JAC JA95-060 User manual
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page ii
Copyright 2018 Jupiter Avionics Corp.
All rights reserved
Jupiter Avionics Corporation (JAC) permits a single copy of this manual to be printed or downloaded for the express use
of an installing agency. Any such electronic or printed copy of this manual must contain the complete text of this copyright
notice. Any unauthorized commercial distribution of this manual is strictly prohibited. Except as described above, no part
of this manual may be reproduced, copied, transmitted, disseminated, downloaded, or stored in any storage medium for
any purpose without the express prior written consent of JAC.
RECORD OF REVISIONS
Revision
Rev Date
Description
ECR
A
Jun 2018
Initial release, Serial number 1001 and higher.
5521
Prepared:
MPB
Checked:
Approved:
IMPORTANT:
Information in this document is subject to change without notice.
To confirm the current revision status of this manual, visit the JAC website:
www.jupiteravionics.com
JAC
KDV
12-12-18 JAC
MQS
12-14-18
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page iii
Table of Contents
SECTION 1 - DESCRIPTION ................................................................................................................................................. 1
1.1 System Overview .................................................................................................................................................... 1
1.2 Features Overview .................................................................................................................................................. 1
1.3 Inputs and Outputs.................................................................................................................................................. 1
1.3.1 Inputs............................................................................................................................................................... 1
1.3.2 Outputs............................................................................................................................................................ 1
1.4 Specifications .......................................................................................................................................................... 1
1.4.1 Electrical Specifications .................................................................................................................................. 2
1.4.2 Mechanical Specifications............................................................................................................................... 3
1.4.3 Configuration Connector ................................................................................................................................. 3
1.4.4 Product Configuration Software Version......................................................................................................... 4
1.4.5 Flammability of Materials ................................................................................................................................ 4
1.4.6 Environmental Specifications .......................................................................................................................... 4
SECTION 2 – INSTALLATION............................................................................................................................................... 5
2.1 Introduction.............................................................................................................................................................. 5
2.2 Continued Airworthiness ......................................................................................................................................... 5
2.3 Unpacking and Inspecting Equipment..................................................................................................................... 5
2.3.1 Warranty.......................................................................................................................................................... 5
2.4 Installation Procedures............................................................................................................................................ 5
2.4.1 Installation Limitations..................................................................................................................................... 5
2.4.2 Cabling and Wiring .......................................................................................................................................... 5
2.4.3 Mechanical Installation.................................................................................................................................... 6
2.4.4
2.4.5
Legend Replacement ...................................................................................................................................... 6
Post Installation Checks.................................................................................................................................. 6
2.5 Adjustments and Configuration using ProCS™ ...................................................................................................... 6
2.5.1 Configuration Cabling Requirements .............................................................................................................. 7
2.5.2 ProCS™ Setup................................................................................................................................................ 7
2.5.3 Configurable Settings...................................................................................................................................... 7
2.5.4 Other Configuration Features.......................................................................................................................... 9
2.6 Installation Kit .......................................................................................................................................................... 9
2.6.1 Recommended Crimp Tools ........................................................................................................................... 9
2.7 Installation Drawings ............................................................................................................................................. 10
2.7.1 Generation of Custom Drawings ................................................................................................................... 10
SECTION 3 – OPERATION.................................................................................................................................................. 11
3.1 Introduction............................................................................................................................................................ 11
3.2 System Diagram.................................................................................................................................................... 11
3.3 Front Panel Controls ............................................................................................................................................. 12
(1) Transceiver Switches .................................................................................................................................... 12
(2) Configuration Connector (io)......................................................................................................................... 12
(3) Transmit Annunciator - TX ............................................................................................................................ 13
(4) Transmit Selector .......................................................................................................................................... 13
(5) AUX Legend .................................................................................................................................................. 13
3.4 Normal Operation Mode........................................................................................................................................ 13
3.4.1 Panel Lighting................................................................................................................................................ 13
3.4.2 Receiving....................................................................................................................................................... 13
3.4.3 Transmitting (Transmit Operation) ................................................................................................................ 14
3.4.4 Transmit Operation, Duplex AUX5................................................................................................................ 14
3.5 Emergency Operation Mode ................................................................................................................................. 14
3.5.1 Auto Emergency Mode.................................................................................................................................. 14
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page iv
Appendix A - Installation Drawings...................................................................................................................................A1
A1 Introduction............................................................................................................................................................A1
A2 Installation Drawings .............................................................................................................................................A1
Appendix B - Certification Documents .............................................................................................................................B1
B1 Airworthiness Approval .........................................................................................................................................B2
B2 Instructions for Continued Airworthiness ..............................................................................................................B2
B3 Environmental Qualification Form.........................................................................................................................B3
Rev A Page 1
JA95-060 Audio Controller - Five Transceiver - Expander
SECTION 1 - DESCRIPTION
1.1 System Overview
The JA95-060 Audio Controller - Five Transceiver - Expander is a compact, lightweight panel that allows connection
of up to 4 additional radios to the aircraft audio system. The JA95-060 is compatible with the transceiver connections
of any of Jupiter’s JA9x series of audio controllers as well as any civil aviation audio controller.
The JA95-060 is set up on a per-installation basis using a configuration cable and a PC running the product
configuration tool to download system configuration settings via the configuration connector (io) without the necessity
of removing the unit from the panel. To facilitate future customizations and certification, no software or complex
electronic devices are used in the JA95-060 design.
1.2 Features Overview
Many of the JA95-060 input and output levels are adjustable, and several audio paths are selectable.
A configuration connector is provided on the faceplate of the JA95-060 for configuration of audio levels and routing.
The JA95-060 has two modes of operation: Normal Mode and Emergency Mode.
The JA95-060 supports up to five transceivers, each selectable from a rotary switch.
The JA95-060 allows transmit access for one audio panel.
1.3 Inputs and Outputs
Refer to the JA95-060 connector maps for the mating connector designators and pin assignments for the
input and output signals.
1.3.1 Inputs
Name
Qty
Type
CONFIG DATA TO JA95
1
Data signal
LIGHTS INPUT
1
Analog control signal
TX MIC HI/LO
1
Audio signal
MODE SELECT
1
Multi format signal
TX PTT INPUT
1
Active low discrete (Feature selected from ProCS)
POWER INPUT
1
14 to 28 Vdc power supply
RX HI/LO
5
Audio signal
1.3.2 Outputs
Name
Qty
Type
CONFIG DATA FROM JA95
1
Data signal
MIC HI/LO
5
Audio signal
TX PTT
5
Active low discrete
(PA PTT feature selected from ProCS)
RX OUTPUT HI/LO
1
Audio signal (Feature selected from ProCS)
R
1
1
P
1
R
R
A
S
D
I
O
O
I
I
R
ev
A
1
.4
1
.4.1
P
ower Input
1
.4.1.1
R
ated Input L
R
ated Output
A
udio Freque
S
purious Res
D
istortion Ch
a
nput Impeda
n
O
utput Imped
O
utput Load
nput to outp
u
nput to Input
Specifi
c
Electrica
Primary n
o
Secondar
y
Maximum
Minimum
v
Emergenc
Input curr
e
Input curr
e
Input curr
e
A
udio Per
f
evel
Micropho
n
Level
RX rated
o
RX rated
o
in
Micropho
n
ncy Respons
A
udio out
p
ponses
A
udio out
p
a
racteristics
A
udio out
p
n
ce
Micropho
n
Receive
A
ance
RX output
Transceiv
e
RX Outpu
t
Transceiv
e
u
t Crosstalk a
n
Input to O
u
Crosstalk Le
v
Input to In
p
c
ations
l Specifica
t
o
minal voltag
e
y
nominal vol
t
voltage
v
oltage
y voltage
e
nt at 28 Vdc
e
nt at 14 Vdc
e
nt at 9 Vdc
f
ormance
n
e input level
o
utput
o
utput,
emergency
m
n
e rated outp
u
e
p
ut audio freq
p
ut spurious
r
p
ut distortion
a
n
e input Impe
d
udio input Im
Impedance
e
r Microphon
e
t
load
e
r Microphon
e
n
d Bleed-thr
o
u
tput crosstal
v
el
p
ut crosstalk
J
A
t
ions
e
t
age
m
ode or with
p
ut
uency respo
n
r
esponse atte
a
t rated pow
e
d
ance
pedance
e
output Imp
e
e
load
o
ugh Level
k
A
95-060 Au
p
ower input
≤
n
se
nuation
e
r
e
dance
dio Contro
l
I
≤
6 Vdc
l
ler - Five
T
I
nstallation
28 Vdc
14 Vdc
32.2 Vdc
10.2 Vdc
9.0 Vdc
≤ 0.7 A
≤ 1.4 A
≤ 2.4 A
250 mVr
m
7.75 Vrm
s
2.10 Vrm
s
250 mVr
m
≤3dB fro
m
≥50 dB
≤10%
150 1
0
1000
1
≤ 60
≤ 80
600 1
0
150 1
0
≤55 dB
≤60 dB
T
ransceiver
and Opera
m
s 10%
s
10%
s
10%
m
s10%
m
300 to 600
0
0
%
1
0%
0
%
0
%
- Expand
e
ting Manu
a
Page
2
0
Hz
r
al
2
R
I
A
L
1
1
1
1
1
T
C
R
ev
A
nput to Micr
o
A
udio Noise
L
L
istening Tes
t
1
.4.1.2
1
.4.1.3
1
.4.1.4
1
.4.2
1
.4.3
T
he JA95-06
0
C
ONFIG DA
T
phone Outp
u
Input to M
i
L
evel without
Noise lev
e
t
A
udio Per
f
RECEIVE
RX output
MIC outpu
Discrete
S
A
ctive low
A
ctive low
A
ctive low
A
ctive low
A
ctive low
A
ctive low
Lights Inp
u
LIGHTS I
N
LIGHTS I
N
Mechani
Height
Behind pa
Faceplate
Behind pa
Weight
Material
Connecto
r
Mounting
Bonding
Installatio
n
Configur
0
configuratio
T
A FROM JA
9
u
t Crosstalk.
i
crophone O
u
Signal
e
l below the r
a
f
ormance, Ot
h
AUDIO input
HI / LO outp
u
t circuitry typ
e
ignals
control input
control input
control input
control input
control outp
u
control outp
u
u
t
N
PUT ranges
N
PUT curren
t
cal Specifi
c
nel depth
width
nel width
r
s (4):
n
kit part num
ation Conn
n connector
c
9
5 data outp
u
J
A
u
tput crosstal
k
a
ted output
h
er
circuitry typ
e
u
t circuitry ty
p
e
, active sign
a
, inactive sig
n
, active sign
a
signals hav
e
u
t, active out
p
u
t active sign
a
c
ations
ber
ecto
r
c
ommunicati
o
u
t signal is R
S
A
95-060 Au
k
e
p
e
a
l level
n
al level
a
l level
e
p
ut
a
l sinks
o
n standard f
o
S
-232.
dio Contro
l
I
J1
J2
J3
J4
o
r CONFIG
D
l
ler - Five
T
I
nstallation
≤1.0 mV
≥60 dB
Loud and
differenti
a
single en
d
differenti
a
+3 Vdc
+10 Vd
c
0.1 to 10
m
internal p
u
+2 Vdc
1 Adc
0 to 28, 0
10 mA m
a
1.875 in [
4
5.48 in [1
3
5.75 in [1
4
5.00 in [1
2
1.64 lb [0.
brushed
a
coating
One 37-p
i
One 50-p
i
One 4 pol
One 4-40
4 Dzus fa
s
2.5 m
INST-JA9
D
ATA TO JA
9
T
ransceiver
and Opera
Clear
a
l
d
ed
a
l
c
mA
u
ll-up resisto
r
to 14 and 0 t
a
x.
4
7.6 mm] ma
x
3
9 mm] max
4
6 mm]max
2
7 mm]max
.
74 kg] ma
x
a
luminum wit
h
i
n D-Sub mal
e
i
n D-Sub mal
e
e 3.5mm ste
r
stud, 0.5 in
m
s
teners
5
9
5 data input
s
- Expand
e
ting Manu
a
Page
3
r
o 5 Vdc
x
h
conversion
e
e
r
eo jack
m
ax
s
ignal and
r
al
3
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 4
1.4.4 Product Configuration Software Version
Configuration of the JA95-060 requires the Product Configuration Software (ProCS) version v0.61.0 or later. Refer to
the release notes from http://www.jupiteravionics.com/productsoftware.php or contact Jupiter Avionics to ensure the
correct version is used.
1.4.5 Flammability of Materials
The JA95-060 complies with the requirements of RTCA/DO-160G Sec 26.3.3 "Flammability", through equivalent
flammability testing of materials and the Small Parts Exemption.
1.4.6 Environmental Specifications
The JA95-060 Audio Controller - Five Transceiver - Expander has been qualified to the environmental conditions
listed below. Environmental categories for which TSO compliance has been demonstrated are listed in the
Environmental Qualification Form in Appendix Bof this manual.
Temperature:
Operating -45 °C to +70 °C
Ground Survival -55 °C to +85 °C
Altitude 50,000 ft
Humidity Cat A (48 hours)
Shock, Crash Safety 6 g, 20 g for 11 ms
Rev A Page 5
JA95-060 Audio Controller - Five Transceiver - Expander
SECTION 2 – INSTALLATION
2.1 Introduction
This section contains unpacking and inspection procedures, installation information, and post-installation checks.
2.2 Continued Airworthiness
Maintenance of the JA95-060 is on condition only. Scheduled inspection and/or periodic maintenance of this unit is
not required.
2.3 Unpacking and Inspecting Equipment
Unpack the equipment carefully. Check for shipping damage and report any problems to the relevant carrier. Confirm
that the Authorized Release Certificate or Certificate of Conformance is included. Complete the on-line warranty card
from the Jupiter Avionics Corporation (JAC) website - www.jupiteravionics.com/warranty
2.3.1 Warranty
This product manufactured by JAC is warranted to be free of defects in workmanship or performance for 2 years from
the date of installation by an approved JAC dealer or agency. This warranty covers the cost of all materials and labour
to repair or replace the unit, but does not include the cost of transporting the defective unit to and from JAC or its
designated warranty repair centre, or of removing and replacing the defective unit in the aircraft. This warranty does
not cover failures due to abuse, misuse, accident, or unauthorized alteration or repairs.
THIS WARRANTY IS VOID IF THE PRODUCT IS NOT INSTALLED BY AN AUTHORIZED JAC DEALER. If the on-
line warranty card is not completed, the product will be warranted from the date of manufacture.
Contact JAC for return authorization, and for any questions regarding this warranty and how it applies to your unit(s).
JAC is the final arbiter concerning warranty issues.
2.4 Installation Procedures
WARNING: Loud noise can cause hearing damage. Set the headset volume to minimum before
conducting tests, and slowly increase the volume to a comfortable listening level.
CAUTION: The power input circuitry of the unit may be damaged if the installation does not conform to the
wiring instructions in this manual.
2.4.1 Installation Limitations
The conditions and tests for CAN TSO approval of the JA95-060 are minimum performance standards. Those
installing the JA95-060, on or in a specific type or class of aircraft, must determine that the aircraft installation
conditions are within TSO standards. The JA95-060 may be installed only by following the applicable airworthiness
requirements.
2.4.2 Cabling and Wiring
All wire shall be selected in accordance with the original aircraft manufacturer’s maintenance instructions, or AC43.13-
1B Change 1, Paragraphs 11-76 through 11-78. Unshielded wire types shall qualify to MIL-W-22759 as specified in
AC43.13-1B Change 1, Paragraphs 11-85, 11-86, and listed in Table 11-11. For shielded wire applications, use Tefzel
MIL-C-27500 shielded wire with tag ring or equivalent (for shield terminations) to make the most compact and easily
terminated interconnect. Follow the Connector Map in Appendix A of this manual.
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 6
Allow 3” from the end of the shielded wiring to the shield termination to allow the connector hood to be easily installed.
Refer to the Interconnect drawing in Appendix A of this manual for shield termination details. Note that this unit has a
‘clamshell’ hood that is installed after the wiring is complete.
Maintain wire segregation and route wiring in accordance with the original aircraft manufacturer’s maintenance
instructions.
Unless otherwise noted, all wiring shall be a minimum of 24 AWG, except power and ground lines, which shall be a
minimum of 22 AWG. Refer to the Interconnect drawing for additional specifications. Check that the ground
connection is clean and well secured, and that it shares no path with any electrically noisy aircraft accessories such
as blowers, turn-and-bank instruments, or similar loads.
2.4.3 Mechanical Installation
The JA95-060 can be mounted in any attitude and location with adequate space for the front panel and sufficient
clearance for the connector and wiring harness. It requires no direct cooling.
2.4.4 Legend Replacement
The JA95-060 illuminated legends are field replaceable. For further information, refer to the ‘Legend Replacement’
document in Appendix A of this manual.
2.4.5 Post Installation Checks
2.4.5.1 Voltage/Resistance checks.
Do not attach this unit until the following conditions are met:
a) Check P1 pin 19 for lights buss voltage.
b) Check P2 pin 17 for +28 Vdc or +14 Vdc relative to ground.
c) Check P2 pin 34 for continuity to ground (less than 0.5 Ω).
d) Check all pins for shorts to ground or adjacent pins.
2.4.5.2 Configuration
Ensure that the JA95-060 contains the correct configuration settings. This may be done at the factory, on the
maintenance bench or in the aircraft before the power on checks are performed. Refer to section 2.5.1.
2.4.5.3 Power on Checks.
Power up the aircraft’s systems and confirm normal operation of all functions of the JA95-060. Refer to
Section 3 (Operation) for specific operational details.
a) Confirm radio operation for both receive and transmit. Check yoke or cyclic switch action. Check the radio
selection and inputs. Do not proceed until the radios are functioning correctly.
b) Unusual buzzes, hums or other background audio are symptomatic of multiple grounds, or noisy external
systems such as blowers or pumps sharing wiring with the audio system. If a transmitter fails to key or
correctly modulate it is often the result of not connecting all required grounds to the radio or external audio
system.
c) Check the Emergency operation.
d) Check that all configurations settings are correct.
When all performance checks are satisfied, complete the necessary regulatory documentation before releasing the
aircraft for service. Refer to Appendix B.
2.5 Adjustments and Configuration using ProCS™
All the JA95-060 internal adjustments are set from the Product Configuration Software ProCS™. Configuration data is
sent to the JA95-060 via the front panel connector (io), using the Configuration Cables and a computer running the
ProCS™ software. For configuration requirements, see section 2.5.1.
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 7
For full information on the configuration process, and for installation of ProCS™on your computer, refer to the
ProCS™ manual on the Jupiter Avionics website -www.jupiteravionics.com/productsoftware.
2.5.1 Configuration Cabling Requirements
To configure the JA95-060, it is necessary to load the Product Configuration Software ProCS™ onto a Windows-
based computer as described in the ProCS™ manual.
The cables required to configure the JA95-060 are not included with the unit.
Cabling option 1:
Quantity Description JA95-060
1 USB A to RS232 9-Pin Cable CAB-USB-0002
1 Configuration Cable JA99-001
Cabling option 2:
Quantity Description JA95-060
1 USB A Male to RS232 3.5mm Plug CAB-USB-0006
2.5.2 ProCS™ Setup
The ProCS™ JA95-060 menu item 'ProCS Setup' provides Setup drawings showing the cabling arrangement
for connecting the JA95-060 to a computer running the ProCS™.
2.5.3 Configurable Settings
A standard unit is shipped from the factory with all internal adjustments configured to the default levels. At installation,
it may be desirable to change some of these settings to suit the local operating environment.
Note: To properly configure the JA95-060, power must be applied to the unit.
Within ProCS™, the configurable settings are grouped together into the following sections:
2.5.3.1 Front Panel Switches
The Front Panel Switches window is used to specify the text for each legend.
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 8
2.5.3.2 Radios
2.5.3.3 Receive Levels
2.5.3.4 Transmit Levels
The Transceiver MIC output signals can be adjusted from 0.010 to 1.000 Vrms.
(Default 250 mVrms)
The Radios window is used to define the
radios for the transceivers.
The receive level of each of the RX inputs can be
adjusted from 1 to 10 Vrms.
(Default 7.75 Vrms)
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 9
When the Transmit Timeout check box is checked the transmit time-out is
enabled (Default not checked)
When the AUX5 Duplex check box is checked the AUX5 radio is set to
duplex operation (Default not checked) (see section 3.4.4)
2.5.3.5 Sidetone Levels
2.5.3.6 Audio Muting
2.5.3.7 Lighting Voltage Selection
2.5.4 Other Configuration Features
In the JA95-060 Product Information Window, the model number, serial number and check sum of the JA95-060
Audio Controller - Five Transceiver - Expander can be viewed.
2.6 Installation Kit
The kit required to install this unit is not included with the unit.
The installation kit (Part # INST-JA95) consists of the following:
Quantity Description JAC Part #
2 TAG ring CON-5500-0625
1 D-Sub 37-pin connector, hood and 37 crimp pins CON-3420-0037
1 D-Sub 50-pin connector, hood and 50 crimp pins CON-3420-0050
2 Heat Shrink Tubing WIR-HTSK-1000
2.6.1 Recommended Crimp Tools
Standard D-Sub Crimp Tool Chart
Tool Type
Hand crimping tool
Positioner
Insertion/extractor tool
POSITRONIC
9507-0-0-0
9502-5-0-0
4711-2-0-0
DANIELS
AFM 8
K13-1
91067-2
MIL-SPEC
M22520/2-01
M22520/2-08
M81969/1-02
The lights input may be +5 Vdc, +14 Vdc or +28Vdc
(Default +28 Vdc).
The Receive Sidetone Level can be adjusted from 0 to -12 dB
of the rated phone Level. (Default -6 dB)
To select Audio Muting during Transmit, check the box as shown.
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 10
2.7 Installation Drawings
The drawings and documents required for Installation can be found in Appendix A of this manual.
2.7.1 Generation of Custom Drawings
The interconnects and connector maps in Appendix A of this manual are generic drawings based on the standard
version of the JA95-060. However, if a unit has been configured using JAC’s ProCS™ software to change switch
legends or lighting voltages, the software can be used to generate fully customized interconnects and connector
maps for use by the installer.
Rev A Page 11
JA95-060 Audio Controller - Five Transceiver - Expander
SECTION 3 – OPERATION
3.1 Introduction
This section contains the system diagram and operating instructions for the JA95-060.
3.2 System Diagram
The JA95-060 Audio Controller - Five Transceiver - Expander is a compact, lightweight panel that allows connection
of up to 4 additional radios to the aircraft audio system. The JA95-060 is compatible with the transceiver connections
of any of Jupiter’s JA9x series of audio controllers as well as any civil aviation audio controller.
The text on the JA95-060 legend (shown here as AUX) should be selected to match the text on the main panel legend
representing the expanded transceiver position.
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 12
3.3 Front Panel Controls
Note: The legends and deadfront annunciator are removable and may be replaced with custom ordered
parts. The controls will be referred to by the default legend and annunciator names as shown below.
1. Transceiver switches and associated legends
2. Music/configuration input connector and legend
3. Transmit annunciator (deadfront)
4. Transmit selector
5. AUX Legend
(1) Transceiver Switches
These are five white two-position toggle
switches. When a switch is set to the ‘up’
position, audio from the associated
transceiver is routed to the phones.
The legends (above the switches) are
interchangeable to allow customization.
(Default – AUX1, AUX2, AUX3, AUX4, AUX5.)
(2) Configuration Connector (io)
This connector is used during installation to change configuration settings.
CAUTION:
Attempting to connect an incompatible plug or device could damage the
unit
, the attached
device, or both.
If in doubt, check with your installing agency.
1
2
3
4
5
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 13
(3) Transmit Annunciator - TX
This is a deadfront annunciator that will illuminate when
the JA95-060 is transmitting.
The default legend is ‘TX’, but it is interchangeable to allow customization.
(4) Transmit Selector
This is a rotary six-position control that is used to
select transmission via one of the five transceivers.
Each of the transmit selector positions is linked by a
white line to the corresponding transmit select
annunciator, transceiver switch and legend.
The appropriate annunciator will light green to show
which transceiver is selected for transmit –
‘AUX3’ in this example.
Note: Transmission on any of the transceivers linked to the JA95-060 is only possible if the designated
transceiver (AUX in these examples) is selected on the main audio panel.
(5) AUX Legend
This is a customizable legend that is intended to remind the
operator which transceiver on the main audio panel must be
selected to allow transmission on the JA95-060 Expander Panel.
The default legend is ‘AUX’, but it is interchangeable to allow customization to match the legend on the main audio
panel.
3.4 Normal Operation Mode
Note: Numbers in parentheses refer to the front panel controls shown in section 3.2.
The JA95-060 is in Normal mode when suitable electrical power is supplied to the unit.
3.4.1 Panel Lighting
The legends and annunciators will be illuminated (when appropriate) and dim through the aircraft lighting buss.
3.4.2 Receiving
Note: Transmission on any of the transceivers linked to the JA95-060 is only possible if the designated
transceiver (AUX in these examples) is selected on the main audio panel.
When the JA95-060 receives an incoming transmission on a transceiver or receiver that has been selected, either by
the white transceiver receive switches (1) or the transmit selector (4), the incoming audio will be directed to the user’s
phones.
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Rev A Page 14
3.4.3 Transmitting (Transmit Operation)
Note: Transmission on any of the transceivers linked to the JA95-060 is only possible if the designated
transceiver (AUX in these examples) is selected on the main audio panel.
To select a transceiver, rotate the Transmit Select Switch until it aligns with the line leading to the Transceiver Select
switch legend (see 1) - default legends AUX1, AUX2, AUX3, AUX4, or AUX5. The corresponding Transmit Select
annunciator will illuminate.
When the TX PTT input is activated, the unit will transmit on the selected transceiver, and the deadfront Transmit
Annunciator (3) will illuminate ‘TX’. All MIC and sidetone audio will be routed to the RX OUTPUT.
3.4.4 Transmit Operation, Duplex AUX5
Note: If the AUX5 transceiver has been configured as duplex, it can be used with a cellphone or
sat-phone. Check your configuration with the installing agency.
If the unit has been configured for cellphone or sat-phone use and AUX5 has been selected for transmit, momentarily
activating the TX PTT will keep AUX5 transmitting. A second momentary activation of the TX PTT, or moving the
Transmit Selector away from AUX5, will stop the AUX5 from transmitting.
AUX5 Transmit timeout operation does not operate when AUX5 transmit mode is set to duplex.
3.5 Emergency Operation Mode
Emergency mode is entered automatically if power to the unit is lost.
3.5.1 Auto Emergency Mode
If the unit is in emergency mode because power has been lost to the unit, the AUX1 transceiver will be routed to the
RX OUTPUT. The TX microphone and TX transmit key are connected to the AUX1 transceiver. No other function in
the JA95-060 will operate when power is lost. All indicator LEDs, legends and annunciators will be dark.
Rev A Page A1
JA95-060 Audio Controller - Five Transceiver - Expander
Installation and Operating Manual
Appendix A - Installation Drawings
A1 Introduction
The drawings necessary for installation and troubleshooting of the JA95-060 Audio Controller - Five Transceiver -
Expander are in this Appendix, as listed below.
Note: A fully customized set of Connector Maps and Interconnects can be created using the ProCS software.
Refer to the ProCS™ manual for further information.
A2 Installation Drawings
DOCUMENT Rev
JA95-060 Connector Map A
JA95-060 Interconnect A
JA95-060 Mechanical Installation A
JA95-060 Equipment Block Diagram A
Reference Documents
TOL-CUST-EXTR Legend Replacement A
JUPITER AVIONICS TEMPLATE AUTOCAD PORTRAIT SIZEA REV B.DWT
TITLE
APPROVED
PREPARED
CHECKED
L00N3
NCAGE CODE PART NO. SHEET
DOC NO.
37 PIN FEMALE DMIN
MATING CONNECTOR
VIEW IS FROM REAR OF MATING CONNECTOR
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35
18 19
36 37
SPARE 17
SPARE 16
SPARE 15
SPARE 14
AUX 5 RX LO
AUX 4 RX LO
AUX 3 RX LO
AUX 2 RX LO
AUX 1 RX LO
SPARE 13
SPARE 4
LIGHTS INPUT
SPARE 3
RX OUTPUT HI
SPARE 2
SPARE 12
AUX 5 RX HI
SPARE 11
AUX 4 RX HI
1/4
P1
SPARE 10
AUX 3 RX HI
SPARE 9
AUX 2 RX HI
SPARE 8
AUX 1 RX HI
SPARE 7
SPARE 1
SPARE 6
SPARE 5
RECEIVE CONNECTOR
JA95-060 Connector Map Rev A
RX OUTPUT LO
SPARE 24
SPARE 23
JA95-060
SPARE 22
SPARE 21
SPARE 20
KV
SPARE 19
SPARE 18
Audio Controller - Five Transceiver - Expander
P1 Connector Map
Table of contents
