JanSan T1715 User manual

T1715&T2015FloorMachines
Operator’sManual
Shownw/oponalShampooTank&PadDriver
Merrillville,IN46411
PoBox14065
866‐350‐7160
www.JanSanMFG.com
Distributed By:
Doc#98‐20011
Rev.04/2011

Delivery&Unpacking
Yourfloormachinewasprotecvelypackedtopreventdamageinshipment.Wesuggestthatuponremovingtheunitfromitscar‐
ton,carefullyinspectitforanypossibledamageintransit.Ifdamageisdiscovered,immediatelynofythetransportaoncompany
whodeliveredyourmachine.Weareunabletoactuponanyclaimforconcealeddamage;youmustoriginatetheclaim.
LimitedWarranty
1YearLimitedWarrantyonParts,3YearLimitedPartsWarrantyonMotor&Transmission
Thisfloormachineiswarrantedforone(1)yeartobefreefrommanufacturingdefectsduetoimperfeconsinworkmanshipand
materials.TheManufacturerwillexchangepartsforyourfloormachineintheeventofamanufacturingdefectasfollows:
PARTS:Neworcomparablerebuiltparts,foroneyearaeroriginalpurchaseandthreeyearsonmotorandtransmission.
Normalwearitemshaveawarrantyof90days.Normalwearitemsinclude:carbonbrushes,bearings,hoses,filters,gaskets,quick
connects,switches,solenoids,electricalpowercords,o‐rings,crossfingrubbergaskets,wheels,casters,oranypartdeemedasa
wearitembytheoriginalmanufacturer.
Contactanauthorizedservicecenterforwarrantyitemexchanges/repairs.Customerresponsibleforallshippingcosts.
IMPORTANTWARRANTYCONDITIONS:Apurchasereceiptorotherproofofdateoforiginalconsumerpurchasealsowillbere‐
quiredbeforewarrantyserviceisrendered.
Thiswarrantycoversnormaluseanddoesnotcoverdamagewhichoccursinshipmentorfailureresulngfromalteraon,acci‐
dent,misuse,abuse,neglect,orimpropermaintenance.
STATEMENT:Thiswarrantyisnottransferableandextendsonlytotheoriginalpurchaserwhenanewfloormachineispurchased
fromanAuthorizedDealer.Thiswarrantygivesyouspecificlegalrights,andyoumayhaveotherrightsthatvaryfromstateto
state.
SafetyInstrucons
ThismachineisdesignedtobesafewhenusedtoperformthefunconsspecifiedinthisOperator’sManual.Shoulddamageoccur
toelectricalormechanicalparts,Priortofurtheruse,themachineshouldberepairedbythemanufacturerorcompetentservice
centertoavoidfurtherdamagetothemachineorphysicalinjurytouser.Yourfloormachineisequippedwithasafetyswitchlock‐
outdevicedesignedforyoursafety.Donotaempttobypassordefeatthesafetylockoutdevice.Neveruseanydevicetolockthe
powerswitchtriggersintheONposion.
Thisfloormachineshouldbegroundedwhileinusetoprotecttheoperatorfromelectricshock.Thismachineisequippedwitha3‐
conductorcordanda3‐pronggroundedtypeaachmentcapplugtofitthepropergroundingtypereceptacle.Thegreen(orgreen
andyellow)conductorinthecordisthegroundingwire.Neverconnectthiswiretoanythingotherthanthegroundingblade.The
floormachineisprovidedwithanaachmentcapplugandisintendedforuseonanominal120voltcircuit.Ifaproperlygrounded
receptacleisunavailableagroundingadaptershouldbeinstalled,iftheoutletboxthathousesthereceptacleisgrounded.Besure
tofastenthegroundingtaptothefaceplatescrew.

WARNINGS
ReadAllInstruconsBeforeUsingThisAppliance
Whenusinganelectricalappliance,basicprecauonsshouldalwaysbefollowed.
WARNING‐Toreducetheriskoffire,electricshockorinjury:
 Donotleaveappliancewhenpluggedin.Unplugfromoutletwhennotinuseandbeforeservicing.
 WARNING:ELECTRICSHOCKCOULDOCCURIFUSEDOUTDOORSORONWETSURFACES.
 Donotallowtobeusedasatoy.Closeaenonisnecessarywhenusedbyornearchildren.
 Useonlyasdescribedinthismanual.Useonlymanufacturer'srecommendedparts.
 Donotusewithdamagedcordorplug.Ifapplianceisnotworkingasitshould,hasbeendropped,damaged,leoutdoors,or
droppedintowater,followwarrantyinstruconsandcontactanapprovedservicecenter.
 Donotpullorcarrybycord,usecordasahandle,closeadooroncord,orpullcordaroundsharpedgesorcorners.Donotrun
applianceovercord.Keepcordawayfromheatedsurfaces.
 Donotunplugbypullingoncord.Tounplug,grasptheplug,notthecord.
 Donothandleplugorappliancewithwethands.
 Donotputanyobjectintoopenings.Donotusewithanyopeningblocked;keepfreeofdust,lint,hairandanythingthatmay
reduceairflow.
 Keephair,looseclothing,fingersandallpartsofbodyawayfromopeningsandmovingparts.
 Donotpickupanythingthatisburningorsmoking,suchascigarees,matchesorhotashes.
 Turnoffallcontrolsbeforeunplugging.
 Donotuseapplianceonstairs.
 Alwayswearsafetyequipmentandappropriateclothingwhenoperangextractortoprotectfromhotwater.
 Donotusetopickupflammableorcombusbleliquidssuchasgasolineoruseinareaswheretheymaybepresent.
 Connecttoaproperlygroundedoutletonly.
 Donotaempttoservicetheunitwhileapplianceispluggedin.
FloorMachineApplicaons
Your1.5hpmachineisextremelyversale.Thisfloormachinecanbeusedtopolish,buff,scrub,strip,shampoo,sand,andgrind
surfaces.Usetheproperdriversorbrushesforthespecificjob.Aachmentslikeshampootanks,paddrivers,brushes,etccanbe
foundfromyourlocaldistributor.
PreparingtheMachine
Toaachthedriveblockorbrushorotheraachment,besurethehandleis“locked”intheuprightposion.
Laythefloormachineonitsbackwiththehandlelyingonthefloor,thisexposesthedrivingplateontheun‐
dersideofthefloormachine.Holdingthedriveblock,brushoraachmentinbothhandsandstraddlingthe
motorwithyourbacktothehandlebox,bendoverandfitthethreeslotsoftheclutchplate(buildintothe
backofthebrush)overthethreelugsofthedrivingplate.Turnthedriveblock,brushoraachmentcounter‐
clockwiseasfarasitwillgounlitisseatedintheready‐to‐useposion.CAUTION:Thisistheonlyproper
waytoinstalladriveblock,brushoraachment.NEVERputadriveblock,brushoraachmentonthemachinebyplacingitonthe
floorandmovingtherunningmachineoverit,orbyplacingthemachineovertheblockoraachmentandthenstarngthemo‐
tor.Returnthefloormachinetouprightposionandadjusthandletooperangposion.Recommendedhandleposionisclose
tothewaistwitharmsextendeddown.Lockthecamreleaseleverintoposion.

OperangtheMachine
Firstinstallthepaddriverandpad,brushorotheraachmentstobeused.Plugthemachineinasdirectedandlowerthehandletothedesired
operangheightandlockinplaceusingthecamleverhandle.Pushthesafetyswitchforwardandsqueezetheswitchtriggersbeneaththehan‐
dlegrips.Thisacvatesthemotorandstartstheblock,brushoraachmentinoperaon.Eachmeyoureleasethetriggersthesafetyswitch
willreset.Youwillneedtofollowthedireconabovetorestartthemachine.CAUTION:Whenleavingthemachineunaended,disconnectthe
wallplugandreturnthehandletothe“locked”uprightposiontopreventaccidentalstarng.
ToRight:raisehandleslightly.Thehigherthehandleislied,thefasterthemachinewillmovetotheright.ToLe:tochangedirecon,lowerthe
handleunlthemachinetravelstothele.Themorethehandleislowered,thefasterthemovementtothele.
TransporngtheMachine
Placethehandleintheuprightposion.Lockthehandlecamreleaselever.Tipthemachinebackandtransportonthewheels.
Maintenance
Onceamonthremovethemotorcoverandvacuumoutanydustordebriswhichhasaccumulatedonthemotor.Replacethemotorcoverby
sengitovertheholesinthehousingandreplaceallofthescrews.Checkandmaintaintheghtnessofallthefasteners.
WARNING:Donotover‐ghtentheswitchhousingscrews.Keepthemachinecleanespeciallyatthehandletubeandcollarsothehandletube
willmovefreelythroughthecollar.Inspectthecordforcuts,gashes,orlooseprongs;replaceasneeded.Disassemblyofthismotorvoidsthe
warranty.Improperdisassemblyandassemblyofthismotorcanpermanentlydamagethefieldorrotor.
Troubleshoong
MachineDoesNotRun:Thecircuitbreakerhastripped.Allowthecircuitbreaker2minutestocoolbeforereseng.Plugisbrokenorhasloose
contact.Replace.
Preventcircuitoverload:Checkthepadandchangeitifitisroughordirty.Spraybuffingorspraycleaningisnotasubstuteforscrubbingor
moppingafloor.Preparethefloorsurfacebeforespraybuffing.Eliminateanyextensioncordthatissmallerthan12/3wireorgreaterthan25
feetinlength.Unpluganythingotherthanthemachinefromthecircuitorlocateanothercircuit.
Machinewillnotstart:Circuitbreakerisnotreset.Resetbreaker.Plugisbrokenorhasaloosecontact.Replace.Circuitbreakerisdefecveor
weak.Replace.
Machinewillnotreachoperangspeed:Unpluganythingelseotherthanthemachinefromthecircuitorlocateanothercircuit.
Motorrunsbutpadorbrushdoesnotturn:Couplingisbroken.Replace.Couplingisnotcoveredunderwarranty.Donotaempttoplacearun‐

Schemac
Ref#Part#Description
1‐a50‐40001 Handle,FloorMachine
1‐b50‐40002 HandleAssembly,FloorMachine
250‐40003 HandleGrip1inDia.
350‐10002 Thumbswitchactuator
450‐40004 LabelLogo(IndicateModel#)
550‐40005 Insulationsheet2.5x2x.0.015
650‐10003 Switch25ampspmonmentaryw/nuts
750‐40006 Cordhook,plated
850‐10004 Circuitbreaker,17amp
950‐50006 10‐32x3/4fmhsss
10 N/A
11 50‐40007 MotorCover
12 50‐40008 Spacerformotorcover,metalfloormachines
13 50‐50007 Screw1/4‐20x3/4flatphillips
14 50‐50008 Washer,Countersunk,axle
15 50‐40009 Wheel,black5inx1‐1/4in
16 50‐50009 Washer,spring,1inODx1/2inID
17 50‐10001 Motor,1.5hp120v60hz,floormachine
Ref#Part#Description
18 50‐40010 Label,frontfloormachine(IndicateModel#)
19 50‐40011 Motorbase,metal
20‐a50‐40012 Brushcover17inmetalw/bumper
20‐b50‐40013 Brushcover20inmetalw/bumper
21 50‐50010 Washer1/4medsplitlockzinc
22 50‐50011 Washer5/16saeflatzinc
23 50‐50012 Washer3/8saeflatzinc
24 50‐50013 Screw1/4‐20x1‐3/4hexcap
25 50‐50014 Pivotpinmetalfloormachine
26 50‐50015 Axle,wheel
27 50‐50016 Spacer,handle,metalfloormachine
28 50‐40014 Handlebrace,leftw/slot
29 50‐40015 Handlebrace,rightw/hole
30 50‐10005 Cord14/3SJTW51.25black(inhandle)
31 50‐50017 Knob,plastic,handleclamp
32 50‐50018 Clamp,collar,handle
33 50‐50019 Camleverassembly(includes50‐50017&washers)
