J-Tech Digital JTECH-MV161 User manual

4K HDMI 16x1 multi-viewer
JTD-2953 | JTECH-MV161
USER MANUAL
J-TECH DIGITAL INC.
9807 EMILY LANE
STAFFORD, TX 77477
TEL: [phone]
E-MAIL: [email protected]

2 | P a g e
Table of Contents
1. Introduction............................................................................ 3
2. Remote Control Operation ........................................................ 3
3. Features................................................................................. 4
4. Specifications ......................................................................... 4
5. Unit Interface ......................................................................... 5
6. Connection Diagram ................................................................ 5
7. Common Multi-Viewer Modes.................................................... 6
8. Operating Steps ...................................................................... 6
9. Clearer Subtitles ..................................................................... 7
10. Application........................................................................... 7
11. Package Contents.................................................................. 7
12. Product Service..................................................................... 8
13. Warranty .............................................................................. 8
14. Mail-In Service...................................................................... 8
15. Limited Warranty and Exclusions............................................. 9
16. Extended Warranty ................................................................ 9

3 | P a g e
1. Introduction
JTECH-MV161 is a high-performance multi-viewer unit with 16 HD screen segmentation
and seamless switching output. It can display 16 HD digital video signal on the same
screen, and has a variety of video segmentation, seamless switching 16HD input signal
synchronously. The control methods of this unit are flexible; it can be switched via front
panel buttons an IR control. This unit is practical and stable, easy to install, and can be
used in major projects such as conference rooms, meeting halls, etc.
2. Remote Control Operation

4 | P a g e
3. Features
•16 x HDMI Inputs, 1 x HDMI Output
•16 HDMI signal screen segmentation
•16 HDMI signal seamless switching
•IR Remote Control
•HDMI 1.4 | HDCP 1.4 | DVI 1.0
•Audio and video superposition
•Clear subtitles
4. Specifications
HDMI Input Resolution
1080P / 720P / 1080i / 1024x768 / 1360x768 etc.
HDMI Output Resolution
1080P@60Hz / 2560x1600@60Hz / 2560x1440@60Hz
/ 3840x2160@30Hz
Input/Output Cable
Distance
<15M AWG26 HDMI Standard Cable
Power Adapter Format
Input: AC (50Hz, 60Hz) | 100-240V; Output: DC 12V /
2A
Operating Temp. Range
(-15°C to 55°C) | (5°F to 131°F)
Dimensions (L x W x H)
(460mm x 150mm x 40mm) | (18.1” x 5.91” x 1.57”)
Weight
1.7g

5 | P a g e
5. Unit Interface
6. Connection Diagram

6 | P a g e
7. Common Multi-Viewer Modes
8. Operating Steps
Step 1: Connect HDMI Out with display, HDMI Input 1-16 with source devices
Step 2: Connect the Power, and turn on the multi-viewer
Step 3: Please set the resolution of output as 1080P with remote control if the display
only supports 1080P

7 | P a g e
9. Clearer Subtitles
10. Application
11. Package Contents
(1) x JTECH-MV161 Multi-Viewer
(1) x 12V / 2A Power Adapter
(1) x Remote Control
(1) x User Manual

8 | P a g e
12. Product Service
1) Damage requiring service: The unit should be serviced by qualified service personnel
if:
(a) The DC power supply cord or AC adapter has been damaged;
(b) Objects or liquids have gotten into the unit;
(c) The unit has been exposed to rain;
(d) The unit does not operate normally or exhibits a marked change in performance; (e)
The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that described in these
operating instructions. Refer all other servicing to authorized servicing personnel.
3) Replacement Parts: When parts need replacing, ensure that the servicer uses parts
specified by the manufacturer, or parts that have the same characteristics as the original
parts. Unauthorized substitutes may result in fire, electric shock, or other hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety checks to
confirm that the unit is in proper working condition.
13. Warranty
If your product does not work properly because of a defect in materials of workmanship,
our company (referred to as “the warrantor”) will, for the length of the period indicated
as below, “Parts (1) Year, Labor (90) Days”, which starts with the date of original
purchase (“Limited Warranty period”), at its option either (a) repair your product with
new or refurbished parts, or (b) replace it with a new or a refurbished product. The
decision to repair or replace will be made by the warrantor.
During the “Labor” limited warranty period, there will be no charge for labor. During the
“Parts” warranty period, there will be no charge for parts. You must mail-in your product
during the warranty period. This Limited Warranty is extended only to the original
purchaser and only covers products purchased as new. A purchase receipt or other proof
of original purchase date is required for Limited Warranty service.
14. Mail-In Service
When shipping the unit, carefully pack and send it prepaid, adequately insured, and
preferably in the original carton. Include a letter detailing the complaint and provide a
day time phone and/or email address where you can be reached.

9 | P a g e
15. Limited Warranty Limits and Exclusions
This Limited Warranty ONLY COVERS failures due to defects in material or workmanship,
and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty
ALSO DOES NOT COVER damages which occurred in shipment, or failures which are
caused by products not supplied by warrantor, or failures which result from accidents,
misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-
up adjustments, mis-adjustment of consumer controls, improper maintenance, power
line surge, lightning damage, modification, or service by anyone other than a Factory
Service center or other Authorized Servicer, or damage that is attributed to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED
WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTAIL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR
ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes
damages for lost time, cost of having someone remove or re-install an installed unit if
applicable, travel to and from the service, loss of or damage to media or images, data or
other recorded content. The items listed are not exclusive, but are for illustration only.)
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE
YOUR RESPONSIBILITY.
16. Extended Warranty
With the registration of supported J-Tech Digital products, you extend the current
warranty by 6 months. This extension is added to the warranty that starts at the purchase
date of the device supported. Total product warranty with the extended period will equate
to a total of 18 months of warranty from the date of purchase.
For extended warranties to be accepted, all warranty extensions must be claimed within
30 days of purchasing the eligible J-Tech Digital product. Extensions attempted to be
claimed outside of the 30-day window will not be accepted. Visit www.jtechdigital.com
to register your extended warranty.
