iZ3D H220Z1
3D/2D Switchable LCD Monitor
iZ3D H220Z1
3D/2D Switchable LCD Monitor
What are PC gamers saying
about their iZ3D monitor?
More fun and enjoyment playing in 3D –and at an affordable price
iZ3D’s award winning 3D/2D Switchable Monitor brings games, movies,
pictures and other 3D content to life without headaches, fatigue, or eyestrain
and at an affordable price.
© 2009 iZ3D, Inc. All rights reserved. iZ3D, the iZ3D logo, Excite Your Eyes are trademarks of iZ3D, Inc. All other company or product names are for
informational purposes only and may be the property of their respective owners. Product specification are subject to change without notice.
“The iZ3D monitor is amazing. It really
blew me away and that's even in
comparison to nVidia's 3D Vision which
is sitting right next to it.”
“I'm addicted! I admit it and I'm proud of
it! Playing in 3D on my iZ3D puts me in
a pleasant state of mind and makes the
game captivating, almost hypnotizing. I
love it! Period!
“I‘d tried everything in 3D: anaglyph,
HMD, dual projector, and shutter
glasses, and iZ3D’s is by far the best
method. There are no shutter glasses
that "flicker“ and the screen has fine
color and brightness.”
“This is a fantastic monitor for stereo 3D
gaming. So much more immersive than
anything else (even huge screens) –it
makes games incredible.”
“My iZ3D monitor makes the whole 3D
experience a total "wow-factor."
“Good 2D performance as well”
The World’s First 3D Monitor for PC Gamers
The iZ3D H220Z1 3D/2D Switchable LCD Monitor and 3D accessories
revolutionize and energize PC game play by presentingthe game in 3D.
This monitor was designed with gamers in mind. It’s unique dual-stacked
LCD design and extra backlights puts all of the 3D technology in the
monitor where it belongs –and off the viewer’s face –for maximum comfort
and hours of play.
State-of-the-Art LCD with Passive 3D Technology
The H220Z1 is a blend of state-of-the-art LCD technology , high-
performance software drivers, and simple, lightweight passive polarized
glasses that work in combination to present games, movies, pictures, and
graphics in 3D. By being a passive solution, there are no headaches,
fatigue, or eyestrain often associated with active 3D solutions like shutter
glasses.
Work in 2D –Play in 3D
Plug and Play connectivity to systems with any dual output graphics card
and Window’soperating system makes the H220Z1 installation easy. The
keyboard toggle makes it a versatile solution whether playing in 3D or
working in 2D.
Broadest Compatibility
The H220Z1 was designed to have the broadest compatibilitywith any
dual-output graphics card –ATI®, nVidia®, S3®, Matrox®.
Over 600 Games Play in 3D
As for PC games –the sky’s the limit. There are over 600 games that can
be played in 3D on an iZ3D monitor. iZ3D’s software reads the 3D off of
the game and presents it in the display and then lets the user control the 3D
effect (both camera separation and convergence focus).

iZ3D H220Z1
3D/2D Switchable LCD Monitor
Product Overview
Features
•3D / 2D Keyboard Switchable
•Stacked Dual Panel Technology
•Full 3D resolution to both eyes
•Wide 3D viewing angle for multiple
viewers/players
•Passive 3D technology eliminating
headaches, fatigue, and eyestrain
•Full user control of 3D camera
separation and convergence
•Bright display for ambient light
•Complete 3D display bundle:
monitor, drivers, glasses, cables
3D Software Drivers (included)
•iZ3D 3D Output Driver
•Anaglyph 3D Output Driver
3D Glasses (3 pair included)
•Linear polarized passive lenses
System Requirements
•Dual output graphics card
OS and API Support
•Windows®Vista or Vista64
•Windows® XP or XP64
•Microsoft DirectX®8 and 9
•OpenGL®Quad Buffer
iZ3D Warranty and Support
•1 year limited product repair /
replacement warranty
•Direct toll free phone and email
access to dedicated monitor
technical support team
•Accessory parts replacement
Accessories (for purchase at iZ3D)
•Eight polarized 3D glasses styles
and clip-ons
•Six Special Edition painted monitor
designs
•Six additional 3D Output Drivers
•3D Media Player
•3D Image Viewer
For more information and
locations to see an iZ3D
monitor visit www.iz3d.com
Type Passive
Coating Linear Polarization
Weight 1 Oz
Monitor Specifications
Glasses Specifications
Display Size 22"
3D Technology Dual Stacked Panels
Panel Type a-si TFT Active Matrix
Aspect Ratio 16:9 Wide Screen WSXGA+
Resolution 1680 x 1050
Displayable Colors 16.7 Milion
Pixel Pitch 0.282mm
Brightness 300 cd/m2
Contrast Ratio 700:1
Response Time 5ms
Backlight CCFL
3D Viewing Angle 170 degrees
Refresh 60Hz
Input Video Compatibility Analog RGB, Digital
Connectors D-Sub (1), DVI-D (2)
Power Supply AC 100-240V, 1.6A, 50/60Hz
Power Consumption 100W Typ.
Power Compliance
VES DPMS, DVI DMPM,
Energy Star
Temperature
5~35oC, 20~80% RH
Runs in Standard 2D Yes
Hotkey Switchable to 3D Yes
OS Windows
Plug and Play DDC 2B Compliance
Stand Adjustments Tilt
Dimensions (W x H x D) 21" x 16" x 9.6"
Weight 12 lbs.
Driver Specifications
Included with monitor iZ3D (Included)
Anaglpyh (Included)
For purchase at iZ3D.com 3D-DLP (Checkerboard)
Dual Output (L-R)
Interlaced
Shutter
Stereo Mirror
VR920
API
DirectX 8, 9, 10
OpenGL Quad Buffer
Anaglyph (Included)
8 and 9
