not connect the power cord to an outlet that has an illegal number of
connections.
The electric current exceeding the rated flow overheats the outlet, which may
cause a fire.
Do not pull the cable when disconnecting it.
When disconnecting the cable from the device, hold the cable connector and
pull it straight out. Pulling the cable out by the cable portion or giving
mechanical stress to the connector could damage the cables and connectors
to result in an electrical shock hazard or a fire.
Insert the power plug into the outlet as far as it goes.
Heat generation resulting from a halfway inserted power plug (imperfect
contact) may cause a fire. Heat will also be generated if condensation is
formed on dusty blades of the halfway inserted plug, increasing the possibility
of fire.
