Janus FM-200 Sv Series Installation and operating instructions

FM-200® Operation, Design,
& Service Manual
Sv Series, Mv Series, Lv Series
Issued February 1, 2009
DOC102 REV F
40YE

BLANK

Page: iii
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
BLANK
Contents
1 GENERAL INFORMATION 1
1.1 Listings and Approvals 2
1.2 Extinguishing Agent 2
1.3 Safety Considerations 2
2 SYSTEM DESCRIPTION AND COMPONENTS 5
2.1 Cylinder Assembly 6
2.1.1 Cylinder 6
2.1.1.1 Rupture Disc 6
2.1.1.2 Liquid Level Indicator 7
2.1.2 Dip Tube 7
2.1.3 Cylinder Valve 7
2.1.3.1 Sv Series Valve Features 8
2.1.3.2 Mv Series Valve Features 10
2.1.3.3 Lv Series Valve Features 12
2.2 Trim Components 14
2.2.1 Pressure Gauge 14
2.2.1.1 Sv Series Pressure Gauge 14
2.2.1.2 Mv and Lv Series Pressure Gauge Assembly 14
2.2.2 Low-Pressure Supervisory Switch 15
2.2.2.1 Sv Series Low-Pressure Supervisory Switch 15
2.2.2.2 Mv and Lv Series Low-Pressure Supervisory Switch Assembly 15
2.2.2.3 Low-Pressure Supervisory Switch Conduit Adapter 16
2.2.3 Electric Valve Actuator 16
2.2.3.1 Electric Valve Actuator w/ Limit Switch 17
2.2.4 Manual Valve Actuator 17
2.2.5 Discharge Connection Fittings 18
2.2.5.1 Sv Series Fittings 18
2.2.5.2 Mv Series Fittings 18
2.2.5.3 Lv Series Fittings 19
2.3 Slave Arrangement Components 19
2.3.1 Pneumatic Valve Actuator 19
2.3.2 Vent Check 20
2.3.3 Pilot Actuation Check Valve 20
2.3.4 NPT Style PilotActuation Check Valve 20
2.3.5 Pilot Actuation Adapter 20
2.3.6 Pilot Actuation Mid Line Tee 21
2.3.7 Male NPTAdapter 21
2.3.8 Pilot Actuation End Line Tee 21
2.3.9 Flex Hose 21
2.4 Supplemental Components 22
2.4.1 Manifold Check Valve 22
2.4.2 Discharge Pressure Switch 23
2.4.3 Discharge Manifold 24
2.4.4 Pressure Release Trip 28
2.4.5 Discharge Indicator 28
2.5 Selector Valve Components 29
2.5.1 Selector Valves 31
2.5.1.1 Valve Solenoid 32
2.5.1.2 Manual Lockout 33
2.5.1.3 Position Indicator Switch 33

Page: iv
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
2.5.2 Lockout Valves 33
2.5.2.1 Limit Switch 35
2.5.3 Pilot Line Regulator 35
2.5.4 Discharge Relief Valve 35
2.6 Discharge Nozzles 36
3 SYSTEM DESIGN 37
3.1 Hazard Analysis 37
3.1.1 Fuel Source 37
3.1.2 Hazard Dimensions 38
3.1.3 Hazard Integrity 38
3.1.4 Hazard Altitude 39
3.2 Agent Requirement 39
3.3 Number of Cylinders 40
3.4 Cylinder Location 41
3.5 Nozzle Determination 42
3.6 Pipe Determination 43
3.6.1 Elevation Changes 44
3.7 Peripheral Equipment and Accessories 45
3.7.1 Control Panel 45
3.7.2 Early Warning Detection 45
3.7.3 Accessories 45
3.8 Sample Equipment Order List 46
4 SYSTEM INSTALLATION 49
4.1 Mechanical Installation 50
4.1.1 Installing Cylinder Bracket Channels 50
4.1.2 Installing Discharge Piping 54
4.1.2.1 Threaded Pipe 54
4.1.2.2 Threaded Fittings 54
4.1.2.3 Grooved Fittings and Couplings 55
4.1.2.4 Pipe Reductions 55
4.1.2.5 Pipe Supports and Hangers 55
4.1.3 Installing Nozzles 56
4.1.4 Installing Cylinder Assembly 56
4.1.4.1 Installing Pressure Gauge Assembly (Mv and Lv Series only) 56
4.1.4.2 Installing Low-Pressure Supervisory Switch Assembly (Mv and Lv Series only) 56
4.1.5 Installing Discharge Pressure Switch 57
4.1.6 Installing Pilot Actuation Line 57
4.1.6.1 Installation Using Flex Hose 58
4.1.6.2 Installation Using Copper Tubing 58
4.1.6.3 Installation Using Schedule 40 Pipe 58
4.1.6.4 Two-Sided Pilot Actuation Lines 59
4.2 Electrical Installation 62
5 COMMISSIONING SYSTEM 63
5.1 System Review 63
5.2 Discharge Piping Pressure Test 64
5.3 Installing Pneumatic Valve Actuator 65
5.4 Installing Electric Valve Actuator 65
5.5 Installing Manual Valve Actuator 66
5.6 Warning Signs 66
5.7 Additional Considerations 66
5.8 Enclosure Venting Considerations 66

Page: v
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
5.9 Manual 68
5.10 Label 68
5.11 Transportation Information 69
6 SYSTEM INSPECTION AND MAINTENANCE 71
6.1 Monthly Inspection 71
6.2 Maintenance 72
6.2.1 Semi-Annual Maintenance 73
6.2.1.1 Pressure Check 73
6.2.1.2 Liquid Level Indicator 73
6.2.1.3 Cylinder Weighing 73
6.2.2 Annual Maintenance 74
6.2.3 Five Year Maintenance 75
7 SYSTEM RECHARGE AND RESET 77
7.1 Piping and Nozzles 77
7.2 Recharging 77
7.2.1 Removing The Cylinder 77
7.2.2 Cleaning and Servicing The Valve Assembly 78
7.2.3 Recharge Procedure 79
APPENDIX A - Material Safety Datasheet 81
APPENDIX B - Assorted Charts & Worksheets 91
APPENDIX C - Master and Selector Valve Ordering Information 111
APPENDIX D - Lockout Valve Ordering Information 113
APPENDIX E - Alternate Nozzle Spacing Options 115

Page: vi
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Diagram Index
Figure 2 Typical Clean Agent System Layout 5
Figure 2.1.3.1a Sv Cylinder Valve Assembly 8
Figure 2.1.3.1b Sv Cylinder Valve w/ Trim Kit 9
Figure 2.1.3.2a Mv Cylinder Valve Assembly 10
Figure 2.1.3.2b Mv Cylinder Valve w/ Trim Kit 11
Figure 2.1.3.3a Lv Cylinder Valve Assembly 12
Figure 2.1.3.3b Lv Cylinder Valve w/ Trim Kit 13
Figure 2.2.1.1 Sv Series Pressure Gauge 14
Figure 2.2.1.2 Mv and Lv Series Pressure Gauge Assembly 14
Figure 2.2.2.1 Sv Series Low-Pressure Supervisory Switch 15
Figure 2.2.2.2 Mv and Lv Series Low-Pressure Supervisory Switch Assembly 15
Figure 2.2.2.3a Low-Pressure Supervisory Switch Conduit Adapter 16
Figure 2.2.2.3b Low-Pressure Supervisory Switch w/ Conduit Adapter (Sv Series Shown) 16
Figure 2.2.3 Electric Valve Actuator 16
Figure 2.2.3.1a Electrical Valve Actuator w/ Limit Switch 17
Figure 2.2.3.1b Electrical Valve Actuator w/ Limit Switch Wiring Diagram 17
Figure 2.2.4 Manual Valve Actuator 17
Figure 2.2.5.1 Sv Series Fittings 18
Figure 2.2.5.2 Mv Series Fittings 18
Figure 2.2.5.3 Lv Series Fittings 19
Figure 2.3.1 Pneumatic Valve Actuator 19
Figure 2.3.2 Vent Check 20
Figure 2.3.3 Pilot Actuation Check Valve 20
Figure 2.3.4 NPT Style PilotActuation Check Valve 20
Figure 2.3.5 Pilot Actuation Adapter 20
Figure 2.3.6 Pilot Actuation Mid Line Tee 21
Figure 2.3.7 Male NPTAdapter 21
Figure 2.3.8 Pilot Actuation End Line Tee 21
Figure 2.3.9 Flex Hose 21
Figure 2.4.1a Lv Manifold Check Valve 22
Figure 2.4.1b Mv Manifold Check Valve 22
Figure 2.4.1c Sv Manifold Check Valve 22
Figure 2.4.2 Discharge Pressure Switch 23
Figure 2.4.3a Suggested Manifold Congurations for 40, 80, and 130 lb Cylinders 24
Figure 2.4.3b Suggested Manifold Congurations for 250 and 420 lb Cylinders 25
Figure 2.4.3c Suggested Manifold Congurations for 600 and 900 lb Cylinders 26
Figure 2.4.3d Suggested Manifold Congurations for 900 lb Cylinders 26
Figure 2.4.3e Suggested Manifold Congurations for 1000 lb Cylinders 27
Figure 2.4.4 Pressure Release Trip 28
Figure 2.4.5 Discharge Indicator 28
Figure 2.5a Selector Valve Arrangement - TYPE A 29
Figure 2.5b Selector Valve Arrangement - TYPE B 30
Figure 2.5.1b Pneumatically Actuated Ball Valve Dimensions 31
Figure 2.5.1a Selector Valve 31
Figure 2.5.1c Series 830 Pneumatically Actuated Wafer Valve 32
Figure 2.5.1.1 Valve Solenoid 32
Figure 2.5.1.2 Manual Lockout 33

Page: vii
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Figure 2.5.1.3.Position Indicator Switch 33
Figure 2.5.2a Lockout Valve 33
Figure 2.5.2b Manually Actuated Ball Valve Dimensions 34
Figure 2.5.2c Series 830 Manually Actuated Wafer Valve 34
Figure 2.5.2.1 Limit Switch 35
Figure 2.5.3 Pilot Line Regulator 35
Figure 2.5.4 Discharge Relief Valve 35
Figure 2.6 Discharge Nozzle Congurations 36
Figure 3.5a 90° Corner Nozzle Maximum Coverage Area 42
Figure 3.5b 180° Sidewall Nozzle Maximum Coverage Area 42
Figure 3.5c 360° Radial Nozzle Maximum Coverage Area 42
Figure 4.1.1a Sv Cylinder Bracket & Dimensions 51
Figure 4.1.1b Mv Cylinder Bracket & Dimensions 52
Figure 4.1.1c Lv Cylinder Bracket & Dimensions 53
Figure 4.1.6.1a Pilot Actuation Line Conguration for Sv Series Cylinders 59
Figure 4.1.6.1b Pilot Actuation Line Conguration for Mv Series Cylinders 60
Figure 4.1.6.1c Pilot Actuation Line Conguration for Lv Series Cylinders 60
Figure 4.1.6.2 Alternate Pilot Actuation Line Conguration – Utilizing Copper Tubing 61
Figure 4.1.6.3 Alternate Pilot Actuation Line Conguration – Utilizing Schedule 40 Pipe 61
Figure 4.1.6.4 Alternate Pilot Actuation Line Conguration – Two-Sided Pilot Actuation Line 62
Figure 5.6a Clean Agent Warning Sign - Exit (P/N 18489) 67
Figure 5.6b Clean Agent Warning Sign - Entrance (P/N 18770) 67
Figure 5.10 FM-200® Cylinder Label 68

Page: viii
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Table Index
Table 1 - System Performance Specications 1
Table 1.3 - Time for Safe Human Exposure at Stated Concentrations for FM-200® (HFC-221ea) 2
Table 2.1.1 Cylinder Capacities 6
Table 2.3.9 Flex Hose Lengths 21
Table 2.5.1a - Pneumatically Actuated Ball Valve Dimensions 31
Table 2.5.1b - Pneumatically Actuated Wafer Valve Dimensions 32
Table 2.5.1.1 - Valve Solenoids 32
Table 2.5.1.2 - Manual Lockout w/ Proximity Switch 33
Table 2.5.2a - Manually Actuated Ball Valve Dimensions 34
Table 2.5.2b - Manually Actuated Wafer Valve Dimensions 35
Table 2.6 - Discharge Nozzle Sizes 36
Table 3.1.4 - Altitude Correction Chart 39
Table 3.6 - Pipe Size vs. Flow Rate 43
Table 4.1.1a Sv Cylinder Dimensions 51
Table 4.1.1b Mv Cylinder Dimensions 52
Table 4.1.1c Lv Cylinder Dimensions 53
Table 4.1.2 Acceptable Pipe Grades 54
Table 7.2.2 Valve Replacement Components 79
Table 3.2a FM-200® (HFC-227ea) Total Flooding Quantity (U.S. Standard) 94
Table 3.2b FM-200® (HFC-227ea) Total Flooding Quantity (Metric) 95
Table 3.1.1a FM-200® (HFC-227ea) Cup Burner Extinguishing Concentrations 96
Table 3.1.1b FM-200® Inerting Concentrations 98
Table 6.2.1.1 - Approximate Container Pressure vs. Temperature 98
Table B.1a U.S. Standard to Metric Conversion Factors 99
Table B.2a Metric to U.S. Standard Conversion Factors 99
Table 6.1.1a Liquid Level Chart – 250 lb Cylinder (U.S. Standard) 100
Table 6.1.1b Liquid Level Chart – 250 lb Cylinder (Metric) 101
Table 6.1.1c Liquid Level Chart – 420 lb Cylinder (U.S. Standard) 102
Table 6.1.1d Liquid Level Chart – 420 lb Cylinder (Metric) 103
Table 6.1.1e Liquid Level Chart – 600 lb Cylinder (U.S. Standard) 104
Table 6.1.1f Liquid Level Chart – 600 lb Cylinder (Metric) 105
Table 6.1.1g Liquid Level Chart – 900 lb Cylinder (U.S. Standard) 106
Table 6.1.1h Liquid Level Chart – 900 lb Cylinder (Metric) 107
Table 6.1.1i Liquid Level Chart – 1000 lb Cylinder (U.S. Standard) 108
Table 6.1.1j Liquid Level Chart – 1000 lb Cylinder (Metric) 109
Table C.1 - Master and Selector Valve Ordering Information 112
Table D.1 - Lockout Valve Ordering Information 114
Table 3.5a - Alternate Nozzle Spacing for 90° Corner Nozzles 116
Table 3.5b - Alternate Nozzle Spacing for 180° Sidewall Nozzles 117

Page: ix
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Revision Description of Change Date
--- Initial Printing 2/1/2009
A Table 4.1.1a, 4.1.1b, 4.1.1c dimensions adjusted 3/23/2009
B Table 4.1.1a dimensions adjusted. Table 2.1.1 capacities adjusted. Figures 2.1.3.2b,
2.2.5.2, and Section 3.8 P/N 18553 changed to 18474. Section 3.8 P/N 17513
changed to FM200. Liquid Level Charts added to Tables 6.1.1a, 6.1.1b, 6.1.1c,
6.1.1d, 6.1.1e, 6.1.1f, 6.1.1g, 6.1.1h, 6.1.1i, and 6.1.1j. Note indicating "Liquid
Level Charts will be added at a later date" removed from Section 6.1.1. Appendix
A Material Safety Datasheet replaced with latest Revision correcting Transportation
Information. Figures 4.1.1a, 4.1.1b, 4.1.1c part numbers added for bracket assembly
components. Stainless steel nozzles added to Table 2.5 and Section 2.5. Section 1.1
listings and approvals updated.
1/5/2010
CListing and Approval requirements claried in Section 3.7.1 and 3.7.2. Figure 5.10
changed to revised label image. Reference to discharge hose removed from Section
6.2.2, 6.2.3, and 7.2.1 Section 7.2 divided into Sections 7.2.1, 7.2.2, and 7.2.3. Table
7.2.2ValveReplacementComponents added.Sentencestating "Thepressuregauge
on the cylinder shall not be used to determine when the proper charge pressure
has been reached. A pressure regulator must be used when the pressure source
is a tank of high pressure gas." added to Section 7.2.3. Warning against removing
Sv low-pressure supervisory switch or pressure gauge during recharge process
added to Section 7.2.1. Step advising removal of pressure gauge and low-pressure
supervisory switch in Section 7.2.1 claried to be Mv and Lv assemblies. Step added
to Section 7.2.2 to reinstall pressure gauge and low-pressure supervisory switch
assemblies to Mv and Lv cylinder valves. Warning to ensure cylinder is empty moved
to beginning of Section 7.2.1. Table Index and Contents revised to reect new table
and sections. Section 2.4.2 "See Figure 2.4.3" corrected to "See Figure 2.4.2" and
part number corrected. Line added to caution in Section 3.6 regarding failure to follow
veried pipe limitations. "Janus Fire System Design Suite" in Section 3.6 corrected
to "Janus Design Suite". Reference to Manual DOC106 added to Preface. Section
3.8 part number "FM200" corrected to "FM200AGENT". Note added to Section 6.1.1
that when using the liquid level charts in Appendix B, user must still not exceed the
limitations listed in Table 2.1.1.
3/15/2010
DSection 1.3 paragraph beginning "A cylinder containing FM-200® must be handled
carefully" made into Caution. Footnote added to Section 2.1.1. Section 2.1.3.1 item
2 phrase "cannot be removed" altered to "shall not be removed". Section 2.1.3.1
item 4 phrase "cannot be removed" altered to "shall not be removed". Sentence
beginning "The pipe plug shall remain in place" added to Section 2.1.3.1 item 6. Sen-
tence beginning "The rupture disc shall not be removed" added to Section 2.1.3.2
item 4. Sentence beginning "The pipe plug shall remain in place" added to Section
2.1.3.2 item 6. Sentence beginning "The pipe plug shall remain in place" added to
Section 2.1.3.3 item 5. Section 2.2.1.1 and Section 2.2.2.1 warning phrase "can-
not be removed" changed to "shall not be removed". Sentence beginning "Note:
The manual valve actuator cannot be attached" added to Section 2.2.4. Sentence
"Elbow outlets may be oriented in any direction" added to Section 2.2.5.1, Section
2.2.5.2, and Section 2.2.5.3. Section 2.3.4 and Figure 2.3.4 NPT Style Pilot Actua-
tion Check Valve added and all applicable section following renumbered. Sentence
beginning "Note: Flex hose must be hydrostatically tested" added to Section 2.3.9.
Sentence beginning "Actual manifold size and dimensions" added to Section 2.4.3.
(CONTINUED NEXT PAGE)
10/13/2010
Revision History

Page: x
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
D (CONTINUED FROM PREVIOUS PAGE) 10/13/2010
Section 3.1.1 sentence "The minimum design concentration for a Class C re shall
be at least that for a Class A surface re" altered to "The minimum design concentra-
tion for a Class C re shall be at least that for a Class A surface re in accordance
with NFPA 2001". On Table 3.6 60% Flow Rate for 1-1/2" pipe corrected to 5.24
lbs/sec and 2.38 kg/sec. In Section 4 warning phrase "to protect against accidental
discharge" altered to "to protect against violent cylinder movement during accidental
discharge". Section 4.1.2 phrase "in accordance with drawings and calculation cre-
ated using the Janus Design Suite" altered to "in accordance with drawings and in
accordance with calculations performed using the Janus Design Suite". Sentence
beginning "The switch should be located so that" added to Section 4.1.5. Section
4.1.6 paragraph beginning "On a multiple cylinder system, the primary and slave
cylinder must be interconnected with pilot actuation hose and ttings" replaced with
paragraph beginning "On a multiple cylinder system, the primary and slave cylinders
must be interconnected with the pilot actuation line". Section 4.1.6 paragraph begin-
ning "The pilot actuation line begins at the pilot actuation port" removed. Sentence
beginning "The vent check contains a ball seat that seal the vent check" added to
Section 4.1.6. Section 4.1.6.1, Section 4.1.6.2, Section 4.1.6.3, and Section 4.1.6.4
added. Figure 4.1.6a renumbered as Figure 4.1.6.1a. Figure 4.1.6b renumbered as
Figure 4.1.6.1b. Figure 4.1.6c renumbered as Figure 4.1.6.1c. Figure 4.1.6.2, Figure
4.1.6.3, and Figure 4.1.6.4 added. Sentence beginning "Room dimensions identied
in the course of this test" added to Section 5.1. Section 5.1 phrase "Check that nozzle
location, size, and drill diameters of orice match" altered to "Check that nozzle loca-
tion, size, style, and drill diameters of orice match". Section 5.8 phrase "i.e., too little
vent area" altered to "i.e., too little vent area or equivalent leakage area (EQL)". Sec-
tion 6.1 phrase "Consult the appropriate technical manual for instructions" altered
to "Consult NFPA 72 and the appropriate technical manual for instructions". Section
6.1.1 Liquid Level Indicator renumbered as Section 6.2.1.2 and all applicable sec-
tions following renumbered accordingly. Section 6.2 phrase "Consult the appropriate
technicalmanual for those products" altered to"Consult NFPA72 and the appropriate
technical manual for those products". Warning beginning "Check the pressure gauge
and cylinder weight to verify the cylinder is empty" moved from Section 7.2.1 to 7.2.2.
Method for cleaning and servicing the valve assembly as described in Section 7.2.2
revised and Table 7.2.2 altered to reect this revision. Section 2.5 Discharge Nozzles
changed to Section 2.6. Section 2.4.4 through Section 2.5.4 added.
EFigure 2.5 revised. Section 7.2.1 phrase "from the cylinder valve" added to end of
sentence beginning "For Mv and Lv Series cylinders, remove the low-pressure su-
pervisory switch and...". Caution added to Section 2.2.2.2. Sentence beginning with
"The electric valve actuator is shipped with a plastic threaded cap..." added to Sec-
tion 2.2.3. Paragraph beginning "Dirt traps and blow-outs" added to Section 4.1.3.
Statement "Refer to Table 2.3.9 for P/N" added to Section 2.3.9. 5 inch pipe removed
from Table 3.6. Section 2.2.2.3, Figure 2.2.2.3a and Figure 2.2.2.3b added. Section
2.2.3.1, Figure 2.2.3.1a, and Figure 2.2.3.1b added. Phrase "GradeA-53 F" changed
to "Grade A-53 F - 3/8" (10 mm) to 4" (100 mm) Pipe Sizes" in Table 4.1.2. Phrase
"Grade A-106 C" removed from Table 4.1.2. Phrase "Grade A-106 A or B" changed
to Grade A-106 A or B or C" in Table 4.1.2. Size 5" pipe removed from Table 3.6.
Appendix E added. Paragraph in Section 3.5 beginning "The 90° corner nozzle can
cover an area that is up to..." replaced with paragraph beginning "The 90° corner
nozzle can cover a maximum area...".
4/7/2011
Revision History

Page: xi
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
E (CONTINUED FROM PREVIOUS PAGE)
Paragraph in Section 3.5 beginning "The 180° corner nozzle can cover an area that
is up to..." replaced with paragraph beginning "The 180° corner nozzle can cover a
maximum area...". Paragraph in Section 3.5 beginning "The 360° corner nozzle can
cover an area that is up to..." replaced with paragraph beginning "The 360° corner
nozzle can cover a maximum area...". Figure 3.5a, 3.5b, and 3.5c revised. Sentence
"The maximum coverage of a single nozzle is 64 ft x 64 ft (19.5 m x 19.5 m)" re-
moved from Section 3.5 rst paragraph.
4/7/2011
FMaterial Safety Datasheet located in Appendix A replaced with latest revision. UL
Listed/FMApproved symbols added to cover and page footers. Part number "17222"
corrected to "18595" in Table 4.1.1a. Figure 5.10 updated with latest label revision.
Sentence "The Sv Series switch has 18 inch (457 mm) leads" added to Section
2.2.2.1. Lead length corrected from 36 inch to 18 inch in Figure 2.2.2.1. Sentence
"The Mv and Lv Series switch has 36 inch (914 mm) leads" added to Section 2.2.2.2.
CE Cylinder Part Numbers added to Table 2.1.1. Warning in Section 2.2.1.1 begin-
ning "The Sv Series pressure gauge is mounted to the cylinder valve" changed to
warning beginning "The Sv Series pressure gauge is mounted directly to the cylin-
der valve". Cautions beginning "The Mv and Lv Series pressure gauge assembly
shall not be removed" and "The Mv and Lv Series cylinder assemblies shall not
be transported" added to Section 2.2.1.2. Phrases "The pressure gauge connec-
tions" and "when the gauge is removed" in Section 2.2.1.2 changed to "The pres-
sure gauge ports" and "when the gauge is absent" respectively. Warning in Section
2.2.2.1 beginning "The Sv Series low-pressure supervisory switch is mounted to the
cylinder valve" changed to warning beginning "The Sv Series low-pressure super-
visory switch is mounted directly to the cylinder valve". Phrases "The low-pressure
supervisory switch connections" and "when the switch is removed" in Section 2.2.2.2
changed to "The low-pressure supervisory switch ports" and "when the gauge is
absent" respectively. Caution beginning "The Mv and Lv Series low-pressure su-
pervisory switch assembly shall not be removed" added to Section 2.2.2.2. Section
5.11 added. Note beginning "Note: Janus Fire System® Fire Extinguishing Systems
are designed" added to Preface, Section 1, Section 3, and Section 3.1.3. Sentence
in Section 3.1.1 beginning "NFPA 2001 requires the minimum design concentra-
tion" changed to sentence reading "NFPA2001 (2012 edition) requires the minimum
design concentration". Sentence in Section 3.1.1 beginning "The minimum design
concentration for a Class C re shall be at least" changed to sentence beginning
"The minimum design concentration for a Class C re shall be 7.0%". Paragraphs
beginning "For a manual-only system" and "The design concentration for a manual-
only Class B" removed from Section 3.1.1. Paragraph beginning "If only the space
under the raised oor is to be protected by a total ooding system" added to Section
3.1.2. Table 3.2A and 3.2B changed to reect revisions to NFPA 2001, 2012 Edi-
tion. Section B.1 and B.2 changed to reect revisions to NFPA 2001, 2012 Edition.
Phrase "minimum concentration level of 6.25%" in Section 1 changed to "minimum
concentration level of 6.7%" to reect revisions to NFPA 2001, 2012 Edition. Calcula-
tion examples in Section 3.2 changed to reect revision to NFPA 2001, 2012 Edition.
Note added to Section 2.2.3.1. Figure 2.5 revised and footnote added.All references
to "Dow Corning No. 4" replaced with "Molykote 55 by Dow Corning (P/N 19056)".
Section 2.5 rewritten. Figure 2.5 changed to Figure 2.5b and Figure 2.5a added.
Maximum ll of Sv Series 40 lb corrected to 43 lbs. Sentences beginning "Refer
to Section" added to Sections 2.1.2.2 and 2.2.2.2. Paragraphs beginning "Prior to
installation" and "Every time the" added to Sections 4.1.4.1 and 4.1.4.2. Sentence
beginning "Typically a combination of" removed from Section 3.7.2.
11/11/2011

Page: xii
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
BLANK

Page: xiii
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Preface
This manual is intended for use with the Janus Fire Systems® Sv Series, Mv Series, and Lv Series FM-200®
Engineered Fire Extinguishing Systems. Those who install, operate, design, or service these systems should read
this entire manual.
All design, implementation, and maintenance of the Janus Fire Systems® Engineered Fire Extinguishing Systems
must be performed in compliance with the National Fire Protection Association (NFPA) 2001 - Standard on Clean
Agent Fire Extinguishing Systems, NFPA 70 - The National Electrical Code, NFPA 72 - The National Fire Alarm
Code, and the guidelines outlined in this manual.
All system designs are preformed in conjunction with the Janus Design Suite® hydraulic ow calculation software
and in compliance with the Janus Design Suite® Flow Calculation Software Manual, DOC106.
Janus Fire Systems® reserves the right to revise and improve its products as it deems necessary without prior
notication. This manual describes the state of Janus Fire Systems® products at the time of its publication and may
not reect those products at all times in the future.
All references to Codes or Standards in this manual refer to the latest edition of that Code or Standard unless
otherwise indicated.
Compressed gases shall be handled and used only by persons properly trained in accordance with Compressed
Gas Association, Inc. (CGA) pamphlets C-1, C-6, and P-1.
CGA pamphlets are published by the Compressed Gas Association Inc. (www.cganet.com).
The contents of this manual may not be reproduced in any form without the express written consent of Janus Fire
Systems®.
Note: Janus Fire System® Fire Extinguishing Systems are designed, manufactured, installed and UL listed and FM
approved to deliver a designated quantity of FM-200® in a "not to exceed" 10 second discharge time. The "Duration
of Protection (Hold Time)" as referenced in NFPA 2001, 2012 edition is a function of the hazard enclosure's (room)
integrity and not a function (or capability) of the re suppression systems referenced in this publication.
Copyright © 2009 Janus Fire Systems. All Rights Reserved. Janus Fire Systems® and Janus Design Suite ® are registered trademarks of
Janus Fire Systems.
FM-200® is a registered trademark of E.I. du Pont de Nemours and Company used under license by Janus Fire Systems.
Janus Fire Systems
1102 Rupcich Drive
Millennium Park
Crown Point, IN 46307
TEL: [phone] FAX: [phone]
e-mail: info@janusresystems.com · www.janusresystems.com
BLANK

Page: xiv
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
BLANK

Page: 1
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Section 1 General Information
1 GENERAL INFORMATION
e Janus Fire Systems® Sv, Mv, and Lv Series Fire Extinguishing Systems utilize FM-200® to protect
high value assets in areas that may be normally occupied, in locations where clean-up of other agents is
problematic, when storage space for a re suppression agent is restricted, and/or when an electrically non-
conductive agent is required.
FM-200® systems may be used in Class A (wood,paper,cloth,rubber,and many plastics),Class B (ammable
liquids and ammable gases), and Class C (energized electrical equipment) surface res.
NFPA 2001 mandates that clean agents such as FM-200® shall not be used on res involving the following
materials unless they have been tested to the satisfaction of the authority having jurisdiction:
• Chemicals or mixtures of chemicals, such as cellulose nitrate and gunpowder, that are capable of rapid
oxidation in the absence of air
• Reactive metals, such as lithium, sodium, potassium, magnesium, titanium, zirconium, uranium, and
plutonium
• Metal hydrides
• Chemicals capable of undergoing autothermal decomposition, such as organic peroxides and
hydrazine
All systems described in this manual are intended only for total ooding application. NFPA 2001 denes
total ooding as the act and manner of discharging an agent for the purpose of achieving a specied minimum
agent concentration throughout a hazard volume.e FM-200® must be discharged within 10 seconds and
reach a minimum concentration level of 6.7% but not exceeding 9% in normally occupied spaces.
Note: Janus Fire System® Fire Extinguishing Systems are designed, manufactured, installed and UL listed
and FM approved to deliver a designated quantity of FM-200® in a "not to exceed" 10 second discharge
time. e "Duration of Protection (Hold Time)" as referenced in NFPA 2001, 2012 edition is a function
of the hazard enclosure's (room) integrity and not a function (or capability) of the re suppression systems
referenced in this publication.
Table 1 - System Performance Specications
Lowest Approved Equipment Temperature 32°F (0°C)
Highest Approved Equipment Temperature 130°F (54°C)
Ambient Temperature Limits for Approved Flow Calculations 70°F ±10°F (21.1°C ±5.5°C)
Minimum Height of Protected Space 12 in (304 mm)
Maximum Height of Protected Space (single tier of nozzles) 16 ft (4877 mm)
Maximum Nozzle Drop Below Finished Ceiling 4 ft (1219 mm)
Nozzle Range (Radius) 44 ft (13411 mm)
Maximum Nozzle Height (Rise) Above Discharge Outlet 30 ft (9144 mm)
BLANK

Page: 2
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Section 1 General Information
1.1 Listings and Approvals
When designed and installed according to the information contained in this manual,the Janus Fire Systems®
Sv, Mv, and Lv Series FM-200® Fire Extinguishing Systems are Underwriters Laboratories Inc. (UL) listed
and Factory Mutual (FM) approved for engineered systems. System equipment has been veried through
testing to function at ambient temperatures ranging from 32°F (0°C) to 130°F (54°C). Flow calculations
have been veried at ambient temperatures of 70°F ±10° (21.1°C ±5.5°). Storage outside of the range of
70°F ±10° (21.1°C ±5.5°) may result in inaccurate ow calculations and may cause one or more nozzles to
not discharge the calculated quantity of FM-200®.
1.2 Extinguishing Agent
FM-200® (HFC-227ea) is a colorless, non-toxic gas
and a clean, eective, environmentally acceptable,
electrically non-conductive re suppression agent.
It is formed from the elements carbon, uorine and
hydrogen (CF3CHFCF3 - heptauoropropane). e
primary extinguishing mechanism of FM-200® is heat
absorption, with a secondary chemical contribution from
the thermal decomposition of FM-200® in the ame.
Most metals, such as aluminum, brass, steel, and
stainless steel, as well as plastics, rubber, and electronic
components, are not aected by exposure to FM-200®.
In the Janus Fire Systems® FM-200® Fire Suppression
Systems, FM-200® is stored as a liquid in steel cylinders
and superpressurized with nitrogen to 360 psig (24.8
bar) at 70°F (21.1°C) to improve its ow characteristics.
When discharged, FM-200® vaporizes at the discharge
nozzles and becomes thoroughly mixed with the air
throughout the protected area reaching a predetermined
design concentration.
1.3 Safety Considerations
e United States Environmental Protection Agency (EPA) Signicant New Alternatives Policy (SNAP)
Program lists FM-200® (HFC-227ea) as acceptable for occupied spaces.
FM-200® must be used in accordance with the NFPA Standard 2001, specically as follows:
Unnecessary exposure to FM-200® — including exposure at and below the no observable adverse
eects level (NOAEL)¹concentrations of 9% or below — and FM-200® decomposition products
shall be avoided. Means shall be provided to limit exposure to no longer than 5 minutes. Unprotected
personnel shall not enter a protected space during or after agent discharge. e following additional
provisions shall apply:
1NOAEL (No Observed Adverse Effect Level) - The highest concentration at which no adverse toxicological or physiological effect has been
observed.
Table 1.3 - Time for Safe Human
Exposure at Stated Concentrations
for FM-200® (HFC-221ea)
FM-200®
Concentration Maximum Human
Exposure Time
(Minutes)
% v/v ppm
9.0 90,000 5.00
9.5 95,000 5.00
10.0 100,000 5.00
10.5 105,000 5.00
11.0 110,000 1.13
11.5 115,000 0.60
12.0 120,000 0.49
Notes:
1. Data derived from the EPA-approved
and peer-reviewed PBPK model or its
equivalent.
2. Based on LOAEL of 10.5% in dogs.

Page: 3
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Section 1 General Information
(1) FM-200® systems for spaces that are normally occupied and designed to concentrations up to the
NOAEL shall be permitted. e maximum exposure in any case shall not exceed 5 minutes.
(2) FM-200® systems for spaces that are normally occupied and designed to concentrations above
the NOAEL shall be permitted, given that means be provided to limit exposure to the design
concentrations shown in Table 1.3 that correspond to an allowable human exposure time of 5
minutes. Higher design concentrations associated with human exposure times less than 5 minutes
as shown in Table 1.3 shall not be permitted in normally occupied spaces. An exposure and egress
analysis shall be performed and approved.
(3) In spaces that are not normally occupied and protected by an FM-200® system designed to
concentrations above the lowest observable adverse eects level (LOAEL)²of 10.5%, and where
personnel could possibly be exposed, means shall be provided to limit exposure times using Table 1.3.
(4) In spaces that are not normally occupied and in the absence of the information needed to
fulll the conditions listed above, the following provisions shall apply:
(a) Where egress takes longer than 30 seconds but less than 1 minute, the FM-200® shall
not be used in a concentration exceeding its LOAEL of 10.5%.
(b) Concentrations exceeding the LOAEL are permitted provided that any personnel in
the area can escape within 30 seconds.
(c) A pre-discharge alarm and time delay shall be provided in accordance with the provisions
noted in NFPA 2001 for Time Delays.
e discharge of FM-200® into a hazard may reduce visibility for a brief period. FM-200® may cause
frostbite if liquid discharge or escaping vapor contacts the skin.
e Material Safety Data Sheet (MSDS) on FM-200® can be found in Appendix A of this manual
and should be read and understood before working with the agent. Training of personnel, re drills, and
evacuation plans should be considered.
Acylinder containing FM-200® must be handled carefully. All anti-recoil safety plugs and devices must be in
place at all times when the cylinder is not connected to discharge piping.
2LOAEL(Lowest Observable Adverse Effect Level) - The lowest concentration at which an adverse physiological or toxicological effect has been
observed.
When FM-200® is exposed to temperatures greater than 1300°F (700°C), the potentially hazardous byproduct
hydrogen uoride (HF) will be formed. The system is designed to discharge within 10 seconds or less to minimize
the amount of HF formed during extinguishment. The effects of agent decomposition on equipment must be
considered when using FM-200® in hazards with high ambient temperatures (e.g., furnaces and ovens).

Page: 4
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
BLANK

Page: 5
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Section 2 System Description and Components
2 SYSTEM DESCRIPTION AND COMPONENTS
The Janus Fire Systems® Sv, Mv, and Lv Series Systems can be divided into the following component cat-
egories:
1. FM-200® Storage Components - ese components consist of the cylinder assembly(s),which contains the
FM-200® chemical agent, and the cylinder bracket(s), which holds the cylinder assembly securely in place.
2. FM-200® Distribution Components - ese components consist of the discharge nozzles used to atomize
the liquid FM-200® and introduce it into a protected hazard along with the associated piping system used
to connect the nozzles to the cylinder assembly.
3. Trim Components - ese components complete the installation of the FM-200® system and may include
connection ttings, a pressure gauge, low-pressure supervisory switch, electric valve actuator, and manual
valve actuator.e specic components used will vary slightly according to the series valve installed.
4. Slave Arrangement Components - ese components consist of the pneumatic valve actuator(s), pilot
actuation check valve, vent check, actuation hoses, and ttings required for a multiple cylinder (slave)
arrangement.
5. Supplemental Components - ese components include the discharge pressure switch and may be utilized
in a variety of locations within an arrangement or for multiple purposes.
6. Control Panel - is device monitors the condition of the electric actuator, detectors, warning devices,
cylinder pressure, and any manual release and abort stations.
7. Early Warning and Alarm Devices - Early warning devices coupled with manual release and abort stations
maximize system eciency while audible and visual alarm devices alert sta of alarm conditions.
The following secons describe the operaon and funcon of all controls and indicators that are used
with the Janus Fire Systems® Sv, Mv, and Lv Series FM-200® Systems.
Alarm
Cylinder Valve
Electric
Valve
Actuator
Smoke Detector
Manual Release
& Abort
Cylinder Bracket
Discharge Nozzle
Agent Storage Cylinder
Control Panel
Warning Sign
Figure 2 Typical Clean Agent System Layout
BLANK

Page: 6
FM-200® OPERATION, DESIGN, & SERVICE MANUAL
Revision F
Document # DOC102
Issued: February 1, 2009
Revised: 11-Nov-2011
40YE
Section 2 System Description and Components
2.1 Cylinder Assembly
e cylinder assembly consists of the cylinder, dip tube, and cylinder valve.
2.1.1 Cylinder
e FM-200® agent is stored as a liquid inside a welded steel cylinder. e cylinders are superpressurized
with dry nitrogen to a pressure of 360 psig (24.8 bar) at 70°F (21°C). Every cylinder has a minimum ll
density of 35 lb/ft3(561 kg/m3) and a maximum ll density of 70 lb/ft3(1121 kg/m3). e capacity of a
cylinder varies according to the design requirements and the Series designation (See Table 2.1.1 for a list
of available capacities).
Standard domestic cylinders are manufactured according to the requirements of the U.S. Department
of Transportation (USDOT) and Transport Canada1(TC) for compressed gas and are tted with an
identication label indicating the ll quantity of FM-200®. Each cylinder has internal neck threads to allow
for connection to the cylinder valve.
2.1.1.1 Rupture Disc
A frangible rupture disc is tted to the Lv Series cylinder body. It functions as an emergency relief device in
the event of excessive internal pressure within the cylinder. Its rupture point is between 850 psi (58.6 bar)
and 1000 psi (68.9 bar).
is feature is not found on the Sv Series or Mv Series cylinder. Instead, a rupture disc is located on the side
of Sv Series and Mv Series cylinder valve as detailed in sections 2.1.3.1 and 2.1.3.2.
Table 2.1.1 Cylinder Capacities
Valve
Series
Nominal
Cylinder
Size P/N P/N
(CE)
Fill Capacity Empty
Weight
Minimum Maximum
lb kg lb kg lb kg
Sv 40 lb 18583 18586 22 10.0 43 19.5 36 16.3
Sv 80 lb 18584 18587 41 18.6 81 36.7 65 29.5
Sv 130 lb 18585 18588 66 29.9 131 59.4 77 35.0
Mv 250 lb 18525 18589 126 57.2 252 114.3 213 96.6
Mv 420 lb 18526 18590 211 95.7 422 191.4 279 126.6
Lv 600 lb 18527 18591 304 137.9 609 275.3 346 157.0
Lv 900 lb 18528 18592 455 206.4 910 412.7 471 213.6
Lv 1000 lb 18529 18593 561 254.5 1000 453.6 766 346.5
Ordering Instructions: Specify the Cylinder Assembly P/N followed by a dash and the ll
weight in pounds expressed in three digits.
11000 lb Cylinders are not Transport Canada approved.
