Riva®5
WHIRLPOOL PLUS
BATH
MODEL NUMBER:
ES30 — Left-hand
ES40 — Right-hand
EXTERIOR DIMENSIONS:
62" long x 43" wide x
19" high
INTERIOR DIMENSIONS:
41" long x 26" wide
# OF JETS/TYPE OF JETS:
4 TheraPro™ Jets,
4 AccuPro™ Lumbar Jet
OPERATING GALLONS:
49 gallons
Evoking the breathtaking beauty and ancient maritime tradition of the northern
Italian town for which it is named, the Riva®is true to form—an elegant classic. And
truly versatile—at home in both traditional and more contemporary interior design.
WHIRLPOOL BATH FEATURES:
• 4 fully adjustable TheraPro™ jets
• 4 directionally adjustable AccuPro™ jets
• RapidHeat™ in-line heater
• Electronic on/off control with temperature readout
• Air ow adjustability
• Chromatherapy underwater lighting
• PrO3
™ Ozone Sanitation System standard
Riva®5 |WHIRLPOOL PLUS BATH
Detail: The Jacuzzi Magic Touch®control system makes customizing your
bath in the Riva®whirlpool bath easy. 4 massaging TheraPro™ jets
soothe sore, tired muscles.

Riva®5
WHIRLPOOL PLUS BATH
Technical Specifications
DIMENSIONS
62” L x 43” W x 19” H
(1575 mm) L x (1092 mm) W x (483 mm) H
DRAIN/OVERFLOW
A: 14-3/4” (375 mm) B: 9-1/2” (241 mm)
CUTOUT
Template Provided Part Number: P186000
TOTAL WEIGHT
779 lb (354 kg) / 44.2 lb/sq. ft. (215 kg/m2)
OPERATING GALLONAGE
49 U.S. Gal. (185 Liters)
Min. 40 U.S. Gal. (151 Liters)
Max. 58 U.S. Gal. (220 Liters)
PRODUCT WEIGHT
96 lb (44 kg)
SKIRT MOUNTING
Not Available
ELECTRICAL SPECIFICATIONS
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
HEATER (OPTIONAL)
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
© 2007 Jacuzzi Whirlpool Bath • 14880 Monte Vista Avenue • Chino, CA 91710 • www.jacuzzi.com
INSTALLATION NOTES
Refer to installation instructions included with xture before
beginning installation. Please conrm product availability and
specications before commencing with any installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
#FS39000 11/07
ES30
Riva 5 Whirlpool Bath, Left Hand
ES40
Riva 5 Whirlpool Bath, Right Hand
• Left and Right Hand Drain Location
• Accessories / Hardware:
Trim Kit: 4 HTC Jet Rings #D095
Rotary Drain Kit, 26” Cable #8730
Trim Kit: 2 BMH Jet Rings #J869
Trip-Lever Drain Kit: #X559
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
RIVA™ 6, Right Hand
72"
21"
42"
2"
14" x 4"
11-1/2"
6-7/8"
Motor
12" H x 18" L
Service Access
END VIEW
SIDE VIEW
2"
(51 mm)
(Heater)
(Motor)
RIVA® 5 PLUS, Right Hand
19"
43"
62"
DRAIN/OVERFLOW
A
B
Product Shown: Riva® 5 Plus Whirlpool Bath
Right Hand Shown Model: ES40
* Measurements inside unit represent cutout in
floor to allow for drain/overflow.
Minimum Service Access dimensions given.
