Jarvis VC User manual

JARVIS
TABLE OF
CONTENTS Page.........................
Model VC Package 4302008...........
Model VC 4302007...............
Balancer 1350084................
Air Control Circuit 3350006........
Vacuum Hose (8 ft.) 1323010......
Air Hose Assembly 1323011.......
Water Tube (8 ft.) 1323019........
Grease (1 lb.) 1348001............
Oil (1 pt.) 1348004................
•Notice to Employer and Safety
Director 2.........................
•Notice to Operators, Maintenance
and Cleanup Personnel 3............
•Parts Diagram and List 4............
•Installation Instructions 6............
•Specifications 7....................
•Operation Instructions 8.............
•Blade / Pilot Pin Information 9........
•Maintenance Instructions 10.........
•Troubleshooting 12.................
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone]
WWW .jarvisproducts.com
Model VC
Poultry Vent Cutter
EQUIPMENT
SELECTION Ordering No...........
6222009::.
®

noticetoemployer
and safety director
Model VC page 2 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
NOTICE TO EMPLOYER AND SAFETY DIRECTOR
AVOID INJURY
1. Remove and repair any tool that malfunctions. All personnel must be instructed to remove any
malfunctioning tool.
2. Ensure that all employees who use this tool are trained in the proper use of this tool and are aware of
the dangers that may arise if they do not follow the procedures outlined in this brochure.
3. Ensure that all employees who use this tool wear a steel mesh glove at all times. Do not rely on the
steel mesh glove for safety; employees who use this tool must be instructed to keep their free hand(s)
away from the cutting edge and the cutting path of the tool.
4. Enclosed are four (4) copies of “NOTICE TO OPERATORS, MAINTENANCE AND CLEANUP
PERSONNEL.” Post one copy on the employees’ bulletin board; give one copy to the operator(s);
give one copy to the maintenance foreman; and give one copy to the sub-contract / internal cleanup
foreman. Additional copies will be provided upon request.
5. The tool is designed and intended to be powerful. This fact should be obvious to your employees, but
you must emphasize it to them.
6. Never make modifications or alterations to the tool. Replace any missing or illegible labels.
7. Ensure that proper procedures are established (in accordance with OSHA’s lockout/tagout procedures
29 CFR 1910.147) to prevent accidental startup or release of stored energy.
8. Hand/Wrist/Arm injury and other Cumulative Trauma Disorders may result from repetitive work,
motion or vibration. You must make your employees aware of hazards, symptoms of injury and ap-
propriate prevention. See OSHA’s “Ergonomics Program Management Guidelines for Meatpacking
Plants.”
9. Follow our installation and maintenance instructions for proper installation and care of the tool.
10. Avoid injury. Do not permit the tool to be misused.
11. If you resell or distribute a Jarvis product, you must provide the purchaser with the appropriate safety
sheets and tool brochure. Additional copies of safety sheets and tool brochures will be provided upon
request.
Keep hands clear

notice to operators, maintenance
and cleanup personnel
Model VC
page 3 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
1. Disconnect the air supply in accordance with OSHA’s lockout/tagout procedures (29 CFR 1910.147)
before changing the blade.
2. Disconnect the air supply in accordance with OSHA’s lockout/tagout procedures (29 CFR 1910.147)
before performing any repairs or maintenance.
3. Disconnect the air supply -- or have the air supply disconnected -- in accordance with OSHA’s lockout/
tagout procedures (29 CFR 1910.147) before performing any cleanup.
4. Disconnect the air hose when the tool is not in use.
5. Never put fingers, hands or other parts of the body on the cutting edge of the blade or in the cutting path
of the tool.
6. Always wear a steel mesh glove on the hand that is not operating the tool. Always wear steel mesh
gloves when handling the blade.
7. Test the tool prior to use or daily. Pull the trigger and the tool should start; release the trigger and the
tool should stop. If the tool malfunctions, remove it from service and report or repair it immediately.
8. Never depress the trigger unless you want to use the tool.
9. Never make modifications or alterations to the tool. Report or replace any missing or illegible labels.
NOTICE TO OPERATORS, MAINTENANCE AND CLEANUP PERSONNEL
REMOVE ANY MALFUNCTIONING TOOL FROM SERVICE
REPORT ANY PROBLEMS TO YOUR SUPERVISOR
Keep hands clear

parts diagram and list
Model VC page 4 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
1 1327038
3
/
8
inch Pilot Pin 1
2 3332001
7
/
8
inch Blade 1
3 1312043 Cutter Shaft 1
4 3330007 Shaft Housing Assembly 1
5 1324040 Hose Connector 1
6 1343004 O--ring 2
7 1350032 Throttle Lever 1
8 1324033 Close Pipe Nipple 1
9 1350033 Lever Pivot Pin 1
10 1324061 Tube Connector w/Washer 1
11 3327002 Trigger Pin Assembly 1
12 1346001 Water Valve 1
13 1324066 Tube Connector 1
14 1350066 Grease Fitting 2
15 1311019 Needle Bearing 2
16 1342003 Planetary Gear 2
17 1350042 Rotor Vane 4
18 1304035 Motor End Plate (Rear) 1
19 1311020 Ball Bearing 1
20 1301060 Screw 1
21 1017084 Warning Label 1
ITEM PART NO. PART NAME QTY
ITEM PART NO. PART NAME QTY
22 1330042 Pistol Grip Handle 1
(includes items 20--23)
23 1317010 Hanger Ring 1
24 1327062 Trigger Retaining Pin 1
25 1343022 Gasket Seal 1
26 1303022 Split Lock Washer 2
27 1350081 Air Exhaust Muffler 1
28 1350043 Air Screen 1
29 1301092 Socket Head Cap Screw 2
30 1317012 Retaining Ring 1
31 1324017 Quick Connect Coupling 1
32 1350080 Air Inlet Valve 1
33 1327064 Valve Stem Pin 1
34 1327063 Valve Pin 1
35 1327048 Cam Retaining Pin 1
36 1349001 Trigger Cam 1
37 1338017 Trigger Bushing 1
38 1345005 Air Motor Trigger 1
39 1327046 Rotor Housing Pin 1
40 1337018 Rotor Sleeve 1
41 1312044 Splined Rotor 1
42 1304034 Motor End Plate (Front) 1
43 1311021 Ball Bearing 1
44 1303019 Washer 1
45 1311018 Needle Bearing 1
46 1312045 Gear Shaft 1
47 1327047 Planetary Gear Pin 2
48 1342004 Ring Gear 1
49 1311017 Ball Bearing 1
50 1316037 Shaft Spacer 1
Model VC
Figure A
see page 9 for
additional blade and
pilot pin information.
*
* use tool 8327001 to remove

parts diagram and list
Model VC
page 5 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
Air Control Circuit
Figure B
51 1324069 Tube Connector 1
52 1324058 Tube Connector 4
53 3350002 Venturi Assembly 1
54 1324063 Reducer Bushing 2
55 1323012 Tubing (9 inch) 2
56 1324051 Street Elbow 3
57 1324049 Hex Pipe Nipple 6
58 1350063 Air Regulator 1
59 1350079 Air Pilot Valve 1
60 1324050 Pipe Tee 2
61 1350048 Air Pressure Gauge 1
62 1350067 Air Regulator 1
63 1324039 Hex Soc Pipe Plug 1
64 1350050 Air Filter 1
65 1350078 Air Pilot Valve 1
66 1346007 Check Valve 1
67 1350057 Air Lubricator 1
1323015 Trigger Control Hose ft
3343009 Seal Kit for item 59
ITEM PART NO. PART NAME QTY

installation instructions
Model VC page 6 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
15 inch
Approx.
3--6 inch
Water Tube (1323019)
Vacuum Hose (1323010)
Air Hose (1323011)
Model VC
Air Control Circuit
To Vacuum Tank:
1
1
/
2
inch Pipe min.
1
/
4
Turn Shutoff Valve
To Water Supply:
1
/
2
inch Pipe
1
/
4
Turn Shutoff Valve
Tie all tubes and
hoses together.
To compressed
air supply:
1
/
2
inch Pipe
Trigger Control Hose (1323015)
Figure C
To Balancer
The vacuum pipe,
water pipe, air pipe
should all end at the
same height from
the floor.
Trough
Weld “s” hook
to angle or pipe.
Hang tool ba-
lancer from “s”
hook.
Weld angle or
pipe to rail.
Figure D
The tool
should be
suspended
at this level.

installation instructions
and specifications
Model VC
page 7 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
SPECIFICATIONS
Model VC
Operating Pressure 30-60 psi 2.0-4.1 bar
Air Consumption 5.6-14 ft
3
/min 0.16--0.39 m
3
/min
Vacuum Requirements 15 in Hg 50.8 kPa
Air Flow(vacuum) 6--7 ft
3
/min 0.16--0.19 m
3/
min
Capacity Limited by operator skill (avg. 3000 / hour)
Control Handle Single Trigger
Blade Dia. (range) 0.75--1.75 in 19--44 mm
Blade Length (range) 0.88--3.50 in 22--89 mm
Overall Length 11.0 in 267 mm
Weight 3.2 lbs 1.45 kg
INSTALLATION INSTRUCTIONS
1 Make a bracket to suspend the Model VC and ba-
lancer. Refer to Figure D, page 6.
2 Install a balancer (1350084) from the bracket. Refer
to Figures C and D, page 6.
3 Suspend the Model VC from a balancer (1350084).
Refer to Figures C and D, page 6.
4 Make the necessary vacuum connection. Refer to
Figures C and D, page 6.
5 Make the necessary water connection. Refer to Fig-
ures C and D, page 6.
6 Make the necessary air connection. Refer to Figures
C and D, page 6.
6.1 The air control circuit (3350006) must be in-
stalled in the air supply line.
6.1.1 The required compressed air supply is 14
ft
3
/min at 60 psi.
7 Model VC hook--up. Refer to Figure C, page 6. Re-
fer to pages 4 and 5 for all referenced items.
7.1 Vacuum:
7.1.1 Attach the 8 ft. vacuum hose (1323010) to
the vacuum supply.
7.1.2 Attach the 8 ft. vacuum hose (1323010) to
connector (item 5).
7.2 Water:
7.2.1 Attach the 8 ft. water tube (1323019) to the
water supply.
7.2.2 Attach the 8 ft. water tube (1323019) to con-
nector assembly (item 13).
7.3 Air:
7.3.1 Attach the air hose (1323011) to street el-
bow (item 56).
7.3.2 Attach the air hose (1323011) to quick con-
nect coupling (item 31).
7.3.3 Attach trigger control hose (1323015) to
tube connector (item 51).
7.3.4 Attach trigger control hose (1323015) to
tube connector (item 10).

operation instructions
Model VC page 8 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
OPERATION INSTRUCTIONS
IMPORTANT: DISCONNECT THE AIR LINE IN ACCOR-
DANCE WITH OSHA’S LOCKOUT/TAGOUT PROCEDURES
(29 CFR 1910.147) BEFORE SHARPENING BLADES. DIS-
CONNECT THE AIR LINE IN ACCORDANCE WITH OSHA’S
LOCKOUT/TAGOUT PROCEDURES (29 CFR 1910.147) BE-
FORE PERFORMING ANY REPAIR OR MAINTENANCE.
Refer to pages 4 and 5 for all referenced items.
1 Attach the 8 ft. vacuum hose (1323010) to connector
(item 5).
2 Attach the 8 ft. water tube (1323019) to connector
assembly (item 13).
3 Attach the air hose (1323011) to quick connect cou-
pling (item 31).
4 Attach trigger control hose (1323015) to tube con-
nector (item 10).
5Each day, before you begin operation, go through
the following checklist:
5.1 Make sure that the Model VC moves freely on
its balancer.
5.2 Make sure that you are wearing a steel mesh
safety glove on the hand that will not be operat-
ing the Model VC.
6 Making the cut:
6.1 Pull the trigger until it touches the round trigger
on the motor. This activates the vacuum at the
blade. Refer to Figure 1.
Trigger in
rest position
Round motor
trigger
Trigger in
activated
position
Figure 1
6.2 With the vacuum activated, insert the pilot pin
(item 1) into the anus of the bird. The entire anus
ring should be enclosed by the blade, and the
skin of the bird should be sucked up around the
entire cutting edge of the blade. Refer to Figure
2.
Anus
Anus ring
Backbone
Oil gland
Tail
Rosebud
gland
Pilot pin
Blade
Figure 2
6.3 While vacuum is holding the skin upward, pull
the trigger back fully and allow the blade to ro-
tate. Move the blade gently forward into the bird
about 1/2 to 3/4 of the length of the blade. Do
not apply pressure on the bird until the blade is
rotating. Refer to Figures 3 and 4.
Proper Method
Rosebud gland
is inside of the
blade.
Skin is pulled up by
vacuum against the
cutting edge of the blade.
Figure 3
Improper Method Skin is depressed
before the blade is
activated.
Rosebud gland
is outside of the
blade.
Figure 4

operation instructions
and blade/pilot pin information
Model VC
page 9 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
6.4 A gentle motion with a downward pressure will
cut the bird properly. Forcing the blade will
leave all or part of the rosebud in the bird. Do
not force the blade or stab the bird with the
blade. Do not let go of the trigger after fully de-
pressing it. The blade will turn only a few revo-
lutions and will shut off automatically (it will
not cut the intestines). The vacuum will remain
sucking as long as the trigger is held in the fully
depressed position.
6.5 The blade must always be angled toward the
center of the bird. If the blade is directed toward
either side, it will leave solid muscle attached to
the vent and this material cannot be broken loose
by hand.
6.6 While still holding the trigger, pull the blade
slowly out of the bird. The vacuum will hold the
anus and the fecal material long enough for the
operator to either grab the vent and move it away
from the hole or to move the vent away from the
hole with the gun.
6.7 Release the trigger. The vacuum will shutoff
and release the vent into the operators hand so
that it can be pulled out of the carcass and laid
gently over the side of the carcass or it will re-
lease the vent over the side of the carcass if the
vacuum pulls the vent completely out of the car-
cass.
6.8 After releasing the vent, the operator must aim
the blade at the trough before reaching the next
bird. Depress the water flush lever to flush out
all materials from the blade before attempting to
cut another bird. Do not flush waste material on
the birds. The water will not flush out the blade
unless the vacuum trigger is in the rest position.
When both vacuum and water triggers are acti-
vated, all water will be sucked up the vacuum
tube sending all waste material to the collector
tank.
6.9 When a bird has fecal material on the outside of
the carcass, it can be washed off with the vent
gun before cutting the bird. Be sure that the
blade has been sufficiently flushed into the
trough before attempting to wash off any bird.
Do not attempt to wash the bird after cutting into
the carcass.
BLADE INFORMATION (inches)
PART NO. DIAMETER LENGTH
3332001 7/8 15/8
3332002 3/4 15/8
3332003 1 2
3332004 11/4 2
3332005 11/2 2
3332006 7/8 21/2
3332008 11/8 31/2
3332009 11/4 31/2
3332010 13/8 31/2
3332011 11/2 31/2
3332015 11/8 2
3332016 13/8 2
3332026 13/4 23/4
PILOT PIN INFORMATION (inches)
PART NO. DIAMETER LENGTH
1327038 3/8 2
1327040 1/2 21/2
1327041 5/16 2
1327052 1/2 31/4
1327053 3/8 23/4
1327054 3/8 21/2
1327057 3/8 33/4

maintenance instructions
Model VC page 10 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
MAINTENANCE INSTRUCTIONS
IMPORTANT: DISCONNECT THE AIR LINE IN ACCOR-
DANCE WITH OSHA’S LOCKOUT/TAGOUT PROCEDURES
(29 CFR 1910.147) BEFORE PERFORMING ANY REPAIR OR
MAINTENANCE.
Refer to pages 4 and 5 for all referenced items.
1 DAILY:
1.1 Check to see that the Model VC is getting
enough lubrication. Each one or two pulls of the
trigger should produce one drop of oil in the
sight dome. If required, adjust the oil flow.
1.2 Make sure that the oil in the lubricator is up to
the full mark. Use USDA approved Jarvis Air
Mist Lubricator Oil.Do not use mineral oil.
2 WEEKLY:
2.1 Add four to five shots of grease to grease fitting
(item 14). Use USDA approved Jarvis 1315
White Grease.
3 WHEN NECESSARY:
Wear cut protective gloves when handling blades.
3.1 Sharpen the blade (item 2) when the blade be-
comes difficult to push into the carcass, or when
the cutting produces contamination.
3.1.1 Place a sharpening stone on the cutting
angle of the blade and activate the tool.
Continue to desired sharpness. If this action
rolls the cutting edge inward, hold a small
steel on the inside edge of the blade.
3.1.2 Repeat the process until the blade is sharp.
3.1.3 If the angle of the blade becomes too short
or when the cutting edge has excessive
nicks, the blade must be reground. Do not
heat the cutting edge. Heat will anneal the
material and make it impossible to hold a
sharp edge. Return to Jarvis for regrinding.
4 MODEL VC BLADE DISASSEMBLY:
Wear cut protective gloves when handling blades.
4.1 While holding base of blade (item 2) in place,
use special wrench (part number 8327001) to
loosen pilot pin (item 1).
4.2 Remove blade (item 2).
4.3 Inspect blade (item 2) for wear and sharpen if
necessary.
5 MODEL VC BLADE ASSEMBLY:
Wear cut protective gloves when handling blades.
5.1 Place blade (item 2) over cutter shaft (item 3).
5.2 Assemble pilot pin (item 1) through blade (item
2).
5.3 Tighten pilot pin (item 1) hand tight into cutter
shaft (item 3). The pilot pin will automatically
tighten with use of the tool.
6 MODEL VC DISASSEMBLY:
6.1 Follow steps and procedures 4.1 and 4.2.
6.2 Unscrew the knurled ring on shaft housing as-
sembly (item 4).
6.3 Remove shaft housing assembly (item 4). Be
careful not to lose the trigger pin assembly (item
11).
6.4 Place a pin through the cross hole in the cutter
shaft (item 3) and hit pin with a hammer on the
proper end to turn it counter--clockwise.
WARNING: pin may fly out of unit. Protect
yourself and other employees when disassem-
bling this part.

maintenance instructions
Model VC
page 11 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
6.5 Remove the cutter shaft (item 3).
6.6 Place the Model VC in a soft jaw vise (apply
pressure only to the handle) and unscrew ring
gear (item 48).
6.7 Remove the ring gear (item 48).
6.8 Remove the gear shaft assembly (items 15--16,
45--47).
6.9 Tap on the front of pistol grip handle (item 22)
with a soft hammer (plastic lead, wood) to dis-
lodge the motor assembly (items 17--19, 39--43).
6.10 Remove the motor assembly (items 17--19,
39--43). Do not lose rotor housing pin (item 39).
6.11 Inspect all parts for wear and replace if neces-
sary.
7 MODEL VC ASSEMBLY:
7.1 Reverse steps and procedures outlined in steps
6.1--6.10. See note below:
7.1.1 Install motor assembly with rotor housing
pin (item 39) in proper place.
8 GEAR SHAFT DISASSEMBLY:
8.1 Press out planetary gear pin (item 47) from the
non--threaded end of gear shaft (item 46).
8.2 Remove planetary gear assemblies (items 15
and 16).
8.3 Push needle bearing (item 15) from planetary
gear (item 16).
8.4 Use bearing puller (part number 1350131). In-
sert nut into the center of gear shaft (item 46).
Screw cap head screw into the nut until needle
bearing (item 45) is removed.
8.5 Inspect all parts for wear and replace if neces-
sary.
9 GEAR SHAFT ASSEMBLY:
9.1 Press needle bearing (item 45) into gear shaft
(item 46).
9.2 Insert needle bearings (item 15) into planetary
gears (item 16).
9.3 Place bearing and gear assembly (items 15 and
16) into gear shaft (item 46) making sure that
bearing hole and gear pin hole are aligned.
9.4 Press planetary gear pins (item 47) into the
threaded end of gear shaft (item 46).
10 MOTOR DISASSEMBLY:
10.1 Hold front motor end plate (item 42) while tap-
ping on the splined end of the splined rotor (item
41) with a soft hammer (plastic, lead, wood).
10.2 Remove the front motor end plate (item 42) and
ball bearing (item 43).
10.3 Slide off rotor sleeve (item 40).
10.4 Remove vanes (items 17).
10.5 Press splined rotor (item 41) from rear motor
end plate (item 18).
10.6 Press ball bearings (items 19 and 43) out of rear
motor end plate (item 18) and front motor end
plate (item 42).
10.7 Inspect all parts for wear and replace if neces-
sary.
11 MOTOR ASSEMBLY:
11.1 Reverse steps and procedures outlined in steps
10.1--10.6.

troubleshooting
Model VC page 12 of 12
JARVIS
6222009::.
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL. [email protected]
TEL. [phone] FAX. [phone] WWW.jarvisproducts.com
®
PROBLEM SOLUTION
MOTOR RUNS WHEN THE TRIGGER IS RELEASED.
Refer to page 4 for referenced items.
CHECK THE AIR MOTOR TRIGGER (ITEM 38).
If the trigger flops in and out or stays depressed when touched,
it is malfunctioning. Remove the air inlet valve (item 32) and
valve stem pin (item 33). With long nose pliers, remove valve
pin (item 34). Clean pins until their surfaces are smooth. Clean
out the deepest hole in the pistol grip handle (item 22) with a drill.
Rotate the drill by hand. Do not increase the size of the hole.
CHECK THE O--RING LOCATED IN AIR INLET VALVE (ITEM
32).
Remove the retaining ring, screen, spring, and poppet from the
air inlet valve (item 32). Check for an o--ring on the poppet. If
there is no o--ring on the poppet, check the inside of the air inlet
valve. Reassemble the o--ring to the poppet and reassemble the
air inlet valve.
BLADE DOES NOT ROTATE AND SHUT OFF WHEN TRIG-
GER IS PULLED.
ADJUST AIR REGULATOR (ITEM 58).
Pull trigger on Model VC, and turn air regulator knob (item 58)
Refer to page 5 for referenced items.
g
g
,
g
(
)
clockwise until the blade on the vent gun turns off. Continue to
adjust until desired number of blade rotations is accomplished.
CHECK AIR PILOT VALVE (ITEM 59).
Remove four screws and cover on air pilot valve (item 59) care-
fully. Check rubber diaphragm. If the rubber diaphragm has a
hole, it must be replaced (part number 3343009).
CLEAN VENTURI ASSEMBLY (ITEM 53).
If the regulator has no range of adjustment, clean the venturi as-
sembly. Remove tube connector (item 52). Clear the small hole
in the silver pin with a small diameter wire. Do not increase the
size of the hole.
BLADE DOES NOT ROTATE WHEN TRIGGER IS PULLED.
Refer to pages 4 and 5 for referenced items.
CHECK THE AIR SUPPLY.
The air pressure gage (item 61) must show pressure.
CHECK THE VACUUM.
When trigger is pulled, there is suction at the blade. If there is
no suction at the blade, the air supply to the tool is shut off.
CHECK VANES (ITEM 17).
If air is exhausting through the butt of the pistol grip handle, re-
lease trigger and turn blade 1/2 revolution. Pull trigger. If the
Model VC runs properly now, it is an indication of sticky vanes
(causes: wrong oil, dirt in slots, lack of oil). Disassemble motor,
clean rotor, and check length of vanes (they should be .002
shorter than the length of the rotor). Check rotation of each bear-
ing (they should rotate freely).
WATER VALVE LEAKS.
Refer to page 4 for referenced items.
WATER VALVE LEAKS AT TIME OF INSTALLATION.
Check for metal fragments from the threaded pipe. Remove wa-
ter tube from tube connector (item 13). Remove tube connector
(item 13). Check water valve (item 12) for debris, and remove
debris with small pointed object. Do not damage spring or seal.
WATER VALVE LEAKS AFTER CONSIDERABLE USE.
Replace water valve (item 12).
TROUBLESHOOTING
REMOVE ANY MALFUNCTIONING TOOL FROM SERVICE
