Jands SNVR-8004ST User manual

1
Network Video Recorder
SNVR-8004ST
Thanks for purchasing our product. Before operating the unit, please read the instructions
carefully and keep this manual for future reference.

2
Statement:
This manual supports NVR model: 1U 4/8ch and 2U 16/32ch.
As product update, the NVR functions might be different from the manual showing, please
follow the product that you got.
Safety Precautions
1. Do not use wet hands or any damp objects to touch the power switch and network digital
video recorder (NVR), in order to avoid electric shock.
2. After installing the host, it must be ensured that the host and the chassis have grounded to
avoid the video, audio signal being disturbed, and to avoid NVR being damaged by static
electricity.
3. The device does not include hard disk. Hard disk should be properly installed before use,
otherwise it will not perform the record and playback.
4. Host system supports format of the hard disk. If the hard disk has been used, please note
whether it is FAT32 format. The embedded network digital video recorder supports only FAT32
format, otherwise there will be a hidden danger. Note: Please format hard disk when it is the
first time for you to use.
``

3
Table of Contents
1.Hard Disk Installation.......................................................................................................................- 1 -
1.1Hard Disk Installation Steps................................................................................................- 1 -
2.Rear Panel Interface..........................................................................................................................- 1 -
3.Host Side Operation..........................................................................................................................- 2 -
3.1Start System ........................................................................................................................- 2 -
3.2System Login ......................................................................................................................- 2 -
3.3IP Channel Setting...............................................................................................................- 2 -
3.4Power off.............................................................................................................................- 3 -
4.Display Setting..................................................................................................................................- 3 -
5.Network Setting................................................................................................................................- 3 -
6.Connect with IP Camera...................................................................................................................- 4 -
6.1Manual Search.....................................................................................................................- 4 -
6.2Automatic Search................................................................................................................- 5 -
7.Preview.............................................................................................................................................- 5 -
7.1Drag and Drop the Image....................................................................................................- 5 -
7.2Drag to Change Channel Sequence.....................................................................................- 5 -
7.3Digital Zooming..................................................................................................................- 5 -
8.Manual Capture ................................................................................................................................- 6 -
9.System Setting..................................................................................................................................- 7 -
9.1Device Parameter................................................................................................................- 7 -
9.2Channel Information ...........................................................................................................- 7 -
10.Recording.....................................................................................................................................- 8 -
10.1Manual Recording & Schedule Record...............................................................................- 8 -
10.2Playback............................................................................................................................- 10 -
10.3Record Backup..................................................................................................................- 10 -
10.4File Manager.....................................................................................................................- 11 -
11.System Setting............................................................................................................................- 11 -
11.1HDD Setting......................................................................................................................- 11 -
11.2System Upgrade................................................................................................................- 12 -
11.3Import/Export Configuration ............................................................................................- 12 -
12.IE Viewing .................................................................................................................................- 13 -
12.1 User Log In.........................................................................................................................- 13 -
13.Mobile View Operation Instruction............................................................................................- 13 -
13.1Client Software Obtaining.................................................................................................- 13 -
13.2The Parameter Settings of the NVR which Supports Mobile Surveillance.......................- 13 -
13.3Android Mobile Phones System........................................................................................- 14 -
13.4Blackberry Mobile Phone System.....................................................................................- 14 -
13.5Windows Mobile System..................................................................................................- 14 -
13.6APPLE IOS System..........................................................................................................- 15 -

- 1 -
1. Hard Disk Installation
Prepare a screwdriver. Take 1U chassis as an example, this series NVR can have a hard disk
installed in the chassis, the largest capacity of which amounts to 4TB.
1.1 Hard Disk Installation Steps
1.Remove the fix screws on the side chassis 2. Connect the hard disk data wire and power
and open the top cover supply wire
3.Fix the HDD on the bottom plate 4.Put back the cover and fix it by screws
2. Rear Panel Interface
(PoL ports only exist in SNVR-8004ST-P)

- 2 -
3. Host Side Operation
3.1 Start System
Plug power cable, press power switch, the power led will be on and the NVR will start. After
booting, the video output default to multi-window output mode. If the booting time is within the
record setting time period, the system will auto enable the record function.
Note: Please use the NVR matching power supply instead of any other power supply of any other
type or brand.
3.2 System Login
After normal booting, right click to bring the menu,
select Start Login,
input the user name: admin and password blank (default to be blank) in the input box
Click 【Start】icon，
1) Power Off: click “Power off” button, the device will shutdown.
2) Reboot: click “Reboot” button, the device will reboot.
3) Login: click “Login” button , user name: admin,
password: blank
4) onLock: click “Lock” , the menu will be locked.
5) User Guide: Setup the basic settings step by step.
3.3 IP Channel Setting
After login successfully, system will pop out the host side
IP address setting menu automatically, after setting successfully click “ OK”, then it will pop out the
menu for IP channel setting, click “ Yes”, the system will save the IP automatically. If need to
manual setting IP address, click “NO”.

- 3 -
3.4 Power off
1. Click the power switch at the rear panel can shutdown the device.
2. 【Main Menu】【Power Off】，select【Yes】(By this way, user need have shutdown authority)
(Suggest to shutdown device in this way, it can avoid damaging the device from v electricity
cut-off by accident).
Note: Before changing the HDD operation, please shutdown the device and cut the power supply
first.
4. Display Setting
Click 【Display】on the menubar，
show the menu as the right side:
1) Language: select different language according to the
necessary, after that need restart the device
2) AutoLogout: system automatic logout and lock time.
3) TV Adjust: adjust the display position.
4) Display: set monitor lightness, contrast, saturation,
color
5) Resolution: the default resolution is 1024x768,
please select the best resolution according the monitor
condition, or it will affect the image definition.
There are 6 modes for option.
6) Rotation interval: Setup the time interval of rotation. Tick “Enable SEQ” to start rotation.
5. Network Setting
Connect NVR with network cable to LAN switch.
After power on, click 【Network】on the menubar
to enter setting menu, set NVR IP address, subnet
mask, and gateway and so on. Then use PC to run
ping command to check NVR IP has connected
with LAN
Note: IP address might conflict with each other, please set the gateway correctly, or NVR might
fail to work. Please ensure all the IP addresses in LAN are unique.

- 4 -
Remote port setting: the default is 5050, if there are several NVRs in the LAN, need to change
this port is for login NVR by IE, CMS. Login NVR by mobile, the port should be +3 based on the
device port.
HTTP port: the default port is 80, suggest modifying it. This port is for login NVR by IE, input NVR
IP address or domain name; need to add colon and HTTP port number.
Example: show as the above right picture, access NVR by IE in LAN, first add 2 forwarding rules
in the router, the IP address is 192.168.1.188, the forwarding ports are 5050-5053, 80. Please
input http://192.168.1.188:80 at IE browser and download ActiveX, then close the IE before install
the ActiveX, after installing it successfully, then reopen IE with http://192.168.1.188:80, it will show
login menu, input device port:5050, user name: admin, no password, can access NVR.
If access NVR by IE in WAN, please use static IP or dynamic domain name, the operation is same
as LAN.
6. Connect with IP Camera
6.1 Manual Search
Right click to select【IP channelSetting】Manual, click Search button, NVR will search out all IP
cameras in the LAN, it will take 18-30 seconds, after finishing the configuration, click Save to
logout, then the image will come out.
A –Area is cameras IP address searching area——click Search to get the camera IP addresses
in LAN.
B- Area is camera IP address modification area——double click IP camera in A area, B area will
show camera network data, some cameras can change IP address directly in B area.

- 5 -
C- Area is cameras channel setting area——according to the selection sequence in A zone, to
sort the 1-36 channels image order. Select All to add IP cameras to the all channel by one click.
D-Area is camera user name and password filling area——this area is camera network parameter
6.2 Automatic Search
Right click to select 【IP channel Setting】Auto
If the IP camera has private protocol with AEVISION NVR, NVR will assign IP address to the
camera automatically, after finish the searching, will connect the image automatically.
Camera IP addresses will be added automatically in the preview channel area.
7. Preview
7.1 Drag and Drop the Image
The preview image location can be drag and drop to different place as necessary, but the channel
physical address will keep the same
7.2 Drag to Change Channel Sequence
Right click to select 【IP Channel Setting】【Drag to change channel sequence】, then drag the
image, IP camera will reconnect in the new channel, during this process, the image will lost for
some while till the image connect sucessfully.

- 6 -
7.3 Digital Zooming
During image preview and playback, roll mouse
roller to do digital zooming, it zoom the image as
mouse pointer as the center. The max can do 15X
zooming. Drag the zoomed image by mouse to see
image detail.
The channel is recording. Light flashing means frame lost or recording lost.
Magnifying glass: digital zooming, the red number in the middle is magnification figures, click
this icon, it can change to PTZ control
8. Manual Capture
Right click to bring main menu, click【Capture】, it supports all channels manual capturing. After
capture, there is information to hint capturing is successful or
failure or this channel does not support capture. The image of
capture resolution is D1 by JPG format, and it is saved in
special area, the recording file will not replace it .
Capture image can be viewed or backup in file manage folder.
Right click to bring main menu, click【File Manager】and click Refresh button, the captured file
shows in the file list area, the file are named by channel number&capture time, double click it to
check.
Capture back up: plug flash disk by USB port, click Refresh to check whether flash disk connect
well, then select the capture files that need back up, and click Back Up to begin it.
Zoom In Zoom Out

- 7 -
9. System Setting
9.1 Device Parameter
Click【Setting】DeviceDevice info to check device spec, information and time setting
Attention: select mode according the connected IP camera channels and resolution, after
change the model, click save and reboot the device.
When the image is good in 9/16/25/26 screen modes, after double click the image to zoom, the
image is stuck or become black screen change to 1080 mode can solve it.
Systerm version: check the system version and time, when do software update, need to check
version first to avoid updating failure and damage the device.
9.2 Channel Information
Click【Setting】ChannelVideo Parameters, to adjust IP camera preview and recording
resolution.
