Jacobsen Greens King IV Plus User manual

Parts & Maintenance
Manual
When Performance Matters.
™
WARNING
If incorrectly used, this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its
dangers, and should read the entire manual before attempting to set up,
operate, adjust, or service the machine.
19
17
18
13
6
5
9
15
16
7 8
10
4
3
11
1-INCLUDESITEMS3 - 16
GB
Greens King IV™Plus with ROPS
62304 – Kubota®D722-E3B Engine
Serial Number 1701 and Up
4212746-Rev B

This manual contains adjustment, maintenance,
troubleshooting instructions, and parts list for your new
Jacobsen machine. This manual should be stored with
the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following the safety, operating, and
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
The serial plate is located on the frame, near the battery.
Jacobsen recommends you record these numbers below
for easy reference.
11524 WILMAR BLVD,
CHARLOTTE, NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A. A Textron Company
2
Proposition 65 Warning
This product contains or emits
chemicals known to State of California
to cause cancer and birth defects or
other reproductive harm.
FOREWORD
Suggested Stocking Guide
To Keep your equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more
commonly used maintenance items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your
order form.
2. Explain where and how to make shipment:
❑UPS ❑Regular Mail
❑Overnight ❑2nd Day
3. Order by the quantity desired, the part number, and
the description of the part.
4. Send or bring the order to your authorized Jacobsen
Dealer.
© 2009, Jacobsen, A Textron Company/Textron Innovations Inc.
“All rights reserved, including the right to reproduce this material
or portions thereof in any form.”
These are the original instructions verified by
Jacobsen, A Textron Company.
Service Parts
Service Support Material
Qty. Part No. Description Qty. Part No. Description
554011 Diesel Engine Oil FIlter 4199040 500 Hours Service Kit
5000913 Diesel Engine Air FIlter 5001951 Alternator Belt
5000436 Diesel Engine Fuel FIlter
558022 Hydraulic Oil Filter
Qty. Part No. Description
4212747 Safety & Operation Manual
4212746 Parts & Maintenance
4191631 Video, Operator Training
Qty. Part No. Description
4171649 Service Manual
Litho in U.S.A. 2-2012

3
Table of Contents
1 Safety
1.1 Operating Safety .............................................. 4
1.2 Important Safety Notes ..................................... 5
2 Specifications
2.1 Product Identification........................................ 6
2.2 Engine .............................................................. 6
2.3 Cutting Units ..................................................... 6
2.4 Mower ............................................................... 7
2.5 Weights and Dimensions .................................. 7
2.6 Accessories & Support Literature ..................... 7
2.7 Declaration of Conformity ................................. 8
3 Adjustments
3.1 General........................................................... 10
3.2 Bedknife-To-Reel ........................................... 10
3.3 Bedknife Adjustment ...................................... 11
3.4 Cutting Height ................................................. 11
3.5 Antisway Spring .............................................. 12
3.6 Accelerator Pedal ........................................... 12
3.7 Brake Pedal .................................................... 12
3.8 Parking Brake ................................................. 13
3.9 Interlock Switches .......................................... 13
3.10 Traction Lever ................................................ 13
3.11 Reel Control ................................................... 14
3.12 Reel Switches ................................................. 14
3.13 Leveling Procedure ........................................ 15
3.14 Reel Bearing ................................................... 15
3.15 Fan Belt .......................................................... 15
3.16 Lift Cylinders ................................................... 16
3.17 Specific Torque Requirements ....................... 16
3.18 Torque Specification ....................................... 17
4 Maintenance
4.1 General .......................................................... 18
4.2 Engine ............................................................ 18
4.3 Engine Oil ....................................................... 19
4.4 Diesel Air Filter ............................................... 19
4.5 Fuel ................................................................ 20
4.6 Fuel System ................................................... 20
4.7 Battery ............................................................ 20
4.8 Jump Starting ................................................. 21
4.9 Charging Battery ............................................ 21
4.10 Hydraulic Hoses ............................................. 22
4.11 Hydraulic Oil ................................................... 22
4.12 Hydraulic Oil Filters ........................................ 23
4.13 Electrical System ............................................ 23
4.14 Muffler And Exhaust ....................................... 23
4.15 Tires ............................................................... 23
4.16 Wheel Mounting Procedure ............................ 24
4.17 Roll Over Protective Structure (Rops) ............ 24
4.18 Care And Cleaning ......................................... 24
4.19 Radiator .......................................................... 25
4.20 Backlapping .................................................... 25
4.21 Storage ........................................................... 26
5 Troubleshooting
5.1 General .......................................................... 27
6 Maintenance & Lubrication Charts
6.1 General .......................................................... 28
6.2 Lubrication Chart ............................................ 28
6.3 Maintenance Charts ....................................... 29
7Notes
8 Parts Catalog
8.1 How To Use The Parts Catalog ..................... 31
8.2 To Order Parts ............................................... 31
8.3 Table Of Contents .......................................... 31

1 SAFETY
4
1 SAFETY
1.1 OPERATING SAFETY ______________________________________________________
1. Safety is dependent upon the awareness, concern
and prudence of those who operate or service the
equipment. Never allow minors to operate any
equipment.
2. It is your responsibility to read this manual and all
publications associated with this equipment (Safety &
Operation Manual, Engine Manual, and attachments/
accessories instruction sheets). If the operator
cannot read English it is the owner’s responsibility to
explain the material contained in this manual to them.
3. Learn the proper use of the machine, the location
and purpose of all the controls and gauges before
you operate the equipment. Working with unfamiliar
equipment can lead to accidents.
4. Never allow anyone to operate or service the
machine or its attachments without proper training
and instructions; or while under the influence of
alcohol or drugs.
5. Wear all the necessary protective clothing and
personal safety devices to protect your head, eyes,
ears, hands, and feet. Operate the machine only in
daylight or in good artificial light.
6. Evaluate the terrain to determine what accessories
and attachments are needed to properly and safely
perform the job. Only use accessories and
attachments approved by Jacobsen.
7. Stay alert for holes in the terrain and other hidden
hazards.
8. Inspect the area where the equipment will be used.
Pick up all the debris you can find before operating.
Beware of overhead obstructions (low tree limbs,
electrical wires, etc.) and also underground obstacles
(sprinklers, pipes, tree roots, etc.). Enter a new area
cautiously. Stay alert for hidden hazards.
9. Never direct discharge of material toward bystanders,
nor allow anyone near the machine while in
operation. The owner/operator can prevent and is
responsible for injuries inflicted to themselves, to
bystanders, and damage to property.
10. Do not carry passengers. Keep bystanders and pets
a safe distance away.
11. Never operate equipment that is not in perfect
working order or is without decals, guards, shields,
discharge deflectors, or other protective devices
securely fastened in place.
12. Never disconnect or bypass any switch.
13. Do not change the engine governor setting or
overspeed the engine.
14. Carbon monoxide in the exhaust fumes can be fatal
when inhaled. Never operate the engine without
proper ventilation or in an enclosed area.
15. Fuel is highly flammable; handle with care.
16. Keep the engine clean. Allow the engine to cool
before storing and always remove the ignition key.
17. Disengage all drives and engage parking brake
before starting the engine (motor). Start the engine
only when sitting in operator’s seat, never while
standing beside the unit.
18. Equipment must comply with the latest federal, state,
and local requirements when driven or transported
on public roads. Watch out for traffic when crossing
or operating on or near roads.
19. Local regulations may restrict the age of the operator.
20. Never use your hands to search for oil leaks.
Hydraulic fluid under pressure can penetrate the skin
and cause serious injury.
21. Operate the machine up and down the face of slopes
(vertically), not across the face (horizontally).
22. To prevent tipping or loss of control, do not start or
stop suddenly on slopes. Reduce speed when
making sharp turns. Use caution when changing
directions.
23. Always use the seat belt when operating mowers
equipped with a Roll Over Protective Structure
(ROPS).
Never use a seat belt when operating mowers
without a ROPS.
24. Always disconnect battery cables from battery before
performing any welding operation on the mower.
This machine is to be operated and maintained as specified in this manual and is intended for the professional
maintenance of specialized turf grasses. It is not intended for use on rough terrain or long grasses.
WARNING
EQUIPMENT OPERATED IMPROPERLY OR BY UNTRAINED PERSONNEL CAN BE DANGEROUS.
Familiarize yourself with the location and proper use of all controls. Inexperienced operators should receive
instruction from someone familiar with the equipment before being allowed to operate the machine.
!

SAFETY 1
5
1.2 IMPORTANT SAFETY NOTES ________________________________________________
This safety alert symbol is used to alert you to potential hazards.
DANGER - Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.
WARNING - Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious
injury.
CAUTION - Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury
and property damage. It may also be used to alert against unsafe practices.
NOTICE - Indicates a potentially hazardous situation which, if not avoided, MAY result in property damage. It may
also be used to alert against unsafe practices.
For pictorial clarity, some illustrations in this manual may show shields, guards or plates open, or removed. Under no
circumstances should this equipment be operated without these devices securely fastened in place.
By following all instructions in this manual, you will prolong the life of your machine and maintain its maximum
efficiency. Adjustments and maintenance should always be performed by a qualified technician.
If additional information or service is needed, contact your Authorized Jacobsen Dealer who is kept informed of the
latest methods to service this equipment and can provide prompt and efficient service.
WARNING
The Interlock System on this mower prevents the mower from starting unless
the parking brake is engaged, reel levers are off, and traction lever is in
Neutral. The system will stop the engine if the operator leaves the seat
without engaging the parking brake, setting the reel levers to off, and placing
traction lever in Neutral.
NEVER operate mower unless the Interlock System is working.
!
WARNING
1. Before leaving the operator’s position for any reason:
a. Return traction lever to Neutral.
b. Disengage all drives.
c. Lower all implements to the ground.
d. Engage parking brake.
e. Stop engine and remove the ignition key.
2. Keep hands, feet, and clothing away from moving parts. Wait for all
movement to stop before you clean, adjust, or service the machine.
3. Keep the area of operation clear of all bystanders and pets.
4. Never carry passengers.
!

2 SPECIFICATIONS
6
2 SPECIFICATIONS
2.1 PRODUCT IDENTIFICATION _________________________________________________
62304.............................. Greens King IV Plus, 17.7 hp
diesel engine, power steering.
Without reels.
Serial Number ................ An identification plate, like the one
shown, listing the serial number, is
attached to the frame of the
mower near the battery.
Always provide the serial number of the unit when ordering
replacement parts or requesting service information.
2.2 ENGINE__________________________________________________________________
Make ............................... Kubota
Model .............................. D722-E3B
Horsepower..................... 17.7 hp (13.2 kW) @3200 rpm
Displacement .................. 40.03 cu. In. (719 cc)
Torque ............................. 26 ft. lbs. (35 Nm) @ 2600 rpm
Fuel:
Type .......................... No. 2 Low or Ultra Low Sulfur
Diesel
Rating ....................... Min. Cetane rating 45
Capacity.................... 5 U.S. Gal. (18.9 liters)
Governor......................... Ball Type Governor
Low Idle ................... 1100 RPM
High Idle ................... 3400 RPM
Lubrication:
Capacity.................... 3.4 quarts (3.2 liter) with filter
Type .......................... SAE 20W, SAE 30W
API Classification ..... CD, CE
Air Filter .......................... Dry type with evacuator valve and
service indicator.
Alternator ........................ 14 amp
Cooling System .............. Liquid Cooled
Capacity...................... 3qt. (2.8 l) 50/50 water ethylene
glycol mix
2.3 CUTTING UNITS___________________________________________________________
Reel ................................ 3 Reels, 22 in. (559 mm) wide.
Reel Diameter................. 5 in. (127 mm)
Blade Options ................. 7, 9 or 11 blades
Cutting Width .................. 62 in. (1574 mm)
Cutting Frequency:
7 Blade ..................... 0.084 in./mph (1.33 mm/kph)
9 Blade ..................... 0.065 in./mph (1.03 mm/kph)
11 Blade ................... 0.053 in./mph (0.84 mm/kph)
Product EEC Sound
Power
Sound Pressure
Level
Operator Ear
Vibration M/S2
Arms Body
62304 102 dBa 87 dBa 2.03 0.52
11524 WILMAR BLVD,
CHARLOTTE, NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A. A Textron Company
587 13.2 XXXX
62304001651

SPECIFICATIONS 2
7
2.4 MOWER__________________________________________________________________
Tires ................................ 18 x 9.5 - 8 tubeless
Tire Pressure:
Front..........................10-12 psi (0.69-0.83 BAR)
Rear ..........................8-10 psi (0.55-0.69 BAR)
Battery:
Type .......................... 12 Volt Lead/Acid
Group ........................22 GMF
Parking Brake.................. Mechanical front drum brakes
Hand lever actuated
Speed:
Mow ......................... 0 - 3.7 mph (5.9 kph)
Transport .................. 0 - 6.6 mph (10.6 kph)
Reverse..................... 0 - 3.5 mph (5.6 kph)
Hydraulic System:
Capacity.......................... 5 U.S. gal. (19 liters) System
Fluid Type ....................... GreensCare 46 Biodegradable
Filter................................ Full Flow 20 micron
Steering ......................... Hydrostatic power steering
Mower Lift ....................... Hydraulic Double Acting Cylinders
2.5 WEIGHTS AND DIMENSIONS ________________________________________________
Dimensions: Inches (mm)
Length - Grass Catchers On ........................ 99.5 (2526)
Height - with ROPS ......................................... 78 (1981)
Wheel Base.................................................. 52.8 (1341)
Width - Transport Position ............................... 68 (1727)
Width - Mowing Position.................................. 70 (1778)
Width - Wheel .............................................. 50.5 (1283)
Turning Radius................................................ 18 (457)
Weights: Lbs. (kg)
Working Weight Less Operator
62304 .......................................................... 1468 (666)
2.6 ACCESSORIES & SUPPORT LITERATURE _____________________________________
Contact your area Jacobsen Dealer for a complete listing of accessories and attachments.
Accessories
Orange Touch-up Paint (12 oz. spray) ...................... 554598
Arm Rest ................................................................. 4139431
Grass Catcher............................................................. 67891
Brush, 62 in................................................................. 68623
Fine Bristle Brush........................................................ 68536
Green Sentry II Oil System Monitor ............................ 68669
Light Kit ................................................................... 2811910
Motor / Light / Brush Mounting Kit........................... 2811909
Rear Roller Cleaner .................................................... 68643
Quick Roller (Set of 3)................................................. 68664
Spiker (Set of 3) .......................................................... 68665
Traction Tire (Set of 2)................................................. 62616
Turf Groomer 1/4 in. Spacing R.H. (2 Required) ......... 67911
Turf Groomer 1/4 in. Spacing L.H. (1 Required) ......... 67912
Turf Groomer 1/2 in. Spacing R.H. (2 Required) ......... 67913
Turf Groomer 1/2 in. Spacing L.H. (1 Required) ......... 67914
Vertical Mower L.H. (1 Required)................................ 68549
Vertical Mower R.H. (2 Required) ............................... 68550
Variable Step Cut ........................................................ 68551
High Cut Roller Kit ...................................................... 68634
MAGSystem™ Kit ................................................... 4158083
Reels
7 Blade Reel L.H. (1 Required)....................................68588
7 Blade Reel R.H. (2 Required) ...................................68589
9 Blade Reel L.H. (1 Required)....................................68599
9 Blade Reel R.H. (2 Required) ...................................68600
11 Blade Reel L.H. (1 Required)..................................68621
11 Blade Reel R.H. (2 Required) .................................68622
Rollers
Grooved Front Roller ...................................................68527
Solid Roller .................................................................68530
Segmented Front Roller...............................................68673
Grooved Front Roller (Steel)........................................68613
Grooved Front Roller (Aluminum) ................................68614
Grooved Rear Roller....................................................68580
Support Literature
Safety & Operation Manual......................................4212747
Parts & Maintenance Manual...................................4212746
Diesel Engine Parts Catalog....................................4189622
Operator Training Video...........................................4191631
Service & Repair Manual.........................................4171649
CAUTION
Use of other than Jacobsen authorized parts and accessories may cause personal injury or damage to the
equipment.
!

2 SPECIFICATIONS
8
2.7 DECLARATION OF CONFORMITY ____________________________________________
DECLARATION OF CONFORMITY ▪ДЕКЛАРАЦИЯ ЗА СЪОТВЕТСТВИЕ ▪PROHLÁŠENÍ O SHODĚ▪
OVERENSSTEMMELSESERKLÆRING ▪CONFORMITEITSVERKLARING ▪VASTAVUSDEKLARATSIOON ▪
VAATIMUSTENMUKAISUUSVAKUUTUS ▪DECLARATION DE CONFORMITE ▪KONFORMITÄTSERKLÄRUNG ▪
ΔΗΛΩΣΗ ΣΥΜΜΟΡΦΩΣΗΣ ▪MEGFELELŐSÉGI NYILATKOZAT ▪DICHIARAZIONE DI CONFORMITÀ ▪ATBILSTĪBAS
DEKLARĀCIJA ▪ATITIKTIES DEKLARACIJA ▪DIKJARAZZJONI TAL-KONFORMITÀ ▪DEKLARACJA ZGODNOŚCI ▪
DECLARAÇÃO DE CONFORMIDADE ▪DECLARAŢIE DE CONFORMITATE ▪VYHLÁSENIE O ZHODE ▪IZJAVA O
SKLADNOSTI ▪DECLARACIÓN DE CONFORMIDAD ▪DEKLARATION OM ÖVERENSSTÄMMELSE
Business name and full address of the manufacturer ▪Търговско име ипълен адрес на производителя ▪Obchodní jméno a plná adresa výrobce ▪
Producentens firmanavn og fulde adresse ▪Bedrijfsnaam en volledig adres van de fabrikant ▪Tootja ärinimi ja täielik aadress ▪
Valmistajan toiminimi ja täydellinen osoite ▪Nom commercial et adresse complète du fabricant ▪Firmenname und vollständige Adresse des Herstellers ▪
Επωνυμία και ταχυδρομική διεύθυνση κατασκευαστή ▪A gyártó üzleti neve és teljes címe ▪Ragione sociale e indirizzo completo del fabbricante ▪
Uzņēmuma nosaukums un pilna ražotāja adrese ▪Verslo pavadinimas ir pilnas gamintojo adresas ▪Isem kummerċjali u indirizz sħiħtal-fabbrikant ▪
Nazwa firmy i pełny adres producenta ▪Nome da empresa e endereço completo do fabricante ▪Denumirea comercialăşi adresa completăa
producătorului ▪Obchodný názov a úplná adresa výrobcu ▪Naziv podjetja in polni naslov proizvajalca ▪Nombre de la empresa y dirección completa del
fabricante ▪Tillverkarens företagsnamn och kompletta adress
Jacobsen, A Textron Company
11524 Wilmar Blvd.
Charlotte, NC 28273, USA
Product Code ▪Код на продукта ▪Kód výrobku ▪Produktkode ▪Productcode ▪Toote kood ▪Tuotekoodi ▪Code produit ▪Produktcode ▪Κωδικός προϊόντος
▪Termékkód ▪Codice prodotto ▪Produkta kods ▪Produkto kodas ▪Kodiċi tal-Prodott ▪Kod produktu ▪Código do Produto ▪Cod produs ▪Kód výrobku ▪
Oznaka proizvoda ▪Código de producto ▪Produktkod
62304
Machine Name ▪Наименование на машината ▪Název stroje ▪Maskinnavn ▪Machinenaam ▪Masina nimi ▪Laitteen nimi ▪Nom de la machine ▪
Maschinenbezeichnung ▪Ονομασία μηχανήματος ▪Gépnév ▪Denominazione della macchina ▪Iekārtas nosaukums ▪Mašinos pavadinimas ▪Isem tal-
Magna ▪Nazwa urządzenia ▪Nome da Máquina ▪Numele echipamentului ▪Názov stroja ▪Naziv stroja ▪Nombre de la máquina ▪Maskinens namn
Greens King IV Plus Diesel
Designation ▪Предназначение ▪Označení ▪Betegnelse ▪Benaming ▪Nimetus ▪Tyyppimerkintä ▪Pažymėjimas ▪Bezeichnung ▪Χαρακτηρισμός ▪
Megnevezés ▪Funzione ▪Apzīmējums ▪Lithuanian ▪Denominazzjoni ▪Oznaczenie ▪Designação ▪Specificaţie ▪Označenie ▪Namen stroja ▪Descripción
▪Beteckning
Lawnmower, Article 12, Item 32
Serial Number ▪Сериен номер ▪Sériové číslo ▪Serienummer ▪Serienummer ▪Seerianumber ▪Valmistusnumero ▪Numéro de série ▪Seriennummer ▪
Σειριακός αριθμός ▪Sorozatszám ▪Numero di serie ▪Sērijas numurs ▪Serijos numeris ▪Numru Serjali ▪Numer seryjny ▪Número de Série ▪Număr de
serie ▪Sériové číslo ▪Serijska številka ▪Número de serie ▪Serienummer
6230401701-6230402500
Engine ▪Двигател ▪Motor ▪Motor ▪Motor ▪Mootor ▪Moottori ▪Moteur ▪Motor ▪Μηχανή ▪Modulnév ▪Motore ▪Dzinējs ▪Variklis ▪Saħħa Netta Installata ▪
Silnik ▪Motor ▪Motor ▪Motor ▪Motor ▪Motor ▪Motor Kubota D722-E3B Diesel
Net Installed Power ▪Нетна инсталирана мощност ▪Čistý instalovaný výkon ▪Installeret nettoeffekt ▪Netto geïnstalleerd vermogen ▪Installeeritud
netovõimsus ▪Asennettu nettoteho ▪Puissance nominale nette ▪Installierte Nettoleistung ▪Καθαρή εγκατεστημένη ισχύς ▪Nettó beépített teljesítmény ▪
Potenza netta installata ▪Paredzētātīkla jauda ▪Grynoji galia ▪Wisa’ tal-Qtugħ▪Moc zainstalowana netto ▪Potência instalada ▪Puterea instalatănetă▪
Čistý inštalovaný výkon ▪Neto vgrajena moč▪Potencia instalada neta ▪Nettoeffekt
13,2 kW @ 3200 RPM
Cutting Width ▪Широчина на рязане ▪Šířka řezu ▪Skærebredde ▪Maaibreedte ▪Lõikelaius ▪Leikkuuleveys ▪Largeur de coupe ▪Schnittbreite ▪
Μήκος μισινέζας ▪Vágási szélesség ▪Larghezza di taglio ▪Griešanas platums ▪Pjovimo plotis ▪Tikkonforma mad-Direttivi ▪Szerokość cięcia ▪
Largura de Corte ▪Lăţimea de tăiere ▪Šírka záberu ▪Širina reza ▪Anchura de corte ▪Klippbredd
157 cm
Conforms to Directives ▪Всъответствие сдирективите ▪Splňuje podmínky směrnic ▪Er i overensstemmelse med direktiver ▪Voldoet aan de richtlijnen ▪
Vastab direktiividele ▪Direktiivien mukainen ▪Conforme aux directives ▪Entspricht Richtlinien ▪Ακολουθήστε πιστά τις Οδηγίες ▪Megfelel az irányelveknek
▪Conforme alle Direttive ▪Atbilst direktīvām ▪Atitinka direktyvųreikalavimus ▪Valutazzjoni tal-Konformità ▪Dyrektywy związane ▪Cumpre as Directivas ▪
RespectăDirectivele ▪Je v súlade so smernicami ▪Skladnost z direktivami ▪Cumple con las Directivas ▪Uppfyller direktiv
2004/108/EC
2006/42/EC
2000/14/EC, 2005/88/EC
2006/66/EC
Conformity Assessment ▪Оценка за съответствие ▪Hodnocení plnění podmínek ▪Overensstemmelsesvurdering ▪Conformiteitsbeoordeling ▪
Vastavushindamine ▪Vaatimustenmukaisuuden arviointi ▪Evaluation de conformité ▪Konformitätsbeurteilung ▪Διαπίστωση Συμμόρφωσης ▪
Megfelelőség-értékelés ▪Valutazione della conformità ▪Atbilstības novērtējums ▪Atitikties įvertinimas ▪Livell tal-Qawwa tal-Ħoss Imkejjel ▪Ocena
zgodności ▪Avaliação de Conformidade ▪Evaluarea conformităţii ▪Vyhodnotenie zhodnosti ▪Ocena skladnosti ▪Evaluación de conformidad ▪
Bedömning av överensstämmelse
2006/42/EC Annex VIII
Measured Sound Power Level ▪Измерено ниво на звукова мощност ▪Naměřený akustický výkon ▪Målte lydstyrkeniveau ▪Gemeten geluidsniveau ▪
Mõõdetud helivõimsuse tase ▪Mitattu äänitehotaso ▪Niveau de puissance sonore mesuré ▪Gemessener Schalldruckpegel ▪
Σταθμισμένο επίπεδο ηχητικής ισχύος ▪Mért hangteljesítményszint ▪Livello di potenza sonora misurato ▪Izmērītais skaņas jaudas līmenis ▪
Išmatuotas garso stiprumo lygis ▪Livell tal-Qawwa tal-Ħoss Iggarantit ▪Moc akustyczna mierzona ▪Nível sonoro medido ▪Nivelul măsurat al puterii
acustice ▪Nameraná hladina akustického výkonu ▪Izmerjena raven zvočne moči ▪Nivel de potencia sonora medido ▪Uppmätt ljudeffektsnivå
102 dB(A) LWA
Guaranteed Sound Power Level ▪Гарантирано ниво на звукова мощност ▪Garantovaný akustický výkon ▪Garanteret lydstyrkeniveau ▪
Gegarandeerd geluidsniveau ▪Garanteeritud helivõimsuse tase ▪Taattu äänitehotaso ▪Niveau de puissance sonore garanti ▪Garantierter
Schalldruckpegel ▪Εγγυημένο επίπεδο ηχητικής ισχύος ▪Szavatolt hangteljesítményszint ▪Livello di potenza sonora garantito ▪Garantētais skaņas
jaudas līmenis ▪Garantuotas garso stiprumo lygis ▪Livell tal-Qawwa tal-Ħoss Iggarantit ▪Moc akustyczna gwarantowana ▪Nível sonoro farantido ▪
Nivelul garantat al puterii acustice ▪Garantovaná hladina akustického výkonu ▪Zajamčena raven zvočne moči ▪Nivel de potencia sonora garantizado ▪
Garanterad ljudeffektsnivå
102dB(A) LWA
Conformity Assessment Procedure (Noise) ▪Оценка за съответствие на процедурата (Шум) ▪Postup hodnocení plnění podmínek (hluk) ▪
Procedure for overensstemmelsesvurdering (Støj) ▪Procedure van de conformiteitsbeoordeling (geluid) ▪Vastavushindamismenetlus (müra) ▪
Vaatimustenmukaisuuden arviointimenettely (Melu) ▪Procédure d’évaluation de conformité (bruit) ▪Konformitätsbeurteilungsverfahren (Geräusch) ▪
Διαδικασία Αξιολόγησης Συμμόρφωσης (Θόρυβος) ▪Megfelelőség-értékelési eljárás (Zaj) ▪Procedura di valutazione della conformità (rumore) ▪
Atbilstības novērtējuma procedūra (troksnis) ▪Atitikties įvertinimo procedūra (garsas) ▪Proċedura tal-Valutazzjoni tal-Konformità (Ħoss) ▪
Procedura oceny zgodności (poziom hałasu) ▪Processo de avaliação de conformidade (nível sonoro) Procedura de evaluare a conformităţii (zgomot) ▪
Postup vyhodnocovania zhodnosti (hluk) ▪Postopek za ugotavljanje skladnosti (hrup) ▪Procedimiento de evaluación de conformidad (ruido) ▪
Procedur för bedömning av överensstämmelse (buller)
2000/14/EC Annex VI, Part 1
UK Notified Body for 2000/14/EC ▪Нотифициран орган вОбединеното кралство за 2000/14/ЕО ▪Úřad certifikovaný podle směrnice č. 2000/14/EC ▪
Det britiske bemyndigede organ for 2001/14/EF ▪Engels adviesorgaan voor 2000/14/EG ▪Ühendkuningriigi teavitatud asutus direktiivi 2000/14/EÜ
mõistes ▪Direktiivin 2000/14/EY mukainen ilmoitettu tarkastuslaitos Isossa-Britanniassa ▪Organisme notifié concernant la directive 2000/14/CE ▪
Britische benannte Stelle für 2000/14/EG ▪Κοινοποιημένος Οργανισμός Ηνωμένου Βασιλείου για 2000/14/ΕΚ ▪
2000/14/EK – egyesült királyságbeli bejelentett szervezet ▪Organismo Notificato in GB per 2000/14/CE ▪2000/14/EK AK reģistrētāorganizācija ▪
JK notifikuotosios įstaigos 2000/14/EC ▪Korp Notifikat tar-Renju Unit għal 2000/14/KE ▪Dopuszczona jednostka badawcza w Wielkiej Brytanii wg 2000/
14/WE ▪Entidade notificada no Reino Unido para 2000/14/CE ▪Organism notificat în Marea Britanie pentru 2000/14/CE ▪
Notifikovaný orgán Spojeného kráľovstva pre smernicu 2000/14/ES ▪Britanski priglašeni organ za 2000/14/ES ▪
Cuerpo notificado en el Reino Unido para 2000/14/CE ▪Anmält organ för 2000/14/EG i Storbritannien
Number: 1088
Sound Research Laboratories Limited
Holbrook House, Little Waldingfield
Sudbury, Suffolk CO10 0TH
Operator Ear Noise Level ▪Оператор на нивото на доловим от ухото шум ▪Hladina hluku v oblasti uší operátora ▪Støjniveau i førers ørehøjde ▪
Geluidsniveau oor bestuurder ▪Müratase operaatori kõrvas ▪Melutaso käyttäjän korvan kohdalla ▪Niveau de bruit à hauteur des oreilles de l’opérateur ▪
Schallpegel am Bedienerohr ▪Επίπεδο θορύβου σε λειτουργία ▪A kezelőfülénél mért zajszint ▪Livello di potenza sonora all’orecchio dell’operatore ▪
Trokšņa līmenis pie operatora auss ▪Dirbančiojo su mašina patiriamo triukšmo lygis ▪Livell tal-Ħoss fil-Widna tal-Operatur ▪
Dopuszczalny poziom hałasu dla operatora ▪Nível sonoro nos ouvidos do operador ▪Nivelul zgomotului la urechea operatorului ▪
Hladina hluku pôsobiaca na sluch operátora ▪Raven hrupa pri ušesu upravljavca ▪Nivel sonoro en el oído del operador ▪Ljudnivå vid förarens öra
87 dB(a) Leq (2006/42/EC)

SPECIFICATIONS 2
9
Harmonised standards used ▪Използвани хармонизирани стандарти ▪Použité harmonizované normy ▪Brugte harmoniserede standarder ▪
Gebruikte geharmoniseerde standaards ▪Kasutatud ühtlustatud standardid ▪Käytetyt yhdenmukaistetut standardit ▪Normes harmonisées utilisées ▪
Angewandte harmonisierte Normen ▪Εναρμονισμένα πρότυπα που χρησιμοποιήθηκαν ▪Harmonizált szabványok ▪Standard armonizzati applicati ▪
Izmantotie saskaņotie standarti ▪Panaudoti suderinti standartai ▪Standards armonizzati użati ▪Normy spójne powiązane ▪Normas harmonizadas usadas
▪Standardele armonizate utilizate ▪Použité harmonizované normy ▪Uporabljeni usklajeni standardi ▪Estándares armonizados utilizados ▪
Harmoniserade standarder som används
BS EN ISO 20643
BS EN ISO 5349-1
BS EN ISO 5349-2
BS EN 836
Technical standards and specifications used ▪Използвани технически стандарти испецификации ▪Použité technické normy a specifikace ▪
Brugte tekniske standarder og specifikationer ▪Gebruikte technische standaards en specificaties ▪Kasutatud tehnilised standardid ja spetsifikatsioonid ▪
Käytetyt tekniset standardit ja eritelmät ▪Spécifications et normes techniques utilisées ▪Angewandte technische Normen und Spezifikationen ▪
Τεχνικά πρότυπα και προδιαγραφές που χρησιμοποιήθηκαν ▪Műszaki szabványok és specifikációk ▪Standard tecnici e specifiche applicati ▪
Izmantotie tehniskie standarti un specifikācijas ▪Panaudoti techniniai standartai ir techninėinformacija ▪Standards u speċifikazzjonijiet tekniċi użati ▪
Normy i specyfikacje techniczne powiązane ▪Normas técnicas e especificações usadas ▪Standardele tehnice şi specificaţiile utilizate ▪
Použité technické normy a špecifikácie ▪Uporabljeni tehnični standardi in specifikacije ▪Estándares y especificaciones técnicas utilizadas ▪
Tekniska standarder och specifikationer som används
B71.4
ISO 2631-1
ISO 21299
The place and date of the declaration ▪Място идата на декларацията ▪Místo a datum prohlášení ▪Sted og dato for erklæringen ▪
Plaats en datum van de verklaring ▪Deklaratsiooni väljastamise koht ja kuupäev ▪Vakuutuksen paikka ja päivämäärä ▪Lieu et date de la déclaration ▪
Ort und Datum der Erklärung ▪Τόπος και ημερομηνία δήλωσης ▪A nyilatkozat kelte (hely és idő) ▪Luogo e data della dichiarazione ▪
Deklarācijas vieta un datums ▪Deklaracijos vieta ir data ▪Il-post u d-data tad-dikjarazzjoni ▪Miejsce i data wystawienia deklaracji ▪Local e data da
declaração ▪Locul şi data declaraţiei ▪Miesto a dátum vyhlásenia ▪Kraj in datum izjave ▪Lugar y fecha de la declaración ▪Plats och datum för
deklarationen
Jacobsen, A Textron Company
11524 Wilmar Blvd.
Charlotte, NC 28273, USA
January 1, 2011
Signature of the person empowered to draw up the declaration on behalf of the manufacturer, holds the technical documentation and is authorised to
compile the technical file, and who is established in the Community.
Подпис на човека, упълномощен да състави декларацията от името на производителя, който поддържащ техническата документация ие
оторизиран да изготви техническия файл иерегистриран вобщността.
Podpis osoby oprávněné sestavit prohlášení jménem výrobce, držet technickou dokumentaci a osoby oprávněné sestavit technické soubory a založené v
rámci Evropského společenství.
Underskrift af personen, der har fuldmagt til at udarbejde erklæringen på vegne af producenten, der er indehaver af dokumentationen og er bemyndiget til
at udarbejde den tekniske journal, og som er baseret i nærområdet.
Handtekening van de persoon die bevoegd is de verklaring namens de fabrikant te tekenen, de technische documentatie bewaart en bevoegd is om het
technische bestand samen te stellen, en die is gevestigd in het Woongebied.
Ühenduse registrisse kantud isiku allkiri, kes on volitatud tootja nimel deklaratsiooni koostama, kes omab tehnilist dokumentatsiooni ja kellel on õigus
koostada tehniline toimik.
Sen henkilön allekirjoitus, jolla on valmistajan valtuutus vakuutuksen laadintaan, jolla on hallussaan tekniset asiakirjat, joka on valtuutettu laatimaan
tekniset asiakirjat ja joka on sijoittautunut yhteisöön.
Signature de la personne habilitée à rédiger la déclaration au nom du fabricant, à détenir la documentation technique, à compiler les fichiers techniques et
qui est implantée dans la Communauté.
Unterschrift der Person, die berechtigt ist, die Erklärung im Namen des Herstellers abzugeben, die die technischen Unterlagen aufbewahrt und berechtigt
ist, die technischen Unterlagen zusammenzustellen, und die in der Gemeinschaft niedergelassen ist.
Υπογραφή ατόμου εξουσιοδοτημένου για την σύνταξη της δήλωσης εκ μέρους του κατασκευαστή, οοποίος κατέχει την τεχνική έκθεση και έχει την
εξουσιοδότηση να ταξινομήσει τον τεχνικό φάκελο και οοποίος είναι διορισμένος στην Κοινότητα.
A gyártó nevében meghatalmazott személy, akinek jogában áll módosítania a nyilatkozatot, a műszaki dokumentációt őrzi, engedéllyel rendelkezik a
műszaki fájl összeállításához, és aki a közösségben letelepedett személy.
Firma della persona autorizzata a redigere la dichiarazione a nome del fabbricante, in possesso Della documentazione tecnica ed autorizzata a costituire
il fascicolo tecnico, che deve essere stabilita nella Comunità.
Tās personas paraksts, kura ir pilnvarota deklarācijas sastādīšanai ražotāja vārdā, kurai ir tehniskādokumentācija, kura ir pilnvarota sagatavot tehnisko
reģistru un kura ir apstiprināta Kopienā.
Asmuo, kuris yra gana žinomas, kuriam gamintojas suteikėįgaliojimus sudaryti šiądeklaraciją, ir kuris jąpasirašė, turi visątechninęinformacijąir yra
įgaliotas sudaryti techninės informacijos dokumentą.
Il-firma tal-persuna awtorizzata li tfassal id-dikjarazzjoni f’isem il-fabbrikant, għandha d-dokumentazzjoni teknika u hija awtorizzata li tikkompila l-fajl
tekniku u li hija stabbilita fil-Komunità.
Podpis osoby upoważnionej do sporządzenia deklaracji w imieniu producenta, przechowującej dokumentacjętechniczną, upoważnionądo stworzenia
dokumentacji technicznej oraz wyznaczonej ds. wspólnotowych.
Assinatura da pessoa com poderes para emitir a declaração em nome do fabricante, que possui a documentação técnica, que está autorizada a compilar
o processo técnico e que está estabelecida na Comunidade.
Semnătura persoanei împuternicite săelaboreze declaraţia în numele producătorului, care deţine documentaţia tehnică, este autorizatăsăcompileze
dosarul tehnic şi este stabilităîn Comunitate.
Podpis osoby poverenej vystavením vyhlásenia v mene výrobcu, ktorá má technickú dokumentáciu a je oprávnená spracovaťtechnické podklady a ktorá
je umiestnená v Spoločenstve.
Podpis osebe, pooblaščene za izdelavo izjave v imenu proizvajalca, ki ima tehnično dokumentacijo in lahko sestavlja spis tehnične dokumentacije, ter ima
sedež v Skupnosti.
Firma de la persona responsable de la declaración en nombre del fabricante, que posee la documentación técnica y está autorizada para recopilar el
archivo técnico y que está establecido en la Comunidad.
Undertecknas av den som bemyndigad att upprätta deklarationen å tillverkarens vägnar, innehar den tekniska dokumentationen och är bemyndigad att
sammanställa den tekniska informationen och som är etablerad i gemenskapen.
2006/42/EC Annex II 1.A.2
Tim Lansdell
Technical Director
Ransomes Jacobsen Limited
West Road, Ransomes Europark,
Ipswich, IP3 9TT, England
2006/42/EC Annex II 1.A.10
Vasant Godhalekar
VP of Engineering
Jacobsen, A Textron Company
11524 Wilmar Blvd,
Charlotte, NC 28273, USA
Certificate Number ▪Номер на сертификат ▪Číslo osvědčení ▪Certifikatnummer ▪Certificaatnummer ▪Sertifikaadi number ▪Hyväksyntänumero ▪
Numéro de certificat ▪Bescheinigungsnummer ▪Αριθμός Πιστοποιητικού ▪Hitelesítési szám ▪Numero del certificato ▪Sertifikāta numurs ▪
Sertifikato numeris ▪Numru taċ-Ċertifikat ▪Numer certyfikatu ▪Número do Certificado ▪Număr certificat ▪Číslo osvedčenia ▪Številka certifikata ▪
Número de certificado ▪Certifikatsnummer
4212746 Rev B

3 ADJUSTMENTS
10
3 ADJUSTMENTS
3.1 GENERAL________________________________________________________________
1. Adjustments and maintenance should always be
performed by a qualified technician. If proper
adjustment cannot be made, contact an authorized
Jacobsen Dealer.
2. Replace, do not adjust, worn or damaged
components.
3. Long hair, jewelry, or loose fitting clothing may get
tangled in moving parts.
4. Do not change governor settings or overspeed the
engine.
3.2 BEDKNIFE-TO-REEL _______________________________________________________
(Pre-adjustment Check)
1. Check the reel bearings for end play or radial play.
There should be no end play or radial play. See
Section 3.14.
2. Inspect the reel blades and bedknife to insure good
sharp edges without bends or nicks.
a. The leading edge of the reel blades (B) must be
sharp, free of burrs and show no signs of rounding
off.
b. The bedknife and bedknife backing must be
securely tightened. The bedknife must be straight
and sharp.
c. A flat surface of at least 1/16 in. (1.5 mm) minimum
must be maintained on the front face of the bed-
knife. Use a standard flat file to dress the bedknife.
3. If wear or damage is beyond the point where the
reel or bedknife can be corrected by the lapping
process, they must be reground.
4. Proper reel-to-bedknife adjustment is critical. A gap
of 0.001 to 0.003 in. (0.025 to 0.076 mm) must be
maintained across the entire length of the reel and
bedknife.
5. The reel must be parallel to the bedknife. An
improperly adjusted reel will lose its sharp edges
prematurely and may result in serious damage to
the reel and bedknife.
6. Grass conditions will also affect the adjustment.
a. Dry, sparse conditions will require a wider gap to
prevent heat buildup and damage to the reel and
bedknife.
b. High quality grass with a good moisture content
requires a closer gap (near zero).
Figure 3A
Figure 3B
WARNING
To prevent injury, lower implements to the ground,
disengage all drives, engage parking brake, stop
engine and remove key from ignition switch before
making any adjustments or performing maintenance.
Make sure the mower is parked on a solid and level
surface. Never work on a mower that is supported
only by the jack. Always use jack stands.
If only the front or rear of the mower is raised, place
chocks in front of and behind the wheels that are not
raised.
!
CAUTION
Be careful to prevent entrapment of the hands and
fingers between moving and fixed components of the
machine.
!
1/16 in.
(1.5 mm)
B

ADJUSTMENTS 3
11
3.3 BEDKNIFE ADJUSTMENT ___________________________________________________
1. Read Section 3.2 before making the adjustment.
2. Start adjustment at the leading end of the reel,
followed by the trailing end. The leading end of the
reel blades is that end which passes over the
bedknife first during normal reel rotation.
3. Use adjusters (A and B), to adjust gap. Loosen
bottom adjuster (B) and turn top adjuster (A) down
(Clockwise) to close gap.
a. Slide a feeler gauge or shim stock 0.001 - 0.003
in. (0.025 - 0.076 mm) between the reel blade
and the bedknife. Do not turn the reel.
b. Adjust the trailing end of the reel to the same
gap in a similar manner then recheck the
adjustment at the leading end.
c. When the reel is properly adjusted to the
bedknife, the reel will spin freely and you should
be able to cut a piece of newspaper, along the
full length of the reel, when the paper is held at
90° to the bedknife.
Figure 3C
Note: Avoid excessive tightening or serious damage may
result to bedknife and reel blades. Reels must turn freely.
3.4 CUTTING HEIGHT _________________________________________________________
Note: Always make the bedknife to reel adjustment
before adjusting height of cut. (See Sections 3.2 and
3.3).
1. Raise mowers to transport position then engage the
parking brake, stop engine, and remove key from
ignition switch.
2. Set desired cutting height on the gauge (I).
a. Measure distance (J) between the underside of
screw head and gauge block surface.
b. Adjust screw (F) to obtain desired height then
tighten the wing nut.
3. Loosen the locknuts on the front roller brackets (E)
just enough to allow the adjuster knob (H) to raise or
lower the front roller.
4. Place gauge (I) across bottom of front and rear
rollers near one end of roller.
5. Slide the head of gauge screw over the bedknife (G)
and adjust the knob (H) to close the gap between the
screw head and bedknife. Then tighten locknut (E).
6. Repeat Steps 4 and 5 on opposite end. Complete
adjustment to one end before adjusting opposite end.
7. Tighten locknuts (E) and recheck each end.
Figure 3D
CAUTION
To prevent personal injury and damage to the cutting
edges, handle the reel with extreme care.
!
A
B
J
H
E
I
FG

3 ADJUSTMENTS
12
3.5 ANTISWAY SPRING________________________________________________________
1. The antisway spring (C) should be tight but not
under stress.
2. Loosen both nuts on the adjusting rod then adjust the
rear nut as necessary.
3. When properly adjusted, tighten nuts against bracket.
Figure 3E
3.6 ACCELERATOR PEDAL ____________________________________________________
1. The top of the pedal should not be less than 2-3/4
in. (70 mm) from the floorboard when pedal is fully
depressed.
2. Loosen locknut (D) and adjust carriage bolt (E) to
obtain the correct distance between pedal and
floorboard.
Figure 3F
3.7 BRAKE PEDAL____________________________________________________________
1. Drive straight forward with traction lever in MOW
position and throttle in SLOW position. Depress
Brake pedal. If the brake pedal comes too close to
the floorboard, check the amount of brake lining left.
a. Replace lining.
b. Adjust nut (F) to obtain a distance of 3-5/16 in.
(84 mm), between rod pivot points, (when brakes
are new), and to compress spring to 31/32 in. (24
mm).
2. If machine pulls right, turn adjusting nut (F) on left
side clockwise. If machine pulls left, turn adjusting
nut (F) on left side counterclockwise. Do not
compress either spring past 7/8 in. (22 mm).
Figure 3G
C
GKV 2
2-3/4 in. (70 mm)
Fully Depressed
E
DGKV-3
3-5/16 in.
(84 mm)
F
GKV-4
31/32 in.
(24 mm)

ADJUSTMENTS 3
13
3.8 PARKING BRAKE__________________________________________________________
Disengage brake lever and measure the distance
between nut (G) and bottom of pivot. Adjust nut so the
distance is 3/16 in. (5 mm).
Figure 3H
3.9 INTERLOCK SWITCHES ____________________________________________________
1. Refer to the Interlock System check in your Safety &
Operation manual. If the system fails any test listed,
adjustment or replacement of the switches or levers
is required.
2. Remove the front cowling and check the control
linkages to be sure they are properly adjusted
(Sections 3.8, 3.10 and 3.11).
3. Check switches to make sure they are working
properly.
3.10 TRACTION LEVER _________________________________________________________
1. Remove front cowling and adjust lever to align with
the four positions on the instrument panel.
2. Adjust ball joints (M) on rod (N) and/or adjust
position and number of washers (P) for proper
alignment. The lever must engage Neutral start
switch in NEUTRAL position only.
Figure 3I
3/16 in.
GKV-13
G
(5 mm)
CAUTION
Never operate equipment with damaged switches.
Replace faulty switches immediately.
!
P
M
N
M
GKV-15

3 ADJUSTMENTS
14
3.11 REEL CONTROL __________________________________________________________
Adjust the reel control lever linkage so the reels
disengage when they reach the raised position.
1. Remove front cowling and raise mowers. Shift all
reel control levers to OFF and stop engine.
2. Adjust link (R) so there is 1/32 to 1/16 in. (0.8 to
1.6 mm) clearance between the bottom of the
shoulder bolt (S) and the bottom of the slot in link
(R).
3. Remove all hardware holding link (R) in place then
loosen nut (T) and adjust the link.
3. Tighten nut (T) against the link. Reassemble all
components and tighten hardware.
Figure 3J
3.12 REEL SWITCHES__________________________________________________________
The reel lever linkage actuates two electrical switches
located under the levers. Check that both switches are
closed when all reel levers are in their NEUTRAL
position.
1. Check and make sure switches are wired correctly.
Refer to Figure 3K and labels attached to wires for
correct terminal placement.
2. When any of the reel levers are moved to the
forward position, Reel Switch (Wires A and B)
should open, and Backlap Switch (Wires C and D)
should remain closed.
3. When any of the reel levers are moved to the
reverse position, Backlap Switch (Wires C and D)
should open and Reel Switch (Wires A and B)
should remain closed.
Figure 3K
1/32 to 1/16 in.
(0.8 to 1.6 mm)
T
R
S
A
B
C
D
Reel Switch
Backlap Switch

ADJUSTMENTS 3
15
3.13 LEVELING PROCEDURE ____________________________________________________
1. Lower the implements until they are about 1/4 in.
(6.35 mm) above the ground. If they are not level
with the ground, adjust torsion spring (Z).
2. Carefully loosen spring mounting clamp and slowly
turn clamp until implement is level. Tighten clamp
securely.
Figure 3L
3.14 REEL BEARING ___________________________________________________________
Excessive end play or any radial play indicates bad
bearings, a weak tension spring, or a backed off nut.
1. Check bearing housing mounting hardware. Tighten
or replace components as required. Carefully clean
threads with degreaser.
2. Apply a medium strength grade of Loctite to nut (AA),
then thread nut onto the reel shaft until the nut is
1-27/32 in. (46 mm) from the end of the reel shaft.
3. Fill reel bearing housings with NLGI - Grade O
grease after adjusting spring.
Figure 3M
3.15 FAN BELT ________________________________________________________________
Inspect and adjust new belt after first ten hours of
operation. Adjust every 100 hours thereafter.
1. Adjust alternator pulley so belt (B) deflects 9/32 to
11/32 in. (7 to 9 mm) with a 22 lb. (10 kgf) push at
mid span between pulleys.
2. If tension is incorrect, loosen alternator mounting
bolts (A) and adjust alternator until proper belt
tension is achieved. Tighten hardware (A).
Figure 3N
WARNING
The torsion spring is under extreme tension and will
tend to uncoil very rapidly if the clamp is loosened. To
prevent being cut by clamp or spring, unwind spring
by tapping on clamp while slowly loosening nut.
!
ZClamp
GKV-10
GKV-11
AA
AA
1-27/32 in.
(46 mm)
A
B

3 ADJUSTMENTS
16
3.16 LIFT CYLINDERS __________________________________________________________
1. Fully extend the front cylinder, then check spacing at
the cam roller (U). The dimension should be 7/16 to
9/16 in. (11.1 to 14.2 mm).
2. Loosen nut (V) then grip the very end of the cylinder
rod, close to the adjusting nut (point W) and turn
until spacing is correct. Tighten nut (V).
3. Loosen nut (X) on the rear lift cylinder. Adjust the rod
end (Y) until the lift arm (O) just touches the stop
bracket when the cylinder is fully retracted.
Figure 3O
Figure 3P
3.17 SPECIFIC TORQUE REQUIREMENTS _________________________________________
1. Ball joints: 30 - 35 ft. lb., (40.5 - 47.2 N.m).
2. Bedknife shoe: 25 - 37 ft. lb., (34 - 50 N.m).
3. Brake drum and hub to wheel motor: 90 - 100 ft. lb.,
(122 - 135 N.m).
4. Steering wheel nut 25-30 ft. lb., (34-41 N.m).
5. Steering cylinder ball joints (2): 50 - 55 ft. lb., (67.5 -
74.2 N.m).
6. Wheel mounting hardware 65-85 ft. lb., (88 - 115
N.m). Check and retorque daily until torque is
maintained.
7. Engine drain plug 22 ft. lb., (29.7 N.m).
7/16 to 9/16 in.
(11.1 to 14.2 mm)
V
W
U
GKV-8
GKV-9
Stop Bracket X
Y
O

ADJUSTMENTS 3
17
3.18 TORQUE SPECIFICATION ___________________________________________________
Jacobsen uses Grade 5 Plated bolts as standard, unless otherwise noted. For tightening plated bolts, use the value
given for lubricated.
NOTICE
All torque values included in these charts are approximate and are for reference only. Use of these torque values is
at your sole risk. Jacobsen is not responsible for any loss, claim, or damage arising from the use of these charts.
Extreme caution should always be used when using any torque value.
AMERICAN NATIONAL STANDARD FASTENERS
SIZE UNITS GRADE 5 GRADE 8 SIZE UNITS GRADE 5 GRADE 8
Lubricated Dry Lubricated Dry Lubri-
cated
Dry Lubri-
cated
Dry
#6-32 in-lb (Nm) – 20 (2.3) – – 7/16-14 ft-lb (Nm) 37 (50.1) 50 (67.8) 53 (71.8) 70 (94.9)
#8-32 in-lb (Nm) – 24 (2.7) – 30 (3.4) 7/16-20 ft-lb (Nm) 42 (56.9) 55 (74.6) 59 (80.0) 78 (105)
#10-24 in-lb (Nm) – 35 (4.0) – 45 (5.1) 1/2-13 ft-lb (Nm) 57 (77.2) 75 (101) 80 (108) 107 (145)
#10-32 in-lb (Nm) – 40 (4.5) – 50 (5.7) 1/2-20 ft-lb (Nm) 64 (86.7) 85 (115) 90 (122) 120 (162)
#12-24 in-lb (Nm) – 50 (5.7) – 65 (7.3) 9/16-12 ft-lb (Nm) 82 (111) 109 (148) 115 (156) 154 (209)
1/4-20 in-lb (Nm) 75 (8.4) 100 (11.3) 107 (12.1) 143 (16.1) 9/16-18 ft-lb (Nm) 92 (124) 122 (165) 129 (174) 172 (233)
1/4-28 in-lb (Nm) 85 (9.6) 115 (13.0) 120 (13.5) 163 (18.4) 5/8-11 ft-lb (Nm) 113 (153) 151 (204) 159 (215) 211 (286)
5/16-18 in-lb (Nm) 157 (17.7) 210 (23.7) 220 (24.8) 305 (34.4) 5/8-18 ft-lb (Nm) 128 (173) 170 (230) 180 (244) 240 (325)
5/16-24 in-lb (Nm) 173 (19.5) 230 (26.0) 245 (27.6) 325 (36.7) 3/4-10 ft-lb (Nm) 200 (271) 266 (360) 282 (382) 376 (509)
3/8-16 ft-lb (Nm) 23 (31.1) 31 (42.0) 32 (43.3) 44 (59.6) 3/4-16 ft-lb (Nm) 223 (302) 298 404 315 (427) 420 (569)
3/8-24 ft-lb (Nm) 26 (35.2) 35 (47.4) 37 (50.1) 50 (67.8) 7/8-14 ft-lb (Nm) 355 (481) 473 (641) 500 (678) 668 (905)
METRIC FASTENERS
SIZE UNITS
Non Critical
Fasteners
into
Aluminum
Lubricated Dry Lubricated Dry Lubricated Dry Lubricated Dry
M4 Nm(in-lb)––––––3.83(34)5.11(45)2.0(18)
M5 Nm (in-lb) 1.80 (16) 2.40 (21) 4.63 (41) 6.18 (54) 6.63 (59) 8.84 (78) 7.75 (68) 10.3 (910 4.0 (35)
M6 Nm (in-lb) 3.05 (27) 4.07 (36) 7.87 (69) 10.5 (93) 11.3 (102) 15.0 (133) 13.2 (117) 17.6 (156) 6.8 (60)
M8 Nm (in-lb) 7.41 (65) 9.98 (88) 19.1 (69) 25.5 (226) 27.3 (241) 36.5 (323) 32.0 (283) 42.6 (377) 17.0 (150)
M10 Nm (ft-lb) 14.7 (11) 19.6 (14) 37.8 (29) 50.5 (37) 54.1 (40) 72.2 (53) 63.3 (46) 84.4 (62) 33.9 (25)
M12 Nm (ft-lb) 25.6 (19) 34.1 (25) 66.0 (48) 88.0 (65) 94.5 (70) 125 (92) 110 (81) 147 (108) 61.0 (45)
M14 Nm (ft-lb) 40.8 (30) 54.3 (40) 105 (77) 140 (103) 150 (110) 200 (147) 175 (129) 234 (172) 94.9 (70)
4.6
8.8
10.9
12.9

4 MAINTENANCE
18
4 MAINTENANCE
4.1 GENERAL________________________________________________________________
1. Adjustment and maintenance should always be
performed by a qualified technician. If proper
adjustments cannot be made, contact an Authorized
Jacobsen Dealer.
2. Inspect the equipment on a regular basis, establish
a maintenance schedule and keep detailed records.
a. Keep the equipment clean.
b. Keep all moving parts properly adjusted and
lubricated.
c. Replace worn or damaged parts before operating
the machine.
d. Keep all fluids at their proper levels.
e. Keep shields in place and all hardware securely
fastened.
f. Keep tires properly inflated.
3. Long hair, jewelry, or loose fitting clothing may get
tangled in moving parts.
4. Use the illustrations in the Parts Catalog as
reference for the disassembly and reassembly of
components.
5. Recycle or dispose of all hazardous materials
(batteries, fuel, lubricants, anti-freeze, etc.)
according to local, state, or federal regulations.
4.2 ENGINE _________________________________________________________________
IMPORTANT: A separate Engine Manual, prepared by
the engine manufacturer, is supplied with this
mower. Read the Engine Manual carefully until you
are familiar with the operation and maintenance of
the engine. Proper attention to the engine
manufacturer’s directions will assure maximum
service life of the engine. To order a replacement
Engine Manual contact the engine manufacturer.
The proper break-in of a new engine can make a
considerable difference to the performance and life of the
engine.
Note: The mower is designed to operate and cut most
efficiently at the preset governor setting. Do not change
the engine governor settings or overspeed the engine.
During the break-in period, Jacobsen recommends the
following:
1. During the first 50 hours of operation, a new engine
should be allowed to reach an operating temperature
of at least 140°F (60°C) prior to operation at full load.
2. Check the engine oil level twice daily during the first
50 hours of operation. Higher than normal oil
consumption is not uncommon during the initial
break-in period.
3. Change engine oil and oil filter element after first 50
hours of operation.
4. Check and adjust fan and alternator belts.
5. Refer to Section 6.3 and Engine Manual for specific
maintenance intervals.
If the injection pump, injectors, or the fuel system require
service, contact an authorized Jacobsen Dealer.
WARNING
Before you clean, adjust, or repair this equipment,
disengage all drives, lower implements to the ground,
engage parking brake, stop engine, and remove key
from ignition switch to prevent injuries.
Make sure the mower is parked on a solid and level
surface. Never work on a mower that is supported
only by the jack. Always use jack stands.
!

MAINTENANCE 4
19
4.3 ENGINE OIL ______________________________________________________________
Check the engine oil at the start of each day, before
starting the engine. If the oil level is low, remove oil filler
cap and add oil as required.
Perform initial oil change after first 50 hours of operation
and every 75 hours thereafter. See Engine Manual.
Use only engine oils with API classification CD/CE.
Figure 4A
4.4 DIESEL AIR FILTER ________________________________________________________
Check the service indicator daily. If red band appears in
the window (C) replace the element.
Do not remove the element for inspection or
cleaning. Unnecessary removal of the filter increases
the risk of injecting dust and other impurities into the
engine.
When service is required, first clean the outside of the
filter housing; then remove the old element as gently as
possible and discard.
1. Carefully clean the inside of the filter housing without
allowing dust into the air intake.
2. Inspect the new element. Do not use a damaged
element and never use an incorrect element.
3. Assemble the new element and make sure it seats
properly. Reset the indicator by depressing button
(D).
4. Reassemble cap making sure it seals completely
around the filter housing. Dust evacuator must be
facing down.
5. Check all hoses and air ducts. Tighten hose clamps.
Figure 4B
Above 77°F (25°C) SAE 30W or SAE10W30/10W40
32 to 77°F (0 to 25°C) SAE 20W or SAE 10W30/10W40
Below 32° (0°C) SAE10W or SAE 10W30/10W40
Diesel Engine Dipstick
Safe Operating Range
⎧ ⎨ ⎪ ⎪ ⎪ ⎪ ⎩
C
D

4 MAINTENANCE
20
4.5 FUEL ____________________________________________________________________
Handle fuel with care - it is highly flammable. Use an
approved container, the spout must fit inside the fuel filler
neck. Avoid using cans and funnels to transfer fuel.
• Fill the fuel tank to within 1 in. (25 mm) of the bottom of
the filler neck.
• Store fuel according to local, state, or federal
ordinances and recommendations from your fuel
supplier.
• Never overfill or allow the tank to become empty.
• Check fuel lines and clamps every 50 hours. Replace
fuel lines and clamps at the first sign of damage.
• Use clean, fresh, #2 low or ultra low sulfur Diesel fuel.
Minimum Cetane rating 45. Refer to Engine Manual for
additional information.
4.6 FUEL SYSTEM ____________________________________________________________
Refer to Section 6.3 for specific maintenance intervals. Before replacing any filter, thoroughly clean the filter
housing and the area around the filter. Dirt must not be
allowed to enter into fuel system.
4.7 BATTERY ________________________________________________________________
Make absolutely certain the ignition switch is OFF and
the key has been removed before servicing the battery.
Tighten cables securely to battery terminals and apply a
light coat of silicone dielectric grease to terminals and
cable ends to prevent corrosion. Keep vent caps and
terminal covers in place.
Check the electrolyte level every 100 hours. Keep the
cable ends, battery, and battery posts clean.
Verify battery polarity before connecting or disconnecting
the battery cables.
Always disconnect battery cables from battery before
performing any welding operation on the mower.
Always disconnect battery cables from battery before
performing any welding operation on the groomer.
1. When installing the battery, always assemble the
RED, positive (+) battery cable first and the ground,
BLACK, negative (-) cable last.
2. When removing the battery, always remove the
ground, BLACK, negative (-) cable first and the
RED, positive (+) cable last.
3. Make sure battery is properly installed and secured
to the battery tray.
WARNING
Never remove the fuel cap from the fuel tank, or add
fuel, when the engine is running or while the engine is
hot.
Do not smoke when handling fuel. Never fill or drain
the fuel tank indoors.
Do not spill fuel and clean spilled fuel immediately.
Never handle or store fuel containers near an open
flame or any device that may create sparks and ignite
the fuel or fuel vapors.
Be sure to reinstall and tighten fuel cap securely.
!
CAUTION
Always use insulated tools, wear protective glasses or
goggles, and protective clothing when working with
batteries. You must read and obey all battery
manufacturer’s instructions.
!
WARNING
Battery posts, terminals, and related accessories
contain lead and lead compounds, chemicals known
to the State of California to cause cancer and
reproductive harm. Wash your hands after
handling.
!
