INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION, AND MAINTENANCE
INSTRUCTIONS FOR OPERATION, AND MAINTENANCE
Twister® and
Bubble Cup® Nozzles
WARNING
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/serial-
number.
This equipment is intended for use by trained and qualified emergency services personnel for
firefighting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize firefighters and maintenance personnel with the
operation, servicing, and safety procedures associated with this product. This manual should be
kept available to all operating and maintenance personnel.
Twister Series
Bubble Cup Series

©Copyright Task Force Tips LLC 2002-2020 2 LKB-100 September 17, 2020 Rev12
TABLE OF CONTENTS
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
3.1 VARIOUS MODELS AND TERMS
3.2 SPECIFICATIONS
3.3 USE WITH SALT WATER
3.4 NOZZLE COUPLINGS
4.0 FLOW CHARACTERISTICS
5.0 FLOW CHARTS
5.1 STANDARD
5.2 METRIC
6.0 NOZZLE CONTROLS
6.1 FLOW CONTROL
6.1.1 LEVER TYPE FLOW CONTROL (BALL VALVE)
6.1.2 TIP ONLY NOZZLES
6.2 PATTERN CONTROL
6.3 BUBBLE CUP NOZZLES
7.0 USE WITH FOAM
7.1 FOAM ASPIRATING ATTACHMENTS
8.0 COLOR CODED HANDLE COVER AND PISTOL GRIPS
9.0 WARRANTY
10.0 MAINTENANCE
10.1 FIELD LUBRICATION
10.2 SERVICE TESTING
10.3 REPAIR
11.0 EXPLODED VIEWS AND PARTS LISTS
12.0 OPERATION AND INSPECTION CHECKLIST
LIA-025
Manual: Foam Aspirators
LTT-108
Instruction: Pistol Grip
Replacement Kit
TASK FORCE TIPS, Inc.
3701 Innovation Way, Valparaiso, IN 46383-9327
800.348.2686 • 219.462.6161 • Fax [phone]
Instruction: Pistol Grip
Replacement Kit
www.tft.com
1) Remove old grip from valve body
by inserting a 5/16" ball-point hex
driver into the bottom of the grip
and unscrewing the mounting screw.
2) Remove the mounting screw, washer,
grip, and spacer.
3) Wipe the screw thread clean to remove
any debris.
4) Place the washer on the clean screw
and insert the screw into the bottom
of the new pistol grip so that it protrudes
through the hole in the middle.
5) Place the spacer on top of the new grip
so that the screw protrudes through the
hole in that as well.
6) Place enough adhesive on the threads
of the mounting screw so that the first
five threads are 'wetted' with adhesive.
7) Place the new grip assembly on the
nozzle valve body and thread the
mounting screw into the screw hole
in the valve body.
8) Tighten the mounting screw to a
maximum torque of 100 in/lbs.
BALL DRIVER
100 IN•LB MAX.
WASHER
GRIP
SPACER
LOCTITE®
271
HM692BLK-KIT BLACK GRIP
HM692BLU-KIT BLUE GRIP
HM692GRY-KITGRAY GRIP
HM692GRN-KIT GREEN GRIP
HM692ORG-KIT ORANGE GRIP
HM692PNK-KIT PINK GRIP
HM692PPL-KIT PURPLE GRIP
HM692RED-KIT RED GRIP
HM692TAN-KIT TAN GRIP
HM692WHT-KIT WHITE GRIP
HM692YEL-KIT YELLOW GRIP
LTT-108 January 20, 2012 Rev07©Copyright Task Force Tips 2010-1012
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Fire¿ghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Fire¿ghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufacturers and Service Association
P.O. Box 147, Lynn¿eld, MA 01940 • www.FEMSA.org
SUPPORTING MATERIALS
The following documents contain supporting safety and operating
information pertaining to the equipment described in this manual.

©Copyright Task Force Tips LLC 2002-2020 3 LKB-100 September 17, 2020 Rev12
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the definitions of the four signal words are as follows:
2.0 SAFETY
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
DANGER
An inadequate supply of pressure and/or flow will cause an ineffective stream and can result
in injury or death. Choose operating conditions to deliver adequate fire suppression. See flow
graphs.
WARNING
This equipment is intended for use by trained personnel for firefighting. Use of this equipment for
other purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
WARNING
Equipment may be damaged if frozen while containing significant amounts of water. Such damage
may be difficult to detect visually. Subsequent pressurization can lead to injury or death. Any time
the equipment is subject to possible damage due to freezing, it must be tested and approved for
use by qualified personnel before being considered safe for use.
WARNING
Failure to restrain nozzle reaction can cause firefighter injury from loss of footing and/or stream
protection. Opening and closing other nozzles, hose line kinks, changes in pump settings, nozzle
pattern, or flushing will cause changes in nozzle reaction. Nozzle operator must always be prepared
in the event of these changes.
WARNING
If nozzle gets out of control while flowing, violent whipping motion will occur. Serious injury or
death could result. Retreat from the nozzle immediately. Do not attempt to regain control of nozzle
while flowing.
WARNING
Application of water or foam solutions on energized electrical equipment could cause
electrocution. Serious injury or death could result. Assume circuits are energized until confirmed to
be de-energized. Do not apply water or foam to energized electrical equipment.
WARNING
The stream exiting a nozzle is powerful and capable of causing injury and property damage. Make
sure the nozzle is securely attached and pointing in a safe direction before water is turned on. Do
not direct water stream to cause injury or damage to persons or property.
NOTICE
To prevent mechanical damage, do not drop or throw equipment.

©Copyright Task Force Tips LLC 2002-2020 4 LKB-100 September 17, 2020 Rev12
3.0 GENERAL INFORMATION
This manual describes nozzles calibrated at 100 psi (7 bar). Contact the factory for data specific to models that operate with metric flow
calibrations. Task Force Tips Twister and Bubble Cup nozzles are economical, lightweight, and dependable. Their rugged construction is
compatible with the use of fresh water as well as firefighting foam solutions. Other important operating features include:
• Quick-acting pattern control from straight stream to wide fog
• Quick-change rear valve seat
• TFT’s 5-year warranty and unsurpassed customer service
3.1 VARIOUS MODELS AND TERMS
Table 3.1
Figure 3.1
3.2 SPECIFICATIONS
Table 3.2
3.3 USE WITH SALT WATER
Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of the
equipment may be shortened due to the effects of corrosion, and is not covered under warranty.
SERIES MODEL STANDARD
COUPLING SIZE
GALLONAGE SETTINGS
(gpm @ 100 psi)
*C TWISTER 3/4” GHT 10, 24
D TWISTER or BUBBLE CUP 1.0” NH 10, 24
D TWISTER or BUBBLE CUP 1.0” NH 10, 40
F TWISTER or BUBBLE CUP 1-1/2” NH 20, 60
F TWISTER or BUBBLE CUP 1-1/2” NH 20, 95
F BUBBLE CUP 1-1/2” NH 95 Single Gallonage Only
*C series Twister is available in a tip-only nozzle configuration only.
D and F series Twister and Bubble Cups are available in tip-only, ball valve, or ball valve with pistol grip
configurations.
Maximum nozzle inlet pressure with
valve shut off*
Twister 300 psi 20 bar
Bubble Cup 300 psi 20 bar
Operating temperature of fluid 33 to 120°F 1 to 50°C
Storage temperature range of fluid -40 to 150°F -40 to 65°C
Materials used Aluminum 6000 series hard anodized MIL 8625 class 3 type
2, stainless steel 300 series, nylon 6-6, nitrile rubber
*Consult factory for higher pressure applications
NOZZLE WITH VALV
E
and PISTOL GRIP
TIP ONLY NOZZLE
COUPLING
RUBBER
GASKET
PISTOL
GRIP
STREAM
SHAPER
ON
F
L
O
W
C
O
N
T
R
O
L
OFF
NAME LABEL
NOZZLE WITH VALVE

©Copyright Task Force Tips LLC 2002-2020 5 LKB-100 September 17, 2020 Rev12
3.4 NOZZLE COUPLINGS
NH (National Hose Threads) threads are standard on all nozzles. Other threads such as NPSH (National Pipe Straight Hose) can be
specified at time of order.
4.0 FLOW CHARACTERISTICS
At each flow setting, the nozzle is set to a predetermined fixed orifice. Relationship of flow and nozzle pressure at each setting is shown
below. Contact the factory or visit the website (www.tft.com) for range and trajectory data.
The charts in this document give specific examples of pump pressure and flow for various hoses and lengths. Losses may vary due to
differences in hose construction resulting in flows different than shown. For situations or lengths of hose not listed on the chart,
approximate flows can be calculated using conventional hydraulics.
Figure 4.0
CAUTION Mismatched or damaged waterway connections may cause equipment to leak or uncouple under
pressure. Failure could result in injury. Equipment must be mated to matched connections.
CAUTION Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability to
uncouple the connection, or complete loss of engagement over time. Failure could cause injury. Per
NFPA 1962, if dissimilar metals are left coupled together, an anti-corrosive lubricant should be
applied to the connection and the coupling should be disconnected and inspected at least
quarterly.
140
120
100
80
60
40
20
0
PRESSURE (PSI)
FLOW (GPM)
01020304050
10 GPM
24 GPM
40 80 120 160 190
FLOW (L/min)
1
2
3
4
5
6
7
8
9
PRESSURE (bar)
140
120
100
80
60
40
20
0
PRESSURE (PSI)
FLOW (GPM)
0204060
80 100
20 GPM
60 GPM
80 160 240 320
FLOW (L/min)
1
2
3
4
5
6
7
8
9
PRESSURE (bar)
10, 24 GPM TWISTER OR BUBBLE CUP 20, 60 GPM TWISTER OR BUBBLE CUP
140
120
100
80
60
40
20
0
PRESSURE (PSI)
0 1020304050
10GPM
40 GPM
40 80 120 160 190
FLOW (L/min)
1
2
3
4
5
6
7
8
9
PRESSURE (bar)
FLOW (GPM)
140
120
100
80
60
40
20
0
PRESSURE (PSI)
0204060
80 100
20 GPM
95GPM
80 160 240 320
FLOW (L/min)
1
2
3
4
5
6
7
8
9
PRESSURE (bar)
FLOW (GPM)
10, 40 GPM TWISTER OR BUBBLE CUP 20, 95 GPM TWISTER or BUBBLE CUP
or 95 GPM BUBBLE CUP

©Copyright Task Force Tips LLC 2002-2020 6 LKB-100 September 17, 2020 Rev12
5.0 FLOW CHARTS
5.1 STANDARD
Table 5.1
• Number in each box is flow in gallons per minute.
• Actual flows may vary with brand and condition of hose.
• Flows are approximate and do not account for losses in preconnected piping or changes in elevation.
3/4” HOSE
FLOW
SETTING 10 24 40 10 24 40 10 24 40
PUMP PRESSURE (psi)
50 713176111361011
100919249161991416
150 12 23 29 11 20 23 11 17 20
200 13 27 34 13 23 27 12 20 23
250 15 30 38 14 25 30 14 22 25
300 16 33 42 16 28 33 15 24 28
350 18 35 45 17 30 35 16 26 30
400 19 38 48 18 32 38 17 28 32
450 20 40 51 19 34 40 18 30 34
500 21 42 54 20 36 42 19 32 36
550 22 44 56 21 37 44 20 33 37
600 23 46 59 22 39 46 21 35 39
1” HOSE
FLOW
SETTING 10 24 40 10 24 40 10 24 40
PUMP PRESSURE (psi)
50 716257162371522
100 10 23 36 10 22 33 10 21 31
150 12 28 44 12 27 40 12 26 37
200 14 33 51 14 31 47 14 30 43
250 16 36 57 16 35 52 15 34 48
300 17 40 62 17 38 57 17 37 53
350 19 43 67 18 41 62 18 40 57
400 20 46 72 20 44 66 20 43 61
450 21 49 76 21 47 70 21 45 65
500 22 51 80 22 50 74 22 48 68
550 23 54 84 23 52 77 23 50 72
600 24 56 88 24 54 81 24 52 75
1-1/2” HOSE
FLOW
SETTING 20 60 95 20 60 95 20 60 95
PUMP PRESSURE (psi)
50 14 40 58 14 39 56 14 38 54
75 17 49 71 17 48 69 17 47 66
100 20 56 82 20 55 79 20 54 76
125 22 63 92 22 62 89 22 61 85
150 24 69 101 24 68 97 24 67 94
175 26 75 109 26 73 105 26 72 101
200 28 80 117 28 78 112 28 77 108
225 30 85 124 30 83 119 30 82 115
250 31 89 130 31 88 125 31 86 121
1-3/4” HOSE
FLOW
SETTING 20 60 95 20 60 95 20 60 95
PUMP PRESSURE (psi)
50 14 41 61 14 40 59 14 40 58
75 17 50 75 17 49 73 17 49 71
100 20 58 86 20 57 84 20 56 82
125 22 64 96 22 64 94 22 63 91
150 24 71 106 24 70 103 24 69 100
175 26 76 114 26 75 111 26 74 108
200 28 82 122 28 80 119 28 79 116
225 30 86 129 30 85 126 30 84 123
250 31 91 136 31 90 133 31 89 129
100 ft 200 ft 300 ft
100 ft 200 ft 300 ft
150 ft 200 ft 250 ft
150 ft 200 ft 250 ft

©Copyright Task Force Tips LLC 2002-2020 7 LKB-100 September 17, 2020 Rev12
5.2 METRIC
Table 5.2
• Number in each box is flow in liters per minute.
• Actual flows may vary with brand and condition of hose.
• Flows are approximate and do not account for losses in preconnected piping or changes in elevation.
• 1 bar = 100 kPa
19mm HOSE
FLOW
SETTING
30 Meters 60 Meters 90 Meters
10 24 40 10 24 40 10 24 40
PUMP PRESSURE (bar)
3.5 25 50 65 25 40 50 25 40 40
735 70 90 35 60 70 35 55 60
10 4585110407585406575
14 50 100 130 50 85 100 45 75 85
17 55 115 145 55 95 115 55 85 95
21 60 125 160 60 105 125 55 90 105
24 70 130 170 65 115 130 60 100 115
28 70 145 180 70 120 145 65 105 120
31 75 150 195 70 130 150 70 115 130
34 80 160 205 75 135 160 70 120 135
38 85 165 210 80 140 165 75 125 140
41 85 175 225 85 150 175 80 130 150
25mm HOSE
FLOW
SETTING
30 Meters 60 Meters 90 Meters
10 24 40 10 24 40 10 24 40
PUMP PRESSURE (bar)
3.5 25 60 95 25 60 85 25 55 85
740 85 135 40 85 125 40 80 115
10 45 105 165 45 100 150 45 100 140
14 55 125 195 55 115 180 55 115 165
17 60 135 215 60 130 195 55 130 180
21 65 150 235 65 145 215 65 140 200
24 70 165 255 70 155 235 70 150 215
28 75 175 275 75 165 250 75 165 230
31 80 185 290 80 180 265 80 170 245
34 85 195 305 85 190 280 85 180 255
38 85 205 320 85 195 290 85 190 275
41 90 210 335 90 205 305 90 195 285
38mm HOSE
FLOW
SETTING
45 Meters 60 Meters 75 Meters
20 60 95 20 60 95 20 60 95
PUMP PRESSURE (bar)
3.5 55 150 220 55 150 210 55 145 205
5.2 65 185 270 65 180 260 65 180 250
775 210 310 75 210 300 75 205 290
8.6 85 240 350 85 235 335 85 230 320
10 90 260 380 90 255 365 90 255 355
12 100 285 415 100 275 395 100 275 380
14 105 305 445 105 295 425 105 290 410
15.5 115 320 470 115 315 450 115 310 435
17 115 335 490 115 335 475 115 325 460
45mm HOSE
FLOW
SETTING
45 Meters 60 Meters 75 Meters
20 60 95 20 60 95 20 60 95
PUMP PRESSURE (bar)
3.5 55 155 230 55 150 225 55 150 220
5.2 65 190 285 65 185 275 65 185 270
775 220 325 75 215 320 75 210 310
8.6 85 240 365 85 240 355 85 240 345
10 90 270 400 90 265 390 90 260 380
12 100 290 430 100 285 420 100 280 410
14 105 310 460 105 305 450 105 300 440
15.5 115 325 490 115 320 475 115 320 465
17 115 345 515 115 340 505 115 335 490

©Copyright Task Force Tips LLC 2002-2020 8 LKB-100 September 17, 2020 Rev12
6.0 NOZZLE CONTROLS
6.1 FLOW CONTROL
6.1.1 LEVER TYPE FLOW CONTROL (BALL VALVE)
Models with a ball valve are shut off when the valve handle is fully forward. Pulling back on the handle opens the valve. TFT
recommends the use of a pistol grip for easier handling. For additional stress reduction, a hose rope or strap may also be used. This
permits more effective use and ease of advancement, while minimizing strain and fatigue.
6.1.2 TIP ONLY NOZZLES
Twister and Bubble Cup Tip Only nozzles have a twist shut off valve contained within the nozzle.
6.2 PATTERN CONTROL
TFT nozzles have full pattern control from straight stream to wide fog. Turning the stream shaper clockwise (as seen from the operating
position behind the nozzle) moves the shaper to the straight stream position, and the eventually to OFF. Turning the shaper
counterclockwise will result in an increasingly wider pattern.
Since the stream trim point varies with flow, the stream should be “trimmed” after changing the flow to obtain the straightest and farthest
reaching stream. To properly trim the stream, first open the pattern to narrow fog. Then close the stream to parallel to give maximum
reach. Turning the shaper further forward will cause stream crossover and reduce the effective reach of the nozzle.
6.3 BUBBLE CUP NOZZLES
The Bubble Cup nozzle is capable of producing aspirated foam as well as conventional straight stream and wide protective fog patterns.
The Bubble Cup functions just like the Twister nozzle when the aspirating sleeve is in the retracted position.
To use the aspirating feature of the Bubble Cup, slide the aspirating sleeve portion of the nozzle forward. Rotation of the shaper while
the sleeve is extended provides the nozzle operator control of reach and aspiration. If an immediate wide protective fog pattern is
needed, the sleeve can be retracted instantly to its regular position.
Figure 6.3
NOTICE
Control valves must be opened slowly to eliminate unnecessary strain on the hose and couplings,
and reduce pressure surges.
NOTICE
Nozzles attached to an in-service hose shall be stored in the off position.
NOTICE
In partially open positions, a ball valve will cause turbulence and adversely affect stream quality.
WARNING
The nozzle reaction is greatest when the shaper is in the straight stream position. Sudden changes
in pattern can cause changes in reaction, leading to loss of footing or an out of control nozzle. The
nozzle operator must be prepared for a change in reaction as the pattern is changed.
CAUTION Dents or nicks in the nozzle tip can seriously affect the stream reach or pattern, which may increase
the risk of injury due to exposure. Care must be taken to avoid dents or nicks in the nozzle tip.
WARNING
Large amounts or pieces of debris may be unflushable and can reduce the flow of the nozzle
resulting in an ineffective flow. In the event of a blockage, it may be necessary to retreat to a safe
area, uncouple the nozzle and remove debris.
2
95
09
5BC
GPM
FS
/
20
2
95
09
5BC
GPM
FS
/
20
EXTENDED TO
WHITE LINE
ASPIRATING
SLEEVE
SHAPER
Retracted Position Extended Position

©Copyright Task Force Tips LLC 2002-2020 9 LKB-100 September 17, 2020 Rev12
7.0 USE WITH FOAM
The nozzle may be used with foam solutions. Refer to fire service training by the Authority Having Jurisdiction (AHJ) for the proper use
of foam.
7.1 FOAM ASPIRATING ATTACHMENTS
Multi-expansion or low expansion aspirating attachments may be used with nozzles to increase the expansion ratio. These foam tubes
attach and detach quickly from the nozzle. As expansion ratio is increased, the reach of the nozzle will decrease due to the greater
amount of bubbles in the stream and their ability to penetrate the air. Generally, the straight stream reach with foam is approximately
10% less than with water only. Actual results will vary based on brand of foam, hardness of water, temperature, etc. For specific
information, see LIA-025 (MANUAL: Foam Attachments for TFT Nozzles).
8.0 COLOR CODED HANDLE COVER AND PISTOL GRIPS
Nozzles with lever type valve handles are supplied with black valve handle covers and pistol grips. The handle covers and pistol grips
are available from TFT in various colors for those departments wishing to color code the nozzle to the discharge controls. A colored
handle cover set will be sent upon receipt of the warranty card by TFT. Your department’s name can also be engraved on the covers
(see warranty card for more information).
Handle covers are replaceable by removing the four screws that hold the handle covers in place. Use a 3/32” hex key when replacing
screws. Pistol grip is replaceable by following TFT instruction sheet LTT-108.
For standardization NFPA 1901 recommends the following color code scheme:
WARNING
For Class B fires, lack of foam or interruption in the foam stream can cause a break in the foam
blanket and greatly increase the risk of injury or death. Follow procedures established by the AHJ
for the specific fuel and conditions.
WARNING
Improper use of foam or using the wrong type of foam can result in illness, injury, or damage to the
environment. Follow foam manufacturer’s instructions and fire service training as directed by the
AHJ.
WARNING
Use of compressed air foam (CAF) with hand held nozzles can cause sudden surges in nozzle
reaction force resulting in risk of injury or death from loss of footing or hose whipping. Be prepared
for sudden changes in nozzle reaction caused by:
• Slug loading (Loss of foam concentrate sends slugs of air and water into the nozzle)
• Sudden release of built-up pressure in the hose when opening a nozzle
Preconnect #1 or Jump Line Orange Other Colors Available:
Preconnect #2 Red - Gray
Preconnect #3 Yellow - Pink
Preconnect #4 White - Purple
Preconnect #5 Blue - Tan
Preconnect #6 Black
Preconnect #7 Green
Foam Lines Red w/ White Border (Red/White)

©Copyright Task Force Tips LLC 2002-2020 10 LKB-100 September 17, 2020 Rev12
9.0 WARRANTY
Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its
products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the five (5) year period from the date of purchase. TFT’s obligation under this warranty is specifically limited to
replacing or repairing the equipment (or its parts) which are shown by TFT’s examination to be in a defective condition attributable to
TFT. To qualify for this limited warranty, the claimant must return the equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana
46383-9327 USA, within a reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that there is
a defect attributable to it, TFT will correct the problem within a reasonable time. If the equipment is covered by this limited warranty, TFT
will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is an
intended or unintended beneficiary of the equipment, shall not be entitled to recover from TFT any consequential or incidental damages
for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT.
It is agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

©Copyright Task Force Tips LLC 2002-2020 11 LKB-100 September 17, 2020 Rev12
10.0 MAINTENANCE
TFT products are designed and manufactured to be damage resistant and require minimal maintenance. However, as the primary
firefighting tool upon which your life depends, it should be treated accordingly. To help prevent mechanical damage, do not drop or throw
equipment.
10.1 FIELD LUBRICATION
All Task Force Tips nozzles are factory lubricated with high quality silicone grease. This lubricant has excellent wash out resistance,
providing long term performance in firefighting nozzles. If your department has unusually hard or sandy water, the moving parts of the
nozzle may be affected. Foam agents and water additives contain soaps and chemicals that may break down the factory lubrication.
The moving parts of the nozzle should be checked on a regular basis for smooth and free operation, and for signs of damage. IF THE
NOZZLE IS OPERATING CORRECTLY, THEN NO ADDITIONAL LUBRICANT IS NEEDED. Any nozzle that is not operating correctly
should be immediately removed from service. The nozzle can be returned to the factory at any time for a complete checkup and re-
lubrication with silicone grease.
The field use of Break Free CLP (spray or liquid) lubricant will help to temporarily restore the smooth and free operation of the nozzle.
These lubricants do not have the washout resistance and long-term performance of the silicone grease. Once Break Free CLP is
applied, re-application will be needed on a regular basis until the nozzle can be returned to the factory for a complete checkup and re-
lubrication with silicone grease.
10.2 SERVICE TESTING
In accordance with NFPA 1962, equipment must be tested a minimum of annually. Units failing any part of this test must be removed
from service, repaired and retested upon completion of the repair.
10.3 REPAIR
Factory service is available with repair time seldom exceeding one day in our facility. Factory serviced equipment is repaired by
experienced technicians, wet tested to original specifications, and promptly returned. Repair charges for non-warranty items are
minimal. Any returns should include a note as to the nature of the problem and whom to reach in case of questions.
Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability for
damage to equipment or injury to personnel that is a result of user service. Contact the factory or visit the web site at tft.com for parts
lists, exploded views, test procedures and troubleshooting guides.
Performance tests shall be conducted on the equipment after a repair, or anytime a problem is reported to verify operation in accordance
with TFT test procedures. Consult factory for the procedure that corresponds to the model and serial number of the equipment. Any
equipment which fails the related test criteria should be removed from service immediately. Troubleshooting guides are available with
each test procedure or equipment can be returned to the factory for service and testing.
11.0 EXPLODED VIEWS AND PARTS LISTS
Exploded views and parts lists are available at tft.com/serial-number.
CAUTION Aerosol lubricants contain solvents that can swell O-Rings if applied in excess. The swelling can
inhibit smooth operation of the moving parts. When used in moderation, as directed, the solvents
quickly evaporate without adversely swelling the O-Rings.
CAUTION Any alterations to the product or its markings could diminish safety and constitutes a misuse of
this product.
NOTICE
All replacement parts must be obtained from the manufacturer to assure proper operation of the
device.

©Copyright Task Force Tips LLC 2002-2020 12 LKB-100 September 17, 2020 Rev12
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
12.0 OPERATION AND INSPECTION CHECKLIST
BEFORE EACH USE, the nozzle must be inspected to this checklist:
1. There is no obvious damage such as missing, broken or loose parts, damaged labels etc.
2. Waterway is clear of obstructions
3. Coupling is tight and leak free
4. Valve operates freely through full range and regulates flow
5. “OFF” position does fully shut off and flow is stopped
6. Nozzle flow is adequate as indicated by pump pressure and nozzle reaction
7. Shaper turns freely and adjusts pattern through full range
8. Nozzle smoothly moves into full flush and out of flush with normal flow and pressure restored
9. Shaper detent (if so equipped) operates smoothly and positively.
BEFORE BEING PLACED BACK IN SERVICE, nozzles must be inspected to this checklist:
1. All controls and adjustments are operational
2. Shut off valve (if so equipped) closes off the flow completely
3. There are no broken or missing parts
4. There is no damage to the nozzle that could impair safe operation (e.g. dents, cracks, corrosion or other defects)
5. The thread gasket is in good condition
6. The waterway is clear of obstructions
7. Nozzle is clean and markings are legible
8. Coupling is retightened properly
9. Shaper is set to desired pattern
10. Shutoff handle is stored in the OFF position
NFPA 1962: Standard for the care, use, inspection, service testing, and replacement of fire hose, couplings, nozzles and fire hose appliances. Quincy, MA: National Fire
Protection Agency
WARNING
Equipment failing any part of the checklist is unsafe for use and must have the problem corrected
before use or being placed back into service. Operating equipment that has failed the checklist is a
misuse of this equipment.
