Jägermeister JEMUS TAP MACHINE User manual

JEMUS TAP MACHINE
OWNER’S MANUAL
POURING PERFECTION
SINCE 1993

2
Dear JEMUS Jägermeister Tap Machine®Owner:
Thank you for your purchase of the Model JEMUS Jägermeister Tap
Machine®, the quickest and easiest way to pour colder-than-ice shots while
pouring on the prots.
The rst of its kind in the industry, the Jägermeister Tap Machine®has won
praise from the beverage media, but more importantly, it has won over tens
of thousands of owners across the country and around the world.
We are extremely proud of our all new, patented Model JEMUS
Jägermeister Tap Machine®and believe it is the greatest thing to happen
to the corner bar or the home bar. We think you’ll agree. Now, you too can
serve up the best and coldest shots of Jägermeister in town.
The Unique Taste
Jägermeister Herbal Liqueur is a 70 proof spirit imported from
Wolfenbuel, Germany. Made from a secret recipe of 56 herbs and spices,
Jägermeister’s unique taste sets it apart from all other spirits. Jägermeister
is the NUMBER ONE selling imported liqueur in the United States and the
favorite shot of millions.
Why is it so good?
What is it about Jägermeister that makes it so irresisble? Is it the taste?
The ice-cold chill? The eect? Your answer is as good as ours. What we do
know is Jägermeister is available in the 50ml, 100ml, 200ml, 375ml, 750ml,
1L and 1.75L sizes.
The Label and the Legend
Back in the seventh century, a young lad named Hubertus was envied for
his purity. Theoderich of Burgundy was one of these jealous sorts, and
so waged war against Hubertus and his uncle. By defeang Theoderich,
Hubertus proved himself valiant in bale and dashing in a codpiece, and
so won the hand of the beauful princess, Floribana. Together they lived
happily with the benets of wealth and good fortune.
The good Princess soon fell ill and died. In his grief, Hubertus turned away
from the sumptuous life of royalty and became a solitary gure, oen going
to the woods to hunt alone. During one of these hunng trips, Hubertus
encountered a splendid stag with a cross that appeared to oat between
its antlers. The vision moved Hubertus to change his life. He gave all his
material possessions to the poor, gave up his tle, and founded several
monasteries. Aer his death, Hubertus was made a saint and became the
Patron Saint of Hunters.

ENGLISH
3
Register your Jägermeister®JEMUS Tap Machine online at:
www.tapmachine.com
PLEASE MAKE SURE TO REGISTER YOUR FREEZER
AND RETAIN YOUR ORIGINAL BOX AND PACKING
MATERIALS. FAILURE TO DO SO MAY CAUSE
DELAYS IF YOU REQUIRE WARRANTY SERVICE.
NOTE: THIS FREEZER COMES WITH A 1 YEAR LIMITED
WARRANTY. THESE MATERIALS WILL BE NEEDED
FOR SHIPPING IF YOUR FREEZER NEEDS
TO BE RETURNED FOR SERVICE OR REPAIR.
Please visit www.tapmachine.com for more informaon on warranty,
repair and returns and for an online version of this owner’s manual.

to do so by Tap Machine Inc.

call: 1–800–713–8881 or email: [e-mail]


number will be refused and returned to sender.
This manual is provided with each new Jägermeister®JEMUS Tap Machine
and contains important informaon to keep your machine running
problem free. This manual is also available online at
www.tapmachine.com.

Jägermeister is the registered trademark of Mast-Jägermeister SE. Jägermeister JEMUS Tap
Machine manufactured and sold under license exclusively by Tap Machine Inc. Jägermeister®
Liqueur, 35% Alc./Vol., Imported by Mast-Jägermeister US, Inc., White Plains, NY. Made in
China. Tap Machine technology protected by one or more United States patents: 5427276,
546387, 5494195. Addional Patents Pending. All Rights Reserved. © Tap Machine Inc.
2007, 2008.
STOP

4
Table of Contents
Dear JEMUS Jägermeister Tap Machine® Owner ............................................................ 2
Table of Contents .................................................................................................................... 4
List of Figures ........................................................................................................................... 5
WARNINGS AND IMPORTANT NOTICES ....................................................................... 6
NOTICE ............................................................................................................................... 7
Unpacking Your New Machine ................................................................................. 8–9
Note: If You Must Return Your JEMUS Jägermeister Tap Machine® .................. 10
Chapter 2 - What’s in the Box? - Parts Supplied .......................................................... 11
Chapter 3 - Key Features ................................................................................................... 12
Chapter 4 - Locang Key Components on Your Tap Machine ................................... 13
Locate the Machine Serial Number ........................................................................... 13
Other Components ....................................................................................................... 13
Chapter 5 - JEMUS Setup and Operaon ...................................................................... 15
General ............................................................................................................................. 15
How Much Jägermeister Does The Machine Hold? .............................................. 15
Electrical Requirements ................................................................................................ 15
Operang Environment ................................................................................................ 15
Remove the Machine from the Shipping Container .............................................. 15
Remove From Plasc Bag ............................................................................................ 15
Placing the Machine on the Bar ................................................................................. 16
Tap Handle Installaon ................................................................................................. 16
Bole Stopper Inseron and Removal ............................................................... 17–18
Chapter 6 - Plug It In, Turn It On, And Load It! ....................................................... 19–20
Chapter 7 - Keeping Your Tap Machine®Clean ............................................................. 21
Weekly ............................................................................................................................. 21
Monthly ............................................................................................................................ 22
Chapter 8 - Let’s Talk About Temperature ...................................................................... 23
Chapter 9 - When Problems Arise ................................................................................... 24
Chapter 10 - Contacng Tap Machine Inc. .................................................................... 25
JEMUS Specicaons ......................................................................................................... 26
Limited Warranty ................................................................................................................. 27
FRANÇAIS ...................................................................................................................... 28–53

ENGLISH
5
List of Figures
Figure 1 - Items Supplied ................................................................................................... 11
Figure 2 - Rear View - Machine On/O Switch and Fuse Locaon ......................... 13
Figure 3 - Front View .......................................................................................................... 13
Figure 4 - Front View – Filter and Drip Tray .................................................................. 14
Figure 5 - Top View .............................................................................................................. 14
Figure 6 – Level Indicator ................................................................................................... 14
Figure 7 - Handle In Place .................................................................................................. 16
Figure 8 – Screw On Bole Stopper ................................................................................ 17
Figure 9 – Screw On ............................................................................................................ 17
Figure 10 - Seated ............................................................................................................... 17
Figure 11 - Install ................................................................................................................. 17
Figure 12 - In Place .............................................................................................................. 18
Figure 13 - Remove ............................................................................................................. 18
Figure 14 - Rear View .......................................................................................................... 21
Figure 15 - Clean Filter ....................................................................................................... 21

6
NOTICE
The Jägermeister®Tap Machine is not intended
for use by persons with reduced physical, sensory or mental
capabilies, or lack of experience and knowledge, unless they
have been given supervision or instrucon concerning
the use of the Jägermeister® Tap Machine by a person
responsible for their safety.
Children should not operate the Jägermeister®
Tap Machine in any instance.
The Tap Machine’s intended use is to dispense Jägermeister


takes place.




DO NOT PLACE machine ON AN ANGLE.
FAILURE TO PROVIDE ADEQUATE CLEARANCE
AROUND THE MACHINE WILL RESULT IN
IMPROPER CHILLING OR POSSIBLE DAMAGE
TO INTERNAL COMPONENTS.
IMPORTANT!

ENGLISH
7
WARNING




causing internal damage.
DANGER
ELECTRICAL SHOCK HAZARD
Can cause injury or death. Service should only be performed



THERE ARE NO USER REPLACEABLE PARTS OR
USER ADJUSTMENTS INSIDE THE machine.
IF THE POWER CORD IS DAMAGED IT MUST BE
REPLACED BY THE MANUFACTURER, AUTHORIZED
SERVICE AGENT, OR SIMILARLY QUALIFIED
PERSONS TO AVOID A HAZARD.
WARNINGS
AND IMPORTANT NOTICES

8
INSTRUCTIONS
Unpacking and Start-Up Instructions
Failure to follow these simple unpacking instrucons may result in damage
to your new machine. Please follow these instrucons carefully.
PLEASE READ BEFORE UNPACKING YOUR
JÄGERMEISTER TAP MACHINE
1. Remove the foam that is protecng the top of the machine.
2. Remove the insulaon protecng the front and the rear of the tap machine.
STOP

ENGLISH
9
3. Using the straps around the machine, li the tap machine straight
up and out of the box. AT NO TIME SHOULD YOU HOLD THE TAP
MACHINE BY THE FRONT FAUCET ASSEMBLY.
4. Remove the accessory package from the box. The accessory package
contains the operator’s manual, warranty registraon card, tap handle,
lter, and drip tray and bole stoppers for your new
JEMUS Jägermeister Tap Machine.
5. Return all packing materials to the box.
6. RETAIN AND STORE THE BOX IN A COOL, DRY LOCATION.
YOU WILL BE REQUIRED TO USE THIS
CONTAINER IF YOU MUST RETURN YOUR
JEMUS JÄGERMEISTER TAP MACHINE.
7. Finally, remove any protecve coverings on the display panels.

10
Note: If You Must Return Your JEMUS
Jägermeister Tap Machine®, DO NOT
RETURN YOUR MACHINE UNLESS YOU RECEIVE
AUTHORIZATION TO DO SO BY TAP MACHINE INC.
READ THIS NOTE
SHOULD YOUR TAP MACHINE® NEED TO BE RETURNED FOR REPAIRS,
IT MUST BE RETURNED IN THE ORIGINAL BOX. THIS CONTAINER IS
DESIGNED TO PROTECT THE TAP MACHINE® FROM DAMAGE DURING
SHIPPING. FAILURE TO USE APPROVED PACKING WHEN RETURNING
A MACHINE, WILL RESULT IN THE MACHINE BEING RETURNED TO
YOU IN IN PRESENT CONDITION. ANY DAMAGE SUSTAINED FROM
SHIPPING A TAP IN AN UNAUTHORIZED CONTAINER, WILL NOT BE
THE RESPONSIBILITY OF TAP MACHINE INC.
THE AUTHORIZED CONTAINER IS: ORIGINAL BOX or CONTAINER
AND PACKING PROVIDED BY TAP MACHINE INC.
IF YOU REQUIRE A SHIPPING CONTAINER FOR YOUR MACHINE, CALL
1-800-713-8881 TO ORDER. A SHIPPING BOX WILL BE SHIPPED TO
YOU AT NO CHARGE.
DO NOT RETURN YOUR MACHINE UNLESS YOU RECEIVE
AUTHORIZATION TO DO SO BY TAP MACHINE INC. TO RECEIVE
A RETURN MATERIAL AUTHORIZATION (RMA) NUMBER
CALL 1-800-713-8881
MACHINES RETURNED TO TAP MACHINE INC, SFIC OR OUR NUMBER
WILL BE REFUSED AND RETURNED TO SENDER UNOPENED.
AFFILIATED WAREHOUSES, WITHOUT A SPECIFIC RETURN MATERIAL
AUTHORIZATION (RMA) NUMBER WILL BE REFUSED AND RETURNED
TO SENDER UNOPENED.

ENGLISH
11
Chapter 2
What’s in the Box? - Parts Supplied
Check and verify that the parts shown below are packaged with the
dispenser. If any of these items are missing or to order spare parts,
call 1-800-713-8881 or visit www.tapmachine.com.
Descripon Quanty
1. Bole Stopper 3
2. Drip Tray 1
3. Drip Tray Cover 1
4. Handle with Logo 1
5. Filter-Reusable 1
6. Plasc Shot Glasses 48
7. JEMUS Tap Machine® 1
8. This Manual (Not Shown) 1
9. Warranty Registraon Card (Not Shown) 1
Figure 1 - Items Supplied

12
Chapter 3
Key Features
1. When the power switch at the rear of the machine is in the OFF
posion, the graphics will be the standard black and white Jägermeister
Logo, but once the power switch is in the  posion, machine comes
to life with the internal display lighng. The machine will change colors
to the dramac Jägermeister orange logo.
2. Another key feature is the digital indicator in the upper right corner
of the machine. This gives you an indicaon of the amount of
Jägermeister in the cooling system. An L on the display indicates that
there is less than 420 ml le in the cooling system. As a safety feature,
when the “L” is displayed, the refrigeraon system is disabled and
will no longer operate. As product is added into the system, once the
level reaches 420 ml, the display will change from “L” to “F” and the
refrigeraon system will begin to operate.
3. A simple dra beer style faucet is used as the dispense point.
The machine dispenses with no motors or pumps.

ENGLISH
13
Chapter 4
Locating Key Components on Your
Tap Machine
Locate the Machine Serial Number
The serial number tag is located on the rear of the machine next to the
fuse. The serial number is also located on the front page of this manual.
Figure 2 - Rear View
Machine On/O Switch and Fuse Locaon
Figure 3 - Front View
OTHER COMPONENTS
The On/O switch enables/disables both
the LED lighng and refrigeraon system.
Fuse is user replaceable as necessary.

14

The lter must be kept clean to allow for proper
venlaon. If the lter is clogged the machine will
not be able to eecvely cool the Jägermeister.
If you noce the machine has goen warmer over
me, this is by far the most likely cause.
The lter can be vacuumed or cleaned under
warm water. If you use water to clean the lter
it should be allowed to dry completely before
using the machine.
The ler is held in place at the FRONT of the
machine by a lter tray. When the drip tray is
in place, the lter is not visible. When removing
the drip tray for cleaning, the lter will also be
extracted from the lter tray.
If the lter is damaged a replacement can
be ordered at www.tapmachine.com
or 1-800-713-8881.

This acts a reservoir that lls with Jägermeister
when boles are supplied to the machine.

These should always be sealed closed when
a bole is not present.

An “L” shown on the digital display (le)
indicates that the level of Jägermeister
has fallen below 420ml. An “F” shown on
the digital display indicates the level of
Jägermeister is above 420ml.
NOTE: The refrigeraon system will shut o
and no longer chill the Jägermeister when
the “L” is displayed. Once the level is above
420ml, the display will change from “L” to “F”
and the refrigeraon system will turn on.
Figure 4 - Front View
Filter and Drip Tray
Figure 5 - Top View
Figure 6 - Level Indicator

ENGLISH
15
Chapter 5
JEMUS Setup and Operation
 The Model JEMUS Jägermeister Tap Machine®is a unique display,
refrigeraon and delivery system designed to chill and dispense Jägermeister
Herbal Liqueur at temperatures well below freezing - 0ºF (-18ºC).
How Much Jägermeister Does The Machine Hold?
The Jägermeister Tap Machine®holds the following amounts of Jägermeister:
• Bole Well Assembly (not chilled) - 100ml – @3.38 . oz.
• Cooling System (Chilled Colder Than Ice) - 1470ml - @49.68 . oz
• Total - 1570 ml - @53.06 . oz.
The Model JEMUS Jägermeister Tap Machine® is designed to hold only 750ml
or 1.0 L Jägermeister boles.

 The Model JEMUS requires a 115 VAC, 60 Hz. 15
Amp, 3-pronged power receptacle within 5 feet of the rear of the unit.
DO NOT USE AN EXTENSION CORD OR SURGE SUPRESSOR TO POWER
THIS UNIT. FAILURE TO PROVIDE ADEQUATE ELECTRICAL POWER WILL
RESULT IN IMPROPER CHILLING OF THE JÄGERMEISTER OR POSSIBLE
DAMAGE TO INTERNAL COMPONENTS.
 The Model JEMUS is designed for indoor use only
and for correct operaons should be used in ambient temperatures between
32°F (0°C) and 100°F (38°C).
Follow the instrucons
for removing the machine from the shipping box. DO NOT HOLD OR CARRY
THE MACHINE BY THE FAUCTET MOUNTED ON THE FRONT OF THE
MACHINE. DOING SO MAY DAMAGE THE MACHINE.
 Remove the plasc handles from the machine by
cung with a scissors. Remove the machine from the protecve plasc bag.
Remove the protecve plasc coverings that are protecng the display
panels on the unit.
THE MACHINE WILL LOAD A TOTAL
OF APPROXIMATELY 1.5 Liters OR ABOUT 53 OUNCES
OF JÄGERMEISTER.

16
Placing the Machine on the Bar
Place the JEMUS on a at, level surface with a MINIMUM of 1 inches
of clear space at the rear of the unit and 1 inch MINIMUM on both sides
is required to permit adequate airow for the refrigeraon system.
An addional 5 inches at the front of the machine is necessary for the drip
tray/lter access that is provided with the unit.







Tap Handle Installation
The Model JEMUS uses a fully funconal dra beer type faucet and
requires an acrylic handle. The handle is packaged in the drip tray. Locate
the acrylic handle and screw it on the top poron of the faucet. DO NOT
OVERTIGHTEN THEN HANDLE ON THE FAUCET. OVERTIGHTENING
MAY DAMAGE OR BREAK THE HANDLE AND/OR THE FAUCET STEM.
The nger grooves on the back of the handle should be facing to the rear
of the machine. Use the adjustment on the faucet to ghten in place.
Once installed correctly, the at poron of the handle will face the user.
Figure 7 – Handle In Place

ENGLISH
17
Bottle stopper insertion and removal
Figure 8 - Screw On Bole
Stopper
Figure 9 - Screw On
Figure 10 - Seated Step 2
Figure 11 - Install - Step 3
Model JEMUS bole stoppers are screw
on style. This stopper used in conjuncon
with the Model JEMUS bole well
assembly supports up to 1 liter boles
without the use of a bole cage. Do
not use these stoppers in older model
Jägermeister Tap Machines.






Step 1
Remove the cap from the Jägermeister
Bole and posion the Bole Stopper
above the Bole.
Step 2
Verify the internal washer is in place.
Screw onto the threaded neck of the
bole.
Screw on ghtly but do not over ghten.
A correctly installed bole stopper will
ensure a ght seal between the bole
stopper neck and the bole.
Step 3
Unsnap the three (3) dust caps from the
bole well assembly. Carefully and slowly
turn the bole upside down and posion
it directly over the machine. If any
Jägermeister begins to drip ensure the
bole stopper is securely screwed on.

18
Figure 12 - In Place
Figure 13 - Remove
Step 4
Slowly insert the bole stopper into
the hole of the bole well. Push down
slightly and allow the bole to rest
inside the bole well. The weight of
the bole will keep the bole securely
in the bole well. If the bole is
slightly turned, you can turn the bole
up to 1/8 turn to line up with the front
of the machine.
Repeat for All Boles.
Step 5
To remove a bole, li it straight up-
Do not pull it forward or to the side-
pull the bole directly up unl it has
cleared the bole well.
Unscrew the bole stopper from
the bole before discarding- Bole
Stoppers ARE NOT Disposable!




ENGLISH
19
Chapter 6
Plug It In, Turn It On, And Load It!
1. Unsnap the 3 protecve dust caps from the bole well assembly located
on the top of the dispenser. These caps should not be removed and should be
snapped in place when a well space is not being used.



2. Plug in the power cord of the machine into a 115VAC, 60 Hz. 15 Amp,
3-pronged power receptacle within 5 feet of the rear of the unit. 

If the power switch is , the built in lighng will be on. If the lighng does
not come on, turn the power switch to the  posion.
3. Unscrew the caps from 3 fresh boles of Jägermeister and insert the
tapered end of the bole stoppers as described in 
 above. The bole stoppers are spring actuated and prevent
dispensing unl they are inserted into the bole well assembly.
4. Place each of the Jägermeister boles on the top of the machine by
inverng the bole and inserng the barrel end of the bole stopper
assembly into the bole well assembly unl the collar of the bole stopper
rests inside the bole well assembly ange. The Jägermeister ow into the
machine is automacally acvated when the bole stopper is placed correctly
into the bole well.


5. If the power switch is not in the  posion, place it in the  posion.
Allow 30 minutes for the system to chill down before dispensing shots of
Jägermeister. When the refrigeraon switch is in the  posion and the
level indicates F, the refrigeraon compressor and the condenser fan will
begin to run within 2 minutes. It is very important that the front and the rear
of the machine is kept free and clean of obstrucons. Air is drawn from the
front of the machine through a removable lter and exhausted through the
rear of the machine. Once the machine reaches the factor set temperature,
the refrigeraon system will shut o. The refrigeraon system will turn
on as need to keep the Jägermeister at the opmum temperature.

20
IMPORTANT INFORMATION
IF THE FLOW FROM THE BOTTLES DOES NOT STOP AFTER A FEW
SECONDS (the bubbles connue and you may noce Jägermeister
owing all over your counter) - DO NOT CONTINUE ANY FURTHER.
REMOVE THE BOTTLES AND CALL OUR SERVICE CENTER
AT 1-800-713-8881.
When product is dispensed, it is normal for bubbles to connue in the
bole(s) for a few seconds aer you close the tap handle.
GREEN, RED or PINK FLUID INFORMATION
If this is the rst me the machine has been used, or has been returned
from repair, the inial ow from the Jägermeister Tap Machine®will be
a harmless pink or green uid followed by Jägermeister. This red, pink or
green uid is an FDA approved glycol soluon used during factory tests.
All of the liquid dispensed prior to the Jägermeister must be discarded.
IMPORTANT
It is very important that the rear of the machine is kept clean and free
of obstrucons. Air is drawn from the front of the machine through a
removable lter and exhausted through the rear of the machine.
ANY OBSTRUCTION IN AIRFLOW WILL RESULT IN WARM SHOTS
OF JÄGERMEISTER BEING DISPENSED.
Note
As with air condioning units, once the refrigeraon switch has been
turned on or o - do not switch it again for at least 5 minutes. Rapidly
turning the switch on and o will prevent the compressor from properly
starng and/or reseng. If you suspect this has happened, turn the
machine o and allow at least 5 full minutes for it to properly reset
before restarng.
